Hyundai Coupe 2005 Owner's Manual

YOUR VEHICLE AT A GLANCE
B255A01GK-EAT INDICATOR SYMBOLS ON THE INSTRUMENT PANEL * More detailed explanations of these items will be found beginning on page 1-40.
Malfunction Indicator Light (Not all models)
SRS (Airbag) Service Reminder Indicator (SRI)(Not all models)
Hatchback Door Open Warning Light
Low Fuel Level Warning Light
Door Open (Ajar) Warning Light (Not all models)
ABS Service Reminder Indicator (Not all models)
Turn Signal Indicator Lights
High Beam Indicator Light Low Oil Pressure Warning Light Parking Brake/Brake Fluid Level Warning Light Charging System Warning Light
Cruise Indicator (Not all models)
Seat Belt Warning Light
CRUISE SET Indicator Light (Not all models)
Electronic Stability Program (ESP) Indicator Light (Not all models)
Immobiliser Warning Light
gkfluk-0.p65 11/21/2005, 3:03 PM
12

1
Fuel Recommendations ............................................... 1-2
Running In Your New Hyundai ..................................... 1-3
Immobiliser System ...................................................... 1-4
Door Locks ................................................................... 1-6
Anti-thief Alarm System ................................................ 1-7Power Windows........................................................... 1-11
Seats ........................................................................... 1-12
Seat Belts .................................................................... 1-18
Child Restraint System ................................................ 1-22
Supplemental Restraint (AIRBAG ) System................. 1-30
Instrument Cluster and Indicator Lights .......................1-38
Warning and Indicator Lights....................................... 1-40
Trip Computer .............................................................. 1-47
Multi Gauge ................................ ................................. 1-49
Multi-function Switch .................................................... 1-50
Windscreen Wiper/Washer Switch ..............................1-52
Sunroof ........................................................................ 1-59
Mirror ........................................................................... 1-62
Bonnet Release ........................................................... 1-65
Cruise Co ntrol.............................................................. 1-70
Audio Remote Control ................................................. 1-73
Heating and Cooling Control .......... ..............................1-75
Stereo Sound System ................................................. 1-93
Antenna ....................................................................... 1-97
CONTROLS AND EQUIPMENT
1
gkfluk-1a.p65
11/21/2005, 2:56 PM
1

1CONTROLS AND EQUIPMENT
2FUEL RECOMMENDATIONS
B010A02A-EAT THIS VEHICLE MUST ONLY BE OP- ERATED WITH UNLEADED FUEL.SERIOUS DAMAGE WILL RESULTFROM THE USE OF LEADED FUEL. For the optimal vehicle performance, we recommend you to use unleaded gasoline with an octane rating of RON(Research Octane Number) 95 /AKI (Anti Knock Index) 91 or higher. To prevent accidental charging of the fuel tank with leaded fuel, a smalldiameter filler neck along with a restrictor flap are fitted to ensure that only unleaded fuel pump nozzles mayenter the filler neck. However, care must be exercised when refuelling the vehicle tank from fuel cans or by meansof a funnel that the fuel being used is unleaded. The use of leaded fuel in this vehiclewill result in irreversible pollution of the catalyst element. Such pollution will prevent correct operation of the cata-lyst and give rise to increased operating temperatures leading to the catalyst element melting and restricting the ex-haust flow along with an increase in exhaust emission levels.
!
B010A02GK
UNLEADED
FUEL ONLY ZB010C1-E "Alternative fuels" Fuels which contain methanol or etha- nol must not be used. ZB010F2-A Fuels for Cleaner Air To help contribute to cleaner air, Hyundai recommends that you use fuels treated with detergent additives, which help to prevent deposit forma-tion in the engine. These fuels will help the engines run cleaner and increase the Emission Control System perfor-mance.
ZB010D1-E Operation in Foreign Countries Drivers of vehicles which are to be operated in foreign countries must satisfy themselves that:
o The vehicle meets all local regula-
tions with respect to insurance, specifications etc..
o The correct types and grades of fuel
are available for satisfactory opera-tion of the vehicle.
CAUTION:
The vehicle warranty will not ex- tend to damage arising from the use of incorrect fuels.
gkfluk-1a.p65 11/21/2005, 2:56 PM
2

1
CONTROLS AND EQUIPMENT
3RUNNING IN YOUR NEW HYUNDAI
B020A01S-EAT The longevity and performance of the vehicle are greatly affected by the care exercised during the first 1,000 miles of motoring. Because of modern manu-facturing techniques, rigid guidelines regarding maximum road speeds have become unnecessary. However, cer-tain precautions should be observed in order to obtain the best possible per- formance and useful life from the ve-hicle.
1) Do not race the engine without a
load (i.e revving the engine in neu- tral).
2) During the first 500 miles the maxi- mum engine speed should be re-stricted to 3,000 rpm and gradually increased thereafter.
3) Avoid prolonged constant speed operation. The internal componentsof the engine will become morequickly run in if the operation speed is varied during the running in pe- riod.
4) Never allow the engine to labour. Use the gearbox freely and avoidlarge throttle openings when theengine speed is below 1,500 rpm.BEFORE ENTERING THE VEHICLEAFTER ENTERING THE VEHICLE
YB020A1-E
o Ensure that all windows, mirrors
and lamps are clean.
o Check condition of all tyres.
o Ensure that no fluid leaks are evi-
dent.
o Ensure that the area around the vehicle is clear before driving off. YB020B1-E
o Ensure that all occupants fasten
and correctly adjust seat belts.
o Ensure that seat and head restraint positions are adjusted for optimum safety, control and comfort.
o Adjust interior and exterior rear view mirrors.
o Verify correct operation of lamps, horn and other electrical equipment.
o Ensure that warning lamps illumi-
nate when ignition is turned on.
NOTE: Fluid levels such as engine oil, en- gine coolant, brake and windscreenwasher fluid should be checked daily or at each refuelling, which- ever occurs sooner.
gkfluk-1a.p65 11/21/2005, 2:56 PM
3

1CONTROLS AND EQUIPMENT
4
!
IMMOBILISER SYSTEM
B880B04A-EAT Keys All of the locks fitted to the vehicle are operated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake. AX10020A-1
5) Avoid rapid acceleration and maxi-
mum throttle openings.
6) Avoid harsh braking during the first 100 miles of urban motoring or 1,000 miles of motorway driving to allowthe friction facings of the brake pads and shoes to bed against the discs and drums properly.
7) No trailer towing should be under- taken during the running in period. B880A01A-EAT The immobiliser system is an anti-theft device, designed to deter automobile theft.
NOTE: A non-genuine duplicate key will not start the engine.
CAUTION:
When starting the engine, do not use the key with other immobiliser keysaround. Otherwise the engine may not start or may stop soon after it starts.Keep each key separate to prevent immobiliser malfunction, once you have received your new vehicle.
gkfluk-1a.p65 11/21/2005, 2:56 PM
4

1
CONTROLS AND EQUIPMENT
5ILLUMINATED IGNITION SWITCH
B880C02A-EAT Key Numbers The vehicle key number is recorded on a metal tag attached to the keys when the vehicle is first delivered to you.The key number should be recorded and kept in a safe place in case the need to order further keys arises. Newkeys are available from any Hyundai authorised repairer by quoting the rel- evant key number.In the interest of security, the metal tag attached to the keys which bears thekey number should be removed fromthe key ring after you receive your new vehicle. In addition, key numbers can- not be provided by Hyundai for secu-rity reasons. If you need additional keys or if you should lose your keys, your Hyundaiauthorised repairer can make new keys.
AX10030A-1 B030C01E
YB030C2-E (Not all models) Whenever a door is opened, the igni- tion switch will be illuminated for your convenience provided the ignition switch is not in the "ON" position. Thelight will go off approximately 10 sec- onds after closing the door or when the ignition switch is turned on.
gkfluk-1a.p65
11/21/2005, 2:56 PM
5

1CONTROLS AND EQUIPMENT
6
!
DOOR LOCKS
B040A02Y-EAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (es- pecially if there are children inthe car), be sure that all the doors are securely closed and locked so that the doors cannot be inad-vertently opened from the inside. This helps ensure that doors will not be opened accidentally. Also,when combined with the proper use of seat belts, locking the doors helps keep occupants frombeing ejected from the car in case of an accident.
o Before opening the door, always look for and avoid oncoming traf-fic.
o In case of accident the door is unlocked automatically (Not allmodels). B040B01A-AAT Locking and unlocking front doors with a key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key towardthe rear. HGK2008-E
UNLOCK
LOCK B040C01S-AAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door. NOTE:
o When locking the door this way,
be careful not to lock the door with the ignition key left in thevehicle.
o To protect against theft, always
remove the ignition key, close allwindows, and lock all doors when leaving your vehicle unattended. HGK2009-E
gkfluk-1a.p65
11/21/2005, 2:56 PM
6

1
CONTROLS AND EQUIPMENT
7
B040G01GK-GAT Central Door Lock The central door locking is operated by pushing the driver's door lock switch toward the front or rear of the vehicle.If the passenger door is open when the switch is pushed, the door will remain locked when closed. NOTE:
o When pushing the switch toward
the rear, all doors will unlock. When pushing the switch toward the front, all doors will lock.
o When the door is unlocked, the
red mark on the switch is visible.
o The central door locking is oper-
ated by turning the key (driver's door only) toward the front or rear of the vehicle. HGK2009-E
B040D01S-AAT Locking From the Inside To lock the doors from the inside, simply close the door and push the lock switch to the "LOCK" position.When this is done, neither the outside nor the inside door handle can be used. NOTE: When the door is locked, the red mark on the switch is not visible. UNLOCK
HGK2010-E
LOCK
ANTI-THEFT ALARM SYS- TEM
B070A01A-EAT (Not all models) This system is designed to provide protection from unauthorised entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal light.
gkfluk-1a.p65 11/21/2005, 2:56 PM
7

1CONTROLS AND EQUIPMENT
8
!
B070D04GK-EAT Disarmed Stage
UNLOCK
The system will be disarmed when either of the following steps are taken: CAUTION:
Avoid trying to start the engine whilethe system is armed.
B070D01GK
LOCK!
B070C01GK-EAT Alarm Stage The alarm will be activated if any of the following occur while the car is parked and the system is armed.
1) A front door is unlocked and opened without using the transmitter.
2) The hatchback door is opened with- out using the key.
3) The engine bonnet is opened.The siren will sound and the turn signal lamp will blink continuously for approxi- mately 30 seconds. To turn off thesystem, unlock the door with the trans- mitter.
B070B02GK-EAT Armed Stage Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine bonnet, doors and hatchback door are closed.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal lamp will blink once to indicate that the system is armed. NOTE:
1) If any door, hatchback door or engine bonnet remains open, the system will not be armed.
2) If this happens, rearm the system as described above.
3) Once the system is armed, only
the hatchback door may be un- locked using the key without dis- arming the system. CAUTION:
Do not arm the system until allpassengers have left the car. If thesystem is armed while a passenger(s) remains in the car, the alarm may be activated whenthe remaining passenger(s) leaves the car.
gkfluk-1a.p65 11/21/2005, 2:56 PM
8

1
CONTROLS AND EQUIPMENT
9
1) The driver's or passenger's door is
unlocked by depressing the "UN- LOCK" button on the transmitter.
2) In the middle of alarming or after
alarming, it disarms after 30 sec-onds if the key is turned to and kept in the "ON" position.
After completing one of steps above,the turn signal lamp will blink twice to indicate that the system is disarmed. NOTE: If any door, hatchback door or en- gine bonnet is not opened within 30 seconds, the system will be re-armed. B070F01A-GAT KEYLESS ENTRY SYSTEM (Not all models) Locking doors
1. Close all doors.
2. Push the "LOCK" button on the trans-
mitter.
3. At the same time all doors lock, the turn signal lights will blink once to indicate that the system is armed.
Unlocking doors
1. Push the "UNLOCK" button on the transmitter.
2. At the same time the driver's door unlocks, the turn signal lights will blink twice to indicate that the sys-tem is disarmed.
B075E01O-AAT Panic Warning
1. Push the "PANIC" button on the
transmitter.
2. At the same time, the siren will sound
and the turn signal lights will blink for 30 seconds.
3. To turn off the system, push the
"PANIC" button again on the trans-mitter. B070D01GK
PANIC
