POWER SOCKET
1. Remove A/T console finisher. Refer to IP-10, "Component Parts
Location".
2. Remove instrument clock finisher. Refer to IP-10, "
Component
Parts Location".
3. Disconnect power socket connector.
4. Remove inner socket from the ring while pressing the hook on the ring out from square hole.
5. Remove ring from ashtray while pressing pawls.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Front Power Socket - 2INFOID:0000000001328602
REMOVAL
1. Remove inner socket from the ring. While pressing the hook on
the ring out from square hole.
2. Remove ring from power socket finisher while pressing pawls.
3. Disconnect power socket connector.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Rear Power SocketINFOID:0000000001328603
REMOVAL
1. Remove console rear finisher. Refer to IP-16, "Disassembly and
Assembly".
2. Disconnect power socket connector.
3. Remove inner socket from the ring. While pressing the hook on the ring out from square hole.
4. Remove ring from power socket finisher while pressing pawls.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of Luggage Room Power SocketINFOID:0000000001328604
REMOVAL
PKIC9710E
SKIA5096E
SKIA5094E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

POWER SOCKETWW-47
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
WW
N
O P
1. Remove inner socket from the ring. While pressing the hook on the ring out from square hole.
2. Remove ring from power socket finisher while pressing pawls.
3. Disconnect power socket connector.
INSTALLATION
Installation is the reverse order of removal.
SKIA5097E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

WW-48
< SERVICE INFORMATION >
HORN
HORN
Wiring Diagram - HORN -INFOID:0000000001328605
Removal and InstallationINFOID:0000000001328606
REMOVAL
1. Remove front grille. Refer to EI-22, "Component Parts Location".
TKWM4378E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

HORN
WW-49
< SERVICE INFORMATION >
C
D E
F
G H
I
J
L
M A
B
WW
N
O P
2. Disconnect all horn connectors.
3. Remove horn mounting bolt and remove horn from vehicle.
INSTALLATION
Installation is the reverse order of removal.
 Tighten horn bolt to specified torque.
SKIA5093E
Horn mounting bolt : 5.8 N·m (0.59 kg-m, 51 in-lb)
