TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 July 2007 FX35/FX45
DTC 11 CONTROL UNITNKS003F4
1. CHECK ICC UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if any item other than “DTC 11 CONTROL UNIT” is indicated on self-diagnosis display.
Is any indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 20 CAN COMM CIRCUITNKS003F5
1. CHECK CAN COMMUNICATION
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
>> After printing self-diagnostic result, go to “CAN system”. Refer to LAN-49, "
CAN System Specifi-
cation Chart" .
DTC 31 POWER SUPPLY CIR, DTC 34 POWER SUPPLY CIR 2NKS003F6
1. CHECK CONNECTOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector, and connect it securely again.
3. Erase DTC and perform ICC running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC running test. Then perform self-diagnosis of ICC system again.
2. CHECK POWER SUPPLY CIRCUIT FOR ICC UNIT
1. Turn ignition switch ON.
2. Check voltage between ICC unit harness connector and ground.
OK or NG
OK >> GO TO 3.
NG >> 1. Repair ICC unit power supply harness. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
ICC unit connector Terminal
Voltage (Approx.)
(+) ( −)
M89 33
Ground Battery voltage
42
SKIA1173E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-45
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
3. CHECK GROUND CIRCUIT FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector.
3. Check continuity between ICC unit harness connector and ground.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Repair ICC unit ground harness. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 41 VHCL SPEED SE CIRCNKS003F7
1. CHECK ICC UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “DTC 43 ABS/TCS/VDC CIRC” or “DTC 20 CAN COMM CIRCUIT” other than “DTC 41 VHCL SPEED SE CIRC” is indicated in self-diagnosis item in the display.
Is any indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK AT VEHICLE SPEED SENSOR
With CONSULT-II
With “DATA MONITOR”, check “VHCL SPD AT” operates normally. Refer to ACS-33, "
DATA MONITOR" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform “A/T” self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
ICC unit con-
nector Terminal
Ground Continuity
M88 19
Ye s
20
M89 46
SKIA6650E

ACS-46
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 July 2007 FX35/FX45
DTC 43 ABS/TCS/VDC CIRCNKS003F8
1. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis.
2. Check if “DTC 20 CAN COMM CIRCUIT” other than “DTC 43 ABS/TCS/VDC CIRC” is indicated in self- diagnosis item in the display.
Is it indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis of ABS actuator and electric unit (control unit). Refer to BRC-11, "
TROUBLE
DIAGNOSIS" .
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 45 BRAKE SW/STOP L SWNKS003F9
1. CHECK CONNECTOR FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector, and connect it securely again.
3. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Is malfunction indicated?
YES >> GO TO 2.
NO >> Poor connector connection
1. Check connector. (Check connector housing for disconnected, loose, bent, and collapsed ter- minals. If any malfunction is detected, repair applicable part.)
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH
With CONSULT-II
With “DATA MONITOR”, check if “STOP LAMP SW” and “BRAKE SW” are operated normally. Refer to ACS-
33, "DATA MONITOR" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >>

BRAKE SW: GO TO 3.

STOP LAMP SW: GO TO 5.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-61
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
18. CHECK ICC BRAKE HOLD RELAY
With CONSULT-II
1. Connect ICC unit connector and ICC brake hold relay.
2. Disconnect stop lamp switch connector.
3. Perform “ACTIVE TEST” (“STOP LAMP”) with CONSULT-II, and make sure that stop lamp is illuminated.
OK or NG
OK >> GO TO 19.
NG >> 1. Replace ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
19. CHECK ICC UNIT STANDARD VOLTAGE
With CONSULT-II
1. Connect stop lamp switch connector.
2. Perform “ACTIVE TEST” (“STOP LAMP”:“STP LMP DRIVE ON”) with CONSULT-II, check voltage between ICC unit harness
connector and ground.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Replace stop lamp switch. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 92 ECM CIRCUITNKS003FH
1. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis with CONSULT-II.
2. Check if “DTC 20 CAN COMM CIRCUIT” other than “DTC 92 ECM CIRCUIT” is indicated in self-diagnosis item in the display.
Is it indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
ICC unit
connector Terminal
Condition Voltage
(Approx.)
(+) ( −)
M89 29 Ground During “ACTIVE
TEST” 0 V
SKIA1200E

ACS-64
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 July 2007 FX35/FX45
DTC 97 AT CIRCUITNKS003FJ
1. CHECK AT CIRCUIT
With CONSULT-II
With TCM diagnosis, check that shift operates normally. Refer to AT- 11 2 , "
DTC P0705 PARK/NEUTRAL
POSITION SWITCH" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 98 GEAR POSITIONNKS003FK
1. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis.
2. Check if “DTC 43 ABS/TCS/VDC CIRC” or “DTC 41 VHCL SPEED SE CIRC” other than “DTC 98 GEAR POSITION” is indicated in self-diagnosis item in the display.
Is any indicated?
YES >> 1. Repair or replace applicable item. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK VEHICLE SPEED SIGNAL
With CONSULT-II
With “DATA MONITOR”, check that “VHCL SPEED SE” is normal.
OK or NG
OK >> GO TO 3.
NG >> 1. Replace ICC unit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. CHECK SHIFT GEAR POSITION
Check that gear positions are correct in A/T.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4. CHECK TCM GEAR POSITION SIGNAL
With CONSULT-II
With TCM “DATA MONITOR” with CONSULT-II, check that gear positions are correct.
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis.
2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS ACS-65
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
5. CHECK TCM TURBINE ROTATION
With CONSULT-II
With TCM diagnosis, check that turbine rpm is normal. Refer to AT- 11 6 , "
DTC P0717 TURBINE REVOLUTION
SENSOR" .
OK or NG
OK >> 1. Replace ICC unit. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NG >> 1. Perform TCM self-diagnosis. 2. After repairing or replacing applicable item, erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 102 RADAR STAINNKS003FL
1. VISUAL INSPECTION 1
Check that there is no contamination and foreign material on ICC sensor body window.
OK or NG
OK >> GO TO 2.
NG >> 1. If any, remove them.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
2. VISUAL INSPECTION 2
Check ICC sensor body window for cracks.
OK or NG
OK >> GO TO 3.
NG >> 1. Replace ICC sensor, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. ASKING COMPLAINTS
1. Ask if there is any trace of contamination or foreign material on ICC sensor.
2. Ask if vehicle was driven in snow or ICC sensor was frosted.
3. Ask if ICC sensor was fogged temporarily. (Front window glass may have also tended to be fogged.)
Is there any symptom?
YES >> Explain difference in displays between contamination detection result and current indication to customer, and tell them “This is not malfunction”.
NO >> 1. Replace ICC sensor, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 103 LASER SENSOR FAILNKS003FM
1. CHECK ICC UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “DTC 11 CONTROL UNIT” or “DTC 20 CAN COMM CIRCUIT” item other then “DTC 103 LASER SENSOR FAIL” is indicated in self-diagnosis item in the display.
Is any indicated?
YES >> Go to applicable item inspection. Refer to ACS-44, "DTC 11 CONTROL UNIT" , and ACS-44,
"DTC 20 CAN COMM CIRCUIT" .
NO >> 1. Replace ICC sensor, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.

ACS-66
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 July 2007 FX35/FX45
DTC 104 LASER AIMING INCMPNKS003FN
1. CHECK DIAGNOSIS
1. Adjust laser beam aiming. Erase DTC and perform ICC system running test.
2. After that, perform self-diagnosis of ICC system.
3. Check if “DTC 104 LASER AIMING INCMP” is indicated.
Is it indicated?
YES >> 1. Replace ICC sensor, and adjust laser beam aiming. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> INSPECTION END
DTC 107 LASER COMM FAILNKS003FO
1. CHECK ICC UNIT SELF-DIAGNOSIS
1. Perform self-diagnosis.
2. Check if “DTC 11 CONTROL UNIT” or “DTC 20 CAN COMM CIRCUIT” item other than “DTC 107 LASER COMM FAIL” is indicated in the self-diagnosis item in the display.
Is any indicated?
YES >> Go to applicable item inspection. Refer to ACS-44, "DTC 11 CONTROL UNIT" , and ACS-44,
"DTC 20 CAN COMM CIRCUIT" .
NO >> 1. Replace ICC sensor, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
DTC 109 LASER HIGH TEMPNKS003FP
1. CHECK SYMPTOM
Check if cooling system malfunctions.
Does it malfunction?
YES >> 1. Repair cooling system. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
NO >> 1. Replace ICC sensor, and adjust laser beam aiming. 2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.

TROUBLE DIAGNOSIS FOR SYMPTOMS ACS-67
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 July 2007 FX35/FX45
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Symptom ChartNKS003FQ
Symptoms Reference page
Operation MAIN switch does not switch ON.
Symptom 1
ACS-68
MAIN switch does not switch OFF. Symptom 1
ACS-68
Cruise does not function for setting (powering functions). Symptom 2
ACS-68
CANCEL switch does not function. Symptom 3
ACS-69
Resume does not function. Symptom 3
ACS-69
Set speed does not increase. Symptom 3
ACS-69
Set distance to the vehicle ahead cannot be changed. Symptom 3
ACS-69
ICC is not cancelled when the A/T selector lever is in other
than “D” and “M” position. Symptom 4
ACS-70
Display/Chime ICC system display does not appear.
Check combination meter. Refer to
DI-16, "Trouble Diagnosis" .
Chime does not function. Symptom 5
ACS-70
Control Driving force is hunting. Symptom 6
ACS-71
Function to detect
the vehicle ahead System frequently cannot detect the vehicle ahead.
Symptom 7
ACS-71
Distance to detect the vehicle ahead is short. Symptom 7
ACS-71
System misidentifies a vehicle even though there is no vehi-
cle ahead.

Refer to ACS-14, "LASER BEAM AIMING
ADJUSTMENT" .

Refer to ACS-11, "ICC System Running Test"
.
System misidentifies a vehicle in the next lane.

Refer to ACS-14, "LASER BEAM AIMING
ADJUSTMENT" .

Refer to ACS-11, "ICC System Running Test"
.
System does not detect a vehicle at all. Symptom 8
ACS-72

ACS-68
[ICC]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2006 July 2007 FX35/FX45
Symptom 1: MAIN Switch Does Not Turn ON*1 , MAIN Switch Does Not Turn
OFF
*2NKS003FR
NOTE:

*1: The ICC system display in the combination meter does not illuminate.

*2: The ICC system display in the combination meter remains powered.
1. CHECK MAIN SWITCH
With CONSULT-II
With “DATA MONITOR”, check that MAIN switch operates normally.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK CONNECTOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connector.
3. Check connector housing for disconnected, loose, bent, and collapsed terminals.
OK or NG
OK >> GO TO 3.
NG >> Poor connector connection
1. Repair ICC unit connector.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
3. CHECK ICC UNIT SELF-DIAGNOSIS
With CONSULT-II
1. Perform self-diagnosis with CONSULT-II.
2. Check if “DTC 20 CAN COMM CIRCUIT” is indicated.
Is it indicated?
YES >> Refer to ACS-44, "DTC 20 CAN COMM CIRCUIT" .
NO >> Refer to ACS-48, "
DTC 46 OPERATION SW CIRC" .
Symptom 2: ICC System Cannot Be Set (MAIN Switch Turns ON/OFF)NKS003FS
The ICC cannot be set in the following cases.

When the vehicle speed is not in range of approx. 40 km/h (25 MPH) to 144 km/h (90 MPH).

When the A/T selector lever is in gears other than “D” and “M” position.

While the brake is in operation.
1. CHECK CAUSE OF AUTOMATIC CANCELLATION
With CONSULT-II
With “CAUSE OF AUTO-CANCEL” in “WORK SUPPORT”, check if any cause of cancellation exists.
OK or NG
OK >> Cancel with appropriate cause, and go to specified diagnosis.

“OPE SW VOLT CIRC”: Refer to ACS-48, "DTC 46 OPERATION SW CIRC" .

“VHCL SPD UNMATCH”: Refer to ACS-45, "DTC 41 VHCL SPEED SE CIRC" .

“IGN LOW VOLT”: Refer to ACS-44, "DTC 31 POWER SUPPLY CIR, DTC 34 POWER SUP-
PLY CIR 2" .
NG >> GO TO 2.

ACS-72
[ICC]
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2006 July 2007 FX35/FX45
2. CHECK FUNCTION
After adjusting ICC sensor beam aiming, perform ICC system running test. Check that preceding vehicle
detection performance has been improved.
OK or NG
OK >> INSPECTION END
NG >> 1. Replace ICC sensor, and perform laser beam aiming adjustment.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
Symptom 8: The System Does Not Detect the Vehicle Ahead at AllNKS003FY
1. VISUAL CHECK 1
With ignition switch turned ON (engine not started), check that all indicator lamps in ICC system display are
continuously lit. (Check for a missing segment in preceding vehicle detection display.)
OK or NG
OK >> GO TO 2.
NG >> Check for combination meter. Refer to DI-16, "
Trouble Diagnosis" .
2. VISUAL CHECK 2
Check ICC sensor body window for contamination and foreign materials.
OK or NG
OK >> If any contamination or foreign materials are found, remove them. Perform ICC system running test.
NG >> GO TO 3.
3. VISUAL CHECK 3
Check ICC sensor body window for cracks and scratches.
OK or NG
OK >> GO TO 4.
NG >> 1. Replace ICC sensor, and perform laser beam aiming adjustment.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
4. ADJUST ICC SENSOR
After adjusting ICC sensor beam aiming, perform ICC system running test. Check that preceding vehicle
detection performance has been improved.
OK or NG
OK >> INSPECTION END
NG >> 1. Replace ICC sensor, and perform laser beam aiming adjustment.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system again.
