trunk INFINITI G CONVERTIBLE 2013 Owner's Manual

0-4Illustrated table of contents
GUID-28870A23-2B4B-4EAB-9C8A-4625AE3B26BE
SSI0674
1. High-mounted stop light (P.8-27)
2. Antenna (P.4-77)—Satellite radio antenna (P.4-39)
3. Rear window defroster (P.2-33)
4. Retractable hard top (P.3-18)
5. RearView Monitor camera (P.4-23) 6. Trunk (P.3-28)
—Intelligent Key system (P.3-7)
— Remote keyless entry system
(P.3-14)
7. Sonar system sensors (if so equipped) (P.5-48) 8. Rear combination light (bulb replace-
ment) (P. 8-27)
9. Fuel-filler door —Operation (P.3-31)
— Fuel recommendation (P.9-4)
EXTERIOR REAR

GUID-2075472C-6623-4D22-B652-4F7655531773
SSI0819
1. Vehicle Dynamic Control (VDC) OFFswitch (P.5-55)
2. Trunk lid release switch (P.3-28)
3. Sonar system OFF switch (if so
equipped) (P.5-50) 4. Instrument brightness control switch
(P.2-37)
5. TRIP/RESET switch for twin trip od- ometer (P.2-7)
6. Headlight, fog light and turn signal switch (P.2-33) 7. Paddle shifter (if so equipped) (P.5-16)
8. Steering-wheel-mounted controls (Left
side)
—ENTER or tuning switch (P.4-76)
— BACK switch (P.4-76)
— TALK switch (P.4-103)/Phone
switch (P.4-79, 4-89)
— Volume control switches (P.4-76)
— Source select switch (P.4-76)
9. Trip computer switch (P.2-25)
10. Windshield wiper and washer switch (P.2-30)
11. Steering-wheel-mounted controls
(Right side)
—Cruise control switches (P.5-21)
— Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-23)
12. Hood release handle (P.3-17)
13. Intelligent Key port (P.5-9)
14. Electric tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
15. Manual tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
16. Steering wheel —Horn (P.2-39)
— Driver supplemental air bag
(P.1-35)
Illustrated table of contents0-7
COCKPIT

17. Retractable hard top operating switch(P.3-18)
18. Rear window and outside mirror
defroster switch (P.2-33)
19. Glove box lid release handle (P.2-46)
20. Trunk release power cancel switch (P.3-29)
*: Refer to the separate Navigation System
Owner’s Manual.
Illustrated table of contents0-9

Interior lights...
................................................... 2-51
Map lights ...
..................................................... 2-51
Interior light control switch ...
............................ 2-52
Vanity mirror lights ...
............................................ 2-53
Trunk light ...
......................................................... 2-53
HomeLink
®Universal Transceiver (if
so equipped) ...
..................................................... 2-53
Programming HomeLink
®...
.............................. 2-54 Programming HomeLink
®for Canadian
customers and gate openers ...
........................ 2-56
Operating the HomeLink
®
Universal Transceiver ...
................................... 2-56
Programming troubleshooting ...
...................... 2-56
Clearing the programmed information ...
.......... 2-57
Reprogramming a single
HomeLink
®button ...
....................................... 2-57
If your vehicle is stolen ...
............................... 2-57

GUID-3D0B5C00-6F2B-4B4E-80B4-0BCB718F22F5
SSI0819
1. Vehicle Dynamic Control (VDC) OFFswitch (P.5-55)
2. Trunk lid release switch (P.3-28)
3. Sonar system OFF switch (if so
equipped) (P.5-50) 4. Instrument brightness control switch
(P.2-37)
5. TRIP/RESET switch for twin trip od- ometer (P.2-7)
6. Headlight, fog light and turn signal switch (P.2-33) 7. Paddle shifter (if so equipped) (P.5-16)
8. Steering-wheel-mounted controls (Left
side)
—ENTER or tuning switch (P.4-76)
— BACK switch (P.4-76)
— TALK switch (P.4-103)/Phone
switch (P.4-79, 4-89)
— Volume control switches (P.4-76)
— Source select switch (P.4-76)
9. Trip computer switch (P.2-25)
10. Windshield wiper and washer switch (P.2-30)
11. Steering-wheel-mounted controls
(Right side)
—Cruise control switches (P.5-21)
— Intelligent Cruise Control (ICC)
switches (if so equipped) (P.5-23)
12. Hood release handle (P.3-17)
13. Intelligent Key port (P.5-9)
14. Electric tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
15. Manual tilting/telescopic steering
wheel lever (if so equipped) (P.3-34)
16. Steering wheel —Horn (P.2-39)
— Driver supplemental air bag
(P.1-35)
Instruments and controls2-3
COCKPIT

18. Rear window and outside mirror (if soequipped) defroster switch (P.2-33)
19. Glove box lid release handle (P.2-46)
20. Trunk release power cancel switch (P.3-29)
*: Refer to the separate Navigation System
Owner’s Manual.
Instruments and controls2-5

2-14Instruments and controls
.Parking brake release warning
. Door/trunk open warning
. Loose fuel cap warning
. Check tire pressure warning
See “Dot matrix liquid crystal display” (P.2-
17).
Preview Function warning light
(orange; if so equipped)
GUID-82B96A00-53B7-4A66-B4A8-0DC25F7726B2The light comes on if there is a malfunction
in the Brake Assist (with Preview Function)
system.
If the warning light comes on, park the
vehicle in a safe place. Turn the engine off,
restart the engine, resume driving and set
the ICC system again.
If it is not possible to set the system or the
indicator stays on, it may indicate that the
system is malfunctioning. Although the
vehicle is still driveable under normal
conditions, have the vehicle checked at
an INFINITI retailer.
Seat belt warning lightGUID-97087213-3971-4726-A0FE-1FFDDC320E7EThe light and chime remind you to fasten
seat belts. The light illuminates whenever
the ignition switch is pushed to the ON
position, and will remain illuminated until
the driver’s seat belt is fastened. At the same time, the chime will sound for about
6 seconds unless the driver’s seat belt is
securely fastened.
The seat belt warning light for the front
passenger will illuminate if the seat belt is
not fastened when the front passenger’s
seat is occupied. For approximately 5
seconds after the ignition switch is in the
ON position, the system does not activate
the warning light for the front passenger.
See
“Seat belts” (P.1-11) for precautions
on seat belt usage.
Supplemental air bag warning
light
GUID-C450F6BC-AD31-42E7-A143-D8289371BB6EAfter pushing the ignition switch to the ON
position, the supplemental air bag warning
light will illuminate. The supplemental air
bag warning light will turn off after about 7
seconds if the supplemental front air bag
and supplemental side air bag, curtain
side-impact air bag systems and/or pre-
tensioner seat belt are operational.
If any of the following conditions occur, the
front air bag, side air bag, curtain air bag
and pretensioner systems needs servicing
and your vehicle must be taken to your
nearest INFINITI retailer. .
The supplemental air bag warning light
remains on after approximately 7 sec-
onds.
. The supplemental air bag warning light
flashes intermittently.
. The supplemental air bag warning light
does not come on at all.
Unless checked and repaired, the supple-
mental restraint systems and/or the pre-
tensioners may not function properly.
For additional information, see “Supple-
mental restraint system” (P.1-35).
WARNING
If the supplemental air bag warning light is
on, it could mean that the front air bag, side
air bag, curtain air bag systems and/or
pretensioner systems will not operate in an
accident. To help avoid injury to yourself or
others, have your vehicle checked by a
retailer as soon as possible.
Vehicle Dynamic Control (VDC)
warning light
GUID-B300F4AE-A31B-490C-8B0C-44DBA460C228The light will blink when the VDC system or
the traction control system is operating,

2-20Instruments and controls
8. Engine start operation indicator
(Manual Transmission models)
GUID-DBDAE3A2-CB00-42CF-830F-56CFC89016D9This indicator means that the engine will
start by pushing the ignition switch with
the clutch pedal depressed.
9. Parking brake release warningGUID-A29E560B-AC65-45EF-BD61-D46B01E8D317This warning appears when the vehicle
speed is above 4 MPH (7 km/h) and the
parking brake is applied.
10. Low fuel warningGUID-C398ED0E-471A-4276-8E87-41D8B1B5D7C6This warning appears when the fuel level in
the tank is getting low. Refuel as soon as it
is convenient, preferably before the fuel
gauge reaches the empty (E) position.
There is a small reserve of fuel remaining
in the tank when the fuel gauge reaches
the empty (E) position.
11. Low washer fluid warningGUID-4B511101-A790-47D3-8A2A-05D513567AC2This warning appears when the washer
tank fluid is at a low level. Add washer fluid
as necessary. (See“Window washer fluid”
(P.8-14).)
12. Door/trunk open warning (igni-
tion switch is in the ON position)
GUID-D73931C6-CD04-450C-81A1-47A834D609C5This warning appears if any of the doors and/or the trunk lid are open or not closed
securely. The vehicle icon indicates which
door or the trunk lid is open on the display.
13. Loose fuel cap warningGUID-BFE458ED-BCA7-4335-B8F7-73E37C39ABB7This warning appears when the fuel-filler
cap is not tightened correctly after the
vehicle has been refueled. (See
“Fuel-filler
cap ”(P.3-32).)
14. Check tire pressure warningGUID-4F8F90C9-1D1A-4B19-84DE-FB30ADE966CCThis warning appears when the low tire
pressure warning light in the meter illumi-
nates and low tire pressure is detected. If
this warning appears, stop the vehicle and
adjust the tire pressure to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label. (See
“Low tire pressure warning light” (P.2-12)
and “Tire Pressure Monitoring System
(TPMS)” (P.5-4).)
15.“Time to rest” indicatorGUID-ED5D6E04-83A9-4A18-A337-1F03BC066E77This indicator appears when the set “time
to rest” indicator activates. You can set the
time for up to 6 hours. (See “Trip
computer” (P.2-25).)
16. Low outside temperature warn-
ing
GUID-780F773F-FB50-4944-8B7B-E69CA36895B2This warning appears if the outside tem-
perature is below 378F (38C). The warning
can be set not to be displayed. (See “Trip
computer” (P.2-25).)
17. Cruise indicatorGUID-3760C120-A3D7-4293-8781-3D4A6A9A5294Cruise main switch indicator:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The indicator is displayed when the cruise
control main switch is pushed. When the
main switch is pushed again, the indicator
disappears. When the cruise control main
switch indicator is displayed, the cruise
control system is operational.
Cruise set switch indicator:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407The indicator is displayed while the vehicle
speed is controlled by the cruise control
system. If the indicator blinks while the
engine is running, it may indicate that the
cruise control system is not functioning
properly. Have the system checked by an
INFINITI retailer.
See“Cruise control” (P.5-21) for details.

2-22Instruments and controls
SIC4168
INDICATORS FOR RETRACTABLE
HARD TOP
GUID-BCD3B15A-CB19-4506-8E3A-09721E0189BBThis indicates the operating state of the
retractable hard top. Displays a message
and displays the status of the hard top.
(See“Retractable hard top” (P.3-18).)
1. Roof in operation indicatorGUID-D636E123-7DDB-4B5D-BB31-B9CA3B944A6AThis indicator is displayed while the
retractable hard top is being operated.
2. Roof open indicatorGUID-41117CBE-E9C8-444A-B37A-E1DAA9EE7358This indicator is displayed when the
retractable hard top is open completely.
3. Roof close indicatorGUID-D41688BF-9BCD-4951-994A-03783776CCBCThis indicator is displayed when the
retractable hard top is closed completely.
4. Check separator indicatorGUID-EE9BAE15-AD0A-4747-A8AA-858CE2D67898This indicator is displayed when the
separator is not set in the holder normally.
5. Check trunk indicatorGUID-8B5E2228-6166-48E0-9C79-AE7703B80996This indicator is displayed when the trunk
is not closed completely.
NOTE:
A message is not displayed while the
Intelligent Cruise Control (ICC) system (if

.BACK
Select this submenu to return to the top
page of the setting mode.
. LANGUAGE
Select this submenu to choose English
or French for display.
. UNIT
Select this submenu to choose the unit
from MPG or l/100 km.
7. Warning checkGUID-B3B1E243-1A4C-443C-A389-E370A01A522CSKIP:GUID-D73A39BF-43C8-459F-9C24-47B7F579C407Push theswitch*Ato move to the
warning check mode.
Push the
switch*Bto select other
menus.
DETAIL:
GUID-D73A39BF-43C8-459F-9C24-47B7F579C407This item is available only when a warning
is displayed.
Select this menu to see the details of
warnings.
GUID-5140D3C5-BD2C-4A49-A516-5D14A5F9BFAC
SIC4169
Your vehicle has two types of security
systems, as follows:
. Vehicle security system
. INFINITI Vehicle Immobilizer System
The security condition will be shown by the
security indicator light.
VEHICLE SECURITY SYSTEMGUID-2E01F60E-CDBB-451D-A069-BFD7EDFAACCDThe vehicle security system provides visual
and audio alarm signals if someone opens
the doors, hood, or trunk lid when the
system is armed. It is not, however, a
motion detection type system that acti-
vates when a vehicle is moved or when a
vibration occurs.
The system helps deter vehicle theft but
cannot prevent it, nor can it prevent the
theft of interior or exterior vehicle compo-
nents in all situations. Always secure your
vehicle even if parking for a brief period.
Never leave your Intelligent Key(s) in the
vehicle, and always lock it when unat-
tended. Be aware of your surroundings,
and park in secure, well-lit areas whenever
possible.
Many devices offering additional protec-
tion, such as component locks, identifica-
tion markers, and tracking systems, are
available at auto supply stores and speci-
alty shops. Your INFINITI retailer may also
offer such equipment. Check with your
insurance company to see if you may be
eligible for discounts for various theft
protection features.
Instruments and controls2-27
SECURITY SYSTEMS
