DISPLAY ITEM LIST
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR- 1
[C1](/img/42/57017/w960_57017-1041.png "INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISBRC-27
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
DISPLAY ITEM LIST
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR- 1
[C1")
TROUBLE DIAGNOSISBRC-27
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
DISPLAY ITEM LIST
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR- 1
[C1101] (Note 1) Circuit of rear RH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-34, "
DTC C1101 RR RH
SENSOR-1"
RR LH SENSOR- 1
[C1102] (Note 1)
Circuit of rear LH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-35, "DTC C1102 RR LH
SENSOR-1"
FR RH SENSOR- 1
[C1103] (Note 1)Circuit of front RH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-35, "DTC C1103 FR RH
SENSOR-1"
FR LH SENSOR- 1
[C1104] (Note 1)Circuit of front LH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-35, "DTC C1104 FR LH
SENSOR-1"
RR RH SENSOR- 2
[C1105] (Note 1)
ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1105 RR RH
SENSOR-2"
RR LH SENSOR- 2
[C1106] (Note 1)ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1106 RR LH
SENSOR-2"
FR RH SENSOR- 2
[C1107] (Note 1)ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1107 FR RH
SENSOR-2"
FR LH SENSOR- 2
[C1108] (Note 1)
ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1108 FR LH
SENSOR-2"
BATTERY VOLTAGE
[ABNORMAL]
[C1109]ABS actuator and electric unit (control unit) power voltage is too low. BRC-36, "DTC C1109 BAT-
TERY VOLTAGE [ABNOR-
MAL]"
CONTROLLER FAILURE
[ C 111 0 ]
Internal malfunction of ABS actuator and electric unit (control unit) BRC-37, "DTC C1110 CON-
TROLLER FAILURE"
PUMP MOTOR
[ C 1111 ] ( N o t e 3 )During actuator motor operation with ON, when actuator motor turns
OFF or when control line for actuator motor relay is open.
BRC-37, "D T C C 1111 P U M P
MOTOR"During actuator motor operation with OFF, when actuator motor turns
ON or when control line for relay is shorted to ground.
G - SENSOR
[C1113] (Note 4) Decel G sensor is malfunctioning, or signal line of decel G sensor is
open or shorted. BRC-38, "
DTC C1113 G-SEN-
SOR"
ABS SENSOR
[ABNORMAL SIGNAL]
[C1115] (Note 1)Wheel sensor input is malfunction. BRC-39, "DTC C1115 ABS
SENSOR [ABNORMAL SIG-
NAL]"
STOP LAMP SW
[ C 111 6 ]
Stop lamp switch circuit is open or shorted. BRC-39, "DTC C1116 STOP
LAMP SW"
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control line is
open or shorted to power supply or ground. BRC-40, "DTC C1120 FR LH IN
ABS SOL"
FR LH OUT ABS SOL
[C1121]Circuit of front LH OUT ABS solenoid is
open or shorted, or control line
is open or shorted to power supply or ground. BRC-41, "DTC C1121 FR LH
OUT ABS SOL"
FR RH IN ABS SOL
[C1122]Circuit of front RH IN ABS solenoid is op
en or shorted, or control line is
open or shorted to power supply or ground. BRC-41, "DTC C1122 FR RH IN
ABS SOL"
FR RH OUT ABS SOL
[C1123]
Circuit of front RH OUT ABS solenoid is
open or shorted, or control line
is open or shorted to power supply or ground. BRC-42, "DTC C1123 FR RH
OUT ABS SOL"
RR LH IN ABS SOL
[C1124]Circuit of rear LH IN ABS solenoid is open or shorted, or control line is
open or shorted to power supply or ground. BRC-42, "DTC C1124 RR LH IN
ABS SOL"
RR LH OUT ABS SOL
[C1125] Circuit of rear LH OUT ABS solenoid is open or shorted, or control line
is open or shorted to power supply or ground. BRC-42, "DTC C1125 RR LH
OUT ABS SOL"
RR RH IN ABS SOL
[C1126]
Circuit of rear RH IN ABS solenoid is
open or shorted, or control line is
open or shorted to power supply or ground. BRC-42, "DTC C1126 RR RH IN
ABS SOL"
RR RH OUT ABS SOL
[C1127]Circuit of rear RH OUT ABS solenoid is open or shorted, or control line
is open or shorted to power supply or ground. BRC-42, "DTC C1127 RR RH
OUT ABS SOL"
ENGINE SIGNAL 1
[C1130]Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine fuel cut system is malfunctioning. BRC-42, "DTC C1130 ENGINE
SIGNAL 1"
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1132 of 3924
DI-6
< SERVICE INFORMATION >
COMBINATION METERS
Combination meter indicates the engine speed according to engine speed signal.
WATER TEMPERATURE GAUGE
The water temperature gauge indicates the engine coolant temperature.
ECM provides engine coolant temperature signal to unified meter and A/C amp. with CAN communication.
Unified meter and A/C amp. transmits engine coolant temperature signal to combination meter with commu-
nication line.
Combination meter indicates the engine coolant temper ature according to engine coolant temperature sig-
nal.
FUEL GAUGE
The fuel gauge indicates the approximate fuel level in the fuel tank.
Unified meter and A/C amp. reads a resistor signal from fuel level sensor.
Signal is supplied- from unified meter and A/C amp. terminal 36
- through the fuel level sensor unit and fuel pump (main) terminals 5 and 2, and
- through the fuel level sensor unit (sub) terminals 2 and 1
- to unified meter and A/C amp. terminal 28 for the fuel gauge.
Unified meter and A/C amp. provides a fuel level signal to combination meter with communication line.
Combination meter indicates the approximate fuel level according to the fuel level signal.
ODO/TRIP METER
ABS actuator and electric unit (control unit) provi des a vehicle speed signal to the unified meter and A/C
amp. with CAN communication.
Unified meter and A/C amp. converts the vehicle s peed signal to the 8-pulse signal, and outputs the vehicle
speed signal (8-pulse) to combination meter.
Combination meter uses the vehicle speed signal (8- pulse) to calculate the mileage, and displays it.
How to Change The Display For Odo/trip Meter
PKIB7631E
PKIB7632E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1146 of 3924
DI-20
< SERVICE INFORMATION >
COMBINATION METERS
OK >> GO TO 2.
NG >> Replace combination meter.
2.CHECK FUEL LEVEL SENSOR (SUB) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector and fuel level sensor unit (sub) connector.
3. Check continuity between unified meter and A/C amp. harness
connector (A) M56 terminal 28 and fuel level sensor unit (sub)
harness connector (B) B40 terminal 1.
4. Check continuity between unified meter and A/C amp. harness connector (A) M56 terminal 28 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3.CHECK FUEL LEVEL SENSOR (MAIN·SUB) CIRCUIT
1. Disconnect fuel level sensor unit and fuel pump (main) connector.
2. Check continuity between fuel level sensor unit (sub) harness
connector (A) B40 terminal 2 and fuel level sensor unit and fuel
pump (main) harness connector (B) B39 terminal 2.
3. Check continuity between fuel level sensor unit (sub) harness
connector (A) B40 terminal 2 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4.CHECK FUEL LEVEL SENSOR (MAIN) CIRCUIT
1. Check continuity between fuel level sensor unit and fuel pump (main) harness connector (A) B39 terminal 5 and unified meter
and A/C amp. harness connector (B) M56 terminal 36.
2. Check continuity between fuel level sensor unit and fuel pump (main) harness connector (A) B39 terminal 5 and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5.CHECK FUEL LEVEL SENSOR
Check components. Refer to DI-21, "
Electrical Component Inspection".
OK or NG
OK >> Check fuel level sensor unit installation, and c heck whether the float arm interferes or binds with
any of the internal components in the fuel tank. Repair or replace malfunctioning part, if neces-
sary.
NG >> Replace fuel level sensor unit. 28 – 1 : Continuity should exist.
28 – Ground : Continuity should not exist.
SKIB8527E
2 – 2 : Continuity should exist.
2 – Ground : Continuity should not exist.
SKIB8697E
5 – 36 : Continuity should exist.
5 – Ground : Continuity should not exist.
SKIB8528E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1148 of 3924
DI-22
< SERVICE INFORMATION >
COMBINATION METERS
Check continuity between terminals 25, 26, 35 or 36 and 27.
FUEL LEVEL SENSOR UNIT
For removal, refer to FL-4, "Component".
Fuel Level Sensor Unit and Fuel Pump (Main)
Check the resistance between terminals 2 and 5.
*1 and *2: When float rod is in contact with stopper.
If the results of check are NG, check the fuel level sensor unit and
fuel pump (main) harness. Refer to "Fuel Level Sensor Unit and
Pump (Main) Harness".
Fuel Level Sensor Unit and Pump (Main) Harness
Check continuity at following terminals.
If the results of check are NG, replace fuel pump assembly. If the results of check are OK, replace fuel level sensor unit.
Fuel Level Sensor Unit (Sub)
Check resistance between terminals 1 and 2.
*1 and *2: When float rod is in contact with stopper.
Removal and Installation of Combination MeterINFOID:0000000001328453
Refer to IP-10, "Component Parts Location".
Terminal Condition Continuity
25
27Illumination control swit
ch (–) is pressed. Yes
Illumination control swit ch (–) is released. No
26 Illumination control swit
ch (+) is pressed. Yes
Illumination control swit ch (+) is released. No
35 Trip transfer switch is pressed. Yes
Trip transfer switch is released. No
36 Trip reset switch is pressed. Yes
Trip reset switch is released. No
SKIB8529E
Terminal Float position [mm (in)]
Resistance val-
ue [Ω]
25 *1 Full 236 (9.29) Approx. 3
*2 Empty 29 (1.14) Approx. 80
SKIB3550J
Terminal Continuity
2 - Signal terminal (A) Ye s
5 - Ground terminal (B)
SKIB3551J
Terminal Float position [mm (in)] Resistance val-
ue [Ω]
12 *1 Full 6 (0.24) Approx. 3
*2 Empty 203 (7.99) Approx. 48
SKIB8530E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1248 of 3924
EC-8
Component Inspection ...........................................545
ASCD INDICATOR ..........................................547
Component Description ....................................... ..547
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
547
Wiring Diagram ......................................................548
Diagnosis Procedure .............................................548
ELECTRICAL LOAD SIGNAL .........................550
Description ........................................................... ..550
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
550
Diagnosis Procedure .............................................550
FUEL INJECTOR .............................................552
Component Description ....................................... ..552
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
552
Wiring Diagram ......................................................553
Diagnosis Procedure .............................................554
Component Inspection ...........................................557
Removal and Installation .......................................557
FUEL PUMP .....................................................558
Description ........................................................... ..558
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
558
Wiring Diagram ......................................................559
Diagnosis Procedure .............................................560
Component Inspection ...........................................562
Removal and Installation .......................................562
ICC BRAKE SWITCH ......................................563
Component Description ....................................... ..563
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
563
Wiring Diagram ......................................................564
Diagnosis Procedure .............................................565
Component Inspection ...........................................567
IGNITION SIGNAL ...........................................569
Component Description ....................................... ..569
Wiring Diagram ......................................................570
Diagnosis Procedure .............................................575
Component Inspection ...........................................578
Removal and Installation .......................................580
REFRIGERANT PRESSURE SENSOR ..........581
Component Description ....................................... ..581
Wiring Diagram ......................................................582
Diagnosis Procedure .............................................583
Removal and Installation .......................................585
SNOW MODE SWITCH ...................................586
Description ........................................................... ..586
CONSULT-III Reference Value in Data Monitor
Mode .................................................................... ..
586
Wiring Diagram ......................................................587
Diagnosis Procedure .............................................587
Component Inspection ...........................................589
MIL AND DATA LINK CONNECTOR ...............591
Wiring Diagram .................................................... .591
SERVICE DATA AND SPECIFICATIONS
(SDS) ................................................................
593
Fuel Pressure ....................................................... .593
Idle Speed and Ignition Timing .............................593
Calculated Load Value ..........................................593
Mass Air Flow Sensor ...........................................593
Intake Air Temperature Sensor .............................593
Engine Coolant Temperature Sensor ...................593
Air Fuel Ratio (A/F) Sensor 1 Heater ....................593
Heated Oxygen sensor 2 Heater ..........................593
Crankshaft Position Sensor (POS) .......................594
Camshaft Position Sensor (PHASE) .....................594
Throttle Control Motor .......................................... .594
Fuel Injector ..........................................................594
Fuel Pump .............................................................594
VK45DE
SERVICE INFORMATION .. .......................
595
INDEX FOR DTC ............................................ ..595
DTC No. Index ..................................................... .595
Alphabetical Index .................................................598
PRECAUTIONS .............................................. ..603
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. .
603
Precaution for Procedure without Cowl Top Cover .603
On Board Diagnosis (OBD) System of Engine and
A/T ........................................................................
603
Precaution .............................................................604
PREPARATION ................................................607
Special Service Tool ............................................ .607
Commercial Service Tool ......................................608
ENGINE CONTROL SYSTEM ..........................609
Schematic ............................................................ .609
Multiport Fuel Injection (MFI) System ...................609
Electronic Ignition (EI) System ..............................612
Fuel Cut Control (at No Load and High Engine
Speed) ..................................................................
612
AIR CONDITIONING CUT CONTROL .............614
Input/Output Signal Chart .................................... .614
System Description ...............................................614
AUTOMATIC SPEED CONTROL DEVICE
(ASCD) ..............................................................
615
System Description .............................................. .615
Component Description ........................................616
CAN COMMUNICATION ..................................617
System Description .............................................. .617
EVAPORATIVE EMISSION SYSTEM ..............618
Description ........................................................... .618
Component Inspection ..........................................620
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1255 of 3924
EC-15
C
DE
F
G H
I
J
K L
M
EC A
N
O P
DTC P2119 ELECTRIC THROTTLE CON-
TROL ACTUATOR .........................................
1102
Component Description .......................................1102
On Board Diagnosis Logic ..................................1102
DTC Confirmation Procedure ..............................1102
Diagnosis Procedure ...........................................1103
DTC P2122, P2123 APP SENSOR ................1104
Component Description .......................................1104
CONSULT-III Refe rence Value in Data Monitor
Mode ...................................................................
1104
On Board Diagnosis Logic ..................................1104
DTC Confirmation Procedure ..............................1105
Wiring Diagram ...................................................1106
Diagnosis Procedure ...........................................1107
Component Inspection ........................................1109
Removal and Installation .....................................1109
DTC P2127, P2128 APP SENSOR ................1110
Component Description .......................................1110
CONSULT-III Refe rence Value in Data Monitor
Mode ...................................................................
1110
On Board Diagnosis Logic ..................................1110
DTC Confirmation Procedure ..............................1110
Wiring Diagram ...................................................1111
Diagnosis Procedure ...........................................1112
Component Inspection ........................................1115
Removal and Installation .....................................1115
DTC P2135 TP SENSOR ...............................1116
Component Description .......................................1116
CONSULT-III Refe rence Value in Data Monitor
Mode ...................................................................
1116
On Board Diagnosis Logic ..................................1116
DTC Confirmation Procedure ..............................1116
Wiring Diagram ...................................................1117
Diagnosis Procedure ...........................................1118
Component Inspection ........................................1120
Removal and Installation .....................................1121
DTC P2138 APP SENSOR .............................1122
Component Description .......................................1122
CONSULT-III Refe rence Value in Data Monitor
Mode ...................................................................
1122
On Board Diagnosis Logic ..................................1122
DTC Confirmation Procedure ..............................1123
Wiring Diagram ...................................................1124
Diagnosis Procedure ...........................................1125
Component Inspection ........................................1128
Removal and Installation .....................................1128
DTC P2A00, P2A03 A/F SENSOR 1 ..............1129
Component Description .......................................1129
CONSULT-III Refe rence Value in Data Monitor
Mode ...................................................................
1129
On Board Diagnosis Logic ..................................1129
DTC Confirmation Procedure ..............................1129
Wiring Diagram ...................................................1131
Diagnosis Procedure ...........................................1134
Removal and Installation .....................................1138
ASCD BRAKE SWITCH .................................1139
Component Description .......................................1139
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1139
Wiring Diagram ....................................................1140
Diagnosis Procedure ...........................................1141
Component Inspection .........................................1142
ASCD INDICATOR .........................................1144
Component Description .......................................1144
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1144
Wiring Diagram ....................................................1145
Diagnosis Procedure ...........................................1145
ELECTRICAL LOAD SIGNAL .......................1147
Description ...........................................................1147
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1147
Diagnosis Procedure ...........................................1147
FUEL INJECTOR ...........................................1149
Component Description .......................................1149
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1149
Wiring Diagram ....................................................1150
Diagnosis Procedure ...........................................1151
Component Inspection .........................................1154
Removal and Installation .....................................1154
FUEL PUMP ...................................................1155
Description ...........................................................1155
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1155
Wiring Diagram ....................................................1156
Diagnosis Procedure ...........................................1157
Component Inspection .........................................1159
Removal and Installation .....................................1159
ICC BRAKE SWITCH .....................................1160
Component Description .......................................1160
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1160
Wiring Diagram ....................................................1161
Diagnosis Procedure ...........................................1162
Component Inspection .........................................1164
IGNITION SIGNAL .........................................1166
Component Description .......................................1166
Wiring Diagram ....................................................1167
Diagnosis Procedure ...........................................1172
Component Inspection .........................................1175
Removal and Installation .....................................1176
REFRIGERANT PRESSURE SENSOR .........1177
Component Description .......................................1177
Wiring Diagram ....................................................1178
Diagnosis Procedure ...........................................1179
Removal and Installation .....................................1181
SNOW MODE SWITCH ..................................1182
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1256 of 3924
EC-16
Description ...........................................................1182
CONSULT-III Reference Value in Data Monitor
Mode ....................................................................
1182
Wiring Diagram ....................................................1183
Diagnosis Procedure ...........................................1183
Component Inspection .........................................1185
VARIABLE INDUCTION AIR CONTROL SYS-
TEM (VIAS) .....................................................
1187
Description ...........................................................1187
CONSULT-III Reference Va lue in Data Monitor
Mode ....................................................................
1188
Wiring Diagram ....................................................1189
Diagnosis Procedure ...........................................1190
Component Inspection .........................................1193
Removal and Installation .....................................1193
MIL AND DATA LINK CONNECTOR .............1194
Wiring Diagram ....................................................1194
SERVICE DATA AND SPECIFICATIONS
(SDS) ..............................................................
1196
Fuel Pressure .......................................................1196
Idle Speed and Ignition Timing ............................1196
Calculated Load Value .........................................1196
Mass Air Flow Sensor ..........................................1196
Intake Air Temperature Sensor ............................1196
Engine Coolant Temperature Sensor ..................1196
Fuel Tank Temperature Sensor ...........................1196
Crankshaft Position Sensor (POS) ......................1197
Camshaft Position Sensor (PHASE) ....................1197
A/F Sensor 1 Heater ............................................1197
Heated Oxygen sensor 2 Heater .........................1197
Throttle Control Motor ..........................................1197
Fuel Injector .........................................................1197
Fuel Pump ............................................................1197
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1268 of 3924
![INFINITI FX35 2008 Service Manual
EC-28
< SERVICE INFORMATION >[VQ35DE]
PRECAUTIONS
B1 indicates the bank 1, B2 indicates the bank 2 as shown in
the figure.
Do not operate fuel pump when there is no fuel in lines.
Tighten fue](/img/42/57017/w960_57017-1267.png "INFINITI FX35 2008 Service Manual
EC-28
< SERVICE INFORMATION >[VQ35DE]
PRECAUTIONS
B1 indicates the bank 1, B2 indicates the bank 2 as shown in
the figure.
Do not operate fuel pump when there is no fuel in lines.
Tighten fue")
EC-28
< SERVICE INFORMATION >[VQ35DE]
PRECAUTIONS
B1 indicates the bank 1, B2 indicates the bank 2 as shown in
the figure.
Do not operate fuel pump when there is no fuel in lines.
Tighten fuel hose clamps to the specified torque.
Do not depress accelerator pedal when starting.
Immediately after starting, do not rev up engine unnecessar-
ily.
Do not rev up engine just prior to shutdown.
When installing C.B. ham radio or a mobile phone, be sure to
observe the following as it m ay adversely affect electronic
control systems depending on installation location.
- Keep the antenna as far as possi ble from the electronic con-
trol units.
- Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
- Adjust the antenna and feeder line so that the standing-wave
radio can be kept smaller.
- Be sure to ground the radio to vehicle body.
SEC893C
PBIB1569E
SEF709Y
SEF708Y
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1284 of 3924
![INFINITI FX35 2008 Service Manual
EC-44
< SERVICE INFORMATION >[VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Positive pressure is delivered to the EVAP system through the EVAP
service port. If fuel vapor leak
age in the EVAP system occurs, us](/img/42/57017/w960_57017-1283.png "INFINITI FX35 2008 Service Manual
EC-44
< SERVICE INFORMATION >[VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Positive pressure is delivered to the EVAP system through the EVAP
service port. If fuel vapor leak
age in the EVAP system occurs, us")
EC-44
< SERVICE INFORMATION >[VQ35DE]
EVAPORATIVE EMISSION SYSTEM
Positive pressure is delivered to the EVAP system through the EVAP
service port. If fuel vapor leak
age in the EVAP system occurs, use a
leak detector to locate the leak.
Removal and InstallationINFOID:0000000001325906
EVAP CANISTER
Tighten EVAP canister as shown in the figure.
EVAP CANISTER VENT CONTROL VALVE
1. Turn EVAP canister vent control valve counterclockwise.
2. Remove the EVAP canister vent control valve.
Always replace O-ring with a new one.
How to Detect Fuel Vapor LeakageINFOID:0000000001325907
CAUTION:
Never use compressed air or a high pressure pump.
Do not exceed 4.12 kPa (0.042 kg/cm
2, 0.6 psi) of pressure in EVAP system.
NOTE:
Do not start engine.
Improper installation of EVAP service port adapt er to the EVAP service port may cause a leak.
WITH CONSULT-III
1. Attach the EVAP service port adapter securely to the EVAP service port.
2. Also attach the pressure pump and hose to the EVAP service port adapter.
SEF462UA
PBIB1029E
PBIB1030E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1286 of 3924
![INFINITI FX35 2008 Service Manual
EC-46
< SERVICE INFORMATION >[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VA
POR RECOVERY (ORVR)
System DescriptionINFOID:0000000001325908
From the beginning of refueling, the](/img/42/57017/w960_57017-1285.png "INFINITI FX35 2008 Service Manual
EC-46
< SERVICE INFORMATION >[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VA
POR RECOVERY (ORVR)
System DescriptionINFOID:0000000001325908
From the beginning of refueling, the")
EC-46
< SERVICE INFORMATION >[VQ35DE]
ON BOARD REFUELING VAPOR RECOVERY (ORVR)
ON BOARD REFUELING VA
POR RECOVERY (ORVR)
System DescriptionINFOID:0000000001325908
From the beginning of refueling, the air and vapor insi de the fuel tank go through refueling EVAP vapor cut
valve and EVAP/ORVR line to the EVAP canister. The vapor is absorbed by the EVAP canister and the air is
released to the atmosphere.
When the refueling has reached the full level of the fuel tank, the refueling EVAP vapor cut valve is closed and
refueling is stopped because of auto shut-off. The vapor which was absorbed by the EVAP canister is purged
during driving.
WARNING:
When conducting inspections below, be sure to observe the following:
Put a “CAUTION: FLAMMABLE” sign in workshop.
Do not smoke while servicing fuel system. Keep open flames and sparks away from work area.
Be sure to furnish the workshop with a CO
2 fire extinguisher.
CAUTION:
Before removing fuel line parts, carry out the following procedures:
- Put drained fuel in an explosion-pr oof container and put lid on securely.
- Release fuel pressure from fuel line. Refer to EC-87, "
Fuel Pressure Check".
- Disconnect negative battery cable.
Always replace O-ring when the fuel gauge retainer is removed.
Do not kink or twist hose and tube when they are installed.
Do not tighten hose and clamps excessively to avoid damaging hoses.
After installation, run engine an d check for fuel leaks at connection.
Do not attempt to top off the fuel tank afte r the fuel pump nozzle shuts off automatically.
Continued refueling may cause fu el overflow, resulting in fuel spray and possibly a fire.
Diagnosis ProcedureINFOID:0000000001325909
SYMPTOM: FUEL ODOR FROM EVAP CANISTER IS STRONG.
1.CHECK EVAP CANISTER
1. Remove EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
2. Weigh the EVAP canister with EVAP canister vent control valve and EVAP control system pressure sensor
attached.
The weight should be l ess than 2.1 kg (4.6 lb).
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
PBIB1068E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
