INFINITI G CONVERTIBLE 2013 Quick Reference Guide

Quick Reference Guide2013 Infiniti G
Coupe/Convertible

*See your Owner’s Manual for information.
01 INSTRUMENT BRIGHTNESS CONTROL*
02 TRIP COMPUTER SWITCHES
03 HEADLIGHT AND TURN SIGNAL CONTROL
04 LOW TIRE PRESSURE
WARNING LIGHT
05 DOT MATRI x LIQUID CR yS TAL DISPLAy
06 WINDSHIELD WIPER / WASHER SWITCH
07 TRIP A/B RE SET BUTTON*
08 STEERING WHEEL SWITCHES
FOR A
UDIO* / BLUETOOTH®
09 CRUIS E CONTROL
10 PUSH BUT TON IGNITION SWITCH
11 VEHICLE Dy NAMIC CONTROL (VDC) OFF SWITCH*
01
0710
19
18
20
212221
111213
14
040317
12 TRUNK RELEASE SWITCH
13
REAR SONAR SyS TEM SWITCH *
14 TILT AND TELESCOPIC STEERING COLUMN*
15 INTELLIGENT KE y POR T
16 HOOD RELEASE*
17 CONTROL PANEL DISPLAy
18 A UDIO SyS TEM
19 AUTOMATIC CLIMATE CONTROLS
20 FRONT P ASSENGER AIR BAG
STATUS LIGHT*
21 CLIMATE CONTROLLED
SEAT SWITCH ES *
22 HARD TOP OPEN / CLOSE SWITCH
0908
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
05
02
06
15
16

table of contents
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
• A cellular telephone should not be used for any purpose while driving so full attention
m ay be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
r

estraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition
systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
essential information Loose Fuel Cap .................................................2 Tir
e Pressure Monitoring System (TPMS) ............................2 Openin

g/Closing the Hard Top (Convertible models) ..................
3 Aut

omatic Power Windows
.......................................3 A

ccessing the Front Cup Holders (if so equipped)
.....................3
first drive features INFINITI Int elligent Key™ System..................................4 T
runk Lid Release
...............................................5 Se

at Adjustments
...............................................5 Se

at Belt Guide (Convertible models)
...............................6 P

assenger Rear Seat Entry/Exit
....................................6 Aut

omatic Drive Positioner (if so equipped)
..........................6 Outs

ide Mirror Control Switch .....................................
7 St

arting/Stopping the Engine .....................................
7


He

adlight Control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . 8
W

indshield Wiper/Washer Switch
..................................9


C

limate Controls (if so equipped) ..................................
9 FM/AM/Sirius

x
M
™ Satellite Radio With CD/DVD Player (with Navigation System) (if so equipped)
................................................11

USB/iPod
® Interface (if so equipped) ..................................12 C
onventional (Fixed Speed) Cruise Control .........................12 Intelligent Cruise Control (ICC) System (if so equipped)

...............
13 Openin

g/Closing the Hard Top (Convertible models) .................
14 F

uel-Filler Door ................................................
14
system guide Trip Computer.................................................15 Bluetooth® Hands-free Phone System (if so equipped) ...............15

System Operating Tips ........................................15
Bluet

ooth
® System with Navigation (if so equipped)................16 Bluet
ooth® System without Navigation (if so equipped).............18 Nav
igation System (if so equipped) ...............................19 D

VD Player (if so equipped)
......................................20

HomeLink
® Universal Transceiver (if so equipped) ...................21

2
essential information
Loose Fuel Cap
A LOOSE FUEL CAP
warning message will appear in



the dot
matrix liquid crystal display
01 when the
fuel-filler cap is not tightened correctly.
T o tighten, turn the cap clockwise until a single click



is h
eard.
The warning message will disappear when the vehicle



detects the fuel-filler cap is properly tightened and the




reset button 02 is pressed for about 1 second.
If the cap is not properly tightened, the Malfunction




Indicator Light may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and
the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Tire Pressure Monitoring System (TPMS)
A
Ch
EC k t I r E P r ESSU r E warning message will



ap
pear in the dot matrix liquid crystal display
01
and the lo
w tire pressure warning light 02 will

i
lluminate when one or more tires are low on



pr

essure and air is needed.
• The

tire

pressures


should

be

checked

when the




tir

es are cold. The tires are considered cold after



the

vehicle has been parked for 3 hours or more or



driv

en less than 1 mile (1.6km) at moderate speeds.
Af ter tire pressures are adjusted, drive the vehicle



at
speeds above 16 MPH (25km/h). The C h EC k



t I r E P r ESSU r E warning message and low tire



pr
essure warning light will disappear.
When the lo w tire pressure warning light flashes for 1 minute and then remains on, the TPMS



i
s not functioning properly. Have the system checked by an INFINITI retailer.
Tir e pressure rises and falls depending on the heat caused by the vehicle’s operation and the



outs
ide temperature. Low outside temperature can lower the temperature of the air inside the



tir
e, which can cause a lower tire inflation pressure. This may cause the low tire pressure



w
arning light to illuminate. If the warning light illuminates in low ambient temperature, check



the tir
e pressure in your tires.
• Check


the tire pressure (including the spare tire) often and always

prior to long distance trips.
The Tire and Loading Information label contains valuable information. Please refer to section 9,



“T
echnical and consumer information”, in your Owner’s Manual for the location of the Tire and



L
oading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
01
02
02
01

3
Opening/Closing the Hard Top (Convertible models)
The h
ard top can ONLy be oper ated when the trunk



a
rea is EMP t Y and the separator partition

01 is in
the upright
position and secured in its holders.
NO
t

E:
t

he trunk area must be absolutely empty or it may
result in damage to the hard top.
A VOID stopping the retractable hard top OPEN/CLOSE



oper
ation mid-way through the process. If left in the



mid-po
sition, the hard top may creep to its fully



r
etracted position potentially causing roof damage.
For more information, refer to the “Pre-driving checks and adjustment (section 3)” of your Owner’s Manual.
Accessing the Front Cup Holders (if so equipped)
T o open the cup holders, push the lid
01 down and
r
elease.
The flap 02 will fold down when inserting a

l
arge container.
For more information, refer to the “Instruments and controls (section 2)” of
your Owner’s Manual.
Automatic Power Windows
your po wer windows have an automatic adjusting



f
unction to ensure windows close completely to help



se
al against wind noise and weather leaks.
When the fr ont doors are being opened, the windows



aut
omatically lower slightly to avoid contact between



the w
indows and the side roof panels.
If your vehicle’s battery is discharged or disconnected,



y
our power window automatic function will not operate.
R efer to your Owner’s Manual for information to initialize




your power window system.
If the power window functions do not operate properly



af
ter initializing the system, have your vehicle checked



b
y an INFINITI retailer.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
01
01
02

4
first drive features
INFINITI Intelligent Key™ System
The INFINITI Intelligent Key™ system allows you to lock or
unlock the vehicle, open the trunk and start the engine.
NOTE: It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The oper ating range of the Intelligent Key is within



31.5 in (80 c
m) from each request switch.
To lock the vehicle, push either door handle request
s

witch
01 once or press the
button
02 on
the k
eyfob.
T o unlock the vehicle, perform one of the following procedures:
• Push
either door handle request

switch
01 once; the
c
orresponding door will unlock. Push the door handle



r

equest switch
01 again within 1 minute; all other
door
s will unlock, or
• Press


the
button
03 on the keyfob to unlock the driver’s

s
ide door. Press the
button again; all other doors will unlock.
T
o release the trunk lid, press the button
04 for more than
1 sec
ond. Lift the trunk lid to access the trunk.
T o retract your hard top (Convertible models), push and hold the door handle request switch
01
u
ntil the hard top is fully open.
The Int elligent Key can also be used to activate the panic alarm by pressing and holding the

b
utton 05 for more than 1 second. Once activated, the panic alarm and headlights will stay
on f
or 25 seconds.
INFINITI INTELLIGENT KEy™ BATTERy DISCHARGE
If the battery in the Intelligent Key is almost discharged,



the guide light 06 of the Intelligent Key port blinks and
the Int
elligent Key battery discharge indicator 07 is
di
splayed in the dot matrix liquid crystal display.
T o start the engine under these circumstances, insert



the Int
elligent Key into the key port with the buttons



f
acing upward and the key ring end toward you until



it
latches into place. Then push the ignition switch to



s
tart the engine.
To remove the Intelligent Key from the port, push the



ignition sw
itch to turn the engine off and then pull the



Int
elligent Key out of the port.
The Int elligent Key port does not charge the Intelligent Key battery. If you see the low battery
indic

ator
07 , replace the battery in the Intelligent Key.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
01
07
06
02
03
04
05

5
Trunk Lid Release
Use one of the following methods to open the trunk:
Push the trunk open request switch
01 for more

than one second while carrying the INFINITI



Intelligent Key™ with you.
Press the trunk buttonHOLD on the Intelligent Key for
more than one second.
P
ush down on the trunk lid release switch
02
loc
ated on the instrument panel to the left of the



s

teering wheel.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
Seat Adjustments
T o slide the seat forward or backward, push the control

s

witch
01 forward or backward .

T
o recline the seatback, push the switch
02

f
orward or backward.
SEAT LIFTER

T o adjust the angle of the front seat cushion or height
of the seat, push the front or rear end of the switch



01 up or down.
POWER LUMBAR SUPPORT (if so equipped)

To adjust the seat lumbar support, push the front or back end of the switch
03 .
For more information, refer to the “Safety
–– Seats, seat belts and supplemental restraint system (section 1)” of your
Owner’s Manual.
01
02
010203

6
first drive features
Seat Belt Guide (Convertible models)
Un
snap the seat belt guide
01 to allow rear seat p
assengers easier access.
B efore fastening the seat belt, ensure the seat belt is



in
serted into the seat belt guide and the snaps are



sec
urely fastened.
When u sing the seat belt guide, do not allow the seat



belt
to twist so that it will retract correctly.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)” of your Owner’s Manual.
Automatic Drive Positioner (if so equipped)
Two positions for the driver’s seat, steering column



and outside mirrors can be stored in the automatic




drive positioner memory.
F ollow these procedures to set the memory positions:
• Confirm
the shift

lever is

in the P (PA rk ) position



(aut
omatic transmissions) or the parking brake is applied (manual transmissions).
• Push
the ignition switch to the ON position.
• Adjust


the driver’s

seat, steering column and outside mirrors

to the desired positions

using



the a
djusting switches for each feature.
• Push
the SE
t sw
itch and within 5 seconds, push the memory switch (1 or 2) for at least 1 second.
• The
indicator light

on the memory

switch
y
ou select

will

illuminate for approximately

5 seconds.



• The driver’s

seat, steering column and outside mirror positions

are now set

to
y
our preference.
These memorized positions can also be linked to your INFINITI Intelligent Key™.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Passenger Rear Seat Entry/Exit
F
or ease in entering and exiting the rear passenger



ar
eas of the vehicle, perform the following steps:



1.

R
elease the front seatbelt guide and seat belt.



(C
onvertible models)



2.

P
ull the seatback lever
01 upward to fold the

fr
ont seatback forward. Make sure that the front



se

atback is completely folded.



3.


T

o slide the front seat forward, firmly push the



se

atback button
02 . The front seat will move forward.
NO

TE: To stop the front seat from sliding, press the
se

atback button
02 again.

T
o return the front seat to its original position:



1.

P
ush or pull the seatback backward until it locks in place.



2.

Pr
ess the seatback button
02 to slide the front seat backward.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)” of your Owner’s Manual.
Coupe
Convertible
01
01
02
02
01

7
Outside Mirror Control Switch
To select the right or left side mirror, turn the control
s

witch
01 right or left.
T
o adjust the mirror angle, move the control switch
01 up, down, right or left.
T
o prevent accidentally moving the mirror, turn and



set
the switch to the middle “neutral” position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Starting/Stopping the Engine
AUTOMATIC TRANSMISSION (if so equipped)
Depress the brake pedal.
• If


the brake pedal

is

not

depressed, pushing the




ignition sw
itch once enters the ACC mode.
• If


the ignition is

pushed a second time, the
v
ehicle




w
ill enter the ON mode.
Pr
ess the ignition switch StA rt /StOP button to start



the en
gine.
NOTE: It is important to make sure the INFINITI Intelligent Key
™ is with you (that is, in your pocket
or purse).
MANUAL TRANSMISSION (if so equipped)
D epress the brake pedal.
• If


the brake pedal

is

not

depressed, pushing the ignition switch once enters

the ACC mode.
• If


the ignition is

pushed a second time, the
v
ehicle will

enter the ON mode.
Move the shift lever to N (NEU tr AL).
Depress the clutch pedal to the floor.
Pr ess the ignition switch StA rt /StOP button.
TURNING THE ENGINE OFF
F or an automatic transmission, move the shift lever to the P (PA rk ) position, apply the parking



br
ake and push the ignition switch.
For a manual transmission, apply the foot brake, place the vehicle in 1st gear, apply the parking



br
ake and push the ignition switch.
EMERGENC
y
ENGINE
SHUT OFF
To shut off the engine in an emergency situation while driving, perform one of the following procedures:
R apidly push the push-button ignition switch 3 consecutive times in 1.5 seconds, or
Push and hold the push-button ignition switch for more than 2 seconds.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
01

8
first drive features
Headlight Control Switch
HEADLIGHT CONTROL
T
urn the headlight control switch to the position

01 to turn on the front parking, side marker, tail, license
p
late and instrument panel lights. Turn the switch to the
position
02 to turn on the headlights.
AUTOLIGHT S
yS

TEM (if so equipped)
The aut
olight system will automatically turn the headlights on when it is dark and off when it is



light
. The system will keep the headlights on for a period of time after you turn the ignition off



and al
l doors are closed.
T
o activate the autolight system, turn the headlight control switch to the AUt O position
03
t
hen push the ignition switch to ON. To deactivate the autolight system, turn the headlight



c

ontrol switch to the OFF,
01 or
position
02 .
HIGH BEAM SELECT
P
ush the headlight control switch forward
04 to
sel
ect the high beam function. The blue indicator
light


illuminates in the instrument panel. Pull



the he

adlight switch back to the original position to



sel

ect the low beam. The blue indicator light goes off.
P
ull and release the headlight control switch
05 to
fla
sh the headlight high beams on and off.
FOG LIGHT SWITCH
NOTE: The headlights must be on and the low beams
selected for the fog lights to operate.
T
urn the switch (inside collar) to the position
06
t
o turn the fog lights on.
T urn the switch (inside collar)
to the OFF position to



t
urn the fog lights off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
03
01
02
04
05
06
