FEATURES OF YOUR HYUNDAI 1- 53
HGK023
HGK024
Floor-Level
Air is discharged through the floor vents, wind- shield defroster nozzle, side defroster nozzle,side ventilator.
Floor-Defrost Level
Air is discharged through the windshield de-froster nozzle, the floor vents, side defrosternozzle, side ventilator.
HGK025
Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents.
HGK022
Bi-Level
Air is discharged through the face vents and the floor vents. This makes it possible to have coolerair from the dashboard vents and warmer air fromthe floor outlets at the same time.
HGK021
If the "Floor-Defrost" mode is selected, the A/C will turn on automatically and "Fresh" mode willbe activated.
Defrost-Level
Air is discharged through the windshield de-froster nozzle, side defroster nozzle, side venti-lator.If the "Defrost" mode is selected, the A/C will turnon automatically and "Fresh" mode will be acti-vated.

FEATURES OF YOUR HYUNDAI
1- 54
B690A01S-AAT HEATING CONTROLSFor normal heating operation, set the air intake control to the "Fresh" position and the air flowcontrol to "Floor". For faster heating, the air intake control should be in the "Recirculation" position. If the windows fog up, move the air flow control to the "Def" (defroster) position. (The A/C will turnon automatically and "Fresh" mode will be acti-vated.) For maximum heat, move the temperature con- trol to "Warm".
B730A01FC-AAT Operation Tips
o To keep dust or unpleasant fumes from enter-
ing the car through the ventilation system, temporarily set the air intake control to "Recir-culation". Be sure to return the control to"Fresh" when the irritation has passed tokeep fresh air in the vehicle. This will helpkeep the driver alert and comfortable.
o Air for the heating/cooling system is drawn in through the grilles just ahead of the wind-shield. Care should be taken that these arenot blocked by leaves, snow, ice or otherobstructions.
o To prevent interior fog on the windshield, set the air intake control to the fresh air ( )position, turn on the air conditioning system,and adjust temperature control to desiredtemperature fan speed to the desired posi-tion.
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4". NOTE: When the A/C is operated continuously onthe floor-defrost level ( ) or defrost level( ), it may cause fog to form on the exteriorwindshield. If this occurs, set the air flowcontrol to the face level position ( ) and fanspeed control to the low position.
Use the heating/ventilation system to defrost ordefog the windshield: To remove interior fog on the wind- shield:
o Set the air flow control to the defrost (
)
position. (The A/C will turn on automatically and "Fresh" mode will be activated.)
o Set the temperature control to the desired position.
o Set the fan speed control between "1" and "4" position.
To remove frost or exterior fog on the windshield:
o Set the air flow control to the defrost (
)
position. (The A/C will turn on automatically and "Fresh" mode will be activated.)
B720A02FC-GAT DEFROSTING/DEFOGGING
HGK002

FEATURES OF YOUR HYUNDAI 1- 55
B740A01S-AAT AIR CONDITIONING SYSTEM (If installed)Air Conditioning Switch
HGK018
The air conditioning is turned on or off by pushing the A/C button on the heating/air conditioningcontrol panel.
HGK002
B740B01S-AAT Air Conditioning Operation Cooling
To use the air conditioning to cool the interior:
o Set the side vent control to "OFF", to shut off outside air entry.
o Turn on the fan control switch.
o Turn on the air conditioning switch by pushing in on the switch. The air conditioning indicatorlight should come on at the same time.
o Set the air intake control to "Fresh" mode ( ).
o Set the temperature control to "Cool". ("Cool" provides maximum cooling. The temperaturemay be moderated by moving the controltoward "Warm".)
o Adjust the fan control to the desired speed. For greater cooling, turn the fan control toone of the higher speeds or temporarilyselect the "Recirculation" position on the airintake control.
B740C01S-AAT Dehumidified HeatingFor dehumidified heating:
o Turn on the fan control switch.
o Turn on the air conditioning switch. The airconditioning indicator light should come on atthe same time.
o Set the air intake control to "Fresh" mode ( ).
o Set the air flow control to "Face".
o Adjust the fan control to the desired speed.
o For more rapid action, set the fan at one of the higher speeds.
o Adjust the temperature control to provide the desired amount of warmth.

FEATURES OF YOUR HYUNDAI
1- 56
B740D01A-AAT Operation Tips
o If the interior of the car is hot when you first
get in, open the windows for a few minutes to expel the hot air.
o When you are using the air conditioning sys- tem, keep all windows closed to keep hot airout.
o When moving slowly, as in heavy traffic, shift to a lower gear. This increases engine speed,which in turn increases the speed of the airconditioning compressor.
o On steep grades, turn the air conditioner off to avoid the possibility of the engine over-heating.
o During winter months or in periods when the air conditioner is not used regularly, run theair conditioner once every month for a fewminutes. This will help circulate the lubricantsand keep your system in peak operatingcondition.

FEATURES OF YOUR HYUNDAI 1- 57
B970A01Y-AAT AUTOMATIC HEATING AND COOLING CONTROL SYSTEM (If lnstalled)Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperat
ure.
B970B01GK-GATHeating and Cooling Controls TYPE A (Without Air Quality System) TYPE B (With Air Quality System)
1. Temperature Control Button
2. Defroster Switch
3. Display Window
4. Air Conditioning Switch
5. Rear Window Defroster Switch
6. Fan Speed Control Switch 7. Air Flow Control Switch
8. AUTO (Automatic Control)Switch
9. OFF Switch
10. Air lntake Control Switch
11. Ambient Temperature Switch
12. Air Quality System Switch (If installed)HGK004
HGK003
1 235
4 6
78 9 10 11 1
2
3
4 5
6
78 910 1211

FEATURES OF YOUR HYUNDAI
1- 58
B970C02E-GAT Automatic Operation
HGK020
The FATC (Full Automatic Temperature Control) system automatically controls heating and cool-ing as follows:
1. Push the "AUTO" switch. The indicator light will illuminate confirming that the Face, Floor and/or Bi-Level modes as well as the blowerspeed and, air conditioner will be controlledautomatically. 2. Push the "TEMP" button to set the desired
temperature.The temperature will increase to the maxi-mum 32°C(90°F) by pushing on the button.Each push of the button will cause the tem-perature to increase by 0.5°C(1°F).The temperature will decrease to the mini-mum 17°C(62°F) by pushing on the button.Each push of the button will cause the tem-perature to decrease by 0.5°C(1°F).
G280A01GK
Photo sensor
HGK014
NOTE: Never place anything over the sensor whichis located on the instrument panel to ensurebetter control of the heating and coolingsystem.
NOTE: If the battery has been discharged or discon-nected, the temperature mode will reset tocentigrade degrees.This is a normal condition and you can changethe temperature mode from centigrade tofarenheit as follows;Press the TEMP button down 3 seconds ormore with the button held down. Thedisplay shows that the unit of temperature isadjusted to centigrade or fahrenheit.(°C °F or °F °C)
OUTSIDETEMP

FEATURES OF YOUR HYUNDAI 1- 59
B980B01Y-AAT Fan Speed Control Switch
HGK015
The fan speed can be set to the desired speed by pressing the appropriate fan speed control but-ton. The higher the fan speed is, the more air isdelivered. Pressing the "OFF" button turns offthe fan.
B980A01Y-AAT MANUAL OPERATION The heating and cooling system can be con- trolled manually as well by pushing buttons otherthan the "AUTO" button. In this state, the systemsequentially works according to the order ofbuttons selected.The function of the buttons which are not select-ed will be controlled automatically.Press the "AUTO" button in order to convert toautomatic control of the system. Pressing the button displays the ambienttemperature on the display.
OUTSIDE
TEMP
B995A01Y-GAT AMBIENT SWITCH
HGK009
B670C01GK-AAT Air Intake Control Switch (Without A.Q.S)
HGK008-1
This is used to select fresh outside air or recircu- lation inside air.To change the air intake control mode, (Freshmode, Recirculation mode) push the control but-ton. FRESH MODE ( ) : The indicator light on the button goes on when the air intake control is freshmode. RECIRCULATION MODE ( ) : The indica- tor light on the button is illuminated when the airintake control is recirculation mode. With the "Fresh" mode selected, air enters the vehicle from the outside and is heated or cooledaccording to the function selected.

FEATURES OF YOUR HYUNDAI
1- 60 Exhaust gas cutoff mode :
Air enters the vehicle from the outside. But if exhaust gas enters the vehicle from the outside, the exhaust gas cutoff mode ( ) is automa tically converted to the mode, to
prevent exhaust gas from entering the vehicle. NOTE:
o It should be noted that prolonged opera- tion of the heating system in recirculationmode ( ) will give rise to misting ofthe windshield and side windows and theair within the passenger compartment willbecome stale. In addition, prolonged useof the air conditioning with the recircula- tion mode ( ) selected may result in the air within the passenger compartmentbecoming excessively dry.
o When the ignition switch is turned "ON" the air intake control will change to "Fresh" mode (regardless of switch position). Thisis normal operation. The air intake controloperates in "AUTO" mode when turningthe ignition to the ON position if the"AUTO" mode was used before shuttingoff the engine.
CAUTION:If the windows fog up with the Recirculationor A.Q.S mode selected, set the air intakecontrol to the Fresh air position or A.Q.Scontrol to "OFF".
With the "Recirculation" mode selected, air from within the passenger compartment will be drawnthrough the heating system and heated or cooledaccording to the function selected. NOTE:
o It should be noted that prolonged opera- tion of the heating system in "recircula-tion" mode will give rise to fogging of thewindshield and side windows and the airwithin the passenger compartment willbecome stale. In addition, prolonged useof the air conditioning with the "Recircu-lation" mode selected may result in the airwithin the passenger compartment be-coming excessively dry.
o When the ignition switch is turned "ON" the air intake control will change to " "mode (regardless of switch position). Thisis normal operation. The air intake controloperates in "AUTO" mode when turningthe ignition to the ON position if the"AUTO" mode was used before shuttingoff the engine.
This is used to select fresh outside air or recircu- late inside air automatically.
: OFF
:ON Fresh mode :
Air enters the vehicle from the outside and is heated or cooled according to the function se- lected.
Recirculation mode :
Air from within the passenger compartment will be drawn through the heating system and heated or cooled according to the function selected.
B980C01GK-GAT Air Intake Control Switch (With A.Q.S) (If Installed)
HGK010-1

FEATURES OF YOUR HYUNDAI 1- 61
This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, or wind-shield. Four symbols are used to represent Face,Bi-Level, Floor and Floor-Defrost air position.
B980D01Y-AAT Heating and Cooling System OffPress the "OFF" button to stop the operation of the heating and cooling system.
B980E01GK-GAT Air Flow Control
HGK019
HGK021
HGK022
Face-Level
When selecting the "Face" mode, the indicator light will come on, causing air to be dischargedthrough the face level vents.
Bi-Level
When selecting the "Bi-Level" mode, the indica-tor light will come on and the air will be dischargedthrough the face vents and the floor vents. This makes it possible to have cooler air from thedashboard vents and warmer air from the flooroutlets at the same time.
Floor-Level
When selecting the "Floor-Level" mode, the indi-cator light will come on and the air will be dis-charged through the floor vents, windshield de-froster nozzle, side defroster nozzle, side venti-lator.
HGK023
HGK024

FEATURES OF YOUR HYUNDAI
1- 62
B760A01E
The air filter is located in front of the blower unit behind the glove box.It operates to decrease pollutants from enteringthe car and to filter the air. CAUTION:
o Replace the filter every 20,000 km (12,000 miles) or once a year.If the car is being driven in severe condi-tions such as dusty, rough roads, morefrequent air filter inspections and changesare required.
o When the air flow rate is decreased, it must be checked at authorized dealer.
Evaporator coreBlower fan
Heater core
B760A03GK-GAT AIR CONDITIONER FILTER (IN FRONT OF BLOWER UNIT) (If Installed)
Outside air
Filter
Inside air
Inside air
Floor-Defrost Level
When selecting the "Floor-Defrost" mode, the indicator light will come on and the air will bedischarged through the windshield defrost nozzle,the floor vents, side defroster nozzle, side venti-lator. B980F01E-GAT Defrost Switch When the "Defrost" button is pressed, the " " mode will be automatically selected and the airwill be discharged through the windshield defrostvents. To assist in defrosting, the air conditioningwill operate if ambient temperature is higher than3.5°C and automatically turns off if the ambienttemperature drops below 3.5°C.
HGK012
