Hyundai Coupe 2005 Owner's Guide

1
FEATURES OF YOUR HYUNDAI
7
!
DOOR LOCKS
B040A02Y-AAT
WARNING:
o Unlocked doors can be danger- ous. Before you drive away (es- pecially if there are children inthe car), be sure that all the doors are securely closed and locked so that the doors cannot be inad-vertently opened from the inside. This helps ensure that the doors will not be opened accidentally.Also, when combined with the proper use of seat belts, locking the doors helps keep occupantsfrom being ejected from the car in case of an accident.
o Before opening the door, always look for and avoid oncoming traf-fic.
o In case of accident, the door is unlocked automatically (If in-stalled).
B040B01A-AAT Locking and Unlocking Front Doors With a Key
o The door can be locked or unlockedwith a key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key towardthe rear. HGK2008
UNLOCK
LOCKB030C01Y-AAT ILLUMINATED IGNITION SWITCH (If installed)
Whenever a door is opened, the igni- tion switch will be illuminated for your convenience, provided the ignitionswitch is not in the "ON" position. The light will go off approximately 10 seconds after closing the door or whenthe ignition switch is turned on. B030C01E-1

1FEATURES OF YOUR HYUNDAI
8
B040G02GK-GAT Central Door Lock The central door locking is operated by pushing the driver's door lock switch toward the front or rear of the vehicle.If the passenger door is open when the switch is pushed, the door will remain locked when closed. HGK2009B040D01S-AAT Locking From the Inside To lock the doors from the inside, simply close the door and push the lock switch to the "LOCK" position.When this is done, neither the outside nor the inside door handle can be used. NOTE: When the door is locked, the red mark on the switch is not visible.UNLOCK
HGK2010
LOCK
B040C01S-AAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switch to the "LOCK" position sothat the red mark on the switch is not visible, then close the door. NOTE:
o When locking the door this way,be careful not to lock the door with the ignition key left in thevehicle.
o To protect against theft, always
remove the ignition key, close allwindows, and lock all doors when leaving your vehicle unattended. HGK2009

1
FEATURES OF YOUR HYUNDAI
9THEFT-ALARM SYSTEM
NOTE:
o When pushing the switch toward the rear, all doors will unlock. When pushing the switch towardthe front, all doors will lock.
o When the door is unlocked, the
red mark on the switch is visible.
o The central door locking is oper- ated by turning the key (driver'sdoor only) toward the front orrear of the vehicle.
o If the door is locked/unlocked mul-
tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stop operating temporarily in order toprotect the circuit and prevent damage to system components. B070A01A-AAT (If Installed) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an audible alarm with blinking of the turnsignal light.
B070B02GK-AAT Armed Stage Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the ignition switch.
2) Make sure that the engine hood and
tail gate are closed and latched.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal light will blink once to indicate that the system is armed. NOTE:
1) If any door, tail gate or engine
hood remains open, the system will not be armed.
2) If this happens, rearm the system as described above.
3) Once the system is armed, only the tail gate may be unlocked using the key without disarming the system.
! CAUTION:
Do not arm the system until all passengers have left the car. If the system is armed while a passenger(s) remains in the car,the alarm may be activated when the remaining passenger(s) leaves the car.

1FEATURES OF YOUR HYUNDAI
10
! B070D04GK-AAT Disarmed Stage
UNLOCK
The system will be disarmed when either of the following steps are taken:
1) The driver's or passenger's door is unlocked by depressing the "UN- LOCK" button on the transmitter.
2) In the middle of alarming or after
alarming, it disarms after 30 sec-onds if the key is turned to and kept in the "ON" position.
After completing one of steps above,the turn signal light will blink twice toindicate that the system is disarmed.
CAUTION:
Avoid trying to start the engine while the system is armed. HGK102
LOCK
B070C01GK-GAT Alarm Stage The alarm will be activated if any of the following occur while the car is parkedand the system is armed.
1) A front door is unlocked and opened
without using the transmitter.
2) The tail gate is opened without us-
ing the key.
3) The engine hood is opened.The siren will sound and the turn signal lights will blink continuously for 30 sec- onds. (E.C only/Except E.C : This hap- pens 3 times). To turn off the system,unlock the door with the transmitter.
B075E01O-AAT Panic Warning
1. Push the "PANIC" button on the
transmitter.
2. At the same time, the siren will sound and the turn signal lights will blink for 30 seconds.
3. To turn off the system, push the "PANIC" button again on the trans-mitter. HGK102
PANIC
NOTE: If any door, tail gate or engine hood is not opened within 30 seconds, the system will be rearmed.

1
FEATURES OF YOUR HYUNDAI
11
B070F02A-GAT KEYLESS ENTRY SYSTEM (If installed)Locking doors
1. Close all doors.
2. Push the "LOCK" button on the trans- mitter.
3. At the same time all doors lock, the turn signal lights will blink once to indicate that the system is armed.
Unlocking doors
1. Push the "UNLOCK" button on the transmitter.
2. At the same time all doors unlock,
the turn signal lights will blink twice to indicate that the system is dis- armed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is weak. - Other vehicles or objects may be
blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the trans- mitter.
When the transmitter does not workcorrectly, open and close the doorwith the ignition key. If you have a problem with the transmitter, con- tact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo-sure to water or liquids, it will not be covered by your manufacturer ve- hicle warranty.
B070E02GK-GAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR2032 Replacement instructions:
Screwdriver
1. Carefully separate the case with a blade screwdriver as shown in the illustration. HGK122

1FEATURES OF YOUR HYUNDAI
12POWER WINDOW
B050A02GK-AAT The power windows operate only when the ignition key is in the "ON" position. The main switches are located on thedriver's arm rest and control the front windows on the respective sides of the vehicle. The windows may be openedby depressing the front portion of the switch. To stop at the desired opening, release the switch. The window maybe closed by pulling the front portion of the switch. In order to prevent opera- tion of the passenger front window bythe passenger, a window lock switch (1) is provided on the arm rest of the driver's door. To disable the HGK2015
(1)
2. Remove the old battery from the
case and note the polarity. Make sure the polarity of the new battery is the same(+side facing down), then insert it in the transmitter.
3. Installation is the reverse order of disassembly.Battery
HGK121
NOTE: Install a new battery within 30 sec- onds after removing the old one. If installing a new battery takes morethan 30 seconds, take the following steps.
1) Turn the ignition key to the "ACC"position.
2) Make sure that the turn signal lights blink once by pushing the "LOCK" or "UNLOCK" button on the transmitter.

1
FEATURES OF YOUR HYUNDAI
13
!WARNING:
1) Be careful that someone's head, hands and body are not trapped by a closing window.
2) Never try to operate the main switch on the driver's door andthe individual door windowswitch in opposing directions at the same time. If this is done, the window will stop and cannot beopened or closed.
passenger's power window, push thewindow lock switch. To revert to nor-mal operation, push in on the window lock switch again.
HGK2016
SEATS
!
B080A01A-AAT ADJUSTABLE FRONT SEATS
WARNING:
Never attempt to adjust the seat while the vehicle is in motion. This could result in loss of control or anaccident which may cause death, serious injury or property damage.
3) Do not leave children alone in the
car. Always remove the ignition key for their safety.
B050A02GK
Auto-Down Window (Driver's Side) (If Installed) The Auto-Down window is moved to its fully open position by pushing the switch. To stop at the desired position push in on the switch again.

1FEATURES OF YOUR HYUNDAI
14
!!WARNING:
To ensure the seat is locked se- curely, attempt to move the seatforward or rearward without using the lock release lever. B080C01A-AAT Adjusting Seatback Angle
HGK2028
To recline the seatback, lean forward to take your weight off it, then pull up onthe recliner control lever at the outside edge of the seat. Now lean back until the desired seatback angle is achieved.To lock the seatback into position, release the recliner control lever. WARNING:
To minimize risk of severe injury inthe event of a collision or a sudden stop, both the driver's andpassenger's seatbacks should al- ways be in an upright position while the vehicle is in motion. The protec-tion provided by the seat belts and airbags in a frontal collision may be reduced significantly when the seatbacks are reclined. There is greater risk that the driver and passenger will slide under the seat belt which may result in serious injury if a crash occurs when the seatbacksare reclined. The seat belt cannot provide full protection to an occu- pant if the seat back is reclined.
B080B02A-AAT Adjusting Seat Forward and Rearward To move the seat toward the front or rear, pull the lock release lever up-ward. This will release the seat on its track so you can move it forward or rearward to the desired position. Whenyou find the position you want, release the lever and slide the seat forward or rearward on its track until it locks intothe desired position and cannot be moved further. HGK2027

1
FEATURES OF YOUR HYUNDAI
15
B080D02JM-AAT Adjustable Headrests Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. To remove the head- rest, raise it as far as it can go thenpress the lock knob while pulling up- ward. Lock Knob
HGK2032
!WARNING:
o For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the top of the occupant's eyes.The use of a cushion that holds the body away from the seatback is not recommended.
o Do not operate the vehicle with the
headrests removed as severe in- jury to an occupant may occur inthe event of an accident. Head- rests may provide protection against severe neck injuries whenproperly adjusted.
o Do not adjust the headrest hejght
while the vehicle is in motion.
B080D01JM

1FEATURES OF YOUR HYUNDAI
16
B080F01F-AAT Seat Cushion Height Adjustment (Driver's Seat Only) (If Installed) To raise or lower the front part of the seat cushion, turn the knob forward orrearward. B100A02HP-GAT SEAT WARMER (If Installed) The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" posi-tion, push either of the switches to warm the driver's seat or the passenger's seat.During mild weather or under condi- tions where the operation of the seat warmer is not needed, keep theswitches in the "OFF" position.
HGK2029
HGK2033B080E01F-AAT Lumbar Support Control (Driver's seat only) (If Installed) The driver's seat is equipped with ad- justable lumbar support.To increase the amount of lumbar sup- port, pull the lever forward. To decrease it, push the lever towardthe rear.SOFT
HGK2030
FIRM
