WARNINGO Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
O To avoid the danger of being scalded,
never remove the radiator cap while the
engine is still hot. When the radiator cap
is removed, pressurized hot water will
spurt out, possibly causing serious in-
jury.
O Do not open the hood if steam is coming
out.
If your vehicle is overheating (indicated
by an extremely high temperature gauge
reading), or if you feel a lack of engine
power, detect abnormal noise, etc., take
the following steps:
1. Move the vehicle safely off the road,
apply the parking brake and move the
shift lever to the N (Neutral) position
(automatic transmission to the P
(Park) position).
Do not stop the engine. 2. Turn off the air conditioner. Open all
the windows, and move the tempera-
ture control to maximum hot and the
fan control to high speed.
3. If engine overheating is caused by
climbing a long hill on a hot day, run
the engine at a fast idle (approximately
1,500 rpm) until the temperature gauge
indication returns to normal.
4. Get out of the vehicle. Look and listen
for steam or coolant escaping from the
radiator before opening the hood. (If
steam or coolant is escaping, turn off
the engine.) Do not open the hood fur-
ther until no steam or coolant can be
seen.
5. Open the engine hood.
WARNING If steam or water is coming from the engine,
stand clear to prevent getting burned.
6. Visually check if the cooling fan is run-
ning. The radiator hoses and radiator
should not leak water. If coolant is
leaking or the cooling fan does not
run, stop the engine. WARNING O Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or to get caught in, the engine
belts or the engine cooling fan.
O The engine cooling fan can start at any
time when the coolant temperature is
high.
7. After the engine cools down, check
the coolant level in the reservoir tank
with the engine running. Add coolant
to the reservoir tank if necessary.
Have your vehicle repaired at an
INFINITI dealer.
If needed, Roadside Assistance is avail-
able. Please see your Warranty Information
Booklet or Roadside Assistance I.D. Card
for the toll-free number to call (U.S.) or War-
ranty Information Booklet (Canada).IF YOUR VEHICLE OVERHEATS
In case of emergency
6-11
w 06.1.4/V35-D/V5.0
X

8 Maintenance and do-it-yourself Maintenance requirements ............................... 8-2
General maintenance........................................ 8-2
Explanation of general maintenance
items .......................................................... 8-3
Maintenance precautions .................................. 8-5
Engine compartment check locations................ 8-7
Engine cooling system ..................................... 8-8
Checking engine coolant level..................... 8-8
Changing engine coolant............................. 8-9
Engine oil ....................................................... 8-10
Checking engine oil level........................... 8-10
Changing engine oil and filter ................... 8-11
Automatic transmission fluid........................... 8-13
Power steering fluid ........................................ 8-13
Brake and clutch fluid..................................... 8-14
Brake fluid................................................. 8-14
Clutch fluid ............................................... 8-15
Window washer fluid ....................................... 8-15
Battery ............................................................ 8-16
Jump starting ............................................. 8-18
Drive belts ...................................................... 8-19
Spark plugs .................................................... 8-19
Replacing spark plugs ............................... 8-20 Air cleaner...................................................... 8-20
Windshield wiper blades ................................. 8-21
Cleaning .................................................... 8-21
Replacing .................................................. 8-22
Parking brake and brake pedal....................... 8-23
Checking parking brake............................. 8-23
Checking brake pedal................................ 8-23
Brake booster ........................................... 8-24
Fuses .............................................................. 8-25
Engine compartment.................................. 8-25
Passenger compartment ............................ 8-27
Keyfob battery replacement ............................ 8-28
Keyfob (except Intelligent Key) .................. 8-28
Intelligent Key ........................................... 8-29
Lights.............................................................. 8-31
Headlights................................................. 8-33
Exterior and interior lights......................... 8-33
Wheels and tires ............................................ 8-37
Tire pressure ............................................. 8-37
Tire labeling .............................................. 8-41
Types of tires ............................................ 8-43
Tire chains ................................................ 8-44
Changing wheels and tires ........................ 8-45
w 06.1.4/V35-D/V5.0
X

Inside the vehicle The maintenance items listed here should
be checked on a regular basis, such as
when performing periodic maintenance,
cleaning the vehicle, etc.
Accelerator pedal: Check the pedal for
smooth operation and make sure the
pedal does not catch or require uneven
effort. Keep the floor mat away from the
pedal.
Automatic transmission P (Park) mecha-
nism: On a fairly steep hill check that your
vehicle is held securely with the selector
lever in the P (Park) position without ap-
plying any brakes.
Brake pedal*: Check the pedal for smooth
operation and make sure it has the proper
distance under it when depressed fully.
Check the brake booster function. Be sure
to keep the floor mat away from the
pedal.
Brakes: Check that the brakes do not pull
the vehicle to one side when applied.
Parking brake*: Check that the pedal/
lever has the proper travel and confirm
that your vehicle is held securely on a
fairly steep hill with only the parking
brake applied. Seats: Check seat position controls such
as seat adjusters, seatback recliner, etc.
to ensure they operate smoothly and that
all latches lock securely in every position.
Check that the head restraints move up
and down smoothly and that the locks (if
so equipped) hold securely in all latched
positions.
Seat belts: Check that all parts of the seat
belt system (For example, buckles, an-
chors, adjusters and retractors) operate
properly and smoothly, and are installed
securely. Check the belt webbing for cuts,
fraying, wear or damage.
Steering wheel: Check for changes in the
steering conditions, such as excessive
free play, hard steering or strange noises.
Warning lights and chimes: Make sure
that all warning lights and chimes are op-
erating properly.
Windshield defroster: Check that the air
comes out of the defroster outlets prop-
erly and in sufficient quantity when oper-
ating the heater or air conditioner.
Windshield wiper and washer*: Check that
the wipers and washer operate properly
and that the wipers do not streak. Under the hood and the vehicle The maintenance items listed here should
be checked periodically (For example,
each time you check the engine oil or re-
fuel).
Battery*: Check the fluid level in each
cell. It should be between the MAX and
MIN lines. Vehicles operated in high tem-
peratures or under severe conditions re-
quire frequent checks of the battery fluid
level.
Brake and clutch fluid level*: Make sure
that the brake and clutch fluid levels are
between the MAX and MIN lines on the
reservoir.
Engine coolant level*: Check the coolant
level when the engine is cold.
Engine drive belts*: Make sure that no
belt is frayed, worn, cracked or oily.
Engine oil level*: Check the level after
parking the vehicle on a level location
and turning off the engine. (Wait at least
10 minutes for the oil to drain back into
the oil pan.)
Exhaust system: Make sure there are no
loose supports, cracks or holes. If the
sound of the exhaust seems unusual or
8-4 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

such as rings, watches, etc. before work-
ing on your vehicle.
O Always wear eye protection whenever
you work on your vehicle.
O If you must run the engine in an enclosed
space such as a garage, be sure there is
proper ventilation for exhaust gases to
escape.
O Never get under the vehicle while it is
supported only by a jack. If it is neces-
sary to work under the vehicle, support it
with safety stands.
O Keep smoking materials, flame and
sparks away from the fuel tank and bat-
tery.
O On gasoline engine models with the Mul-
tiport Fuel Injection (MFI) System, the
fuel filter or fuel lines should be serviced
by an INFINITI dealer because the fuel
lines are under high pressure even when
the engine is off. CAUTION O Do not work under the hood while the en-
gine is hot. Turn the engine off and wait
until it cools down.
O Never connect or disconnect the battery
or any transistorized component while
the ignition switch is in the ON position.
O Never leave the engine or automatic
transmission related component har-
ness connector disconnected while the
ignition switch is in the ON position.
O Avoid contact with used engine oil and
coolant. Improperly disposed engine oil,
engine coolant and/or other vehicle
fluids can damage the environment. Al-
ways conform to local regulations for
disposal of vehicle fluid.
This ª8. Maintenance and do-it-yourselfº
section gives instructions regarding only
those items which are relatively easy for
an owner to perform. A genuine INFINITI Service Manual is also
available. See ªOwner's Manual/Service
Manual order informationº in the ª9.
Technical and consumer informationº sec-
tion.
You should be aware that incomplete or
improper servicing may result in oper-
ating difficulties or excessive emissions,
and could affect your warranty coverage.
If in doubt about any servicing, have it
done by an INFINITI dealer.
8-6 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

1. Fuse/fusible link holder
2. Battery
3. Engine oil filler cap
4. Brake fluid reservoir
5. Clutch fluid reservoir (MT models)
6. Power steering fluid reservoir
7. Engine coolant reservoir
8. Window washer fluid reservoir
9. Radiator filler cap
10. Drive belts
11. Engine oil dipstick
12. Air cleaner
SSI0160ENGINE COMPARTMENT CHECK
LOCATIONS
Maintenance and do-it-yourself
8-7
w 06.1.4/V35-D/V5.0
X

The engine cooling system is filled at the
factory with a high-quality, year-round,
anti-freeze coolant solution. The anti-
freeze solution contains rust and corro-
sion inhibitors, therefore additional
cooling system additives are not neces-
sary.
WARNINGO Never remove the radiator or coolant res-
ervoir cap when the engine is hot. Wait
until the engine and radiator cool down.
Serious burns could be caused by high
pressure fluid escaping from the ra-
diator. See precautions in ªIf your ve-
hicle overheatsº found in the ª6. In case
of emergencyº section.
O The radiator is equipped with a pressure
type radiator cap. To prevent engine
damage, use only a genuine NISSAN ra-
diator cap. CAUTION When adding or replacing coolant, be sure to
use only a Genuine Nissan Long Life
Antifreeze/Coolant or equivalent with the
proper mixture ratio of 50% antifreeze and
50% demineralized water/distilled water.
The use of other types of engine coolant may
damage your engine cooling system. Outside temperature
down to
Antifreeze Deminer-
alized
water/
distilled
waterÉC ÉF
þ35 þ30 50% 50%
CHECKING ENGINE COOLANT LEVEL Check the coolant level in the reservoir
tank when the engine is cold. If the cool-
ant level is below the MIN level
q 2
, open
the cap and add coolant up to the MAX
level
q 1
. If the reservoir tank is empty,
check the coolant level in the radiator
when the engine is cold. If there is insuffi-
cient coolant in the radiator, fill the radia-
tor with coolant up to the filler opening
and also add it to the reservoir tank up to
the MAX level
q 1
. SDI1385B
ENGINE COOLING SYSTEM
8-8 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

If the cooling system frequently requires
coolant, have it checked by an INFINITI
dealer.
CHANGING ENGINE COOLANT O Major cooling system repairs should be
performed by an INFINITI dealer. The
service procedures can be found in the
appropriate INFINITI Service Manual. O Improper servicing can result in re-
duced heater performance and engine
overheating.
WARNING O To avoid being scalded, never change
the coolant when the engine is hot.
O Never remove the radiator cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escaping
from the radiator.
O Avoid direct skin contact with used cool-
ant. If skin contact is made, wash thor-
oughly with soap or hand cleaner as
soon as possible.
O Keep coolant out of reach of children and
pets.
1. Open radiator drain plug
q A
at the
bottom of radiator, and remove ra-
diator filler cap
q B
.
O Be careful not to allow coolant to con-
tact drive belts.
O Waste coolant must be disposed of
properly. Check your local regulations. SDI0114B
Maintenance and do-it-yourself
8-9
w 06.1.4/V35-D/V5.0
X

2. Close the radiator drain plug securely
after the coolant is drained.
3. Fill the radiator slowly with the proper
mixture of antifreeze solution and
demineralized water/distilled water.
Fill the reservoir tank up to the MAX
level. Then install the radiator filler
cap.
4. Start the engine and warm it up until
it reaches normal operating tempera-
ture. Then race the engine 2 or 3 times
under no load. Watch the engine cool-
ant temperature gauge for signs of
overheating.
5. Stop the engine. After it completely
cools down, refill the radiator up to
the filler opening. Fill the reservoir
tank up to the MAX level. Check the
drain plug for any sign of leakage.
6. Check the coolant level again after
driving the vehicle.
CHECKING ENGINE OIL LEVEL 1. Park the vehicle on a level surface and
apply the parking brake.
2. Run the engine until it reaches operat-
ing temperature.
3. Turn off the engine. Wait more than 10
minutes for the oil to drain back into
the oil pan.
4. Remove the dipstick
q A
and wipe it
clean. Reinsert it all the way. 5. Remove the dipstick again and check
the oil level. It should be between the
H and L marks
q B
. If the oil level is
below the L mark
q A
, remove the oil
filler cap and pour recommended oil
through the opening. Do not overfill
q C
.
6. Recheck oil level with dipstick.
It is normal to add some oil between oil
maintenance intervals or during the break-
in period, depending on the severity of op-
erating conditions. SDI1386D SDI1781
ENGINE OIL
8-10 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

WARNINGAntifreeze is poisonous and should be
stored carefully in marked containers out of
the reach of children.
CAUTIONDo not substitute engine anti-freeze coolant
for window washer solution. This may result
in damage to the paint.
O Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
O Pre-mix washer fluid concentrates with
water to the manufacturer's recom-
mended levels before pouring the fluid
into the window washer reservoir tank. Do not use the window washer reservoir
tank to mix the washer fluid concen-
trateand water. O Keep the battery surface clean and
dry. Any corrosion should be washed
off with a solution of baking soda and
water.
O Make certain the terminal connections
are clean and securely tightened.
O If the vehicle is not to be used for 30
days or longer, disconnect the (þ)
negative battery terminal cable to pre-
vent discharging it.
Coupe
CAUTION When the battery cable is removed from the
battery terminal, do not close either of front
doors. The automatic window adjusting func-
tion will not work, and the side roof panel
may be damaged.
To disconnect the negative (þ) battery ter-
minal, perform the procedure in the follow-
ing order. Otherwise, the window and the
side roof panel may contact and be dam-
aged.
1. Close the windows.BATTERY
8-16 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure in-
structed in the ª8. Maintenance and do-it-yourselfº section to determine the proper refill capacity. Capacity (Approximate)
Recommended
specificationsUS
measure Imp
measure Liter
Fuel*1 20 gal 16-5/8 gal 76
Engine oil (Drain and refill)*8
With oil filter change 5 qt 4-1/8 qt 4.7 O API Certification Mark*2, *3
O API grade SG/SH, Energy Conservin gI&IIorAPI grade SJ or SL, Energy Conserving*2, *3
O ILSAC grade GF-I, GF-II & GF-III*2, *3Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system
With reservoir 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid Ð Ð Ð Genuine NISSAN Matic J ATF*4
Manual transmission gear oil Ð Ð Ð Genuine NISSAN Manual Transmission Fluid (MTF)
HQ Multi 75W-85 or API GL-4, Viscosity SAE 75W-85 or 75W-90
Differential gear oil Ð Ð Ð API GL-5, Viscosity SAE 80W-90*5
Transfer fluid Ð Ð Ð Genuine NISSAN Matic D ATF (Continental U.S. and Alaska) or CANADA NISSAN Automatic Trans-
mission Fluid*6
Power steering fluid (PSF) Refill to the proper fluid level according to the in-
structions in the ª8. Maintenance and do-it-yourselfº
section. Genuine NISSAN PSF or equivalent*10
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*7 or equivalent DOT 3
Multi-purpose grease Ð Ð Ð NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant Ð Ð Ð HFC-134a (R-134a)*9
Air conditioning system lubricants Ð Ð Ð NISSAN A/C System Oil Type S or exact equivalent
Windshield washer fluid Ð Ð Ð Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1: For additional information, see ªFuel recommendationº later in this section.
*2: For additional information, see ªEngine oil and oil filter recommendationº later in this section.
*3: For additional information, see ªRecommended SAE viscosity numberº later in this section.
*4: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures always above 32ÉF (0ÉC).
*6: DEXRON TM
III/MERCON TM
or equivalent may also be used. Outside the continental United States and Alaska contact an INFINITI dealer for more information regarding suitable fluids, including recommended
brand(s) of DEXRON TM
III/MERCON TM
automatic transmission fluid.
*7: Available in mainland US through an INFINITI dealer.
*8: For additional information, see ªEngine oilº in the ª8. Maintenance and do-it-yourselfº section for changing engine oil.
*9: For additional information, see ªVehicle identificationº later in this section for air conditioner specification label.
*10: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON TM
III/MERCON TM
or equivalent ATF may also be used.CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2 Technical and consumer information
w 06.1.4/V35-D/V5.0
X
