service INFINITI FX35 2004 Service Manual

PR-1
PROPELLER SHAFT
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION PR
A
B
PR
Revision: 2004 November 2004 FX35/FX45
PROPELLER SHAFT
PREPARATION ........................................................... 2
Special Service Tools ............................................... 2
Commercial Service Tools ........................................ 2
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 3
NVH Troubleshooting Chart ..................................... 3
FRONT PROPELLER SHAFT .................................... 4
On-Vehicle Service ................................................... 4
PROPELLER SHAFT VIBRATION ........................ 4
APPEARANCE CHECKING .................................. 4
Removal and Installation .......................................... 4
REMOVAL ............................................................. 4
INSPECTION ........................................................ 5
INSTALLATION ..................................................... 5
REAR PROPELLER SHAFT ...................................... 6
Service Information .................................................. 6
On-Vehicle Service ................................................... 6
PROPELLER SHAFT VIBRATION ........................ 6APPEARANCE AND NOISE INSPECTION .......... 6
Removal and Installation .......................................... 7
REMOVAL ............................................................. 8
INSPECTION ........................................................ 8
INSTALLATION ................................................... 10
Disassembly and Assembly .................................... 11
DISASSEMBLY ................................................... 11
ASSEMBLY ......................................................... 12
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 14
General Specifications ............................................ 14
2WD MODEL ....................................................... 14
AWD MODEL ...................................................... 14
Front Propeller Shaft .............................................. 14
JOURNAL AXIAL PLAY ....................................... 14
PROPELLER SHAFT RUNOUT LIMIT ................ 14
Rear Propeller Shaft ............................................... 14
JOURNAL AXIAL PLAY ....................................... 14
PROPELLER SHAFT RUNOUT LIMIT ................ 14

PR-2
PREPARATION
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsADS000KJ
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsADS000KC
Tool number
(Kent-Moore No.)
Tool nameDescription
KV40104000
(—)
Flange wrench
a: 85 mm (3.35 in)
b: 65 mm (2.56 in)Removing and installing center flange lock nut
ST30031000
(J-22912-01)
Puller
a: 90 mm (3.54 in) dia.
b: 50 mm (1.97 in) dia.Removing rear propeller shaft center bearing
NT659
NT411
Tool nameDescription
Power toolLoosening bolts and nuts
PBIC0190E

PR-4
FRONT PROPELLER SHAFT
Revision: 2004 November 2004 FX35/FX45
FRONT PROPELLER SHAFTPFP:37200
On-Vehicle ServiceADS000KL
PROPELLER SHAFT VIBRATION
If vibration is present at high speed, inspect propeller shaft runout first.
1. Measure propeller shaft runout at several points by rotating final
drive companion flange with your hands.
2. If runout still exceeds specifications, disconnect propeller shaft
at the final drive companion flange; then rotate companion
flange 90, 180, 270 degrees and reconnect propeller shaft.
3. Check runout again. If runout still exceeds specifications,
replace propeller shaft assembly.
4. Check the vibration by driving the vehicle.
APPEARANCE CHECKING

Inspect propeller shaft tube surface for dents or cracks. If damaged, replace propeller shaft assembly.
Removal and InstallationADS000KM
REMOVAL
1. Remove the front and rear engine undercover with power tool.
2. Remove the front cross bar with power tool. Refer to FSU-6, "
FRONT SUSPENSION ASSEMBLY" .
3. Remove the exhaust front tube bracket with power tool. Refer to EX-3, "
EXHAUST SYSTEM" .
4. Disconnect the heated oxygen sensor harness connector.
5. Remove the exhaust front tube mounting nuts with power tool. Refer to EX-3, "
EXHAUST SYSTEM" .
6. Remove the right bank catalytic converter with power tool. Refer to EM-26, "
Removal and Installation"
(VQ35DE) or EM-178, "Removal and Installation" (VK45DE).
7. Remove the power steering piping mounting bolts. Refer to PS-
41, "HYDRAULIC LINE" .
8. Remove the power steering gear box fixing bolts to secure work-
ing area for removal of propeller shaft. Refer to PS-19, "
POWER
STEERING GEAR AND LINKAGE" .
CAUTION:
Be careful not to damage the steering gear box piping dur-
ing removal.Propeller shaft runout limit : 0.6 mm (0.024 in) or less
SDIA1759E
SDIA1515E
1. Propeller shaft assembly 2. O-ring
SDIA1516E

PR-6
REAR PROPELLER SHAFT
Revision: 2004 November 2004 FX35/FX45
REAR PROPELLER SHAFTPFP:37000
Service InformationADS000KK
Do not support the rear cover (aluminium), when supporting the gear carrier with a transmission jack.
On-Vehicle ServiceADS000KE
PROPELLER SHAFT VIBRATION
CAUTION:
If vibration is present at high speed, check mounting between propeller shaft and companion flange.
If vibration is present at high speed, check propeller shaft runout first.
1. Measure propeller shaft runout at several points by rotating final
drive companion flange with your hands.
2. If runout still exceeds specifications, disconnect propeller shaft
at final drive companion flange: then rotate companion flange
90, 180, 270 degrees and reconnect propeller shaft.
3. Check runout again. If runout still exceeds specifications,
replace propeller shaft assembly.
4. Perform driving test to check.
5. If the runout exceeds the service limit, do the following:

Remove the propeller shaft from the final drive companion flange.

Turn the propeller shaft 60, 120, 180, 240, 300 degrees and reinstall the propeller shaft to the compan-
ion flange, then measure the runout again.

If the runout still exceeds the service limit, replace the propeller shaft assembly.

Check the vibration by driving the vehicle.
APPEARANCE AND NOISE INSPECTION

Inspect propeller shaft tube surface for dents or cracks. If damaged, replace propeller shaft assembly.

If center bearing is noisy or damaged, replace propeller shaft assembly.Propeller shaft runout limit : 0.6 mm (0.024 in) or less
SDIA1781E

PR-14
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2004 November 2004 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsADS000O9
2WD MODEL
AW D M OD E L
Front Propeller ShaftADS000OA
JOURNAL AXIAL PLAY
PROPELLER SHAFT RUNOUT LIMIT
Rear Propeller ShaftADS000OB
JOURNAL AXIAL PLAY
PROPELLER SHAFT RUNOUT LIMIT
Applied model VQ35DE
Propeller shaft model 3S80A-1VL107
Number of joints3
Coupling method with transmission Sleeve type
Applied model VQ35DE VK45DE
Front propeller shaftPropeller shaft model 2S56A
Number of joints 2
Coupling method with front final drive Flange type
Coupling method with transfer Sleeve type
Rear propeller shaftPropeller shaft model 3F80A-1VL107
Number of joints 3
Coupling method with transfer Flange type
Model2S56A
Yoke journal bearing axial play 0 mm (0 in)
Model2S56A
Propeller shaft runout limit 0.6 mm (0.024 in) or less
Model3S80A-1VL107, 3F80A-1VL107
Yoke journal bearing thrust play 0 mm (0 in)
Model3S80A-1VL107, 3F80A-1VL107
Propeller shaft runout limit 0.6 mm (0.024 in) or less

PS-1
POWER STEERING SYSTEM
G STEERING
CONTENTS
C
D
E
F
H
I
J
K
L
M
SECTION PS
A
B
PS
Revision: 2004 November 2004 FX35/FX45
POWER STEERING SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect .......................................... 3
OPERATION PROCEDURE ................................. 3
Precautions for Steering System .............................. 3
PREPARATION ........................................................... 5
Special Service Tools (SST) ..................................... 5
Commercial Service Tools ........................................ 6
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 7
NVH Troubleshooting Chart ..................................... 7
POWER STEERING FLUID ........................................ 8
Checking Fluid Level ................................................ 8
Checking Fluid Leakage ........................................... 8
Air Bleeding Hydraulic System ................................. 8
STEERING WHEEL .................................................. 10
On-Vehicle Inspection and Service ........................ 10
CHECKING CONDITION OF INSTALLATION .... 10
CHECKING STEERING WHEEL PLAY .............. 10
CHECKING NEUTRAL POSITION ON STEER-
ING WHEEL ........................................................ 10
CHECKING STEERING WHEEL TURNING
FORCE ................................................................ 10
CHECKING FRONT WHEEL TURNING ANGLE .... 11
Removal and Installation ......................................... 11
STEERING COLUMN ............................................... 12
Removal and Installation ........................................ 12
REMOVAL ........................................................... 12
INSPECTION AFTER REMOVAL ....................... 14
INSTALLATION ................................................... 14
INSPECTION AFTER INSTALLATION ............... 14
Components (without Automatic Drive Positioner) ... 15
Disassembly and Assembly ................................... 15
DISASSEMBLY ................................................... 15
ASSEMBLY ......................................................... 16Components (with Automatic Drive Positioner) ...... 17
Disassembly and Assembly .................................... 18
DISASSEMBLY ................................................... 18
ASSEMBLY ......................................................... 18
POWER STEERING GEAR AND LINKAGE ............ 19
Removal and Installation ........................................ 19
REMOVAL ........................................................... 19
INSTALLATION ................................................... 20
INSPECTION AFTER INSTALLATION ................ 21
Disassembly and Assembly .................................... 22
DISASSEMBLY ................................................... 23
INSPECTION AFTER DISASSEMBLY ................ 25
ASSEMBLY ......................................................... 26
POWER STEERING OIL PUMP ............................... 31
On-Vehicle Inspection and Service ......................... 31
CHECKING RELIEF OIL PRESSURE (VQ35DE
MODELS) ............................................................ 31
CHECKING RELIEF OIL PRESSURE (VK45DE
MODELS) ............................................................ 31
Removal and Installation (VQ35DE models) .......... 32
REMOVAL ........................................................... 32
INSTALLATION ................................................... 33
Removal and Installation (VK45DE models) .......... 33
REMOVAL ........................................................... 33
INSTALLATION ................................................... 33
Disassembly and Assembly (VQ35DE models) ..... 33
INSPECTION BEFORE DISASSEMBLY ............. 33
DISASSEMBLY ................................................... 34
INSPECTION AFTER DISASSEMBLY ................ 34
ASSEMBLY ......................................................... 34
Disassembly and Assembly (VK45DE models) ...... 37
INSPECTION BEFORE DISASSEMBLY ............. 37
DISASSEMBLY ................................................... 37
INSPECTION AFTER DISASSEMBLY ................ 38
ASSEMBLY ......................................................... 38
HYDRAULIC LINE .................................................... 41
Components ........................................................... 41
Removal and Installation ........................................ 43
Component ............................................................. 44
Removal and Installation ........................................ 45

PS-2Revision: 2004 November 2004 FX35/FX45 SERVICE DATA AND SPECIFICATIONS (SDS) ...... 46
Steering Wheel ....................................................... 46
Steering Angle ........................................................ 46
Steering Column ..................................................... 46Steering Outer Socket and Inner Socket ................. 46
Steering Gear .......................................................... 47
Oil Pump ................................................................. 47
Steering Fluid .......................................................... 47

PRECAUTIONS
PS-3
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
AGS000GO
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions Necessary for Steering Wheel Rotation After Battery DisconnectAGS000L4
NOTE:

This Procedure is applied only to models with Intelligent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).

Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK″ position.

Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
Precautions for Steering SystemAGS000GP

Before disassembly, thoroughly clean the outside of the unit.

Disassembly should be done in a clean work area. It is important to prevent the internal parts from becom-
ing contaminated by dirt or other foreign matter.

For easier and proper assembly, place disassembled parts in order on a parts rack.

PREPARATION
PS-5
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service Tools (SST)AGS000GQ
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
ST3127 S000
(See J25765-A)
Preload gauge
1. GG9103000
(J25765-A)
Torque wrench
2. HT62940000
( — )
Socket adapter
3. HT62900000
( — )
Socket adapterInspecting of sliding torque, steering
torque, and rotating torque for ball joint
HT72520000
(J25730-A)
Ball joint remover
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)Removing steering outer socket
KV4810 5400
(J-46213)
Rear cover wrench
a: 21.6 mm (0.850 in)
b: 34.9 mm (1.374 in)Removing rear cover
KV48104400
( — )
Teflon ring correcting tool
a: 50 mm (1.97 in) dia.
b: 36 mm (1.42 in) dia.
c: 100 mm (3.94 in)Installing of rack Teflon ring
KV48103400
( — )
Torque adapterInspecting rotating torque
S-NT541
NT546
SGIA0516E
S-NT550
ZZA0824D

PS-6
PREPARATION
Revision: 2004 November 2004 FX35/FX45
Commercial Service ToolsAGS000GR
1. KV48102500-04
( — )
Washer
2. KV48102500-01
( — )
Eye joint
3. KV48102500-03
( — )
Bolt
4. KV48102500-02
( — )
Flare Joint
5. KV48103500
(J26357&J26357-10)
Pressure gauge & shut off valveMeasuring oil pump relief pressure
(VQ35DE models)
1. KV48105300-4 and 5295262U10
( — )
Connector A and O-ring
2. KV48105300-3 and 5295262U00
( — )
Eye-bolt and O-ring
3. KV48103500
(J26357 and J26357-10)
Pressure gauge and shut-off valve
4. KV48105300-1 and 5295262U00
( — )
Connector B and O-ring
5. KV48105300-2
( — )
NutMeasuring oil pump relief pressure
(VK45DE models) Tool number
(Kent-Moore No.)
Tool nameDescription
SGIA0442E
SGIA0427E
Tool name Description
Power tool

Removing wheel nuts

Removing undercover

Removing steering gear
PBIC0190E
