diagram INFINITI FX35 2006 Service Manual

GI-40
CONSULT-II CHECKING SYSTEM
Revision: 2006 December 2006 FX35/FX45
CIRCUIT DIAGRAM
TAWM0074E

GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
I BODY
CONTENTS
C
D E
F
G H
J
K L
M
SECTION GW
A
B
GW
Revision: 2006 December 2006 FX35/FX45
GLASSES, WINDOW SYSTEM & MIRRORS
PRECAUTIONS ..................................................... ..... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 3
Precautions for Procedures without Cowl Top Cover ..... 3
Handling for Adhesive and Primer ...................... ..... 3
PREPARATION ...................................................... ..... 4
Special Service Tools .......................................... ..... 4
Commercial Service Tools ................................... ..... 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ........................................................... ..... 5
CUSTOMER INTERVIEW ................................ ..... 5
DUPLICATE THE NOISE AND TEST DRIVE .. ..... 6
CHECK RELATED SERVICE BULLETINS ...... ..... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ................................................. ..... 6
REPAIR THE CAUSE ...................................... ..... 6
CONFIRM THE REPAIR .................................. ..... 7
Generic Squeak and Rattle Troubleshooting ...... ..... 7
INSTRUMENT PANEL ..................................... ..... 7
CENTER CONSOLE ........................................ ..... 7
DOORS ............................................................ ..... 7
TRUNK ............................................................. ..... 8
SUNROOF/HEADLINING ................................ ..... 8
SEATS .............................................................. ..... 8
UNDERHOOD .................................................. ..... 8
Diagnostic Worksheet ......................................... ..... 9
WINDSHIELD GLASS ........................................... ....11
Removal and Installation ..................................... .... 11
REMOVAL ........................................................ .... 11
INSTALLATION ................................................ ... 12
BACK DOOR WINDOW GLASS ........................... ... 13
Removal and Installation ..................................... ... 13
REMOVAL ........................................................ ... 13
INSTALLATION ................................................ ... 14
POWER WINDOW SYSTEM ................................. ... 15
Component Parts and Harness Connector Location ... 15
System Description ............................................. ... 16
MANUAL OPERATION .................................... ... 16
AUTO OPERATION ......................................... ... 18 POWER WINDOW SERIAL LINK ....................
... 19
POWER WINDOW LOCK ................................ ... 19
RETAINED POWER OPERATION ................... ... 19
ANTI-PINCH SYSTEM ..................................... ... 19
POWER WINDOW CONTROL BY THE KEY
CYLINDER SWITCH ........................................ ... 19
CAN Communication System Description ........... ... 20
CAN Communication Unit .................................... ... 20
Schematic ............................................................ ... 21
Wiring Diagram — WINDOW — .......................... ... 22
Terminal and Reference Value for BCM .............. ... 26
Terminal and Reference Value for Power Window
Main Switch ......................................................... ... 27
Terminal and Reference Value for Front Power Win-
dow Switch (Passenger Side) .............................. ... 28
CONSULT-II Function (BCM) .............................. ... 29
CONSULT-II OPERATION ................................ ... 29
ACTIVE TEST .................................................. ... 29
WORK SUPPORT ............................................ ... 29
DATE MONITOR .............................................. ... 29
Work Flow ............................................................ ... 30
Trouble Diagnosis Symptom Chart ...................... ... 30
Check BCM Power Supply and Ground Circuit ... ... 32
Check Power Window Main Switch Power Supply
Circuit .................................................................. ... 33
Check Front Power Window Switch (Passenger
Side) Power Supply and Ground Circuit .............. ... 34
Check Front Power Window Motor (Driver Side) Cir-
cuit ....................................................................... ... 35
Check Front Power Window Motor (Passenger
Side) Circuit ......................................................... ... 36
Check rear Power Window Motor (LH) Circuit ..... ... 36
Check Rear Power Window Motor (RH) Circuit ... ... 39
Check Limit Switch Circuit (Driver Side) .............. ... 41
Check Limit Switch Circuit (Passenger Side) ...... ... 43
Check Encoder Circuit (Driver Side) .................... ... 44
Check Encoder Circuit (Passenger Side) ............ ... 46
Check Door Switch .............................................. ... 49
Check Front Door Key Cylinder Switch ............... ... 51

GW-2Revision: 2006 December 2006 FX35/FX45 Check Power Window Serial Link (Passenger Side)
... 53
Check Power Window Lock Switch ..................... ... 55
SIDE WINDOW GLASS ......................................... ... 56
Removal and Installation ..................................... ... 56
REMOVAL ........................................................ ... 56
INSTALLATION ................................................. ... 57
FRONT DOOR GLASS AND REGULATOR .......... ... 58
Removal and Installation ..................................... ... 58
DOOR GLASS .................................................. ... 58
REGULATOR ASSEMBLY ............................... ... 59
Disassembly and assembly ................................. ... 60
REGULATOR ASSEMBLY ............................... ... 60
Inspection after Installation .................................. ... 60
SETTING OF LIMIT SWITCH ........................... ... 60
FITTING INSPECTION ..................................... ... 60
REAR DOOR GLASS AND REGULATOR ............ ... 62
Removal and Installation ..................................... ... 62
DOOR GLASS .................................................. ... 62
REGULATOR ASSEMBLY ............................... ... 63
Disassembly and assembly ................................. ... 64
REGULATOR ASSEMBLY ............................... ... 64
Fitting Inspection ................................................. ... 64
INSIDE MIRROR .................................................... ... 65
Wiring Diagram — I/MIRR — ............................... ... 65
Removal and Installation ..................................... ... 66
REMOVAL ........................................................ ... 66
INSTALLATION ................................................. ... 66
COMPASS ........................................................ ... 66
REAR WINDOW DEFOGGER ............................... ... 67
Component Parts and Harness Connector Location ... 67
System Description .............................................. ... 67
CAN Communication System Description ........... ... 68
CAN Communication Unit .................................... ... 68 Schematic ............................................................
... 69
Wiring Diagram — DEF — ................................... ... 70
Terminal and Reference Value for BCM ............... ... 74
Terminal and Reference Value for IPDM E/R ....... ... 74
CONSULT-II Function (BCM) ............................... ... 75
CONSULT-II OPERATION ................................ ... 75
DATA MONITOR ............................................... ... 75
ACTIVE TEST ................................................... ... 75
Work Flow ............................................................ ... 76
Trouble Diagnoses Symptom Chart ..................... ... 76
Check BCM Power Supply and Ground Circuit ... ... 77
Check Rear Window Defogger Switch Circuit ...... ... 78
Check rear Window Defogger Power Supply Circuit ... 79
Check Rear Window Defogger Circuit ................. ... 81
Check Door Mirror Defogger Power Supply Circuit ... 82
Check Driver Side Door Mirror Defogger Circuit .. ... 84
Check Passenger Side Door Mirror Defogger Circuit ... 85
Check Rear Window Defogger Signal ................. ... 85
Check Filament .................................................... ... 87
Filament Repair .................................................... ... 87
REPAIR EQUIPMENT ...................................... ... 87
REPAIRING PROCEDURE .............................. ... 88
DOOR MIRROR ...................................................... ... 89
Wiring Diagram — MIRROR — ........................... ... 89
Trouble Diagnosis ................................................ ... 91
Removal and Installation ...................................... ... 92
REMOVAL ......................................................... ... 92
INSTALLATION ................................................. ... 92
Disassembly and Assembly ................................. ... 92
DISASSEMBLY ................................................. ... 92
ASSEMBLY ....................................................... ... 93

GW-22
POWER WINDOW SYSTEM
Revision: 2006 December 2006 FX35/FX45
Wiring Diagram — WINDOW —NIS001QU
TIWM1681E

INSIDE MIRROR GW-65
C
D E
F
G H
J
K L
M A
B
GW
Revision: 2006 December 2006 FX35/FX45
INSIDE MIRRORPFP:96321
Wiring Diagram — I/MIRR —NIS001RY
TIWM1683E

GW-70
REAR WINDOW DEFOGGER
Revision: 2006 December 2006 FX35/FX45
Wiring Diagram — DEF — NIS001S5
TIWM1685E

DOOR MIRROR GW-89
C
D E
F
G H
J
K L
M A
B
GW
Revision: 2006 December 2006 FX35/FX45
DOOR MIRRORPFP:96301
Wiring Diagram — MIRROR —NIS001SM
TIWM1689E

IDX-2
ALPHABETICAL INDEX
A
A/C air flow ...................................................... ATC-37
A/C component layout ..................................... ATC-26
A/C compressor clutch removal and installation ...........
ATC-142
A/C compressor mounting ........... ATC-140, ATC-142,
ATC-146
, ATC-147, ATC-148, ATC-149, ATC-150,
ATC-152
, ATC-153, ATC-154, ATC-155
A/C compressor precaution ............................. ATC-13
A/C compressor special service tool ................ ATC-17
A/C control operation (auto A/C) ...................... ATC-34
A/C diagnostic work flow (auto A/C) .............. ATC-101
A/C evaporator ............................................... ATC-154
A/C HFC134a (R134a) system precaution ........ ATC-6
A/C HFC134a (R134a) system service procedure .......
ATC-137
A/C HFC134a (R134a) system service tools ... ATC-18
A/C HFC134a system service equipment precaution ...
ATC-13
A/C lubricant (R134a) ...................................... ATC-27
A/C lubrication oil ........................................... ATC-160
A/C operational check ...................................... ATC-60
A/C self-diagnoses (auto A/C) ........ ATC-52, ATC-101
A/C service data specification ........................ ATC-160
A/C system description (auto A/C) ................... ATC-30
A/C trouble diagnoses (auto A/C) .................... ATC-40
A/C, A - Wiring diagram ................................... ATC-45
A/T fluid checking ...................... AT-13, AT-53, MA-29
A/T fluid cooler cleaning .................................... AT-15
A/T fluid replacement ............................. AT-12, MA-31
A/T fluid temperature sensor ........................... AT-134
A/T IND - Wiring diagram .................................... DI-53
A/T self-diagnoses ........................................... AT-102
A/T shift lock system ........................................ AT-232
A/T shift lock system - Wiring diagram ............ AT-233
A/T trouble diagnoses ........................................ AT-44
Accelerator pedal position (APP) sensor ........ EC-575,
EC-582
, EC-596, EC-1254, EC-1261, EC-1275
Accelerator pedal released position learning .... EC-84,
EC-743
AF1B1-Wiring diagram ...... EC-233, EC-242, EC-251,
EC-261
, EC-606, EC-903, EC-912, EC-921, EC-931,
EC-1285
AF1B2-Wiring diagram ...... EC-235, EC-244, EC-253,
EC-263
, EC-608, EC-905, EC-914, EC-923, EC-933,
EC-1287
AF1HB1-Wiring diagram .................... EC-167, EC-837
AF1HB2-Wiring diagram .................... EC-169, EC-839
Air bag .............................................................. SRS-3
Air bag precautions ........................................... SRS-3
Air cleaner and air duct(VK45DE) ................... EM-177
Air cleaner and air duct(VQ35DE) .................... EM-17
Air cleaner filter replacement ............................ MA-25
Air cleaner filter replacement(VQ35DE) ........... MA-18
Air cleaner filter(VQ35DE) ................................ EM-18
Air conditioner cut control .................... EC-35, EC-695
Air flow meter - See Mass air flow sensor ...... EC-188,
EC-197
, EC-858, EC-867
Air fuel ratio sensor 1 ......... EC-230, EC-240, EC-249,
EC-258
, EC-604, EC-900, EC-910, EC-919, EC-928,
EC-1283
Air fuel ratio sensor 1 heater ............. EC-165, EC-836
Air mix. door motor ......................... ATC-71, ATC-131
Ambient sensor ............................. ATC-103, ATC-116
Angular tightening application ............................. EM-6
Angular tightening application(VK45DE) ........ EM-165
APPS1 - Wiring diagram ................. EC-577, EC-1256
APPS2 - Wiring diagram ................. EC-584, EC-1263
APPS3 - Wiring diagram ................. EC-598, EC-1277
ASC/BS - Wiring diagram ............... EC-540, EC-1213
ASC/SW - Wiring diagram .............. EC-523, EC-1196
ASCBOF - Wiring diagram .............. EC-617, EC-1296
ASCD .................................................. EC-36, EC-696
ASCD (automatic speed control device) ........... ACS-3
ASCD brake switch .......................................... EC-538
ASCD indicator lamp ....................................... EC-623
ASCD steering switch ...................................... EC-521
ASCIND - Wiring diagram ............... EC-624, EC-1303
AT indicator lamp ................................................ DI-52
Auto air conditioner - Wiring diagram ............. ATC-45
Auto amp ...................................................... ATC-115
Auto anti-dazzling inside mirror ....................... GW-65
Automatic amplifier ........... ATC-50, ATC-62, ATC-115
Automatic transmission fluid replacement ........ MA-32
AV communication line ........................ AV-64, AV-108
AWD - Wiring diagram ....................................... TF-17
Axle ................................................................... MA-37
Axle housing (rear) ........................................... RAX-7
B
Back Door ........................................................ BL-158
Back door ......................................................... BL-158
Back door opener - See Back door .................. BL-162
Basic inspection .................................. EC-77, EC-737
Battery ................................................................. SC-4
Battery/Starting/Charging System Tester SC-7, SC-11,
SC-23
BCM (Body control module) .............................. BCS-3
Block heater(VK45DE) .................................... EM-248
Block heater(VQ35DE) ................................... EM-123
Blower motor ................................... ATC-77, ATC-122
Blower unit .................................................... ATC-120
Brake booster .................................................... BR-15
Brake fluid level ................................................ MA-35
Brake hydraulic line ........................................... BR-11
Brake inspection ............................................... MA-36
Brake lines and cables inspection .................... MA-35
Brake master cylinder ........................................ BR-13
Brake switch ................................... EC-551, EC-1229
BRK/SW - Wiring diagram .............. EC-552, EC-1230
Bulb specifications ........................................... LT-204
Bumper, front ...................................................... EI-14
Bumper, rear ....................................................... EI-17

IDX-3
A
C
D E
F
G H
I
J
K L
B
IDX
ALPHABETICAL INDEX
C
Camshaft inspection(VK45DE) ........................ EM-216
Camshaft inspection(VQ35DE) ......................... EM-85
Camshaft position sensor (PHASE) EC-368, EC-1037
Camshaft(VK45DE) ......................................... EM-215
Camshaft(VQ35DE) ........................................... EM-83
CAN .................................................................. DI-108
CAN - Wiring diagram ......... EC-157, EC-820, AT-105,
LAN-29
, LAN-49, LAN-69, LAN-91, LAN-117, LAN-139,
LAN-163
CAN (Controller Area Network) . BL-24, BL-57, BL-95,
BL-184
, GW-20, GW-68, RF-12, SE-16
CAN communication EC-38, EC-156, EC-159, EC-819,
EC-822
, AT-33, AT-104, TF-13, TF-32, WT-12, BL-24,
BL-57
, BL-95, BL-184, GW-20, GW-68, RF-12, SE-16
Canister-See EVAP canister ............... EC-42, EC-702
Center bearing assembly (propeller shaft) ........ PR-13
Center bearing disassembly (propeller shaft) .... PR-12
CHARGE - Wiring diagram ................................ SC-21
Charging system ................................................ SC-20
Chassis and body maintenance ........................ MA-29
CHIME - Wiring diagram ..................................... DI-61
Circuit breaker ................................................... PG-16
Clock ................................................................. DI-114
CLOCK - Wiring diagram .................................. DI-114
Closed loop control .............................. EC-32, EC-692
Closed loop control (Bank 1) ........... EC-494, EC-1168
Closed loop control (Bank 2) ........... EC-494, EC-1168
Collision diagnosis ........................................... SRS-50
Combination lamp, rear, removal and installation ........
LT-154
Combination meter ............................................... DI-5
Combination meter removal and installation - See
Instrument panel .................................................. IP-11
COMM - Wiring diagram ...................... AV-64, AV-108
COMPAS - Wiring diagram ............................... DI-112
Compass .......................................................... DI-109
Component Location (auto A/C) ...................... ATC-42
Compression pressure(VK45DE) .................... EM-232
Compression pressure(VQ35DE) .................... EM-101
Compressor clutch removal and installation .. ATC-142
Compressor special service tool ...................... ATC-17
Condenser ..................................................... ATC-153
Connecting rod bearing clearance(VK45DE) .. EM-272
Connecting rod bushing clearance .................. EM-143
Connecting rod bushing clearance(VK45DE) .. EM-267
Connecting rod(VK45DE) ................................ EM-267
Connecting rod(VQ35DE) ................................ EM-141
Console box - See Instrument panel ................... IP-10
CONSULT for VDC ......................................... BRC-24
CONSULT-II for engine ................................... EC-119
CONSULT-II Reference value (A/T) .................. AT-90
Control units (terminal arrangement) ................. PG-75
Control valve (A/T) ............................................. AT-38
Controller Area Network (CAN) . BL-24, BL-57, BL-95,
BL-184
, GW-20, GW-68, RF-12, SE-16
Converter housing installation ............ AT-268, AT-272
COOL/F - Wiring diagram ................ EC-501, EC-1175
Coolant replacement(VQ35DE) ........................ MA-15
Cooling circuit (engine)(VK45DE) ..................... CO-36
Cooling circuit (engine)(VQ35DE) ...................... CO-9
Cooling fan motor ............................ EC-508, EC-1182
Cooling fan(VK45DE) ....................................... CO-49
Cooling fan(VQ35DE) ....................................... CO-21
Cowl top .............................................................. EI-23
Cowl top cover .................................................... EI-23
Crankcase ventilation system - See Positive crankcase
ventilation ............................................. EC-51
, EC-711
Crankshaft position sensor (POS) ... EC-361, EC-1030
Crankshaft(VK45DE) ...................................... EM-249
Crankshaft(VQ35DE) ...................................... EM-141
Crash zone sensor .......................................... SRS-46
Cylinder block boring(VK45DE) ...................... EM-270
Cylinder block(VK45DE) ................................. EM-248
Cylinder block(VQ35DE) ................................. EM-123
Cylinder head bolt tightening(VK45DE) .......... EM-234
Cylinder head bolt tightening(VQ35DE) .......... EM-104
Cylinder head(VK45DE) ................................. EM-232
Cylinder head(VQ35DE) ................................. EM-101
D
D/LOCK - Wiring diagram ....................... BL-26
, BL-32
Diagnosis sensor unit ..................................... SRS-49
Diagnostic trouble code (DTC) for OBD system EC-15,
EC-676
, EC-719
Diagnostic trouble code (DTC) inspection priority chart
EC-94
Direct clutch solenoid valve ............... AT-154, AT-156
Display and amp.assembly ............... ATC-50, ATC-62
Door glass ........................................... GW-58, GW-62
Door glass Fitting Adjustment(Front) ................ GW-60
Door lock .......................................................... BL-152
Door mirror ........................................................ GW-92
Door trim ............................................................. EI-35
Door, front ........................................... BL-148, GW-58
Door, rear ............................................ BL-148, GW-62
Drive belt inspection ......................................... MA-22
Drive belt inspection(VQ35DE) ......................... MA-14
Drive belt(VK45DE) ........................................ EM-174
Drive belt(VQ35DE) .......................................... EM-15
Drive shaft ......................................................... MA-38
Drive shaft (rear) ............................................... RAX-9
Driver air bag .................................................. SRS-38
Duct and grilles .............................................. ATC-133
E
ECM input/output signal ................................... EC-110
ECM power supply ............ EC-477, EC-812, EC-1142
ECM/PW - Wiring diagram ............... EC-478, EC-1143
ECTS - Wiring diagram ...................... EC-212, EC-881
Electric sunroof .................................................. RF-10
Electric throttle control actuator ........ EC-562, EC-573,
EC-1240
, EC-1252
Electric throttle control actuator (VK45DE) ..... EM-179
Electric throttle control actuator (VQ35DE) ....... EM-19

IDX-4
ALPHABETICAL INDEX
Electrical load signal circuit .............. EC-626, EC-1305
Electrical unit ..................................................... PG-75
Electrical units location ...................................... PG-68
Electronic ignition (EI) system ............. EC-33, EC-693
Engine control circuit diagram ......................... EC-108
Engine control component parts location ......... EC-101
Engine control module (ECM) .......... EC-481, EC-1146
Engine control system diagram ........... EC-30, EC-690
Engine coolant temperature sensor (ECTS) ... EC-210,
EC-222
, EC-879, EC-892
Engine coolant(VK45DE) .................................. CO-38
Engine coolant(VQ35DE) ................................. CO-11
Engine fail-safe system ...................................... EC-96
Engine oil filter replacement ............................. MA-26
Engine oil filter replacement(VQ35DE) ............. MA-19
Engine oil precautions .......................................... GI-8
Engine oil replacement(VQ35DE) ..................... MA-18
Engine oil(VK45DE) ........................................... LU-25
Engine oil(VQ35DE) ............................................ LU-7
Engine removal(VK45DE) ............................... EM-243
Engine removal(VQ35DE) .............................. EM-113
Engine room cover(VK45DE) ......................... EM-173
ETC1 - Wiring diagram .................... EC-563, EC-1241
ETC2 - Wiring diagram .................... EC-558, EC-1236
ETC3 - Wiring diagram .................... EC-569, EC-1248
EVAP canister ...................................... EC-42, EC-702
EVAP canister purge volume control solenoid valve ....
EC-397
, EC-405, EC-1063, EC-1071
EVAP canister vent control valve ...... EC-412, EC-419,
EC-1078
, EC-1085
EVAP control system (small leak) diagnosis .. EC-388,
EC-450
, EC-1054, EC-1116
EVAP control system pressure sensor ........... EC-425,
EC-428
, EC-434, EC-1091, EC-1094, EC-1100
EVAP control system purge flow monitoring diagnosis
EC-383
, EC-1049
EVAP vapor lines inspection ................. MA-21, MA-28
Evaporative emission (EVAP) system . EC-39, EC-699
Evaporator ..................................................... ATC-154
Exhaust manifold(VK45DE) ............................ EM-183
Exhaust manifold(VQ35DE) .............................. EM-26
Exhaust system ................................................... EX-3
Exhaust system inspection ..................... EX-3, MA-29
Expansion valve ............................................. ATC-155
F
F/PUMP - Wiring diagram ................ EC-636
, EC-1315
Final drive pre-inspection .................. FFD-20, RFD-19
Final drive removal and installation .. FFD-13, FFD-15,
RFD-16
Floor trim ............................................................. EI-40
Flow charts ......................................................... GI-28
Fluid temperature sensor (A/T) ........................ AT-134
Fluorescent leak detector .............................. ATC-156
Freeze frame data ............................... EC-59, EC-720
Front axle ................................ FAX-4, FAX-10, RAX-5
Front brake solenoid valve ................. AT-150, AT-152
Front bumper ...................................................... EI-14
Front door ............................. BL-148, BL-152, GW-58
Front passenger air bag .................................. SRS-42
Front seat belt ...................................................... SB-4
Front seat belt pre-tensioner ..... SB-2, SRS-3, SRS-48
Front suspension .............................................. FSU-6
FTS - Wiring diagram ....................................... AT-135
FTTS - Wiring diagram ...... EC-330, EC-335, EC-999,
EC-1004
Fuel cut control (at no load high engine speed) EC-34,
EC-694
Fuel filter replacement ......................................... FL-4
Fuel gauge ............................................................ DI-5
Fuel injection system (Bank 1) ......... EC-305, EC-317,
EC-975
, EC-986
Fuel injection system (Bank 2) ......... EC-305, EC-317,
EC-975
, EC-986
Fuel injector ..................................................... EC-628
Fuel injector and fuel tube(VK45DE) .............. EM-194
Fuel injector and fuel tube(VQ35DE) ................ EM-45
Fuel level sensor EC-460, EC-462, EC-464, EC-1125,
EC-1127
, EC-1129
Fuel line inspection .................................. FL-3, MA-25
Fuel line inspection(VQ35DE) .......................... MA-17
Fuel precautions .......................................... GI-6, GI-7
Fuel pressure check ........................... EC-86, EC-746
Fuel pressure release ......................... EC-86, EC-746
Fuel pump ....................................... EC-635, EC-1314
Fuel pump and gauge .......................................... FL-4
Fuel system ......................................................... FL-3
Fuel tank ............................................................ FL-10
Fuel tank temperature sensor .......... EC-328, EC-334,
EC-997
, EC-1003
Fuel tank vacuum relief valve ............. EC-42, EC-702
FUELB1 - Wiring diagram .. EC-307, EC-319, EC-977,
EC-988
FUELB2 - Wiring diagram .. EC-309, EC-321, EC-979,
EC-990
Fuse .................................................................. PG-16
Fuse and fusible link box .................................. PG-82
Fusible link ........................................................ PG-16
G
Gauges ................................................................. DI-5
Generic scan tool (GST) .................................. EC-130
Glass ...................................... GW-11, GW-58, GW-62
Grille - See Exterior ............................................ EI-22
Ground distribution ........................................... PG-29
H
Harness connector ............................................ PG-72
Harness layout .................................................. PG-44
Headlining - See Roof trim .................................. EI-42
Heated oxygen sensor 2 (bank 1) .... EC-270, EC-281,
EC-294
, EC-940, EC-951, EC-964
Heated oxygen sensor 2 (bank 2) .... EC-270, EC-281,
EC-294
, EC-940, EC-951, EC-964
Heated oxygen sensor 2 heater (bank 1) ....... EC-173,
