ACTUATOR AND ELECTRIC UNIT (ASSEMBLY) BRC-59
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2006 December 2006 FX35/FX45
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
Be careful of the following when installing ABS actuator and electric unit (control unit).

Tighten the mounting bolts and nuts to the specified torque.

After the work, bleed air from brake piping. Refer to BR-10, "Bleeding Brake System" .

After installing vehicle harness connector in the actuator, make sure connector is securely locked.

When replacing ABS actuator and electric unit (control unit), calibrate steering angle sensor neu-
tral position and decel G sensor. Refer to BRC-6, "
ON-VEHICLE SERVICE" .

BRC-60
[VDC/TCS/ABS]
G SENSOR
Revision: 2006 December 2006 FX35/FX45
G SENSORPFP:47930
Removal and InstallationNFS000O7
REMOVAL
1. Remove center console. Refer to IP-12, "(H) Center Console" .
2. Disconnect G sensor harness connector.
3. Remove G sensor mounting bolts. Then remove G sensor from vehicle.
CAUTION:

Do not drop or strike G sensor, because it has little endur-
ance to impact.

Do not use power tool etc., because G sensor is weak for
the impact.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:

Do not drop or strike G sensor, because it has little endurance to impact.

After performing above works, calibrate decel G sensor (AWD models). Refer to BRC-7, "Calibra-
tion of Decel G Sensor (AWD Models)" .
PFIA0602E

STEERING ANGLE SENSOR BRC-61
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2006 December 2006 FX35/FX45
STEERING ANGLE SENSORPFP:25554
Removal and InstallationNFS000O8
REMOVAL
1. Remove spiral cable assembly. Refer to SRS-40, "SPIRAL CABLE" .
2. Remove steering angle sensor from spiral cable assembly.
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
After work, make sure to adjust neutral position of steering angle sensor. Refer to BRC-6, "
Adjustment
of Steering Angle Sensor Neutral Position" .
SFIA1404E

BRC-62
[VDC/TCS/ABS]
STEERING ANGLE SENSOR
Revision: 2006 December 2006 FX35/FX45
