Page 1265 of 4449
DI-22
COMBINATION METERS
Revision: 2004 November 2004 FX35/FX45
CAN Communication System InspectionAKS005N0
1. CHECK CAN COMMUNICATION
1. Select “SELF-DIAG RESULTS” mode for “METER A/C AMP” with CONSULT-II.
2. Print out CONSULT-II screen.
>> Go to “CAN system”. Refer to LAN-4, "
Precautions When Using CONSULT-II" .
Communication Line InspectionAKS005N1
1. CHECK CONNECTOR
Check combination meter, unified meter and A/C amp. and terminals (combination meter-side, unified meter
and A/C amp. side, and harness side) for looseness or bent terminals.
OK or NG
OK >> GO TO 2.
NG >> Repair terminal or connector.
2. CHECK METER/GAUGES VISUALLY
Does the pointer on the meter/gauge fluctuate at the engine start?
Is the fluctuation acceptable?
YES >> GO TO 3.
NO >> GO TO 6.
3. CHECK CONTINUITY COMMUNICATION CIRCUIT (TX: COMBINATION METER)
1. Turn ignition switch OFF.
2. Disconnect the combination meter connector and unified meter and A/C amp. connector.
3. Check continuity between combination meter harness connector
M20 terminal 13 (L/B) and unified meter and A/C amp. harness
connector M55 terminal 19 (L/B).
4. Check continuity between combination meter harness connector
M20 terminal 13 (L/B) and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK VOLTAGE OF UNIFIED METER AND A/C AMP.
1. Connect unified meter and A/C amp. connector.
2. Turn ignition switch ON.
3. Check voltage between combination meter harness connector
M20 terminal 13 (L/B) and ground.
OK or NG
OK >> GO TO 5.
NG >> Replace unified meter and A/C amp. Refer to DI-34,
"Removal and Installation of Unified Meter and A/C
Amp." . Continuity should exist.
Continuity should not exist.
SKIA4837E
Approx. 5V
SKIA4886E
Page 1271 of 4449
DI-28
UNIFIED METER AND A/C AMP
Revision: 2004 November 2004 FX35/FX45
UNIFIED METER AND A/C AMPPFP:27760
System DescriptionAKS005N8
For the unified meter and A/C amp., the signal required for controlling the combination meter are inte-
grated in the A/C auto amp.
Unified meter and A/C amp. controls each operation for A/C auto amp. For information regarding A/C con-
trol, refer to AT C - 3 0 , "
AIR CONDITIONER CONTROL" in ATC section.
Unified meter and A/C amp. inputs necessary information for combination meter from each unit by CAN
communication and so on.
And unified meter and A/C amp. outputs these signals using communication line (TX, RX) between unified
meter and A/C amp. and combination meter.
The signals required for the distance to empty (DTE) display are centralized in the unified meter and A/C
amp., converted into data, and sent to the display unit (without NAVI) display control unit (with NAVI) using
CAN communication.
Other input signals are also sent to the ECM, TCM, AWD control unit, BCM, display unit (without NAVI)
and display control unit (with NAVI) using CAN communication.
The unified meter and A/C amp. have a CONSULT-II function (self-diagnostic results, CAN diagnostic
support monitor, data monitor).
INPUT/OUTPUT SIGNALS
Between Unified Meter & A/C amp. and Combination Meter
Unit Input Output
Unified meter and A/C amp.
Seat belt buckle switch signal (Driver's side)
Parking brake signal
Illumination control nighttime required signal
Refuel status signal
Low-fuel warning lamp condition signal
Combination meter receive error signal
Delivery destination data signal
Combination meter specifications signal
Vehicle speed signal (8-pulse)
Engine speed signal
Engine coolant temperature signal
Fuel level sensor signal (resistance value)
Malfunction indicator lamp signal
ABS warning lamp signal
Low tire pressure warning lamp signal
Brake warning lamp signal
A/T CHECK warning lamp signal
ICC warning lamp signal
Oil pressure switch signal
Door switch signal
AWD warning lamp signal
VDC OFF indicator lamp signal
SLIP indicator lamp signal
ASCD CRUISE indicator lamp signal
ASCD SET indicator lamp signal
High beam request signal
Turn indicator signal
Snow mode switch signal
ICC system display signal
A/T position indicator signal
Manual mode indicator signal
Manual mode gear position signal
CAN communication condition signal of A/T
Position lights request signal
Buzzer output signal
Page 1291 of 4449
DI-48
WARNING LAMPS
Revision: 2004 November 2004 FX35/FX45
Oil Pressure Warning Lamp Stays Off (Ignition Switch ON)AKS005NF
1. CHECK SELF-DIAGNOSTIC RESULTS OF UNIFIED METER AND A/C AMP.
1. Start engine.
2. Select “METER A/C AMP” on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp.
Refer to DI-31, "
CONSULT-II Function" .
3. After erasing the self-diagnostic results, perform self-diagnosis again.
Self-diagnostic results content
No malfunction detected>> GO TO 2.
Malfunction detected>> GO TO DI-16, "
Symptom Chart 2" in “COMBINATION METER”.
2. CHECK IPDM E/R OUTPUT SIGNAL
Activate IPDM E/R auto active test. Refer to PG-24, "
Auto Active Test" .
Does oil pressure warning lamp is blinking?
YES >> GO TO 5.
NO >> GO TO 3.
3. CHECK BCM INPUT SIGNAL
Select “DATA MONITOR” of “SIGNAL BUFFER”. Refer to BCS-12,
"CONSULT-II" . Operate ignition switch with “OIL PRESS SW” of
“DATA MONITOR” and check operate status.
OK or NG
OK >> GO TO 4.
NG >> Replace IPDM E/R. Refer to PG-30, "
Removal and
Installation of IPDM E/R" .
4. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
Select “METER A/C AMP” on CONSULT-II. Operate ignition switch
with “OIL W/L” of “DATA MONITOR” and check operation status.
OK or NG
OK >> Replace combination meter.
NG >> Replace BCM. Refer to BCS-15, "
Removal and Installa-
tion of BCM" . When ignition switch is in ON
position (Engine stopped): OIL PRESS SW ON
When engine running : OIL PRESS SW OFF
SKIA8709E
When ignition switch is in ON
position (Engine stopped): OIL W/L ON
When engine running : OIL W/L OFF
PKIA2064E
Page 1293 of 4449
DI-50
WARNING LAMPS
Revision: 2004 November 2004 FX35/FX45
3. CHECK OIL PRESSURE SWITCH CIRCUIT
1. Disconnect the IPDM E/R connector.
2. Check continuity between IPDM E/R harness connector E9 ter-
minal 57 (BR) and ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> Repair harness or connector.
Component InspectionAKS005NH
OIL PRESSURE SWITCH
Check continuity between oil pressure switch and ground.Continuity should not exist.
SKIA5013E
Condition
Oil pressure kPa (kg/cm2 , psi)Continuity
Engine stopped Less than 29 (0.3, 4) Yes
Engine running More than 29 (0.3, 4) No
ELF0044D
Page 1296 of 4449
A/T INDICATOR
DI-53
C
D
E
F
G
H
I
J
L
MA
B
DI
Revision: 2004 November 2004 FX35/FX45
A/T Indicator Is MalfunctionAKS005NJ
1. CHECK SELF-DIAGNOSIS OF COMBINATION METER
Perform combination meter self-diagnosis. Refer to DI-12, "
HOW TO
ALTERNATE DIAGNOSIS MODE" .
Are all segments displayed?
YES >> GO TO 2.
NO >> Replace combination meter.
2. CHECK SELF-DIAGNOSIS RESULTS OF UNIFIED METER AND A/C AMP.
1. Start engine.
2. Select “METER A/C AMP” on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp.
Refer to DI-31, "
CONSULT-II Function" .
3. After erasing the self-diagnostic results, perform self-diagnosis again.
Self-diagnostic results content
No malfunction detected>> GO TO 3.
Malfunction detected>> Go to DI-16, "
Symptom Chart 2" in “COMBINATION METER”.
3. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Connect CONSULT-II and start engine.
2. Use “DATA MONITOR” of “METER A/C AMP” on CONSULT-II.
Confirm each indication on the monitor when operating the shift
lever.
OK or NG
OK >> Replace combination meter.
NG >> GO TO 4.
EL-3828D
CONSULT-II display Switch operationOperation
status
AT-M INDManual mode range ON
Except for manual mode range OFF
AT-M GEARManual mode range (shift- up or down) 5-1
Except for manual mode range 1
P RANGE INDP range position ON
Except for P range position OFF
R RANGE INDR range position ON
Except for R range position OFF
N RANGE INDN range position ON
Except for N range position OFF
D RANGE INDD range position ON
Except for D range position OFF
SKIA6259E
Page 1307 of 4449
DI-64
WARNING CHIME
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for Combination MeterAKS005NQ
How to Proceed With Trouble DiagnosisAKS005NR
1. Confirm the malfunction symptom or customer complaint.
2. Understand operation description and function description. Refer to DI-55, "
System Description" .
3. Perform the Preliminary Check. Refer to DI-65, "
Preliminary Check" .
4. Start engine.
5. Select “METER A/C AMP” on CONSULT-II, and perform self-diagnosis of unified meter and A/C amp.
Refer to DI-31, "
CONSULT-II Function" .
6. After erasing the self-diagnostic results, perform self-diagnosis again. When no malfunction detected, go
to next step 7. When malfunction detected, go to DI-16, "
Symptom Chart 2" in “COMBINATION METER”.
7. Check symptom and repair or replace the cause of malfunction.
8. Does the warning chime operate normally? If so, go to 9. If not, go to 7.
9. INSPECTION END
Terminal
No.Wire
colorItem Measuring condition
Reference value
Ignition
switchOperation or condition
5
B Ground ON — Approx. 0V
6
7 G/Y Ignition switch ON or START ON — Battery voltage
8 R/W Battery power supply OFF — Battery voltage
9LG/RSeat belt buckle switch
(driver side) ONUnfastened (ON) Approx. 0V
Fastened (OFF) Approx. 12V
13 L/BTX communication line (To
unified meter and A/C amp.)ON —
14 PURX communication line
(From unified meter and A/C
amp.)ON —
15 B Ground ON — Approx. 0V
SKIA3361E
SKIA3362E
Page 1342 of 4449
EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EC
A
EC
Revision: 2004 November 2004 FX35/FX45
ENGINE CONTROL SYSTEM
VQ35DE
INDEX FOR DTC ...................................................... 15
Alphabetical Index .................................................. 15
DTC No. Index ....................................................... 19
PRECAUTIONS ........................................................ 23
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ................................................................ 23
On Board Diagnostic (OBD) System of Engine and
A/T .......................................................................... 23
Precaution .............................................................. 23
Wiring Diagrams and Trouble Diagnosis ................ 26
PREPARATION ......................................................... 27
Special Service Tools ............................................. 27
Commercial Service Tools ...................................... 28
ENGINE CONTROL SYSTEM .................................. 29
System Diagram ..................................................... 29
Vacuum Hose Drawing ........................................... 30
System Chart ......................................................... 31
Multiport Fuel Injection (MFI) System .................... 32
Electronic Ignition (EI) System ............................... 34
Air Conditioning Cut Control ................................... 35
Fuel Cut Control (at No Load and High Engine
Speed) .................................................................... 35
CAN communication .............................................. 36
BASIC SERVICE PROCEDURE .............................. 37
Idle Speed and Ignition Timing Check .................... 37
Idle Speed/Ignition Timing/Idle Mixture Ratio
Adjustment ............................................................. 38
Accelerator Pedal Released Position Learning ...... 49
Throttle Valve Closed Position Learning ................ 49
Idle Air Volume Learning ........................................ 49
Fuel Pressure Check .............................................. 51
ON BOARD DIAGNOSTIC (OBD) SYSTEM ............ 53
Introduction ............................................................ 53
Two Trip Detection Logic ........................................ 53
Emission-Related Diagnostic Information .............. 54
IVIS (Infiniti Vehicle Immobilizer System — NATS) ... 68
Malfunction Indicator Lamp (MIL) ........................... 68
OBD System Operation Chart ................................ 72TROUBLE DIAGNOSIS ............................................ 77
Trouble Diagnosis Introduction ............................... 77
DTC Inspection Priority Chart ................................. 80
Fail-Safe Chart ....................................................... 82
Basic Inspection ..................................................... 83
Symptom Matrix Chart ............................................ 88
Engine Control Component Parts Location ............ 92
Circuit Diagram ....................................................... 98
ECM Harness Connector Terminal Layout ...........100
ECM Terminals and Reference Value ...................100
CONSULT-II Function ...........................................109
Generic Scan Tool (GST) Function .......................122
CONSULT-II Reference Value in Data Monitor .....125
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................129
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .131
Description ............................................................131
Testing Condition ..................................................131
Inspection Procedure ............................................131
Diagnostic Procedure ...........................................132
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT .......................................................................135
Description ............................................................135
Diagnostic Procedure ...........................................135
POWER SUPPLY AND GROUND CIRCUIT ...........136
Wiring Diagram .....................................................136
Diagnostic Procedure ...........................................137
Ground Inspection ................................................141
DTC U1000, U1001 CAN COMMUNICATION LINE .142
Description ............................................................142
On Board Diagnosis Logic ....................................142
DTC Confirmation Procedure ...............................142
Wiring Diagram .....................................................143
Diagnostic Procedure ...........................................144
DTC P0011, P0021 IVT CONTROL ........................145
Description ............................................................145
CONSULT-II Reference Value in Data Monitor Mode
.145
On Board Diagnosis Logic ....................................146
Page 1346 of 4449
EC-5
C
D
E
F
G
H
I
J
K
L
M
ECA
Revision: 2004 November 2004 FX35/FX45Component Inspection ......................................... 414
Removal and Installation ...................................... 414
DTC P1121 ELECTRIC THROTTLE CONTROL
ACTUATOR ............................................................ 415
Component Description ........................................ 415
On Board Diagnosis Logic ................................... 415
DTC Confirmation Procedure ............................... 415
Diagnostic Procedure ........................................... 416
DTC P1122 ELECTRIC THROTTLE CONTROL
FUNCTION .............................................................. 417
Description ........................................................... 417
On Board Diagnosis Logic ................................... 417
DTC Confirmation Procedure ............................... 417
Wiring Diagram .................................................... 418
Diagnostic Procedure ........................................... 419
Component Inspection ......................................... 422
Removal and Installation ...................................... 422
DTC P1124, P1126 THROTTLE CONTROL MOTOR
RELAY .................................................................... 423
Component Description ........................................ 423
CONSULT-II Reference Value in Data Monitor Mode
. 423
On Board Diagnosis Logic ................................... 423
DTC Confirmation Procedure ............................... 423
Wiring Diagram .................................................... 425
Diagnostic Procedure ........................................... 426
DTC P1128 THROTTLE CONTROL MOTOR ........ 428
Component Description ........................................ 428
On Board Diagnosis Logic ................................... 428
DTC Confirmation Procedure ............................... 428
Wiring Diagram .................................................... 429
Diagnostic Procedure ........................................... 430
Component Inspection ......................................... 431
Removal and Installation ...................................... 432
DTC P1143, P1163 HO2S1 ..................................... 433
Component Description ........................................ 433
CONSULT-II Reference Value in Data Monitor Mode
. 433
On Board Diagnosis Logic ................................... 433
DTC Confirmation Procedure ............................... 434
Overall Function Check ........................................ 435
Diagnostic Procedure ........................................... 435
Component Inspection ......................................... 437
Removal and Installation ...................................... 438
DTC P1144, P1164 HO2S1 ..................................... 439
Component Description ........................................ 439
CONSULT-II Reference Value in Data Monitor Mode
. 439
On Board Diagnosis Logic ................................... 439
DTC Confirmation Procedure ............................... 440
Overall Function Check ........................................ 441
Diagnostic Procedure ........................................... 441
Component Inspection ......................................... 443
Removal and Installation ...................................... 445
DTC P1146, P1166 HO2S2 ..................................... 446
Component Description ........................................ 446
CONSULT-II Reference Value in Data Monitor Mode
. 446
On Board Diagnosis Logic ................................... 446DTC Confirmation Procedure ...............................447
Overall Function Check ........................................447
Wiring Diagram .....................................................449
Diagnostic Procedure ...........................................452
Component Inspection ..........................................454
Removal and Installation ......................................456
DTC P1147, P1167 HO2S2 .....................................457
Component Description ........................................457
CONSULT-II Reference Value in Data Monitor Mode
.457
On Board Diagnosis Logic ....................................457
DTC Confirmation Procedure ...............................458
Overall Function Check ........................................458
Wiring Diagram .....................................................460
Diagnostic Procedure ...........................................463
Component Inspection ..........................................465
Removal and Installation ......................................467
DTC P1148, P1168 CLOSED LOOP CONTROL ....468
On Board Diagnosis Logic ....................................468
DTC Confirmation Procedure ...............................468
Overall Function Check ........................................468
Diagnostic Procedure ...........................................469
DTC P1211 TCS CONTROL UNIT ..........................470
Description ............................................................470
On Board Diagnosis Logic ....................................470
DTC Confirmation Procedure ...............................470
Diagnostic Procedure ...........................................470
DTC P1212 TCS COMMUNICATION LINE ............471
Description ............................................................471
On Board Diagnosis Logic ....................................471
DTC Confirmation Procedure ...............................471
Diagnostic Procedure ...........................................471
DTC P1217 ENGINE OVER TEMPERATURE ........472
Description ............................................................472
CONSULT-II Reference Value in Data Monitor Mode
.475
On Board Diagnosis Logic ....................................475
Overall Function Check ........................................475
Wiring Diagram .....................................................477
Diagnostic Procedure ...........................................479
Main 12 Causes of Overheating ...........................484
Component Inspection ..........................................484
DTC P1225 TP SENSOR ........................................485
Component Description ........................................485
On Board Diagnosis Logic ....................................485
DTC Confirmation Procedure ...............................485
Diagnostic Procedure ...........................................486
Removal and Installation ......................................486
DTC P1226 TP SENSOR ........................................487
Component Description ........................................487
On Board Diagnosis Logic ....................................487
DTC Confirmation Procedure ...............................487
Diagnostic Procedure ...........................................488
Removal and Installation ......................................488
DTC P1229 SENSOR POWER SUPPLY ................489
On Board Diagnosis Logic ....................................489
DTC Confirmation Procedure ...............................489
Wiring Diagram .....................................................490
Diagnostic Procedure ...........................................491
Page 1349 of 4449
EC-8Revision: 2004 November 2004 FX35/FX45 PREPARATION .......................................................674
Special Service Tools ...........................................674
Commercial Service Tools ....................................675
ENGINE CONTROL SYSTEM ................................676
System Diagram ...................................................676
Vacuum Hose Drawing .........................................677
System Chart ........................................................678
Multiport Fuel Injection (MFI) System ...................679
Electronic Ignition (EI) System .............................681
Nissan Torque Demand (NTD) Control System ....682
Air Conditioning Cut Control .................................683
Fuel Cut Control (at No Load and High Engine
Speed) ..................................................................683
CAN communication .............................................684
BASIC SERVICE PROCEDURE .............................685
Idle Speed and Ignition Timing Check ..................685
Idle Speed/Ignition Timing/Idle Mixture Ratio
Adjustment ............................................................687
Accelerator Pedal Released Position Learning ....698
Throttle Valve Closed Position Learning ...............698
Idle Air Volume Learning ......................................698
Fuel Pressure Check ............................................700
ON BOARD DIAGNOSTIC (OBD) SYSTEM ..........703
Introduction ...........................................................703
Two Trip Detection Logic ......................................703
Emission-related Diagnostic Information ..............704
IVIS (Infiniti Vehicle Immobilizer System — NATS) .717
Malfunction Indicator Lamp (MIL) .........................717
OBD System Operation Chart ..............................721
TROUBLE DIAGNOSIS ..........................................726
Trouble Diagnosis Introduction .............................726
DTC Inspection Priority Chart ...............................729
Fail-safe Chart ......................................................731
Basic Inspection ...................................................733
Symptom Matrix Chart ..........................................738
Engine Control Component Parts Location ..........742
Circuit Diagram .....................................................748
ECM Harness Connector Terminal Layout ...........750
ECM Terminals and Reference Value ...................750
CONSULT-II Function ...........................................759
Generic Scan Tool (GST) Function .......................772
CONSULT-II Reference Value in Data Monitor .....775
Major Sensor Reference Graph in Data Monitor
Mode .....................................................................778
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .780
Description ............................................................780
Testing Condition ..................................................780
Inspection Procedure ............................................780
Diagnostic Procedure ...........................................781
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT .......................................................................784
Description ............................................................784
Diagnostic Procedure ...........................................784
POWER SUPPLY AND GROUND CIRCUIT ...........785
Wiring Diagram .....................................................785
Diagnostic Procedure ...........................................786
Ground Inspection ................................................791
DTC U1000, U1001 CAN COMMUNICATION LINE .792
Description ............................................................792On Board Diagnosis Logic ....................................792
DTC Confirmation Procedure ................................792
Wiring Diagram .....................................................793
Diagnostic Procedure ............................................794
DTC P0011, P0021 IVT CONTROL .........................795
Description ............................................................795
CONSULT-II Reference Value in Data Monitor Mode
.796
On Board Diagnosis Logic ....................................796
DTC Confirmation Procedure ................................797
Wiring Diagram .....................................................798
Diagnostic Procedure ............................................801
Component Inspection ..........................................805
Removal and Installation .......................................805
DTC P0031, P0032, P0051, P0052 HO2S1 HEATER .806
Description ............................................................806
CONSULT-II Reference Value in Data Monitor Mode
.806
On Board Diagnosis Logic ....................................806
DTC Confirmation Procedure ................................807
Wiring Diagram .....................................................808
Diagnostic Procedure ............................................811
Component Inspection ..........................................813
Removal and Installation .......................................813
DTC P0037, P0038, P0057, P0058 HO2S2 HEATER .814
Description ............................................................814
CONSULT-II Reference Value in Data Monitor Mode
.814
On Board Diagnosis Logic ....................................814
DTC Confirmation Procedure ................................815
Wiring Diagram .....................................................816
Diagnostic Procedure ............................................819
Component Inspection ..........................................821
Removal and Installation .......................................821
DTC P0101 MAF SENSOR .....................................822
Component Description ........................................822
CONSULT-II Reference Value in Data Monitor Mode
.822
On Board Diagnosis Logic ....................................822
DTC Confirmation Procedure ................................823
Overall Function Check .........................................824
Wiring Diagram .....................................................825
Diagnostic Procedure ............................................826
Component Inspection ..........................................829
Removal and Installation .......................................829
DTC P0102, P0103 MAF SENSOR .........................830
Component Description ........................................830
CONSULT-II Reference Value in Data Monitor Mode
.830
On Board Diagnosis Logic ....................................830
DTC Confirmation Procedure ................................831
Wiring Diagram .....................................................832
Diagnostic Procedure ............................................833
Component Inspection ..........................................836
Removal and Installation .......................................836
DTC P0112, P0113 IAT SENSOR ............................837
Component Description ........................................837
On Board Diagnosis Logic ....................................837
DTC Confirmation Procedure ................................837
Page 1353 of 4449
EC-12Revision: 2004 November 2004 FX35/FX451095
On Board Diagnosis Logic ...................................1095
DTC Confirmation Procedure ..............................1095
Wiring Diagram ....................................................1096
Diagnostic Procedure ..........................................1099
Component Inspection .........................................11 0 2
Removal and Installation .....................................11 0 2
DTC P1143, P1163 HO2S1 ....................................110 3
Component Description .......................................11 0 3
CONSULT-II Reference Value in Data Monitor Mode
11 0 3
On Board Diagnosis Logic ...................................11 0 3
DTC Confirmation Procedure ..............................11 0 4
Overall Function Check .......................................11 0 5
Diagnostic Procedure ..........................................11 0 5
Component Inspection .........................................11 0 7
Removal and Installation .....................................11 0 8
DTC P1144, P1164 HO2S1 ....................................110 9
Component Description .......................................11 0 9
CONSULT-II Reference Value in Data Monitor Mode
11 0 9
On Board Diagnosis Logic ...................................11 0 9
DTC Confirmation Procedure ..............................111 0
Overall Function Check .......................................1111
Diagnostic Procedure ..........................................1111
Component Inspection .........................................111 3
Removal and Installation .....................................111 5
DTC P1146, P1166 HO2S2 ....................................111 6
Component Description .......................................111 6
CONSULT-II Reference Value in Data Monitor Mode
111 6
On Board Diagnosis Logic ...................................111 6
DTC Confirmation Procedure ..............................111 7
Overall Function Check .......................................111 7
Wiring Diagram ....................................................111 9
Diagnostic Procedure ..........................................11 2 2
Component Inspection .........................................11 2 5
Removal and Installation .....................................11 2 6
DTC P1147, P1167 HO2S2 ....................................112 7
Component Description .......................................11 2 7
CONSULT-II Reference Value in Data Monitor Mode
11 2 7
On Board Diagnosis Logic ...................................11 2 7
DTC Confirmation Procedure ..............................11 2 8
Overall Function Check .......................................11 2 8
Wiring Diagram ....................................................11 3 0
Diagnostic Procedure ..........................................11 3 3
Component Inspection .........................................11 3 6
Removal and Installation .....................................11 3 7
DTC P1148, P1168 CLOSED LOOP CONTROL ...113 8
On Board Diagnosis Logic ...................................11 3 8
DTC Confirmation Procedure ..............................11 3 8
Overall Function Check .......................................11 3 9
Diagnostic Procedure ..........................................11 3 9
DTC P1211 TCS CONTROL UNIT .........................114 0
Description ...........................................................11 4 0
On Board Diagnosis Logic ...................................11 4 0
DTC Confirmation Procedure ..............................11 4 0
Diagnostic Procedure ..........................................11 4 0DTC P1212 TCS COMMUNICATION LINE ............11 41
Description ...........................................................11 4 1
On Board Diagnosis Logic ...................................11 4 1
DTC Confirmation Procedure ...............................11 4 1
Diagnostic Procedure ...........................................11 4 1
DTC P1217 ENGINE OVER TEMPERATURE .......11 42
Description ...........................................................11 4 2
CONSULT-II Reference Value in Data Monitor Mode
11 4 3
On Board Diagnosis Logic ...................................11 4 3
Overall Function Check ........................................11 4 3
Wiring Diagram ....................................................11 4 5
Diagnostic Procedure ...........................................11 4 7
Main 12 Causes of Overheating ..........................11 5 0
Component Inspection .........................................11 5 1
DTC P1225 TP SENSOR .......................................11 52
Component Description .......................................11 5 2
On Board Diagnosis Logic ...................................11 5 2
DTC Confirmation Procedure ...............................11 5 2
Diagnostic Procedure ...........................................11 5 3
Removal and Installation ......................................11 5 3
DTC P1226 TP SENSOR .......................................11 54
Component Description .......................................11 5 4
On Board Diagnosis Logic ...................................11 5 4
DTC Confirmation Procedure ...............................11 5 4
Diagnostic Procedure ...........................................11 5 5
Removal and Installation ......................................11 5 5
DTC P1229 SENSOR POWER SUPPLY ...............11 56
On Board Diagnosis Logic ...................................11 5 6
DTC Confirmation Procedure ...............................11 5 6
Wiring Diagram ....................................................11 5 7
Diagnostic Procedure ...........................................11 5 8
DTC P1444 EVAP CANISTER PURGE VOLUME
CONTROL SOLENOID VALVE ..............................11 60
Description ...........................................................11 6 0
CONSULT-II Reference Value in Data Monitor Mode
11 6 0
On Board Diagnosis Logic ...................................11 6 1
DTC Confirmation Procedure ...............................11 6 1
Wiring Diagram ....................................................11 6 2
Diagnostic Procedure ...........................................11 6 4
Component Inspection .........................................11 6 7
Removal and Installation ......................................11 6 7
DTC P1446 EVAP CANISTER VENT CONTROL
VALVE .....................................................................11 68
Component Description .......................................11 6 8
CONSULT-II Reference Value in Data Monitor Mode
11 6 8
On Board Diagnosis Logic ...................................11 6 8
DTC Confirmation Procedure ...............................11 6 9
Wiring Diagram ....................................................11 7 0
Diagnostic Procedure ...........................................11 7 1
Component Inspection .........................................11 7 2
DTC P1564 ICC STEERING SWITCH ...................11 74
Component Description .......................................11 7 4
CONSULT-II Reference Value in Data Monitor Mode
11 7 4
On Board Diagnosis Logic ...................................11 7 4
DTC Confirmation Procedure ...............................11 7 4
