INCH TO METRIC CONVERSION TABLE
(Rounded-off for automotive use)
inchesmminchesmm
.1002.54.61015.49
.1102.79.62015.75
.1203.05.63016.00
.1303.30.64016.26
.1403.56.65016.51
.1503.81.66016.76
.1604.06.67017.02
.1704.32.68017.27
.1804.57.69017.53
.1904.83.70017.78
.2005.08.71018.03
.2105.33.72018.29
.2205.59.73018.54
.2305.84.74018.80
.2406.10.75019.05
.2506.35.76019.30
.2606.60.77019.56
.2706.86.78019.81
.2807.11.79020.07
.2907.37.80020.32
.3007.62.81020.57
.3107.87.82020.83
.3208.13.83021.08
.3308.38.84021.34
.3408.64.85021.59
.3508.89.86021.84
.3609.14.87022.10
.3709.40.88022.35
.3809.65.89022.61
.3909.91.90022.86
.40010.16.91023.11
.41010.41.92023.37
.42010.67.93023.62
.43010.92.94023.88
.44011.18.95024.13
.45011.43.96024.38
.46011.68.97024.64
.47011.94.98024.89
.48012.19.99025.15
.49012.451.00025.40
.50012.702.00050.80
.51012.953.00076.20
.52013.214.000101.60
.53013.465.000127.00
.54013.726.000152.40
.55013.977.000177.80
.56014.228.000203.20
.57014.489.000228.60
.58014.7310.000254.00
.59014.9920.000508.00
.60015.24
METRIC TO INCH CONVERSION TABLE
(Rounded-off for automotive use)
mminchesmminches
1.0394512.008
2.079522.047
3.118532.087
4.157542.126
5.197552.165
6.236562.205
7.276572.244
8.315582.283
9.354592.323
10.394602.362
11.433612.402
12.472622.441
13.512632.480
14.551642.520
15.591652.559
16.630662.598
17.669672.638
18.709682.677
19.748692.717
20.787702.756
21.827712.795
22.866722.835
23.906732.874
24.945742.913
25.984752.953
261.024762.992
271.063773.031
281.102783.071
291.142793.110
301.181803.150
311.220813.189
321.260823.228
331.299833.268
341.339843.307
351.378853.346
361.417863.386
371.457873.425
381.496883.465
391.535893.504
401.575903.543
411.614913.583
421.654923.622
431.693933.661
441.732943.701
451.772953.740
461.811963.780
471.850973.819
481.890983.858
491.929993.898
501.9691003.937

QUICK REFERENCE CHART FX35/FX45
QUICK REFERENCE CHART FX35/FX45PFP:00000
ENGINE TUNE-UP DATA (VQ35DE)ELS0003W
Engine modelVQ35DE
Firing order1-2-3-4-5-6
Idle speed
A/T (In “P” or “N” position)rpm
650±50
Ignition timing (BTDC at idle speed)
A/T (In “P” or “N” position)15°± 5°
CO% at idle 0.7 - 9.9 % and engine runs smoothly
Drive BeltDeflection adjustment Unit: mm (in) Tension adjustment Unit: N (kg, lb)
Used belt
New beltUsed belt
New belt
Limit After adjustment Limit After adjustment
Alternator and power
steering oil pump7 (0.28)4 - 5
(0.16 - 0.20)3.5 - 4.5
(0.138 - 0.177)294 (30, 66)730 - 818
(74.5 - 83.5,
164 - 184)838 - 926
(85.5 - 94.5,
188 - 208)
Air conditioner com-
pressor belt12 (0.47)9 - 10
(0.35 - 0.39)8 - 9
(0.31 - 0.35)196 (20, 44)348 - 436
(35.5 - 44.5,
78 - 98)470 - 559
( 4 8 - 5 7 ,
106 - 126)
Applied pushing force 98N (10kg, 22lb) —
Radiater cap relief pressure
kPa (kg/cm
2 , psi)
Standard 78 - 98 (0.8 - 1.0, 11 - 14)
Limit 59 (0.6, 9)
Cooling system leakage testing pres-
surekPa (kg/cm
2 , psi)157(1.6, 23)
Compression pressure
kPa (kg/cm
2 , psi)/rpm
Standard 1,275 (13.0, 185) /300
Minimum 981 (10.0, 142)/300
Spark plug Standard type PLFR5A - 11
Hot type PLFR4A - 11
Cold type PLFR6A - 11
2004

QUICK REFERENCE CHART FX35/FX45
ENGINE TUNE-UP DATA (VK45DE)
FRONT WHEEL ALIGNMENT (Unladen* )
ELS0003X
* : Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.Engine modelVK45DE
Firing order1-8-7-3-6-5-4-2
Idle speed
A/T (In “P” or “N” position) rpm650±50
Ignition timing
(BTDC at idle speed)12°±5°
CO% at idle 0.7 - 9.9 % and engine runs smoothly
Tensions of drive belts Auto adjustment by auto tensioner
Radiater cap relief pressure
kPa (kg/cm
2 , psi)
Standard 78 - 98 (0.8 - 1.0 , 11 - 14 )
Limit 59 (0.6, 9)
Cooling system leakage testing pressure
157(1.6, 23)
kPa (kg/cm
2 , psi)
Compression pressure
kPa (kg/cm
2 , psi)/rpm
Standard 1,320 (13.5, 191) /300
Minimum 1,130 (11.5, 164)/300
Spark plug Standard type PLFR5A - 11
Hot type PLFR4A - 11
Cold type PLFR6A - 11
Camber Degree minute (Decimal degree) Minimum – 1° 29′ ( – 1.48° )
Nominal – 0° 44′ ( – 0.73° )
Maximum 0° 01′ ( 0.02° )
Left and right difference 45′ ( 0.75° ) or less
Caster Degree minute (Decimal degree) Minimum 3° 02′ ( 3.03° )
Nominal 3° 47′ ( 3.78° )
Maximum 4° 32′ ( 4.53° )
Left and right difference 45′ ( 0.75° ) or less
Kingpin inclination Degree minute (Decimal degree) Minimum 12° 20′ ( 12.33° )
Nominal 13° 05′ ( 13.08° )
Maximum 13 50′ ( 13.83° )
Total toe-in Distance (A – B) Minimum 0.6 mm ( 0.024 in )
Nominal 1.6 mm ( 0.063 in )
Maximum 2.6 mm ( 0.102 in )
Angle (left plus right)
Degree minute (Degree)Minimum –
Nominal 6′ ( 0.1° )
Maximum –
Wheel turning angle (Full turn) Inside MInimum 32° 00′ ( 32.0° )
Degree minute (Decimal degree) Nominal 35° 00′ ( 35.0° )
Maximum 36° 00′ ( 36.0° )
Outside
Nominal 30° 00′ ( 30.0° )
Degree minute (Decimal degree)
2004

QUICK REFERENCE CHART FX35/FX45
REAR WHEEL ALIGNMENT (Unladen*)
ELS0003Y
* : Fuel, engine coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
BRAKEELS0003Z
* : Under force of 490 N( 50 kg, 110 lb ) with engine running.
REFILL CAPACITIESELS00040
Camber
Degree minute (Decimal degree)Minimum – 1° 18′ ( – 1.30° )
Nominal – 0° 48′ ( – 0.80° )
Maximum – 0° 18′ ( – 0.30° )
To t a l t o e - i nDistance ( A – B ) Minimum 2.4 mm ( 0.094 in )
Nominal 4.7 mm ( 0.185 in )
Maximum 7.0 mm ( 0.276 in )
Angle (left plus right )
Degree minute (Degree)Minimum 0° 05′ ( 0.08° )
Nominal 0° 10′ ( 0.17° )
Maximum 0° 15′ ( 0.25° )
Front brake Pad wear limit 2.0 mm ( 0.079 in )
Rotor repair limit 26.0 mm ( 1.024 in )
Rear brake Pad wear limit 2.0 mm ( 0.079 in )
Rotor repair limit 14.0 mm ( 0.551 in )
Pedal free height 161.5 - 171.5 mm ( 6.358 - 6.752 in )
Pedal depressed height* More than 80 mm ( 3.15 in )
UNITLiter US measure
Fuel tank90 23 - 3/4 gal
Coolant ( With reservoir tank )VQ35DE 8.6 9 - 1/8 qt
VK45DE 10.0 10 - 5/8 qt
Engine(VQ35DE)Drain and refill
With oil filter change 4.7 5 qt
Without oil filter change 4.4 4 - 5/8 qt
Dry engine (Overhaul) 5.4 5 - 3/4 qt
Engine(VK45DE)Drain and refill
With oil filter change 6.6 7qt
Without oil filter change 6.0 6 - 3/8 qt
Dry engine (Overhaul) 7.7 8 - 1/8 qt
Transmission A/T 10.3 10 - 7/8 qt
Transfer1.25 2 - 5/8 pt
Differential carrierFront 0.65 1 - 3/8 pt
Rear 1.4 3 pt
Power steering system 1.0 1 - 1/8 qt
Air conditioning systemCompressor oil 0.18 6.0 fl oz
Refrigerant 0.55 kg 1.21 lb
2004
