jacking points INFINITI FX35 2008 Service Manual

EM-112
< SERVICE INFORMATION >[VQ35DE]
ENGINE ASSEMBLY
ENGINE ASSEMBLY
Component (2WD Models)INFOID:0000000001325742
Removal and Installation (2WD Models)INFOID:0000000001325743
WARNING:
 Situate the vehicle on a flat and solid surface.
 Place chocks at front and back of rear wheels.
 For engines not equipped with en
gine slingers, attach proper slingers and bolts described in PARTS
CATALOG.
CAUTION:
 Always be careful to work safely, avoid forceful or uninstructed operations.
 Do not start working until exhaust system and engine coolant are cool enough.
 If items or work required are no t covered by the engine section, refer to the applicable sections.
 Always use the support poin t specified for lifting.
 Use either 2-pole lift type or separate type lift as best you can. If board-on type is used for unavoid-
able reasons, support at rear axle jacking point with transmission jack or similar tool before starting
work, in preparation for the backward shift of center of gravity.
 For supporting points for lifting and jacking point at rear axle, refer to GI-37, "
Garage Jack and
Safety Stand".
REMOVAL
Outline
1. Engine mounting bracket (RH) 2. Heat insulator (RH) 3. Engine mounting insulator (RH)
4. Engine mounting insulator (LH) 5. Heat insulator (LH) 6. Engine mounting bracket (LH)
7. Harness bracket 8. Engine mounting insulator (rear) 9. Rear engine mounting member
PBIC3039E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ENGINE ASSEMBLYEM-115
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
 Make sure that all connection
points have been disconnected.
 Keep in mind the center of vehicle gravity cha nges. If necessary, use jack(s) to support the vehi-
cle at rear jacking point(s) to preven t it from falling it off the lift.
Separation Work
1. Install engine slingers into front of cylinder head (right bank) and
rear of cylinder head (left bank).
 To protect rocker cover against damage caused by tilting ofengine slinger, insert spacer between cylinder head and
engine rear lower slinger, in direction shown in the figure.
NOTE:
Spacer is a component part of engine rear upper slinger
assembly.
2. Remove power steering oil pump from engine side. Refer to PS-27, "
On-Vehicle Inspection and Service".
3. Remove engine mounting insulators (RH and LH) under side nuts with power tool.
4. Lift with hoist and separate the engine and the trans mission assembly from front suspension member.
CAUTION:
 Before and during this lifting, always make sure that any harnesses are left connected.
 Avoid damage to and oil/grease smearing or spills onto engine mounting insulator.
5. Remove alternator. Refer to SC-19, "
System Description".
6. Remove starter motor. Refer to SC-8, "
System Description".
7. Separate the engine from the transmission assembly. Refer to AT-241, "
Removal and Installation (2WD
Models)".
8. Remove each engine mounting insulator and each engine mounting bracket from the engine with power tool.
9. Remove rear engine mounting member and engine mounting insulator (rear) from the transmission assembly.
INSTALLATION
Note the following, and install in the reverse order of removal.
 Do not allow engine mounting insulator to be damage and careful no oil gets on it.
 For a location with a positioning pin, insert it securely into hole of mating part.
 For a part with a specified installation orientation, refer to component figure in EM-112, "
Component (2WD
Models)".
Slinger bolts:
: 28.0 N·m (2.9 kg-m, 21 ft-lb)
PBIC2061E
KBIA1017E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ENGINE ASSEMBLYEM-117
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
Component (AWD Models)INFOID:0000000001325744
Removal and Installation (AWD Models)INFOID:0000000001325745
WARNING:
 Situate the vehicle on a flat and solid surface.
 Place chocks at front and back of rear wheels.
 For engines not equipped with engi
ne slingers, attach proper slingers and bolts described in PARTS
CATALOG.
CAUTION:
 Always be careful to work safely, avoid forceful or uninstructed operations.
 Do not start working until exhaust system and engine coolant are cool enough.
 If items or work required are not covered by th e engine section, refer to the applicable sections.
 Always use the support poin t specified for lifting.
 Use either 2-pole lift type or separate type lift as best you can. If board-on type is used for unavoid-
able reasons, support at rear axle jacking point with transmission jack or similar tool before starting
work, in preparation for the backward shift of center of gravity.
 For supporting points fo r lifting and jacking point at rear axle, refer to GI-37, "
Garage Jack and
Safety Stand".
REMOVAL
Outline
1. Engine mounting bracket (RH) 2. Engine mounting bracket (RH) (Low-
er)3. Dynamic damper
4. Washer 5. Engine mounting insulator (RH) 6. Engine mounting insulator (LH)
7. Engine mounting bracket (LH) 8. Harness bracket 9. Heat insulator
10. Caller 11. Rubber bush 12. Rear engine mounting member
13. Engine mounting insulator (rear) 14. Dynamic damper
PBIC3041E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EM-120
< SERVICE INFORMATION >[VQ35DE]
ENGINE ASSEMBLY
CAUTION:
 Confirm there is no interference with the vehicle.
 Make sure that all connection
points have been disconnected.
 Keep in mind the center of the vehicle gravity changes. If necessary, use jack(s) to support the
vehicle at rear jacking point(s) to pr event it from falling it off the lift.
Separation Work
1. Install engine slingers into front of cylinder head (right bank) and
rear of cylinder head (left bank).
 To protect rocker cover against damage caused by tilting ofengine slinger, insert spacer between cylinder head and
engine rear lower slinger, in direction shown in the figure.
NOTE:
Spacer is a component part of engine rear upper slinger
assembly.
2. Remove power steering oil pump from engine side. Refer to PS-27, "
On-Vehicle Inspection and Service".
3. Remove engine mounting insulators (RH and LH) under side nuts with power tool.
4. Lift with hoist and separate the engine, the transmi ssion assembly, the transfer assembly and the front
final drive assembly from front suspension member.
CAUTION:
 Before and during this lifting, always check if any harnesses are left connected.
 Avoid damage to and oil/grease smearing or spills onto engine mounting insulator.
5. Remove alternator. Refer to SC-19, "
System Description".
6. Remove starter motor. Refer to SC-8
.
7. Remove front propeller shaft from the front final drive assembly side. Refer to PR-4, "
On-Vehicle Inspec-
tion".
8. Separate the engine from the transmission assembly. Refer to AT-241, "
Removal and Installation (2WD
Models)".
9. Remove the front final drive assembly from oil pan (upper). Refer to FFD-14, "
Removal and Installation
(VQ35DE Models)".
10. Remove each engine mounting insulator and each engine mounting bracket from the engine with power
tool.
11. Remove rear engine mounting member and engine m ounting insulator (rear) from the transmission
assembly.
12. Remove dynamic damper from the transfer assembly.
INSTALLATION
Note the following, and install in the reverse order of removal.
 Do not allow engine mounting insulator to be damage and careful no engine oil gets on it.
 For a location with a positioning pin, insert it securely into hole of mating part.
 For a part with a specified installation orientation, refer to component figure in EM-117, "
Component (AWD
Models)".
Slinger bolts:
: 28.0 N·m (2.9 kg-m, 21 ft-lb)
PBIC2061E
KBIA1017E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ENGINE ASSEMBLYEM-237
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
ENGINE ASSEMBLY
ComponentINFOID:0000000001325801
 Refer to
GI-8, "Component" for symbols in the figure.
Removal and InstallationINFOID:0000000001325802
WARNING:
 Situate vehicle on a flat and solid surface.
 Place chocks at front and back of rear wheels.
 For engines not equipped with engi ne slingers, attach proper slingers and bolts described in PARTS
CATALOG.
CAUTION:
 Always be careful to work safely, avoid forceful or uninstructed operations.
 Do not start working until exhaust system and engine coolant are cool enough.
 If items or work required are not covered by th e engine section, refer to the applicable sections.
 Always use the support poin t specified for lifting.
 Use either 2-pole lift type or separate type lift as best you can. If board-on type is used for unavoid-
able reasons, support at the rear axle jacking poin t with transmission jack or similar tool before
starting work, in prepar ation for the backward shif t of center of gravity.
 For supporting points fo r lifting and jacking point at rear axle, refer to GI-37, "
Garage Jack and
Safety Stand".
REMOVAL
Outline
At first, remove engine, transmission assembly and front final drive with front suspension member from vehicle
downward. Then separate engine from transmission.
Preparation
1. Engine mounting bracket (RH) 2. Engine mounting insulator (RH) 3. Engine mounting bracket (LH)
4. Engine mounting insulator (LH) 5. Plate 6. Collar
7. Grommet 8. Engine rear member 9. Engine mounting insulator (rear)
JPBIA0902GB
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ENGINE ASSEMBLYEM-239
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
10. Disconnect steering lower joint at power steering gear
assembly side, and release steering lower shaft.
Refer to PS-12, "
Removal and Installation".
11. Remove rear propeller shaft. Refer to PR-7, "
On-Vehicle Inspection".
 After disconnection, plug the opening on transmission side.
12. Remove front drive shaft (both side). Refer to FAX-13, "
On-Vehicle Inspection".
13. Remove front propeller shaft. Refer to PR-4, "
On-Vehicle Inspection".
14. Remove three way catalyst (both bank). Refer to EM-179, "
Component".
Removal Work
1. Install engine slingers into front of cylinder head (left bank) and
front of cylinder head (right bank).
2. Lift with hoist and secure engine in position.
3. Use manual lift table caddy (commercial service tool) or equivalently rigid tool such as transmission jack. Securely support bottom of suspension member and transmission.
CAUTION:
Put a piece of wood or something similar as the supporting surface, secure a completely stable
condition.
4. Remove engine rear member mounting bolts.
5. Remove front suspension member mounting nuts with power tool. Refer to FSU-5, "
On-Vehicle Inspection
and Service".
6. Carefully lower jack, or raise lift to remove engine, transmission front final drive and front suspension member assembly. When
performing work, observe the following caution:
CAUTION:
 Confirm there is no interference with vehicle.
 Make sure that all connectio n points have been discon-
nected.
 Keep in mind the center of veh icle gravity changes. If nec-
essary, use jack(s) to support vehicle at rear jacking
point(s) to prevent it from falling it off the lift.
Separation Work
1. Change engine slinger installing to cylinder head (right bank).
NOTE:
In order to keep secure position when hoisting engine.
2. Remove engine mounting insulators (RH and LH) under side nut with power tool.
3. Lift with hoist and separate engine and transmission assembly from front suspension member. CAUTION:
 Before and during this lifting, always make sure that any harnesses are left connected.
Slinger bolts:
: 33.4 N·m (3.4 kg-m, 25 ft-lb)
PBIC1556E
PBIC1557E
Slinger bolts: : 33.4 N·m (3.4 kg-m, 25 ft-lb)
PBIC2447E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

PRECAUTIONSGI-3
< SERVICE INFORMATION >
C
DE
F
G H
I
J
K L
M B
GI
N
O P
Precaution for Procedur e without Cowl Top CoverINFOID:0000000001612933
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
General PrecautionINFOID:0000000001325654
 Do not operate the engine for an extended period of time without
proper exhaust ventilation.
Keep the work area well ventilated and free of any flammable
materials. Special care should be taken when handling any flam-
mable or poisonous materials, such as gasoline, refrigerant gas,
etc. When working in a pit or ot her enclosed area, be sure to prop-
erly ventilate the area before working with hazardous materials.
Do not smoke while working on the vehicle.
 Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After jack-
ing up the vehicle, support the vehicle weight with safety stands at
the points designated for proper lifting before working on the vehi-
cle.
These operations should be done on a level surface.
 When removing a heavy component such as the engine or tran- saxle/transmission, be careful not to lose your balance and drop
them. Also, do not allow them to strike adjacent parts, especially
the brake tubes and master cylinder.
 Before starting repairs which do not require battery power: Turn off ignition switch.
Disconnect the negative battery terminal.
 If the battery terminals are disconnected, recorded memory of radio and each control unit is erased.
 Battery posts, terminals and related accessories contain lead and
lead compounds. Wash hands after handling.
PIIB3706J
SGI285
SGI231
SEF289H
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
