INFINITI FX35 2006 Service Manual

TROUBLE DIAGNOSIS AT-87
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
64 Others Extremely large
creep. ON vehicle 1. Engine idle speed EC-82
(for
VQ35DE)
or EC-742

(for
VK45DE)
2. CAN communication line AT-104
3. ATF pressure switch 5AT-175
OFF vehicle 4. Torque converter AT-294
65 With selector lever in
“P” position, vehicle
does not enter parking
condition or, with
selector lever in
another position, park-
ing condition is not
cancelled.
Refer to AT-191, "
In
“P” Position, Vehicle
Moves When Pushed"
. ON vehicle
1. PNP switch
AT- 11 2
2. Control linkage adjustmentAT-231
OFF vehicle 3. Parking pawl components AT-
251(2WD
models) or AT-294

(AWD
models)
66 Vehicle runs with A/T
in “P” position. ON vehicle
1. PNP switch
AT- 11 2
2. A/T fluid level and state AT- 5 3
3. Control linkage adjustmentAT-231
4. Control valve with TCMAT-239
OFF vehicle 5. Parking pawl components AT-
251(2WD
models) or
AT-294

(AWD
models)
6. Gear system AT-274
67 Vehicle runs with A/T
in “N” position.
Refer to AT-192, "In
“N” Position, Vehicle
Moves" . ON vehicle
1. PNP switch
AT- 11 2
2. A/T fluid level and state AT- 5 3
3. Control linkage adjustmentAT-231
4. Control valve with TCMAT-239
OFF vehicle 5. Input clutch
AT-317
6. Gear systemAT-274
7. Direct clutchAT-332
8. Reverse brakeAT-294
9. Forward one-way clutch (Parts behind drum support is
impossible to perform inspection by disassembly. Refer to
AT- 1 8 , "
Cross-sectional View (2WD Models)" , AT-19,
"Cross-sectional View (VQ35DE Models for AWD)" or AT-
20, "Cross-sectional View (VK45DE Models for AWD)" ) AT-294
10. Low coast brake (Parts behind drum support is impossi-
ble to perform inspection by disassembly. Refer to AT-18,
"Cross-sectional View (2WD Models)" , AT- 1 9 , "Cross-sec-
tional View (VQ35DE Models for AWD)" or AT-20, "Cross-
sectional View (VK45DE Models for AWD)" ) AT-294
No. Items Symptom Condition Diagnostic Item
Reference
page

AT-88
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
68 Others Engine does not start
in “N” or “P” position.
Refer to AT-190, "Engine Cannot Be
Started in “P” or “N”
Position" . ON vehicle
1. Ignition switch and starter
PG-3
,
SC-
8
2. Control linkage adjustment AT- 2 3 1
3. PNP switch AT- 11 2
69 Engine starts in posi-
tions other than “N” or
“P”. ON vehicle 1. Ignition switch and starter
PG-3
,
SC-
8
2. Control linkage adjustment AT- 2 3 1
3. PNP switch AT- 11 2
70 Engine stall. ON vehicle 1. A/T fluid level and state
AT- 5 3
2. Engine speed signalAT- 1 2 3
3. Turbine revolution sensor AT- 11 6
4. Torque converter clutch solenoid valveAT- 1 2 5
5. CAN communication lineAT- 1 0 4
6. Control valve with TCMAT- 2 3 9
OFF vehicle 7. Torque converter AT- 2 9 4
71 Engine stalls when
selector lever shifted
“N” → “D”, “R”. ON vehicle 1. A/T fluid level and state
AT- 5 3
2. Engine speed signalAT- 1 2 3
3. Turbine revolution sensor AT- 11 6
4. Torque converter clutch solenoid valveAT- 1 2 5
5. CAN communication lineAT- 1 0 4
6. Control valve with TCMAT- 2 3 9
OFF vehicle 7. Torque converter AT- 2 9 4
72 Engine speed does
not return to idle.
Refer to AT-217,
"Engine Speed Does
Not Return to Idle" . ON vehicle 1. A/T fluid level and state
AT- 5 3
2. ATF pressure switch 5 and direct clutch solenoid valve AT- 1 7 5,
AT- 1 5 4

3. ATF pressure switch 1 and front brake solenoid valve AT- 1 7 1
,
AT- 1 5 0
4. Accelerator pedal position sensor AT- 1 3 1
5. Vehicle speed sensor A/T and vehicle speed sensor MTR AT- 11 8,
AT- 1 3 9
6. CAN communication line AT- 1 0 4
7. Control valve with TCMAT- 2 3 9
OFF vehicle 8. Front brake (brake band)
AT- 2 9 49. Direct clutchAT- 3 3 2
No. Items Symptom Condition Diagnostic Item Reference
page

TROUBLE DIAGNOSIS AT-89
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
TCM Input/Output Signal Reference ValuesNCS001BQ
A/T ASSEMBLY HARNESS CONNECTOR TERMINAL LAYOUT
TCM INSPECTION TABLE
Data are reference value and are measured between each terminal and ground.
SCIA1658E
Terminal Wire
color Item Condition Data (Approx.)
1LG Power supply
(Memory back-up) Always Battery voltage
2LG Power supply
(Memory back-up) Always Battery voltage
3 L CAN-H – –
4PU K-line (CONSULT-
II signal) The terminal is connected to the data link connector for CONSULT-II. –
5 B Ground – –
6 Y Power supply – Battery voltage
–0 V
7OR Back-up lamp
relay Selector lever in “R” position. 0 V
Selector lever in other positions. Battery voltage
8 P CAN-L – –
9GYStarter relay Selector lever in “N” and “P” positions. Battery voltage
Selector lever in other positions. 0 V
10 B Ground – –

AT-90
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
CONSULT-II Function (A/T)NCS001BR
CONSULT-II can display each diagnostic item using the diagnostic test models shown following.
FUNCTION
CONSULT-II REFERENCE VALUE
NOTICE:
1. The CONSULT-II electrically displays shift timing and lock-up timing (that is, operation timing of each sole-
noid).
Check for time difference between actual shift timing and the CONSULT-II display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-II and that indicated in Service Man- ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-II indicates the point where shifts are completed.
3. Display of solenoid valves on CONSULT-II changes at the start of shifting, while gear position is displayed upon completion of shifting (which is computed by TCM).
Diagnostic test mode Function Reference page
Self-diagnostic results Self-diagnostic results can be read and erased quickly. AT- 9 2
Data monitor Input/Output data in the ECU can be read.AT- 9 5
CAN diagnostic support
monitor The results of transmit/receive diagnosis of CAN communication can be read.
AT- 9 9
Function test Performed by CONSULT-II instead of a technician to determine whether each system
is “OK” or “NG”. —
DTC work support Select the operating condition to confirm Diagnosis Trouble Codes. AT- 9 9
ECU part number TCM part number can be read. —
Item name Condition Display value
(Approx.)
VHCL/S SE-A/T During driving Approximately
matches the speed-
ometer reading.
VHCL/S SE-MTR
ACCELE POSI Released accelerator pedal. 0.0/8
Fully depressed accelerator pedal. 8.0/8
CLSD THL POS Released accelerator pedal. ON
Fully depressed accelerator pedal. OFF
W/O THL POS Fully depressed accelerator pedal. ON
Released accelerator pedal. OFF
BRAKE SW Depressed brake pedal. ON
Released brake pedal. OFF
ENGINE SPEED Engine running Closely matches the
tachometer reading.
TURBINE REV During driving (lock-up ON) Approximately
matches the engine
speed.
ATF TEMP SE 1 0 °C (32 ° F) - 20 °C (68 °F) - 80 °C (176 °F) 3.3 - 2.7 - 0.9 V
ATF TEMP SE 2 3.3 - 2.5 - 0.7 V
TCC SOLENOID Slip lock-up is active 0.2 - 0.4 A
Lock-up is active 0.4 - 0.6 A
LINE PRES SOL During driving 0.2 - 0.6 A

TROUBLE DIAGNOSIS AT-91
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
FR/B SOLENOID Front brake engaged. Refer to
AT- 2 2 . 0.6 - 0.8 A
Front brake disengaged. Refer to AT- 2 2
. 0 - 0.05 A
I/C SOLENOID Input clutch disengaged. Refer to
AT- 2 2
. 0.6 - 0.8 A
Input clutch engaged. Refer to AT- 2 2
. 0 - 0.05 A
D/C SOLENOID Direct clutch disengaged. Refer to
AT- 2 2
. 0.6 - 0.8 A
Direct clutch engaged. Refer to AT- 2 2
. 0 - 0.05 A
HLR/C SOL High and low reverse clutch disengaged. Refer to
AT- 2 2
. 0.6 - 0.8 A
High and low reverse clutch engaged. Refer to AT- 2 2
. 0 - 0.05 A
STARTER RELAY Selector lever in “N” and “P” positions. ON
Selector lever in other positions. OFF
SLCT LVR POSI Selector lever in “N” and “P” positions. N/P
Selector lever in “R” position. R
Selector lever in “D” position. D
ON OFF SOL Low coast brake engaged. Refer to
AT- 2 2
.ON
Low coast brake disengaged. Refer to AT- 2 2
.OFF
ATF PRES SW 1 Front brake engaged. Refer to
AT- 2 2
.ON
Front brake disengaged. Refer to AT- 2 2
.OFF
ATF PRES SW 2 Low coast brake engaged. Refer to
AT- 2 2
.ON
Low coast brake disengaged. Refer to AT- 2 2
.OFF
ATF PRES SW 3 Input clutch engaged. Refer to
AT- 2 2
.ON
Input clutch disengaged. Refer to AT- 2 2
.OFF
ATF PRES SW 5 Direct clutch engaged. Refer to
AT- 2 2
.ON
Direct clutch disengaged. Refer to AT- 2 2
.OFF
ATF PRES SW 6 High and low reverse clutch engaged. Refer to
AT- 2 2
.ON
High and low reverse clutch disengaged Refer to AT- 2 2
.OFF
MANU MODE SW Manual shift gate position (neutral) ON
Other than the above OFF
NON M-MODE SW Manual shift gate position OFF
Other than the above ON
UP SW LEVER Selector lever: + side ON
Other than the above OFF
DOWN SW LEVER Selector lever: - side ON
Other than the above OFF
GEAR During driving 1, 2, 3, 4, 5 Item name Condition
Display value
(Approx.)

AT-92
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
CONSULT-II SETTING PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
SELF-DIAGNOSTIC RESULT MODE
After performing AT- 9 2 , "SELF-DIAGNOSTIC RESULT MODE" , place check marks for results on the AT- 4 8 ,
"DIAGNOSTIC WORKSHEET" . Reference pages are provided following the items.
Operation Procedure
Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
Display shows malfunction experienced since the last erasing opera-
tion.
Display Items List
X: Applicable, —: Not applicable
BCIA0031E
Items (CONSULT-II
screen terms) Malfunction is detected when... TCM self-
diagnosis OBD-II
(DTC)
Reference page
“A/T” with
CONSULT-
II MIL indica-
tor lamp(*1) ,
“ENGINE”
with CON-
SULT-II or GST
CAN COMM CIR-
CUIT

When a malfunction is detected in CAN communications U1000 U1000 AT-104
STARTER RELAY/
CIRC

If this signal is ON other than in “P” or “N” position, this is judged
to be a malfunction.
(And if it is OFF in “P” or “N” position, this too is judged to be a
malfunction.) P0615 —
AT-107
TCM
TCM is malfunctioning P0700 P0700 AT- 111
PNP SW/CIRC

PNP switch 1-4 signals input with impossible pattern

“P” position is detected from “N” position without any other posi-
tion being detected in between. P0705 P0705
AT- 11 2
TURBINE REV S/
CIRC
TCM does not receive the proper voltage signal from the sensor.

TCM detects an irregularity only at position of 4th gear for turbine
revolution sensor 2. P0717 P0717
AT- 11 6
VEH SPD SEN/CIR
AT

Signal from vehicle speed sensor A/T (Revolution sensor) not
input due to cut line or the like

Unexpected signal input during running

After ignition switch is turned ON, unexpected signal input from
vehicle speed sensor MTR before the vehicle starts moving P0720 P0720
AT- 11 8
ENGINE SPEED
SIG
TCM does not receive the CAN communication signal from the
ECM. P0725 —
AT-123
TCC SOLENOID/
CIRC
Normal voltage not applied to solenoid due to cut line, short, or
the like P0740 P0740
AT-125
A/T TCC S/V
FNCTN
A/T cannot perform lock-up even if electrical circuit is good.

TCM detects as irregular by comparing difference value with slip
rotation. P0744
P0744(*2)AT-127

TROUBLE DIAGNOSIS AT-93
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
L/PRESS SOL/
CIRC

Normal voltage not applied to solenoid due to cut line, short, or
the like

TCM detects as irregular by comparing target value with monitor
value. P0745 P0745
AT- 1 2 9
TP SEN/CIRC A/T
TCM does not receive the proper accelerator pedal position sig-
nals (input by CAN communication) from ECM. P1705 —
AT- 1 3 1
ATF TEMP SEN/
CIRC
During running, the AT fluid temperature sensor signal voltage is
excessively high or low P1710 P0710
AT- 1 3 4
VEH SPD SE/
CIR·MTR
Signal (CAN communication) from vehicle speed sensor MTR not
input due to cut line or the like

Unexpected signal input during running P1721 —
AT- 1 3 9
A/T INTERLOCK
Except during shift change, the gear position and ATF pressure
switch states are monitored and comparative judgement made. P1730 P1730
AT- 1 4 1
A/T 1ST E/BRAK-
ING
Each ATF pressure switch and solenoid current is monitored and
if a pattern is detected having engine braking 1st gear other than
in the M1 position, a malfunction is detected. P1731 —
AT- 1 4 4
I/C SOLENOID/
CIRC

Normal voltage not applied to solenoid due to functional malfunc-
tion, cut line, short, or the like

TCM detects as irregular by comparing target value with monitor
value. P1752 P1752
AT- 1 4 6
I/C SOLENOID
FNCTN

TCM detects that actual gear ratio is irregular, and relation
between gear position and condition of ATF pressure switch 3 is
irregular during depressing accelerator pedal. (Other than during
shift change)

TCM detects that relation between gear position and condition of
ATF pressure switch 3 is irregular during releasing accelerator
pedal. (Other than during shift change) P1754
P1754
(*2)AT- 1 4 8
FR/B SOLENOID/
CIRC

Normal voltage not applied to solenoid due to functional malfunc-
tion, cut line, short, or the like

TCM detects as irregular by comparing target value with monitor
value. P1757 P1757
AT- 1 5 0
FR/B SOLENOID
FNCT

TCM detects that actual gear ratio is irregular, and relation
between gear position and condition of ATF pressure switch 1 is
irregular during depressing accelerator pedal. (Other than during
shift change)

TCM detects that relation between gear position and condition of
ATF pressure switch 1 is irregular during releasing accelerator
pedal. (Other than during shift change) P1759
P1759
(*2)AT- 1 5 2
D/C SOLENOID/
CIRC

Normal voltage not applied to solenoid due to cut line, short, or
the like

TCM detects as irregular by comparing target value with monitor
value. P1762 P1762
AT- 1 5 4
Items (CONSULT-II
screen terms) Malfunction is detected when... TCM self-
diagnosis OBD-II
(DTC)
Reference page
“A/T” with
CONSULT-
II MIL indica-
tor lamp(*1) ,
“ENGINE”
with CON-
SULT-II or GST

AT-94
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
*1: Refer to EC-68, "Malfunction Indicator Lamp (MIL)" (for VQ35DE engine) or EC-729, "Malfunction Indicator Lamp (MIL)" (for
VK45DE engine. D/C SOLENOID
FNCTN

TCM detects that actual gear ratio is irregular, and relation
between gear position and condition of ATF pressure switch 5 is
irregular during depressing accelerator pedal. (Other than during
shift change)

TCM detects that relation between gear position and condition of
ATF pressure switch 5 is irregular during releasing accelerator
pedal. (Other than during shift change) P1764
P1764
(*2)AT-156
HLR/C SOL/CIRC

Normal voltage not applied to solenoid due to functional malfunc-
tion, cut line, short, or the like

TCM detects as irregular by comparing target value with monitor
value. P1767 P1767
AT-158
HLR/C SOL
FNCTN

TCM detects that actual gear ratio is irregular, and relation
between gear position and condition of ATF pressure switch 6 is
irregular during depressing accelerator pedal. (Other than during
shift change)

TCM detects that relation between gear position and condition of
ATF pressure switch 6 is irregular during releasing accelerator
pedal. (Other than during shift change) P1769
P1769
(*2)AT-160
LC/B SOLENOID/
CIRC
Normal voltage not applied to solenoid due to functional malfunc-
tion, cut line, short, or the like P1772 P1772
AT-162
LC/B SOLENOID
FNCT

TCM detects an improper voltage drop when it tries to operate
the solenoid valve.

Condition of ATF pressure switch 2 is different from monitor
value, and relation between gear position and actual gear ratio is
irregular. P1774
P1774(*2)AT-164
MANU MODE SW/
CIRC
When an impossible pattern of switch signals is detected, a mal-
function is detected. P1815 —
AT-166
ATF PRES SW 1/
CIRC

TCM detects that actual gear ratio is normal, and relation
between gear position and condition of ATF pressure switch 1 is
irregular during depressing accelerator pedal. (Other than during
shift change) P1841 —
AT-171
ATF PRES SW 3/
CIRC

TCM detects that actual gear ratio is normal, and relation
between gear position and condition of ATF pressure switch 3 is
irregular during depressing accelerator pedal. (Other than during
shift change) P1843 —
AT-173
ATF PRES SW 5/
CIRC

TCM detects that actual gear ratio is normal, and relation
between gear position and condition of ATF pressure switch 5 is
irregular during depressing accelerator pedal. (Other than during
shift change) P1845 —
AT-175
ATF PRES SW 6/
CIRC

TCM detects that actual gear ratio is normal, and relation
between gear position and condition of ATF pressure switch 6 is
irregular during depressing accelerator pedal. (Other than during
shift change) P1846 —
AT-177
NO DTC IS
DETECTED FUR-
THER TESTING
MAY BE
REQUIRED

No NG item has been detected. X X —
Items (CONSULT-II
screen terms) Malfunction is detected when... TCM self-
diagnosis OBD-II
(DTC)
Reference page
“A/T” with
CONSULT-
II MIL indica-
tor lamp
(*1) ,
“ENGINE”
with CON-
SULT-II or GST

TROUBLE DIAGNOSIS AT-95
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL.
How to Erase Self-Diagnostic Results
1. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
2. Touch ”ERASE”. (The self-diagnostic results will be erased.)
DATA MONITOR MODE
Operation Procedure
Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
NOTE:
When malfunctions detected, CONSULT-II performs “REAL-
TIME DIAGNOSIS”. Also, any malfunction detected while in this
mode will be displayed at real time.
Display Items List
X: Standard, —: Not applicable, : Option
BCIA0031E
PCIA0061E
BCIA0031E
Monitored item (Unit) Select Monitor Item
Remarks
ECU
INPUT
SIGNALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
VHCL/S SE-A/T (km/h) X X Revolution sensor
VHCL/S SE-MTR (km/h) X —
ACCELE POSI (0.0/8) X — Accelerator pedal position signal
THROTTLE POSI (0.0/8) X X Degree of opening for accelerator recognized by
the TCM
For fail-safe operation, the specific value used
for control is displayed.
CLSD THL POS (ON/OFF) X — Signal input with CAN communications
W/O THL POS (ON/OFF) X —

AT-96
TROUBLE DIAGNOSIS
Revision: 2006 December 2006 FX35/FX45
BRAKE SW (ON/OFF) X — Stop lamp switch
GEAR — X Gear position recognized by the TCM updated
after gear-shifting
ENGINE SPEED (rpm) X X
TURBINE REV (rpm) X X
OUTPUT REV (rpm) X X
GEAR RATIO — X
TC SLIP SPEED (rpm) — X Difference between engine speed and torque
converter input shaft speed
F SUN GR REV (rpm) — —
F CARR GR REV (rpm) — —
ATF TEMP SE 1 (V) X —
ATF TEMP SE 2 (V) X —
ATF TEMP 1 ( °C) — X
ATF TEMP 2 ( °C) — X
BATTERY VOLT (V) X —
ATF PRES SW 1 (ON/OFF) X X (for FR/B solenoid)
ATF PRES SW 2 (ON/OFF) X X (for LC/B solenoid)
ATF PRES SW 3 (ON/OFF) X X (for I/C solenoid)
ATF PRES SW 5 (ON/OFF) X X (for D/C solenoid)
ATF PRES SW 6 (ON/OFF) X X (for HLR/C solenoid)
PNP SW 1 (ON/OFF) X —
PNP SW 2 (ON/OFF) X —
PNP SW 3 (ON/OFF) X —
PNP SW 4 (ON/OFF) X —
1 POSITION SW (ON/OFF) X —
SLCT LVR POSI — X Selector lever position is recognized by the
TCM.
For fail-safe operation, the specific value used
for control is displayed.
OD CONT SW (ON/OFF) X —
Not mounted but displayed.
POWERSHIFT SW (ON/OFF) X —
HOLD SW (ON/OFF) X —
MANU MODE SW (ON/OFF) X —
NON M-MODE SW (ON/OFF) X —
UP SW LEVER (ON/OFF) X —
DOWN SW LEVER (ON/OFF) X — Monitored item (Unit)
Select Monitor Item
Remarks
ECU
INPUT
SIGNALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
