INFINITI FX35 2008 Service Manual
Manufacturer: INFINITI, Model Year: 2008, Model line: FX35, Model: INFINITI FX35 2008Pages: 3924, PDF Size: 81.37 MB
Page 2631 of 3924
![INFINITI FX35 2008 Service Manual
CYLINDER BLOCKEM-147
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Remove main bearing caps and bearings, and using the scale on
the plastigage bag, measure the plastigage width.](/img/42/57017/w960_57017-2630.png "INFINITI FX35 2008 Service Manual
CYLINDER BLOCKEM-147
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Remove main bearing caps and bearings, and using the scale on
the plastigage bag, measure the plastigage width.")
CYLINDER BLOCKEM-147
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Remove main bearing caps and bearings, and using the scale on
the plastigage bag, measure the plastigage width.
NOTE:
The procedure when the measured value exceeds the limit is
same as that described in the “Method by Calculation”.
MAIN BEARING CRUSH HEIGHT
When main bearing cap is removed after being tightened to thespecified torque with main bearings installed, the tip end of bearing
must protrude. Refer to EM-123, "
Disassembly and Assembly" for
the tightening procedure.
If the standard is not met, replace main bearings.
CONNECTING ROD BEARING CRUSH HEIGHT
When connecting rod bearing cap is removed after being tightened to the specified torque with connecting rod bearings installed, the
tip end of bearing must protrude. Refer to EM-123, "
Disassembly
and Assembly" for the tightening procedure.
If the standard is not met, replace connecting rod bearings.
MAIN BEARING CAP BOLT OUTER DIAMETER
Measure the outer diameters (“d1”, “d2”) at two positions as shown
in the figure.
If reduction appears in “A” range, regard it as “d
2”.
If it exceeds the limit (large difference in dimensions), replace main bearing cap bolt with new one.
CONNECTING ROD BOLT OUTER DIAMETER
PBIC1149E
Standard : There must be crush height.
SEM502G
Standard : There must be crush height.
PBIC1646E
Limit (“d1” – “d2”) : 0.11 mm (0.0043 in)
PBIC0911E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2632 of 3924
![INFINITI FX35 2008 Service Manual
EM-148
< SERVICE INFORMATION >[VQ35DE]
CYLINDER BLOCK
Measure the outer diameter “d”
at position shown in the figure.
If the reduction appears in a position other than “d”, regard it as](/img/42/57017/w960_57017-2631.png "INFINITI FX35 2008 Service Manual
EM-148
< SERVICE INFORMATION >[VQ35DE]
CYLINDER BLOCK
Measure the outer diameter “d”
at position shown in the figure.
If the reduction appears in a position other than “d”, regard it as")
EM-148
< SERVICE INFORMATION >[VQ35DE]
CYLINDER BLOCK
Measure the outer diameter “d”
at position shown in the figure.
If the reduction appears in a position other than “d”, regard it as “d”.
When “d” exceeds the limit (when it becomes thinner), replace connecting rod bolt with new one.
DRIVE PLATE
Check drive plate and signal plate for deformation or damage.CAUTION:
Do not disassemble drive plate.
Do not place drive plate with signal plate facing down.
When handling signal plate, take care not to damage or scratch it.
Handle signal plate in a manner that prevents it from becom-
ing magnetized.
If anything is found, replace drive plate.
OIL JET
Check nozzle for deformation and damage.
Blow compressed air from nozzle, and check for clogs.
If it is not satisfied, clean or replace oil jet.
OIL JET RELIEF VALVE
Using a clean plastic stick, press check valve in oil jet relief valve. Make sure that valve moves smoothly with proper reaction force.
If it is not satisfied, replace oil jet relief valve. Standard : 7.90 - 8.00 mm (0.3110 - 0.3150 in)
Limit : 7.75 mm (0.3051 in)
PBIC0912E
SEM760G
EMU0468D
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2633 of 3924
![INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-149
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000001325750
GENERAL S](/img/42/57017/w960_57017-2632.png "INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-149
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000001325750
GENERAL S")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-149
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
SERVICE DATA AND SPECIFICATIONS (SDS)
Standard and LimitINFOID:0000000001325750
GENERAL SPECIFICATIONS
DRIVE BELT
Cylinder arrangement
V- 6
Displacement cm
3 (cu in) 3,498 (213.45)
Bore and stroke mm (in) 95.5 x 81.4 (3.760 x 3.205)
Valve arrangement DOHC
Firing order 1-2-3-4-5-6
Number of piston rings Compression 2
Oil 1
Number of main bearings 4
Compression ratio 10.3
C o m p r e s s i o n p r e s s u r e k P a
(kg/cm
2, psi)/300 rpm Standard 1,275 (13.0, 185)
Minimum 981 (10.0, 142)
Differential limit between cylinders 98 (1.0, 14)
Cylinder number
Valve timing
(Intake valve timing control - “OFF”) Unit: degree
abcde f
240 238 −664 8 52
SEM713A
PBIC0187E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2634 of 3924
![INFINITI FX35 2008 Service Manual
EM-150
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on the](/img/42/57017/w960_57017-2633.png "INFINITI FX35 2008 Service Manual
EM-150
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on the")
EM-150
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: If belt tension gauge cannot be installed at check points shown, check drive belt tension at different location on the belt.
INTAKE MANIFOLD COLLECTOR, INTA
KE MANIFOLD AND EXHAUST MANIFOLD
Unit: mm (in)
SPARK PLUG
CAMSHAFT AND CAMSHAFT BEARING
Unit: mm (in)
Deflection adjustment Unit: mm (in) Tension adjustment* Unit: N (kg, lb)
Used belt New beltUsed belt
New belt
Limit After adjustment Limit After adjustment
Alternator and
power steering
oil pump belt 12 (0.47)
7 - 8
(0.28 - 0.31) 6 - 7
(0.24 - 0.28) 294 (30, 66) 730 - 818
(74.5 - 83.4,
164 - 184) 838 - 926
(85.5 - 94.5,
188 - 208)
A/C compressor
belt 12 (0.47)9 - 10
(0.35 - 0.39) 8 - 9
(0.31 - 0.35) 196 (20, 44) 348 - 436
(35.5 - 44.5, 78 - 98) 470 - 559
(47.9 - 57.0, 106 - 126)
Applied pushing
force 98 N (10 kg, 22 lb) —
PBIC5323E
Items Limit
Surface distortion Intake manifold collector (upper) 0.1 (0.004)
Intake manifold collector (lower) 0.1 (0.004)
Intake manifold 0.1 (0.004)
Exhaust manifold 0.3 (0.012)
Make NGK
Standard type PLFR5A-11
Hot type PLFR4A-11
Cold type PLFR6A-11
Gap (Nominal) 1.1 mm (0.043 in)
Items Standard Limit
Camshaft journal oil clearance No. 1 0.045 - 0.086 (0.0018 - 0.0034)
0.15 (0.0059)
No. 2, 3, 4 0.035 - 0.076 (0.0014 - 0.0030)
Camshaft bracket inner diameter No. 1 26.000 - 26.021 (1.0236 - 1.0244) —
No. 2, 3, 4 23.500 - 23.521 (0.9252 - 0.9260) —
Camshaft journal diameter No. 1 25.935 - 25.955 (1.0211 - 1.0218) —
No. 2, 3, 4 23.445 - 23.465 (0.9230 - 0.9238) —
Camshaft end play 0.115 - 0.188 (0.0045 - 0.0074) 0.24 (0.0094)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2635 of 3924
![INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-151
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
*1: Cam wear limit
*
2: Total indicator reading
Valve Lifter
Unit: mm (in)
Valve Clearanc](/img/42/57017/w960_57017-2634.png "INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-151
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
*1: Cam wear limit
*
2: Total indicator reading
Valve Lifter
Unit: mm (in)
Valve Clearanc")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-151
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
*1: Cam wear limit
*
2: Total indicator reading
Valve Lifter
Unit: mm (in)
Valve Clearance
Unit: mm (in)
*: Approximately 80 °C (176 °F)
Available Valve Lifter
Unit: mm (in)
Camshaft cam height “A” Intake and exhaust 44.865 - 45.055 (1.7663 - 1.7738)
0.2 (0.008)*1
Camshaft runout (TIR*2)Less than 0.02 mm (0.0008) 0.05 (0.0020)
Camshaft sprocket runout (TIR*
2) — 0.15 (0.0059)
SEM671
Items Standard
Valve lifter outer diameter Identification (stamped)
mark “R” or “U” 33.977 - 33.987 (1.3377 - 1.3381)
Identification (stamped) mark “V” 33.980 - 33.990 (1.3378 - 1.3382)
Valve lifter hole diameter 34.000 - 34.016 (1.3386 - 1.3392)
Valve lifter clearance Identification (stamped) mark “R” or “U” 0.013 - 0.039 (0.0005 - 0.0015)
Identification (stamped) mark “V” 0.010 - 0.036 (0.0004 - 0.0014)
Items Cold Hot* (reference data)
Intake 0.26 - 0.34 (0.010 - 0.013) 0.304 - 0.416 (0.012 - 0.016)
Exhaust 0.29 - 0.37 (0.011 - 0.015) 0.308 - 0.432 (0.012 - 0.017)
Identification (stamped) mark Thickness
788U 788R 788V 7.88 (0.3102)
790U 790R 790V 7.90 (0.3110)
792U 792R 792V 7.92 (0.3118)
794U 794R 794V 7.94 (0.3126)
796U 796R 796V 7.96 (0.3134)
798U 798R 798V 7.98 (0.3142)
800U 800R 800V 8.00 (0.3150)
802U 802R 802V 8.02 (03.157)
804U 804R 804V 8.04 (0.3165)
806U 806R 806V 8.06 (0.3173)
808U 808R 808V 8.08 (0.3181)
810U 810R 810V 8.10 (0.3189)
812U 812R 812V 8.12 (0.3197)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2636 of 3924
![INFINITI FX35 2008 Service Manual
EM-152
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
CYLINDER HEAD
Unit: mm (in)
Valve Dimensions
814U 814R 814V 8.14 (0.3205)
816U 816R 816V 8.16 (0.3213) 818U 818R 818V 8.1](/img/42/57017/w960_57017-2635.png "INFINITI FX35 2008 Service Manual
EM-152
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
CYLINDER HEAD
Unit: mm (in)
Valve Dimensions
814U 814R 814V 8.14 (0.3205)
816U 816R 816V 8.16 (0.3213) 818U 818R 818V 8.1")
EM-152
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
CYLINDER HEAD
Unit: mm (in)
Valve Dimensions
814U 814R 814V 8.14 (0.3205)
816U 816R 816V 8.16 (0.3213) 818U 818R 818V 8.18 (0.3220)
820U 820R 820V 8.20 (0.3228)
822U 822R 822V 8.22 (0.3236)
824U 824R 824V 8.24 (0.3244)
826U 826R 826V 8.26 (0.3252)
828U 828R 828V 8.28 (0.3260)
830U 830R 830V 8.30 (0.3268)
832U 832R 832V 8.32 (0.3276)
834U 834R 834V 8.34 (0.3283)
836U 836R 836V 8.36 (0.3291)
838U 838R 838V 8.38 (0.3299)
840U 840R 840V 8.40 (0.3307) Identification (stamped) mark Thickness
SEM758G
Items Standard Limit
Head surface distortion Less than 0.03 (0.0012) 0.1 (0.004)
Normal cylinder head height “H” 126.3 - 126.5 (4.97 - 4.98) —
PBIC0924E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2637 of 3924
![INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-153
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
Valve Guide
Unit: mm (in)
Valve Seat
Valve head diameter “D”
Intake 37.](/img/42/57017/w960_57017-2636.png "INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-153
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
Valve Guide
Unit: mm (in)
Valve Seat
Valve head diameter “D”
Intake 37.")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-153
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
Valve Guide
Unit: mm (in)
Valve Seat
Valve head diameter “D”
Intake 37.0 - 37.3 (1.457 - 1.469)
Exhaust 31.2 - 31.5 (1.228 - 1.240)
Valve length “L” Intake 96.46 (3.7976)
Exhaust 93.99 (3.7004)
Valve stem diameter “d” Intake 5.965 - 5.980 (0.2348 - 0.2354)
Exhaust 5.955 - 5.970 (0.2344 - 0.2350)
Valve seat angle “ α” Intake
45°15 ′ - 45 °45 ′
Exhaust
Valve margin “T” Intake 1.1 (0.043)
Exhaust 1.3 (0.051)
Valve margin “T” limit 0.5 (0.020)
Valve stem end surface grinding limit 0.2 (0.008)
SEM188
Items Standard Oversize (Service) [0.2 (0.008)]
Va l v e g u i d e Outer diameter 10.023 - 10.034 (0.3946 - 0.3950) 10.223 - 10.234 (0.4025 - 0.4029)
Inner diameter (Finished size) 6.000 - 6.018 (0.2362 - 0.2369)
Cylinder head valve guide hole diameter 9.975 - 9.996 (0.3927 - 0.3935) 10.175 - 10.196 (0.4006 - 0.4014)
Interference fit of valve guide 0.027 - 0.059 (0.0011 - 0.0023) Items Standard Limit
Valve guide clearance Intake 0.020 - 0.053 (0.0008 - 0.0021) 0.08 (0.0031)
Exhaust 0.030 - 0.063 (0.0012 - 0.0025) 0.09 (0.0039)
Projection length “L” 12.6 - 12.8 (0.496 - 0.504)
SEM950E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2638 of 3924
![INFINITI FX35 2008 Service Manual
EM-154
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*1: Diameter made by intersection point of conic angles “
α1” and “ α2”
*
2: Diameter made by int](/img/42/57017/w960_57017-2637.png "INFINITI FX35 2008 Service Manual
EM-154
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*1: Diameter made by intersection point of conic angles “
α1” and “ α2”
*
2: Diameter made by int")
EM-154
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
*1: Diameter made by intersection point of conic angles “
α1” and “ α2”
*
2: Diameter made by intersection point of conic angles “ α2” and “ α3”
*
3: Machining data
Valve Spring
CYLINDER BLOCK
Items Standard Oversize (Service) [0.5 (0.02)]
Cylinder head seat recess diameter “D” Intake 38.000 - 38.016 (1.4961 - 1.4967) 38.500 - 38.516 (1.5157 - 1.5164) Exhaust 32.200 - 32.216 (1.2677 - 1.2683) 32.700 - 32.716 (1.2874 - 1.2880)
Valve seat outer diameter “d” Intake 38.097 - 38.113 (1.4999 - 1.5005) 38.597 - 38.613 (1.5196 - 1.5202)
Exhaust 32.280 - 32.296 (1.2709 - 1.2715) 32.780 - 32.796 (1.2905 - 1.2912)
Valve seat interference fit Intake 0.081 - 0.113 (0.0032 - 0.0044)
Exhaust 0.064 - 0.096 (0.0025 - 0.0038)
Diameter “d1”*
1Intake 35 (1.38)
Exhaust 28.7 (1.130)
Diameter “d2”*
2Intake 36.6 - 36.8 (1.441 - 1.449)
Exhaust 30.6 - 30.8 (1.205 - 1.213)
Angle “ α1” Intake 60
°
Exhaust 60 °
Angle “ α2” Intake 88
°45 ′ - 90 °15 ′
Exhaust 88 °45 ′ - 90 °15 ′
Angle “ α3” Intake 120
°
Exhaust 120 °
Contacting width “W”*
3Intake 1.09 - 1.31 (0.0429 - 0.0516)
Exhaust 1.29 - 1.51 (0.0508 - 0.0594)
Height “h” Intake 5.9 - 6.0 (0.232 - 0.236) 5.05 - 5.15 (0.1988 - 0.2028)
Exhaust 5.9 - 6.0 (0.232 - 0.236) 4.95 - 5.05 (0.1949 - 0.1988)
Depth “H” 6.0 (0.236)
PBIC2745E
Free height mm (in) 47.07 (1.8531)
Pressure N (kg, lb) at height mm (in) Installation 166 - 188 (16.9 - 19.2, 37 - 42) at 37.0 (1.457)
Valve open 373 - 421 (38.0 - 42.9, 84 - 95) at 27.2 (1.071)
Out-of-square mm (in) Limit 2.1 (0.083)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2639 of 3924
![INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-155
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
PISTON, PISTON RING AND PISTON PIN
Available Piston
Surface flatness
Standa](/img/42/57017/w960_57017-2638.png "INFINITI FX35 2008 Service Manual
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-155
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
PISTON, PISTON RING AND PISTON PIN
Available Piston
Surface flatness
Standa")
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-155
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Unit: mm (in)
PISTON, PISTON RING AND PISTON PIN
Available Piston
Surface flatness
Standard Less than 0.03 (0.0012)
Limit 0.1 (0.004)
Main bearing housing inner diameter Standard 63.993 - 64.017 (2.5194 - 2.5203)
Cylinder bore Inner diameter StandardGrade No. 1 95.500 - 95.510 (3.7598 - 3.7602)
Grade No. 2 95.510 - 95.520 (3.7602 - 3.7606)
Grade No. 3 95.520 - 95.530 (3.7606 - 3.7610)
Wear limit 0.2 (0.008)
Out-of-round (Difference between “X” and “Y”) Limit0.015 (0.0006)
Taper (Difference between “A” and “C”) 0.01 (0.0004)
Main journal inner diameter grade (Without bearing) Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 763.993 - 63.994 (2.5194 - 2.5194)
63.994 - 63.995 (2.5194 - 2.5195)
63.995 - 63.996 (2.5195 - 2.5195)
63.996 - 63.997 (2.5195 - 2.5196)
63.997 - 63.998 (2.5196 - 2.5196)
63.998 - 63.999 (2.5196 - 2.5196)
63.999 - 64.000 (2.5196 - 2.5197)
64.000 - 64.001 (2.5197 - 2.5197)
64.001 - 64.002 (2.5197 - 2.5198)
64.002 - 64.003 (2.5198 - 2.5198)
64.003 - 64.004 (2.5198 - 2.5198)
64.004 - 64.005 (2.5198 - 2.5199)
64.005 - 64.006 (2.5199 - 2.5199)
64.006 - 64.007 (2.5199 - 2.5200)
64.007 - 64.008 (2.5200 - 2.5200)
64.008 - 64.009 (2.5200 - 2.5200)
64.009 - 64.010 (2.5200 - 2.5201)
64.010 - 64.011 (2.5201 - 2.5201)
64.011 - 64.012 (2.5201 - 2.5202)
64.012 - 64.013 (2.5202 - 2.5202)
64.013 - 64.014 (2.5202 - 2.5202)
64.014 - 64.015 (2.5202 - 2.5203)
64.015 - 64.016 (2.5203 - 2.5203)
64.016 - 64.017 (2.5203 - 2.5203)
Difference in inner diameter between cylinders Standard Less than 0.03 (0.0012)
PBIC0923E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2640 of 3924
![INFINITI FX35 2008 Service Manual
EM-156
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
Piston Ring
Unit: mm (in)
Piston Pin
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
Items Standard Oversize (S
e](/img/42/57017/w960_57017-2639.png "INFINITI FX35 2008 Service Manual
EM-156
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
Piston Ring
Unit: mm (in)
Piston Pin
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
Items Standard Oversize (S
e")
EM-156
< SERVICE INFORMATION >[VQ35DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Unit: mm (in)
Piston Ring
Unit: mm (in)
Piston Pin
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
Items Standard Oversize (S
ervice) [0.2 (0.008)]
Piston skirt diameter “A” Grade No. 1 95.480 - 95.490 (3.7590 - 3.7594) —
Grade No. 2 95.490 - 95.500 (3.7594 - 3.7598) —
Grade No. 3 95.500 - 95.510 (3.7598 - 3.7602) —
Service — 95.680 - 95.710 (3.7669 - 3.7681)
Items Standard Limit
“a” dimension 41.0 (1.614) —
Piston pin hole diameter Grade No. 0 21.993 - 21.999 (0.8659 - 0.8661) —
Grade No. 1 21.999 - 22.005 (0.8661 - 0.8663) —
Piston to cylinder bore clearance 0.010 - 0.030 (0.0004 - 0.0012) 0.08 (0.0031)
SEM882E
Items Standard Limit
Side clearance Top 0.045 - 0.080 (0.0018 - 0.0031) 0.11 (0.0043)
2nd 0.030 - 0.070 (0.0012 - 0.0028) 0.1 (0.004)
Oil ring 0.065 - 0.135 (0.0026 - 0.0053) —
End gap Top 0.23 - 0.33 (0.0091 - 0.0130) 0.54 (0.0213)
2nd 0.33 - 0.48 (0.0130 - 0.0189) 0.80 (0.0315)
Oil (rail ring) 0.20 - 0.50 (0.0079 - 0.0197) 0.95 (0.0374)
Items Standard Limit
Piston pin outer diameter Grade No. 0 21.989 - 21.995 (0.8657 - 0.8659) —
Grade No. 1 21.995 - 22.001 (0.8659 - 0.8662) —
Piston to piston pin oil clearance 0.002 - 0.006 (0.0001 - 0.0002) —
Connecting rod bushing oil clearance 0.005 - 0.017 (0.0002 - 0.0007) 0.030 (0.0012)
Items Standard Limit
Center distance 144.15 - 144.25 (5.68 - 5.68) —
Bend [per 100 (3.94)] — 0.15 (0.0059)
Torsion [per 100 (3.94)] — 0.30 (0.0118)
Connecting rod bushing inner diameter* Grade No. 0 22.000 - 22.006 (0.8661 - 0.8664) —
Grade No. 1 22.006 - 22.012 (0.8664 - 0.8666) —
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
