2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Keyless Remote Response -Horn
1. Select “Keyless Remote Response-Horn”.
2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Keyless Remote Response -Lights
1. Select “Keyless Remote Response-Light”.
2. Push “Enter” switch.
Auto Re-Lock Time
1. Select “Auto Re-Lock Time”.
2. Move the joystick and push “Enter” switch to adjust the time.
Sensitivity of Automatic Headlights
1. Select “Sensitivity of Automatic Headlights”.
2. Move the joystick to left (lower) or right (higher) and push “Enter” switch.
Automatic Headlights Off Delay
1. Select “Automatic Headlights Off Delay”.
2. Move the joystick left or right to adjust the timer and push “Enter” switch.
Speed Dependent Wiper
1. Select “Speed Dependent Wiper”.
2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Intelligent Key Lock Response-Sound
1. Select “Intelligent Key Lock Response-Sound”.
2. Push “Enter” switch to change the sound pattern.
Intelligent Key Unlock Response-Beep Sound
1. Select “Intelligent Key Unlock Response-Sound”.
2. Push “Enter” switch to change the sound pattern.
Intelligent Key Lock/Unlock Function
1. Select “Intelligent Key Lock/Unlock”.
2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Return All Settings to Default
1. Select “Return All Settings to Default”.
2. Push “Enter” switch.

The indicator light alternately turns on and off each time the “Enter” switch is pressed.

AV-96
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
System Settings
How To Perform System Settings
1. Start the engine.
2. Push “SETTING” button.
3. Select “System Settings”.
Application Items
Language Setting
Select “Language/Unit”.

Language setting can be switched.

Unit setting can be changed.
Beep Setting
Select “Beep Setting”.

When Beep Setting is on (indicator light on), a beep will sound if
the button is pushed.
NOTE:
Items in exception of Beep Setting ON/OFF.

An error beep

An interrupted-screen beep
SKIA5988E
Icon Description Reference
page
Language/Unit Settings of Language or unit can be performed. AV- 9 6
Beep Setting Settings of Beep sound can be performed.AV- 9 6
SKIA2065E
SKIA5989E

NAVIGATION SYSTEM AV-97
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
Navigation Settings
How To Perform Navigation Settings
1. Start the engine.
2. Push “SETTING” button.
3. Select “Navigation”.
Application Items
“VIEW” MODE

To open the map screen display with Birdview™, select “Bird-
view™”.

To open the map screen display with Plan View, select “Plan
View”.
SKIA0551E
Icon Description Reference
page
View Map display mode can be switched. AV- 9 7
Heading Heading of the map display can be customized for either north heading or the actual
driving direction of the vehicle. AV- 9 8
Nearby Display Icons
Icons of facilities can be displayed.
Facilities to be displayed can be selected from the variety selections. AV- 9 8
Save Current Location Current vehicle location can be registered in Address Book.
AV- 9 8
Adjust Current Location Current location of position marker can be adjusted. Direction of position marker
also can be calibrated when heading direction of the vehicle on the display is not
matched with the actual direction. AV- 9 8
Auto Re-route On/Off ON/OFF of Auto Re-route can be switched.
AV- 9 9
Avoid Area Setting A particular area can be avoided when routing.AV- 9 9
Clear Memory Address Book, Previous destination or Avoid area can be deleted.AV- 9 9
Edit Address Book Address Book can be edited.AV- 1 0 0
GPS Information The GPS data includes longitude, latitude and altitude (distance above sea level) of
the present vehicle position, and current date and time for the area in which the
vehicle is being driven.
Also indicated are the GPS reception conditions and the GPS satellite position. AV- 1 0 0
Quick Stop Customer Setting One facility of your selection can be added to your quick stop.
AV- 1 0 0
Set Average Speed for Estimated
Journey Time Average vehicle speed can be set to calibrate estimated journey time for the desti-
nation. AV- 1 0 0
Tracking On/Off Tracking to the present vehicle position can be displayed.
AV- 1 0 1
SKIA0554E

AV-98
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
“HEADING” MODE

To display north heading, select “North up”.

To display the actual driving direction of the vehicle, select
“Heading up”.
“NEARBY DISPLAY ICONS” MODE

Select an icon to display on the map screen.
“SAVE CURRENT LOCATION” MODE

The current vehicle location can be registered in “Address
Book”.
NOTE:
“Address Book” can store 50 items max.
“ADJUST CURRENT LOCATION” MODE
1. Select an icon “right” or “left” to calibrate the heading direction.
(Arrow marks will rotate corresponding to the calibration key.)
SKIA0561E
SKIA0562E
SKIA0556E
SKIA0563E

NAVIGATION SYSTEM AV-99
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
2. Select “Set”. Then the vehicle mark will be matched to the arrow
mark.
“AUTO RE-ROUTE” MODE

To activate “AUTO RE-ROUTE” mode, select “On”.

To inactivate “AUTO RE-ROUTE” mode, select “Off”.
“AVOID AREA SETTING” MODE

Areas to avoid can be registered.
“CLEAR MEMORY” MODE

To delete all the stored places in “Address Book”, “Avoid Area”
and “Previous Destinations”, select “Yes”.
SKIA0564E
SKIA0558E
SKIA0563E
SKIA3572E

AV-100
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
“EDIT ADDRESS BOOK” MODE

Edit the items registered in Address Book.
“GPS INFORMATION” MODE

Latitude, longitude, altitude, receiving state (telemetry), and sat-
ellite location are displayed as GPS information.
NOTE:
Altitude is displayed only in three–dimensional status.
“QUICK STOP CUSTOMER SETTING” MODE

Select a category for the “Quick Stop” menu.
“SET AVERAGE SPEED” MODE

Set the average vehicle speed to calibrate the estimated journey
time for the destination.

Set three items; “Freeway”, “Main Roads”, and “Ordinary
Roads”.
SKIA3511E
SKIA0555E
SKIA5996E
SKIA0565E

NAVIGATION SYSTEM AV-101
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
“TRACKING” MODE

To delete the tracking marks on the map, select “Off”.

To leave the tracking marks on the map, select “On”.
NOTE:
When a trail display is turned OFF, trail data is erased from the mem-
ory.
GUIDANCE VOLUME
Description
Following guidance volume setting can be changed.
Activation/Deactivation Setting

The voice prompt can be turned on/off by pressing the “Guidance Volume” button.
Voice Volume Setting

Volume of the voice can be controlled by bending the joystick to left/right.
DISPLAY WITH PUSHED “TRIP” BUTTON

When the “TRIP” button is pushed, the following models will display on the screen.

Warning message (if there are any) →TRIP1 →TRIP2 →FUEL ECONOMY →MAINTENANCE →OFF.
SKIA0559E
SKIA4497E
Display items Display/Setting contents Reference
page
Trip 1 o r Trip2 Elapsed Time Displays driving time with a range of 0000:00:00 to 9999:59:59.
AV-102,
"TRIP 1 OR
TRIP 2"
Driving Distance
[(km) or (miles)] Displays driving distance with a range of 00000.0 to 99999.9.
Average speed
[(km/h) or (MPH)] Displays average speed with a range of 000.0 to 999.9.
Fuel Economy Average Fuel Economy
[(MPG) or (l/100km)] Displays fuel economy with ignition switch ON, average fuel econ-
omy each 30 minutes. AV-102,
"FUEL
ECONOMY"
Distance to Empty [(km) or
(miles)], [(MPG) or (l/100km)] Displays possible driving distance with remaining fuel.
Fuel Economy (MPG) Displays fuel economy each approx. 100 ms.
Maintenance Engine oil Maintenance intervals of engine oil and setting of oil change cycle.
AV-102,
"MAINTE-
NANCE"
Tire rotation Maintenance intervals of tire and setting of tire replacement cycle.
Tire pressure Tire pressure displayed as tire pressure information.

AV-102
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
TRIP 1 OR TRIP 2

Elapsed Time, Driving Distance and Average Speed are dis-
played as Trip 1 information or Trip 2 information.

The way to reset is by pushing the “Reset” switch or by keeping
pushing “TRIP” button more than 1.5 seconds.
FUEL ECONOMY

Average Fuel Economy, Distance to Empty, Fuel Economy are
displayed as Fuel Economy information.

The way to reset is by pushing the “Reset” switch or by keeping
pushing “TRIP” button more than 1.5 seconds.
MAINTENANCE

Engine Oil, Tire Rotation and Tire Pressure are displayed as
Maintenance information.
ENGINE OIL OR TIRE ROTATION

Possible to set up interval of engine oil and tire rotation by mov-
ing joystick right and left.
SKIA5990E
SKIA5991E
SKIA5992E
SKIA5993E

NAVIGATION SYSTEM AV-103
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
TIRE PRESSURE

Pressure indication in psi on the screen indicates that the
pressure is being measured. After a few driving trips, the pres-
sures for all four tires will be displayed.

The order of tire pressure figures displayed on the screen does
not correspond with the actual order of the tire position.

Tire pressure rises and falls depending on the heat caused by
the vehicle's traveling condition and the temperature.

FLAT TIRE–very low tire air pressure.
NOTE:

In a case of FLAT TIRE pressure, interrupt screen is not shown
on the display.

On the screen of TIRE PRESSURE, “FLAT TIRE”, “Check”, “All tire” is displayed.
WARNING INDICATIONS
Warning signal (door switch signal) is received from BCM through
CAN communication line.
SKIA5994E
SKIA5995E
Warning
indicators Warning lamps in
instrument panel Warning detection and cancel conditions
Cases of
malfunction
DOOR OPEN Door Detection condition
Vehicle is running [approx. 5km/h (3 MPH) or faster]
and door ajar of any of the doors is detected. Door is open.
Cancel condition Vehicle is stopped and all the doors lock.

AV-104
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
CAN Communication System DescriptionAKS007Z3
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitAKS007Z0
Refer to LAN-30, "CAN Communication Unit" .
Component Parts Location and Harness Connector LocationAKS007IR
