INFINITI FX35 2004 Service Manual

SRS-60
COLLISION DIAGNOSIS
Revision: 2004 November 2004 FX35/FX45

TF-1
TRANSFER
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION TF
A
B
TF
Revision: 2004 November 2004 FX35/FX45
TRANSFER
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions .............................................................. 3
Service Notice .......................................................... 4
Wiring Diagrams and Trouble Diagnosis .................. 4
PREPARATION ........................................................... 5
Special Service Tools ............................................... 5
Commercial Service Tools ........................................ 6
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 7
NVH Troubleshooting Chart ..................................... 7
TRANSFER FLUID ..................................................... 8
Replacement ............................................................ 8
DRAINING ............................................................. 8
FILLING ................................................................. 8
Inspection ................................................................. 8
FLUID LEAKAGE AND FLUID LEVEL .................. 8
AWD SYSTEM ............................................................ 9
Power Transfer Diagram .......................................... 9
System Description .................................................. 9
DESCRIPTION ...................................................... 9
ELECTRIC CONTROLLED COUPLING ............. 10
AWD CONTROL UNIT ........................................ 10
AWD WARNING LAMP ........................................ 11
System Diagram ...................................................... 11
COMPONENTS FUNCTION DESCRIPTION ..... 12
CAN Communication .............................................. 12
SYSTEM DESCRIPTION .................................... 12
TROUBLE DIAGNOSIS ............................................ 13
Fail-Safe Function .................................................. 13
How to Perform Trouble Diagnosis ........................ 13
BASIC CONCEPT ............................................... 13
Location of Electrical Parts ..................................... 14
Circuit Diagram ...................................................... 15
Wiring Diagram — AWD — .................................... 16
Trouble Diagnosis Chart for Symptoms ................. 19
AWD Control Unit Input/Output Signal Reference
Values .................................................................... 19AWD CONTROL UNIT INSPECTION TABLE ..... 19
CONSULT-II Function (ALL MODE AWD/4WD) ..... 21
FUNCTION .......................................................... 21
CONSULT-II SETTING PROCEDURE ................ 21
SELF-DIAG RESULT MODE ............................... 21
DATA MONITOR MODE ...................................... 23
ACTIVE TEST MODE ......................................... 24
AWD CONTROL UNIT PART NUMBER ............. 24
TROUBLE DIAGNOSIS FOR SYSTEM .................... 25
Power Supply Circuit For AWD Control Unit ........... 25
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 25
DIAGNOSTIC PROCEDURE .............................. 25
AWD Control Unit ................................................... 26
DIAGNOSTIC PROCEDURE .............................. 26
ABS System ........................................................... 26
DIAGNOSTIC PROCEDURE .............................. 26
AWD Solenoid ........................................................ 27
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 27
DIAGNOSTIC PROCEDURE .............................. 27
COMPONENT INSPECTION .............................. 29
AWD Actuator Relay ............................................... 30
CONSULT-II REFERENCE VALUE IN DATA
MONITOR MODE ................................................ 30
DIAGNOSTIC PROCEDURE .............................. 30
Engine Control Signal ............................................. 31
DIAGNOSTIC PROCEDURE .............................. 31
CAN Communication Line ...................................... 31
DIAGNOSTIC PROCEDURE .............................. 31
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 32
AWD Warning Lamp Does Not Turn ON When The
Ignition Switch Is Turned To ON ............................. 32
DIAGNOSTIC PROCEDURE .............................. 32
AWD Warning Lamp Does Not Turn OFF Several
Seconds After Engine Started ................................ 32
DIAGNOSTIC PROCEDURE .............................. 32
Heavy Tight-corner Braking Symptom Occurs
When The Vehicle Is Driven And The Steering
Wheel Is Turned Fully To Either Side After The

TF-2Revision: 2004 November 2004 FX35/FX45Engine Is Started .................................................... 34
DIAGNOSTIC PROCEDURE .............................. 34
Vehicle Does Not Enter AWD Mode Even Though
AWD Warning Lamp Turned To OFF ...................... 35
DIAGNOSTIC PROCEDURE .............................. 35
While Driving, AWD Warning Lamp Flashes Rapidly
(When Flashing In Approx. 1 Minute And Then Turn-
ing OFF) ................................................................. 36
While Driving, AWD Warning Lamp Flashes Slowly
(When Continuing To Flash Until Turning Ignition
Switch OFF) ............................................................ 36
DIAGNOSTIC PROCEDURE .............................. 36
AWD CONTROL UNIT .............................................. 38
Removal and Installation ........................................ 38
REMOVAL ........................................................... 38
INSTALLATION .................................................... 38
FRONT OIL SEAL ..................................................... 39
Removal and Installation ........................................ 39
REMOVAL ........................................................... 39
INSTALLATION .................................................... 39REAR OIL SEAL ....................................................... 40
Removal and Installation ......................................... 40
REMOVAL ............................................................ 40
INSTALLATION .................................................... 41
AIR BREATHER HOSE ............................................. 42
Removal and Installation ......................................... 42
TRANSFER ASSEMBLY ........................................... 43
Removal and Installation ......................................... 43
REMOVAL ............................................................ 43
INSTALLATION .................................................... 43
Components ............................................................ 44
Disassembly and Assembly .................................... 45
DISASSEMBLY .................................................... 45
INSPECTION ....................................................... 49
ASSEMBLY .......................................................... 49
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 55
General Specifications ............................................ 55

PRECAUTIONS
TF-3
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
ADS000RH
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
PrecautionsADS000RI

Before connecting or disconnecting the AWD control unit
harness connector, turn ignition switch “OFF” and discon-
nect negative battery cable. Because battery voltage is
applied to AWD control unit even if ignition switch is turned
“OFF”.

When connecting or disconnecting pin connectors into or
from AWD control unit, take care not to damage pin termi-
nals (bend or break).
When connecting pin connectors, make sure that there are
no bends or breaks on AWD control unit pin terminal.

Before replacing AWD control unit, perform AWD control
unit input/output signal inspection and make sure whether
AWD control unit functions properly or not. Refer to TF-19,
"AWD Control Unit Input/Output Signal Reference Values" .
SEF289H
SEF291H
SDIA1848E

TF-4
PRECAUTIONS
Revision: 2004 November 2004 FX35/FX45
Service NoticeADS000RJ

After overhaul refill the transfer with new transfer fluid.

Check the fluid level or replace the fluid only with the vehicle parked on level ground.

During removal or installation, keep inside of transfer clear of dust or dirt.

Replace all tires at the same time. Always use tires of the proper size and the same brand and pattern.
Fitting improper size and unusual wear tires applies excessive force to vehicle mechanism and can cause
longitudinal vibration.

Disassembly should be done in a clean work area.

Before proceeding with disassembly, thoroughly clean the transfer. It is important to prevent the internal
parts from becoming contaminated by dirt or other foreign matter.

Check for the correct installation status prior to removal or disassembly. If matching marks are required,
be certain they do not interfere with the function of the parts when applied.

All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or
reassembly.

Check appearance of the disassembled parts for damage, deformation, and unusual wear. Replace them
with a new ones if necessary.

Gaskets, seals and O-rings should be replaced any time when the transfer is disassembled.

In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
tightening sequence is specified, use it.

Observe the specified torque when assembling.

Clean and flush the parts sufficiently and blow-dry them.

Be careful not to damage sliding surfaces and mating surfaces.

Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere
with the operation of the transfer.
Wiring Diagrams and Trouble DiagnosisADS000RK
When you read wiring diagrams, refer to the following:

GI-15, "How to Read Wiring Diagrams".

PG-3, "POWER SUPPLY ROUTING CIRCUIT".
When you perform trouble diagnosis, refer to the following:

GI-11, "How to Follow Trouble Diagnoses".

GI-27, "How to Perform Efficient Diagnosis for an Electrical Incident".

PREPARATION
TF-5
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
PREPARATIONPFP:00002
Special Service ToolsADS000RL
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
ST27862000
(—)
Drift
a: 62.5 mm (2.461 in) dia.
b: 42 mm (1.654 in) dia.

Installing front oil seal into front case
KV38108300
(J44195)
Flange wrench

Removing and installing companion flange
lock nut
KV381054S0
(J34286)
Puller

Removing rear oil seal
ST30720000
(J25405)
Drift
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.

Installing rear oil seal
KV40104830
(—)
Drift
a: 76.3 mm (3.004 in) dia.
b: 67.9 mm (2.673 in) dia.

Installing rear oil seal
ST33061000
(J8107-2)
Drift
a: 38 mm (1.50 in) dia.
b: 28.5 mm (1.122 in) dia.

Removing front drive shaft front bearing
ST35322000
(—)
Drift
a: 39 mm (1.54 in) dia.
b: 31 mm (1.22 in) dia.

Removing front drive shaft rear bearing
ZZA0194D
NT771
ZZA0601D
ZZA0811D
ZZA1003D
ZZA0810D
ZZA1000D

TF-6
PREPARATION
Revision: 2004 November 2004 FX35/FX45
Commercial Service ToolsADS000SA
ST30022000
(—)
Drift
a: 110 mm (4.33 in) dia.
b: 56 mm (2.20 in) dia.
c: 46 mm (1.81 in) dia.
Installing front drive shaft front bearing

Installing main shaft into rear case
ST30914000
(—)
Drift
a: 98 mm (3.86 in) dia.
b: 51 mm (2.01 in) dia.
c: 40 mm (1.57 in) dia.

Installing front drive shaft rear bearing
ST30613000
(—)
Drift
a: 72 mm (2.83 in) dia.
b: 48 mm (1.89 in) dia.

Installing main shaft oil seal into front case Tool number
(Kent-Moore No.)
Tool nameDescription
ZZA0978D
ZZA0978D
ZZA1000D
Tool nameDescription
Power tool

Loosening nuts and bolts
PBIC0190E

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
TF-7
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartADS000RM
Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.
Reference pageTF-8TF-44TF-44TF-49TF-49
SUSPECTED PARTS
(Possible cause)
TRANSFER FLUID (Level low)
TRANSFER FLUID (Wrong)
TRANSFER FLUID (Level too high)
LIQUID GASKET (Damaged)
OIL SEAL (Worn or damaged)
GEAR (Worn or damaged)
BEARING (Worn or damaged)
SymptomNoise 1 2 3 3
Transfer fluid leakage 3122

TF-8
TRANSFER FLUID
Revision: 2004 November 2004 FX35/FX45
TRANSFER FLUIDPFP:31001
ReplacementADS000RN
DRAINING
1. Run the vehicle to warm up the transfer unit sufficiently.
2. Stop the engine, and remove the drain plug to drain the transfer
fluid.
3. Apply sealant to drain plug. Install drain plug on transfer and
tighten to the specified torque. Refer to TF-44, "
Components" .

Use Genuine Silicone RTV or equivalent. Refer to GI-48,
"Recommended Chemical Products and Sealants" .
FILLING
1. Remove filler plug and add transfer fluid until fluid level reaches
the specified limit near filler plug mounting hole.
CAUTION:
Carefully fill the fluid. (Fill up for approx. 3 minutes.)
2. Leave the vehicle for 3 minutes, and check the fluid level again.
3. Set a new seal washer onto filler plug and install it on transfer
and tighten to the specified torque. Refer to TF-44, "
Compo-
nents" .
CAUTION:
Do not reuse seal washer.
InspectionADS000RO
FLUID LEAKAGE AND FLUID LEVEL
1. Check fluid level from filler plug mounting hole as shown in the
figure.
2. Before installing filler plug, set a new seal washer. Install filler
plug on transfer and tighten to the specified torque. Refer to TF-
44, "Components" .
CAUTION:
Do not reuse seal washer.
SDIA2087E
Fluid capacity
: Approx. 1.25 (2-5/8 US pt, 2-1/4 lmp pt)
SDIA2028E
SDIA2028E

AWD SYSTEM
TF-9
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: 2004 November 2004 FX35/FX45
AWD SYSTEMPFP:41650
Power Transfer DiagramADS000RV
System DescriptionADS000RW
DESCRIPTION

Electronic control allows optimal distribution of torque to front/rear wheels to match road conditions.

Makes possible stable driving, with no wheel spin, on snowy roads or other slippery surfaces.

On roads which do not require AWD, it contributes to improved fuel economy by driving in conditions close
to rear-wheel drive.

Sensor inputs determine the vehicle's turning condition, and in response tight cornering/braking are con-
trolled by distributing optimum torque to front wheels.
NOTE:

When driving, if there is a large difference between front and rear wheel speed which continues for a long
time, fluid temperature of drive system parts becomes too high and AWD warning lamp flashes rapidly.
(When AWD warning lamp flashes, vehicle changes to rear-wheel drive conditions.) Also, optional distri-
bution of torque sometimes becomes rigid before lamp flashes rapidly, but it is not malfunction.

If AWD warning lamp is flashing rapidly, stop vehicle and allow it to idle for some time. Flashing will stop
and AWD system will be restored.

When driving, AWD warning lamp may flash slowly if there is a significant difference in diameter of the
tires. At this time, vehicle performance is not fully available and cautious driving is required. (Continues
until engine is turned OFF.)

If the warning lamp flashes slowly during driving but remains OFF after engine is restarted, the system is
normal. If it again flashes slowly after driving for some time, vehicle must be inspected.

When the difference of revolution speed between the front and rear wheel with AUTO mode the shift occa-
sionally changes to direct 4-wheel driving conditions automatically. This is not malfunction.
SDIA1611E
