control INFINITI FX35 2004 Service Manual

TROUBLE DIAGNOSES
WT-21
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2004 November 2004 FX35/FX45
Malfunction Code/Symptom ChartAES000O0
Code/Symptom Malfunction partReference
page
15
16
17
18Front-left tire pressure drops to 190 kPa (1.9 kg/cm
2 , 27 psi) or less
Front-right tire pressure drops to 190 kPa (1.9 kg/cm2 , 27 psi) or less
Rear-right tire pressure drops to 190 kPa (1.9 kg/cm2 , 27 psi) or less
Rear-left tire pressure drops to 190 kPa (1.9 kg/cm2 , 27 psi) or less—
21
22
23
24Transmitter no data (front - left)
Transmitter no data (front - right)
Transmitter no data (rear - right)
Transmitter no data (rear - left)WT-22
31
32
33
34Transmitter checksum error (front - left)
Transmitter checksum error (front - right)
Transmitter checksum error (rear - right)
Transmitter checksum error (rear - left)WT-22
35
36
37
38Transmitter pressure data error (front - left)
Transmitter pressure data error (front - right)
Transmitter pressure data error (rear - right)
Transmitter pressure data error (rear - left)WT-23
41
42
43
44Transmitter function code error (front - left)
Transmitter function code error (front - right)
Transmitter function code error (rear - right)
Transmitter function code error (rear - left)WT-22
45
46
47
48Transmitter battery voltage low (front - left)
Transmitter battery voltage low (front - right)
Transmitter battery voltage low (rear - right)
Transmitter battery voltage low (rear - left)WT-22
52 Vehicle speed signalWT-24
Warning lamp does not come on when
ignition switch is turned on.Fuse or unified meter and A/C amp.
Low tire pressure warning control unit connector or circuit
Low tire pressure warning control unit WT-25
Warning lamp stays on when ignition
switch is turned on.Fuse or unified meter and A/C amp.
Low tire pressure warning control unit connector or circuit
Low tire pressure warning control unitWT-26
Warning lamp blinks when ignition
switch is turned on.Low tire pressure warning control unit harness connector or circuit
Low tire pressure warning control unit
Transmitter's mode off
ID registration not yetWT-28
Hazard warning lamp blinks when igni-
tion switch is turned on.Low tire pressure warning control unit harness connector or circuit
Low tire pressure warning control unitWT-29
“TIRE PRESSURE” information in dis-
play does not exist.Fuse
Display control unit
Low tire pressure warning control unit WT-30
ID registration cannot be completed.Transmitter
Antenna harness connector or circuit
AntennaWT-30

WT-22
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2004 November 2004 FX35/FX45
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Inspection 1: Transmitter or Low Tire Pressure Warning Control UnitAES000O1
MALFUNCTION CODE NO. 21, 22, 23 OR 24
1. CHECK CONTROL UNIT

Drive for several minutes. Check all tires' pressure with CONSULT-II “DATA MONITOR ITEM”.
Are all tires' pressure displayed 0 kPa?
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK ANTENNA CONNECTOR

Check antenna and feeder connector R102 for damage or loose connections.
OK or NG
OK >> Replace control unit, GO TO 3.
NG >> Repair or replace antenna or feeder connector.
3. ID REGISTRATION

Carry out ID registration of all transmitters.
Is there a tire that cannot register ID?
YES >> Replace transmitter of the tire, then GO TO 5.
NO >> GO TO 4.
4. VEHICLE DRIVING

Drive at a speed of 40 km/h (25 MPH) or more for several minutes without stopping.
Check all tires' pressure with CONSULT-II “DATA MONITOR ITEM” within 15 minutes after vehicle speed
becomes 17 km/h (11 MPH).
Does
“DATA MONITOR ITEM” displayed tire pressure as normal without any warning lamp?
YES >> INSPECTION END.
NO >> GO TO 5.
5. ID REGISTRATION AND VEHICLE DRIVING
1. Carry out ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes. Then check all tires' pressure with CONSULT-II “DATA MONITOR ITEM” within 5 minutes.
Does
“DATA MONITOR ITEM” displayed tire pressure as normal without any warning lamp?
YES >> GO TO inspection applicable to DTC.
NO >> INSPECTION END.
Inspection 2: Transmitter - 1AES000O2
MALFUNCTION CODE NO. 31, 32, 33, 34, 41, 42, 43, 44, 45, 46, 47 OR 48
1. ID REGISTRATION (CORRECTION OF TRANSMITTER LOCATION)
1. Carry out ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for
10 minutes.
>> GO TO 2.

TROUBLE DIAGNOSIS FOR SYMPTOMS
WT-25
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2004 November 2004 FX35/FX45
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Inspection 1: Warning Lamp Does Not Come On When Ignition Switch Is Turned
On.
AES000O5
DIAGNOSTIC PROCEDURE
1. SELF-DIAGNOSTIC RESULT CHECK
1. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector.
NOTE:
If “AIR PRESSURE MONITOR” is not indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit"
2. Select “AIR PRESSURE MONITOR” on “SELECT SYSTEM” screen.
3. Select “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
4. Check display contents in self-diagnostic results.
Is
“CAN COMM CIRCUIT” displayed in the self-diagnosis display items?
YES >> Malfunction in CAN communication system. GO TO LAN-4, "Precautions When Using CONSULT-
II" .
NO >> GO TO 2.
2. CHECK COMBINATION METER

Check combination meter operation.
OK or NG
OK >> GO TO 3.
NG >> Check combination meter. Refer to DI-4, "
System Description" .
3. CHECK WARNING LAMP

Disconnect low tire pressure warning control unit connector.
Does the warning lamp activate?
YES >> Replace low tire pressure warning control unit.
NO >> GO TO 4.
4. CHECK UNIFIED METER AND A/C AMP. POWER SUPPLY CIRCUIT
1. Disconnect unified meter and A/C amp. connector M56.
2. Check voltage between unified meter and A/C amp. harness connector M56 terminals 21 (R/W), 22 (G/R)
and ground.
OK or NG
OK >> GO TO 5.
NG >> Check unified meter and A/C amp. power supply circuit
for open or short.Te r m i n a l s
Vo l ta g e
(Approx.)
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground 12 V
M5621 (R/W)
22 (G/R)SEIA0337E

WT-26
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2004 November 2004 FX35/FX45
5. CHECK UNIFIED METER AND A/C AMP. GROUND CIRCUIT

Check continuity between unified meter and A/C amp. connector M56 terminals 29 (B), 30 (B) and
ground.
OK or NG
OK >> Check unified meter and A/C amp. Refer to DI-28, "Sys-
tem Description" .
NG >> Repair or replace unified meter and A/C amp. ground circuit.
Inspection 2: Warning Lamp Stays On When Ignition Switch Is Turned On.AES000O6
DIAGNOSTIC PROCEDURE
1. CHECK CONNECTOR
1. Disconnect low tire pressure warning control unit connectors M74.
2. Check terminals for damage or loose connections.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace damaged parts.
2. CHECK POWER SUPPLY CIRCUIT 1
Check voltage between low tire pressure warning control unit connector M74 terminal 12 (R/W) and ground.
OK or NG
OK >> GO TO 3.
NG >> Check low tire pressure warning control unit power sup-
ply circuit for open or short.Te r m i n a l s
Continuity
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground Yes
M5629 (B)
30 (B)
SEIA0338E
Te r m i n a l s
Vo l ta g e
(Approx.)
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground 12 V
M74 12 (R/W)
SEIA0341E

TROUBLE DIAGNOSIS FOR SYMPTOMS
WT-27
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2004 November 2004 FX35/FX45
3. CHECK POWER SUPPLY CIRCUIT 2
1. Turn ignition switch ON.
2. Check voltage between low tire pressure warning control unit connector M74 terminals 11 (LG/R), 24 (G/
R) and ground.
OK or NG
OK >> GO TO 4.
NG >> Check low tire pressure warning control unit power sup-
ply circuit for open or short.
4. CHECK GROUND CIRCUIT

Check continuity between low tire pressure warning control unit connector M74 terminal 20(B) and
ground.
OK or NG
OK >> Replace low tire pressure warning control unit.
NG >> Repair or replace low tire pressure warning control unit
ground circuit.Te r m i n a l s
Vo l ta g e
(Approx.)
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground 12 V
M7411 ( LG /R )
24 (G/R)
SEIA0342E
Te r m i n a l s
Continuity
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground Yes
M74 20 (B)
SEIA0343E

WT-28
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2004 November 2004 FX35/FX45
Inspection 3: Warning Lamp Blinks When Ignition Switch Is Turned On.AES000O7
NOTE:
If warning lamp blink below, the system is normal.
Blink Mode A

This mode shows transmitter status is OFF-mode.
Carry out transmitter wake up operation. Refer to WT-16,
"Transmitter Wake Up Operation" .
DIAGNOSTIC PROCEDURE
1. CHECK CONNECTOR
1. Disconnect low tire pressure warning control unit connectors M74 and R102.
2. Check terminals for damage or loose connections.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace damaged parts.
2. CHECK TIRE PRESSURE WARNING CHECK CONNECTOR CIRCUIT
1. Disconnect low tire pressure warning control unit connector M74.
2. Check continuity between low tire pressure warning control unit harness connector M74 terminal 8 (G)
and ground.
OK or NG
OK >> Replace low tire pressure warning control unit.
NG >> Repair or replace harness connector.
SEIA0347E
Te r m i n a l s
Continuity
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground No
M74 8 (G)
SEIA0344E

TROUBLE DIAGNOSIS FOR SYMPTOMS
WT-29
C
D
F
G
H
I
J
K
L
MA
B
WT
Revision: 2004 November 2004 FX35/FX45
Inspection 4: Hazard Warning Lamp Blinks When Ignition Switch Is Turned On.AES000O8
DIAGNOSTIC PROCEDURE
1. CHECK GROUND CIRCUIT
1. Disconnect low tire pressure waning control unit connector M74.
2. Check continuity between low tire pressure warning control unit harness connector M74 terminal 20 (B)
and ground.
OK or NG
OK >> Replace low tire pressure warning control unit.
NG >> Repair or replace low tire pressure warning control unit
ground circuit.Te r m i n a l s
Continuity
(+) (–)
ConnectorTe r m i n a l
(Wire color)
Ground Yes
M74 20 (B)
SEIA0343E

WT-30
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2004 November 2004 FX35/FX45
Inspection 5: “TIRE PRESSURE” Information In Display Unit Does Not Exist.AES000O9
DIAGNOSTIC PROCEDURE
1. SELF-DIAGNOSTIC RESULT CHECK
1. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector.
NOTE:
If “AIR PRESSURE MONITOR” is not indicated, go to GI-40, "
CONSULT-II Data Link Connector (DLC)
Circuit" .
2. Select “AIR PRESSURE MONITOR” on “SELECT SYSTEM” screen.
3. Select “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
4. Check display contents in self-diagnostic results.
Is
“CAN COMM CIRCUIT” displayed in the self-diagnosis display items?
YES >> Malfunction in CAN communication system. GO TO LAN-4, "Precautions When Using CONSULT-
II" .
NO >> GO TO 2.
2. CHECK DISPLAY CONTROL UNIT

Perform display control unit self-diagnosis. Refer to AV- 1 3 1 , "Self-Diagnosis Mode (DCU)" .
OK or NG
OK >> Replace low tire pressure warning control unit.
NG >> Repair or replace malfunctioning parts.
Inspection 6: ID Registration Cannot Be Completed.AES000OA
DIAGNOSTIC PROCEDURE
1. ID REGISTRATION (ALL)

Carry out ID registration of all transmitters.

Can ID registration of all transmitters be completed?
YES or NO
YES >> INSPECTION END.
NO >> GO TO WT-22, "
Inspection 1: Transmitter or Low Tire Pressure Warning Control Unit" .

WW-1
WIPER, WASHER & HORN
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION WW
A
B
WW
Revision: 2004 November 2004 FX35/FX45
WIPER, WASHER & HORN
PRECAUTION ............................................................ 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Wiring Diagrams and Trouble Diagnosis .................. 3
FRONT WIPER AND WASHER SYSTEM .................. 4
Components Parts and Harness Connector Loca-
tion ........................................................................... 4
System Description .................................................. 4
LOW SPEED WIPER OPERATION ...................... 5
HI SPEED WIPER OPERATION ........................... 5
INTERMITTENT OPERATION .............................. 5
AUTO STOP OPERATION .................................... 6
WASHER OPERATION ......................................... 6
MIST OPERATION ................................................ 6
FAIL-SAFE FUNCTION ......................................... 7
COMBINATION SWITCH READING FUNCTION ..... 7
CAN Communication System Description ................ 9
CAN Communication Unit ........................................ 9
Schematic .............................................................. 10
Wiring Diagram — WIPER — ................................. 11
Terminals and Reference Values for BCM ............. 14
Terminals and Reference Values for IPDM E/R ..... 15
How to Proceed With Trouble Diagnosis ................ 15
Preliminary Check .................................................. 16
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................... 16
CONSULT-II Functions (BCM) ............................... 17
CONSULT-II OPERATION .................................. 17
DATA MONITOR ................................................. 18
ACTIVE TEST ..................................................... 19
CONSULT-II Functions (IPDM E/R) ....................... 19
CONSULT-II OPERATION .................................. 19
SELF-DIAGNOSTIC RESULTS .......................... 20
DATA MONITOR ................................................. 20
ACTIVE TEST ..................................................... 21
Front Wiper Does Not Operate .............................. 21
Front Wiper Does Not Return to Stop Position ....... 24
Only Front Wiper LO Does Not Operate ................ 24Only Front Wiper HI Does Not Operate .................. 25
Only Front Wiper INT Does Not Operate ................ 25
Front Wiper Interval Time Is Not Controlled by Vehi-
cle Speed ................................................................ 26
Front Wiper Intermittent Operation Switch Position
Cannot Be Adjusted ................................................ 26
Wipers Do Not Wipe When Front Washer Operates ... 26
After Front Wipers Operate for 10 Seconds, They
Stop for 20 Seconds, and after repeating the oper-
ations five times, they become inoperative ............. 27
Front Wipers Do Not Stop ....................................... 28
Removal and Installation of Front Wiper Arms,
Adjustment of Wiper Arms Stop Location ............... 28
REMOVAL ........................................................... 28
INSTALLATION ................................................... 28
ADJUSTMENT .................................................... 29
Removal and Installation of Front Wiper Motor and
Linkage ................................................................... 29
REMOVAL ........................................................... 29
INSTALLATION ................................................... 29
Disassembly and Assembly of Front Wiper Motor
and Linkage ............................................................ 30
DISASSEMBLY ................................................... 30
ASSEMBLY ......................................................... 30
Washer Nozzle Adjustment .................................... 30
Washer Tube Layout .............................................. 32
Removal and Installation of Front Washer Nozzle ... 32
Removal and Installation of Front Washer Tube
Joint ........................................................................ 32
REMOVAL ........................................................... 32
INSTALLATION ................................................... 32
Check Valve Inspection .......................................... 32
Removal and Installation of Front Wiper and Washer
Switch ..................................................................... 33
REMOVAL ........................................................... 33
INSTALLATION ................................................... 33
Removal and Installation of Washer Tank .............. 33
REMOVAL ........................................................... 33

WW-4
FRONT WIPER AND WASHER SYSTEM
Revision: 2004 November 2004 FX35/FX45
FRONT WIPER AND WASHER SYSTEMPFP:28810
Components Parts and Harness Connector LocationAKS0056O
System DescriptionAKS0056P

All front wiper relays (HI, LO) are included in IPDM E/R.

Wiper switch (combination switch) is composed of a combination of 5 output terminals and 5 input termi-
nals. Terminal combination status is read by BCM when switch is turned ON.

BCM controls front wiper LO, HI, and INT (intermittent) operation.

IPDM E/R operates wiper motor according to CAN communication signals from BCM.
Power is supplied at all times

through 50 A fusible link (letter M, located in fusible link block)

to BCM (body control module) terminal 55

through 15 A fuse [No. 22, located in fuse block (J/B)]

to BCM (body control module) terminal 42

through 30 A fuse [No. 73, located in IPDM E/R (intelligent power distribution module engine room)]

to front wiper relay [located in IPDM E/R (intelligent power distribution module engine room)]

through 15 A fuse [No. 78, located in IPDM E/R (intelligent power distribution module engine room)]

to CPU (central processing unit) [located in IPDM E/R (intelligent power distribution module engine room)]

through 10 A fuse [No. 71, located in IPDM E/R (intelligent power distribution module engine room)]

to CPU (central processing unit) [located in IPDM E/R (intelligent power distribution module engine
room)].
When the ignition switch ON or START position, power is supplied

through 15 A fuse [No. 1, located in fuse block (J/B)]

to BCM (body control module) terminal 38

through ignition relay [located in IPDM E/R (intelligent power distribution module engine room)]

to front wiper relay [located in IPDM E/R (intelligent power distribution module engine room)]
SKIA5289E
