Hyundai Coupe 2005 Owner's Manual

6
DO-IT-YOURSELF MAINTENANCE
33
!WARNING:
This halogen bulb contains gas under pressure and if impacted could shatter, resulting in flying fragments. Always wear eye pro-tection when servicing the bulb. Protect the bulb against abrasions or scratches and against liquidswhen lighted. Turn the bulb on only when installing in a head- light. Replace the headlight if dam-aged or cracked. Keep the bulb out of the reach of children and dispose of the used bulb with care.
11.To replace the front turn signal
light bulb, remove from the bulbholder and install the new bulb. HGK5036
tic base with the headlight hole.Reattach the bulb spring and re-connect the connector.
9. Use the protective cap and carton
to promptly dispose of the old bulb.
10.Check for proper headlight aim.
G270A03OG270B01GK-GAT Rear Combination Light (Without woofer speaker)
1. Open the tail gate.
HGK5037
(1)
(2)
(3)

6 DO-IT-YOURSELF MAINTENANCE
34
5. To replace the rear combination
light (stop/tail light, turn signal light, back-up light) take it out from the bulb holder by turning it counter-clockwise. (1) Stop/Tail light (2) Back-up light (3) Turn signal light
6. Install the new bulb. HGK5044-1
(1)
(2) (3)
3. Remove the nut (8mm) with a span-
ner. HGK50424. To detach the rear combination
light hit it strongly by hand. HGK5043
HGK5041
2. To remove the cover of the rear luggage trim, turn the knob by hand to the counterclockwise.

6
DO-IT-YOURSELF MAINTENANCE
35
1. Open the tail gate. HGK5039
HGK5040
3. Extract the mounting screws
(10mm) around the woofer speaker with a spaner.
4. Disconnect the power cord from the woofer speaker.
HGK5038
G275B01GK-GAT
Rear Combination Light (With woofer speaker)
HGK5037
(1)
(2)
(3)
2. Take off the luggage board.
HGK5041
5. To remove the cover of the rear luggage trim, turn the knob by hand to the counterclockwise.
HGK5042
6. Remove the nut (8mm) with a wrench.

6 DO-IT-YOURSELF MAINTENANCE
36
G270C01GK-AAT
Luggage Compartment Light
1. Open the tail gate.
2. Remove the cover with a flat-blade
screwdriver.
HGK5045HGK5044-1 (1)
(2) (3) turn signal light), take it out from the bulb holder by turning it coun-terclockwise. (1) Stop/Tail light (2) Back-up light (3) Turn signal light
9. Install the new bulb.
HGK5043
7. To detach the rear combination light hit it strongly by hand.
8. To replace the rear combination light (stop/tail light, back-up light, HTB284
3. Disconnect the power cord.
HGK5046
4. Replace with a new bulb.

6
DO-IT-YOURSELF MAINTENANCE
37
G270G01GK-AAT
Map Light
1. Remove the cover with a flat-blade screwdriver.
2. Replace with a new bulb.
HGK5047
HGK5048HGK2112
2. Open the glove box and remove the mounting screws on the upside of the glove box.
G270H01GK-GAT
Glove Box Illuminated Light
1. Remove the mounting screws on
the downside of the glove box. HGK2111
3. Remove the glove box by pulling
strongly.
CAUTION:
Be careful not to damage the glove box when pulling the glove box.
!
HGK5052

6 DO-IT-YOURSELF MAINTENANCE
38
HTB284
HGK5053
Clip Power Cord
4. Disconnect the power cord.
5. Remove the glove box illuminated light by pushing the clip.
6. Replace with a new bulb.

6
DO-IT-YOURSELF MAINTENANCE
39
Part Name
High Mounted Stop Light Rear Combination License Plate Light Rear Fog Light (If installed) With spoilerWithout spoiler Turn Signal Light Stop/Tail Light Back-up Light
9
10 11 12 13 14
Part Name
Head Light (High/Low) Map Light Front Position Light Front Fog Light (If installed) Front Turn Signal Light Side repeater light (If installed) Front Door Edge Warning Light Luggage Compartment Light
BULB WATTAGE
Socket type
PX 26d/PX 26d W2.1×9.5D
W2.1X9.5d P22d
BAU15s -
W2.1X9.5d S8.5/8.5
G280A04GK-GAT
Wattage
No.No.
1 2 3 4 5 6 7 8
HGK5021-1
(High) (Low)
Wattage55/55 10
5
51 21 55 5
2.4 (LED) 3.5 (LED)
21
21/5 21
5
21
Socket type
N/A-
BA15s
BA15d
BA15s
S8.5/8.5
-

6 DO-IT-YOURSELF MAINTENANCE
40FUSE PANEL DESCRIPTION
G200C02GK-GAT
Engine Compartment NOTE: Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. HGK4005

6
DO-IT-YOURSELF MAINTENANCE
41
PROTECTED COMPONENTS
Generator(1.6L/2.0L) BCM BOX(Tail lamp relay,Power connector,Fuse(2,7,12,13,19,20,24))Condenser fan relayRadiator fan relayEngine control relay, Fuel pump relay, A/T control relay, Generator,ECM(1.6L/2.7L),PCM(2.0L) Ignition switch,Start relayABS/ESP control module,ESP Air bleeding connectorABS/ESP control module,ESP Air bleeding connectorBlower relayInjector Oxygen sensor,Camshaft position sensor, Idle speed control actuator DRL control moduleFront fog lamp relayTCM(2.7L),ECM(2.7L/1.6L)Horn relay,A/C relay Head lamp relay(High) Head lamp relay(Low)
FUSERATING 120A50A 30A30A 30A 30A 40A40A30A 15A 10A15A15A10A15A 15A 15A
DESCRIPTION
BATTBATT
COND RAD ECU
IGN
ABS 1 ABS 2
BLOWER INJ
SNSR DRL
F/FOG ECU
HORN,A/CON H/LP (HI)
H/LP (LO)

6 DO-IT-YOURSELF MAINTENANCE
42
G200D02GK-GAT Inner Panel
HGK204-E
