3. Close and lock all doors, hood and
trunk lid.
Lock all doors by pushing the LOCK
button on the keyfob, the Intelli-
gent Key or by pushing any front door
handle request switch or turning the
door key. When using the remote key-
less entry, the hazard indicators will
operate as shown in ªRemote keyless
entry systemº or ªIntelligent Key
systemº in the ª3. Pre-driving checks
and adjustmentsº section.
4. Confirm that the security indicator
light
q A
comes on. The security indica-
tor light glows for about 30 seconds
and then blinks. The system is now
armed. If, during this 30-second time
period, the door is unlocked by the
key, the remote keyless entry or the
front door request switch, or the igni-
tion switch is turned to the ACC or ON
position, the system will not be
armed.
Even when the driver and/or passengers
are in the vehicle, the system will be
armed with all doors, hood and trunk lid
locked and ignition switch off. Turn the ig-
nition switch to the ACC position to turn off
the system. Vehicle security system activation The security system will give the following
alarm:
O The headlights blink and the horn
sounds intermittently.
O The alarm automatically turns off after
approximately 50 seconds. However,
the alarm reactivates if the vehicle is
tampered with again. The alarm can
be shut off by unlocking a door with
the key, by pushing any front door
handle request switch or by pushing
the UNLOCK button on the keyfob
or Intelligent Key.
The alarm is activated by:
O Opening the door without using the
key or keyfob or Intelligent Key.
O Opening the trunk lid without using
the keyfob or Intelligent Key.
O Opening the hood.
How to stop an activated alarm The alarm will stop only by unlocking a
door with the key, by pushing any door
handle request switch or by pushing the
UNLOCK button on keyfob or Intelli-
gent Key. The alarm will not stop if the ig- nition switch is turned to the ACC or ON
position.
If the system does not operate as de-
scribed above, have it checked by an
INFINITI dealer.
INFINITI VEHICLE IMMOBILIZER
SYSTEM The INFINITI Vehicle Immobilizer System
will not allow the engine to start without
the use of the registered key.
If the engine fails to start using the regis-
tered key (for example, when interference
is caused by another registered key, an
automated toll road device or automated
payment device on the key ring), restart
the engine using the following proce-
dures:
1. Leave the ignition switch in the ON po-
sition for approximately 5 seconds.
2. Turn the ignition switch to the OFF or
LOCK position and wait approximately
10 seconds.
3. Repeat steps 1 and 2.
4. Restart the engine while holding the
device (which may have caused the in-
2-18 Instruments and controls
w 06.1.4/V35-D/V5.0
X

Unlocking doors and fuel-filler
door 1. Push the UNLOCK button on the
keyfob once.
O The driver's door and fuel-filler door
unlock
O The hazard indicator flashes once if all
doors are completely closed with the
ignition switch in any position except
in the ON position.
O The interior light timer activates and
the interior light comes on for 30 sec-
onds when the interior light switch is
at the DOOR position with the ignition
switch in any position except in the
ON position.
2. Push the UNLOCK button on the
keyfob again within 5 seconds.
O All doors and trunk lid unlock
O The hazard indicator flashes once if all
doors are completely closed.
All doors will be locked automatically un-
less one of the following operations is
performed within 1 minute of pushing the
UNLOCK button.
O opening any door. O opening trunk lid.
O turning the ignition switch to the ON
position
The interior light can be turned off
without waiting for 30 seconds by turning
the ignition switch to the ON position or
by locking the doors with the keyfob.
Opening the windows Push the UNLOCK button on the
keyfob.
The driver's door and fuel-filler door will
unlock.
Continue to push the UNLOCK button
for more than 3 seconds. The door win-
dows will start to lower.
Continue to push the UNLOCK button
until windows are fully open.
To stop the windows lowering operation,
release the UNLOCK button.
To start the windows lowering operation,
push the UNLOCK button again for
more than 3 seconds.
Releasing the trunk lid 1. Push the TRUNK button on the
keyfob for longer than 0.5 seconds when the ignition switch is in any po-
sition except the ON position.
2. The trunk lid opens.
The trunk lid cannot be opened by operat-
ing the keyfob when the ignition switch is
in the ON position.
Using the panic alarm If you are near your vehicle and feel
threatened, you may activate the alarm to
call attention as follows:
1. Push the PANIC button on the
keyfob for longer than 0.5 seconds
with the key removed from the ignition
switch.
2. The theft warning alarm and head-
lights will stay on for 25 seconds.
3. The panic alarm stops when:
O It has run for 25 seconds, or
O The LOCK button or the UNLOCK
button on keyfob is pushed, or
O The TRUNK button or the PANIC
button on the keyfob is pushed
for longer than 0.5 second.
Pre-driving checks and adjustments
3-7
w 06.1.4/V35-D/V5.0
X

When the trunk lid is closed with the In-
telligent Key inside the trunk, the outside
buzzer will sound and the trunk will open.
OPENING AND CLOSING WINDOWS O To open the windows, push the UN-
LOCK button on the Intelligent
Key for about 3 seconds or turn the
door key cylinder with the metal key
to the rear of the vehicle for about 2
seconds after the door is unlocked.
To stop opening, release the UNLOCK
button or turn the key to the neu-
tral position.
O To close the windows, turn the door
key cylinder to the front of the vehicle
for about 2 seconds after the door is
locked.
To stop closing, turn the key to the
neutral position.
The door windows will open or close
while turning the metal key. See ªDoorsº
earlier in this section. OPERATING THE ENGINE
Ignition switch positions Push in the ignition switch in the
q B
range when you turn it.
LOCK (Normal parking position)
q A
:
The ignition switch can only be locked in
the
q A
position.
The ignition switch will be unlocked when
it is pushed in, and turned to the ACC po-
sition
q D
while carrying the Intelligent
Key. ACC (Accessories)
q D
:
This position activates electrical accesso-
ries such as the radio, when the engine is
not running.
ON (Normal operating position)
q E
:
This position turns on the ignition system
and electrical accessories.
START
q F
:
This position starts the engine. As soon
as the engine has started, release the
switch immediately. It will automatically
return to the ON position.
For important safety information, see ªIg-
nition switchº in the ª5. Starting and driv-
ingº section.
The ignition switch cannot be turned back
to the LOCK position unless the shift lever
is in P position. (It can be turned to only
q C
.) SPA1628
3-14 Pre-driving checks and adjustments
w 06.1.4/V35-D/V5.0
X

WARNINGO Positioning of the heating or air condi-
tioning controls and display controls
should not be done while driving, in
order that full attention may be given to
driving operation.
O Do not disassemble or modify this
system. If you do, it may result in acci-
dents, fire, or electric shock.
O Do not use this system if you notice any
abnormality, such as a frozen screen or
lack of sound. Continued use of the
system may result in accident, fire or
electric shock.
O In case you notice any foreign object in
the system hardware, spill liquid on it, or
notice smoke or smell coming from it,
stop using the system immediately and
contact an INFINITI dealer. Ignoring such
conditions may lead to accidents, fire, or
electric shock. When you use this system, make sure the
engine is running.
If you use the system with the engine not
running (ignition ON or ACC) for a long
time, it will use up all the battery power,
and the engine will not start.
Reference symbols:
ªENTERº button Ð This is a button on the
control panel.
ª Display º key Ð This is a select key on
the screen. By selecting this key you can
proceed to the next function. NAMES OF THE COMPONENTS 1., 2., 5., 6., 9., 10. and 11.
For Navigation control buttons: refer to
the separate Navigation Owner's Manual.
3. ªSETTINGº button (P. 4-7)
4. ªINFOº button (P. 4-3)
7. Joystick and ªENTERº button (P. 4-3)
8. brightness control button
(P. 4-9)
12. ªBACKº button (P. 4-3) SAA1301
SAFETY NOTE
CONTROL PANEL BUTTONS Ð WITH
NAVIGATION SYSTEM
4-2 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X

3. PTY SCAN tuning mode
Push the SCAN tuning button to tune
the PTY name station, and stop at
each broadcasting station for 5 sec-
onds. Pushing the button again during
this 5 second period will stop SCAN
tuning and the radio will remain tuned
to that station. If the SCAN tuning but-
ton is not pushed within 5 seconds,
SCAN tuning moves to the next sta-
tion.
Compact disc (CD) changer
operation Turn the ignition switch to the ACC or ON
position, push the LOAD button and insert
the compact disc into the slot with the la-
bel side facing up. The CD will be guided
automatically into the slot and start play-
ing.
After loading the disc, the number of
tracks on the disc and the play time will
appear on the display.
If the radio is already operating, it will au-
tomatically turn off and the CD will play. CAUTION O Do not force the compact disc into the
slot. This could damage the player.
O Do not use 3.1 in (8 cm) discs.
If the system has been turned off while
the CD was playing, pushing the
ON z OFF/VOL control button will start the
compact disc.
CD LOAD:
To insert a CD in the CD changer, push
the LOAD button for less than 1.5 sec-
onds. Select the loading slot by pushing
the CD insert select button (1 to 6), then
insert the CD.
To insert 6 CDs to the CD changer in suc-
cession, push the LOAD button for more
than 1.5 seconds.
The inserted slot numbers will illuminate
on the display.
PLAY:
When the CD button is pushed with the
system off and the compact disc loaded,
the system will turn on and the compact
disc will start to play. When the CD button is pushed with the
CD loaded with the radio playing, the
radio will automatically be turned off and
the compact disc will start to play.
DISPLAY:
When the display button is pushed for
more than 1.5 seconds while the CD is be-
ing played, the music information dis-
played can be changed in the following
order.
CD:
CD with MP3 or WMA:
FF (Fast Forward), REW
(Rewind):
CD:
When the (fast forward) or (re-
wind) button is pushed while the compact
disc is being played, the CD will play
while fast forwarding or rewinding. When
Display screen, heater, air conditioner and audio systems
4-25
w 06.1.4/V35-D/V5.0
X

the button is released, the CD will return
to normal play speed.
CD with MP3 or WMA:
When the or button is pushed
for less than 1.5 seconds while the CD is
being played, the folders in the CD will be
changed.
When the or button is pushed
for more than 1.5 seconds while the CD is
being played, the CD will play while fast
forwarding or rewinding. When the button
is released, the CD will return to the
normal play speed.
APS (Automatic Program
Search) FF, APS REW:
When the (APS FF) button is pushed
while the CD is being played, the program
after the present one will start to play
from its beginning. Push several times to
skip through programs. The CD will ad-
vance the number of times the button is
pushed. (When the last program on the
CD is skipped through, the first program
will be played.) When the (APS REW)
button is pushed, the program being
played returns to its beginning. Push sev-
eral times to skip back through programs.
The CD will go back the number of times
the button is pushed. CD PLAY select button:
To change CD, push the CD play select
button (1 to 6).
SCAN tuning:
When the SCAN tuning button is pushed
for less than 1.5 seconds while the CD is
being played, the beginning of all the CD
programs in each track will be played for
10 seconds in sequence.
When the SCAN tuning button is pushed
for more than 1.5 seconds while the CD is
being played, the first program in all the
CDs will be played for 10 seconds.
Pushing the button again during this 10
second period will stop SCAN tuning.
If the SCAN tuning button is not pushed
within 10 seconds, SCAN tuning moves to
the next disc program.
REPEAT (RPT):
When the RPT button is pushed while the
CD is played, the play pattern can be
changed as follows: CD:
CD with MP3 or WMA:
CD EJECT:
When the CD EJECT button is pushed with
the CD loaded, the CD will be ejected.
To eject the discs selected by the CD se-
lect button, push the EJECT button for less
than 1.5 seconds.
To eject all the discs, push the EJECT but-
ton for more than 1.5 seconds.
When this button is pushed while the CD
is being played, CD will come out and the
system will turn off.
If the CD comes out and is not removed, it
will be pulled back into the slot to protect
it.
4-26 Display screen, heater, air conditioner and audio systems
w 06.1.4/V35-D/V5.0
X

AUTOMATIC TRANSMISSION
5-speed automatic transmission The automatic transmission in your ve-
hicle is electronically controlled by a
transmission control module to produce
maximum efficiency and smooth opera-
tion.
Shown on the following pages are the rec-
ommended operating procedures for this
transmission. Follow these procedures for
maximum vehicle performance and
driving enjoyment.
Starting the vehicle After starting the engine, fully depress the
foot brake pedal and push the selector le-
ver button before shifting the selector
lever to the R (Reverse), N (Neutral), D
(Drive) or Manual shift mode position. Be
sure the vehicle is fully stopped before at-
tempting to shift the selector lever.
This automatic transmission model is de-
signed so that the foot brake pedal must
be depressed before shifting from P (Park)
to any drive position while the ignition
switch is the ON position.
The selector lever cannot be moved out of
the P (Park) position and into any of the other gear positions if the ignition switch
is turned to the LOCK, OFF or ACC position
or if the key is removed from the switch.
1. Keep the foot brake pedal depressed
and push the selector lever button to
shift into a driving gear.
2. Release the parking brake and foot
brake, then gradually start the vehicle
in motion.
WARNING O Do not depress the accelerator pedal
while shifting from P (Park) or N (Neutral)
to R (Reverse), D (Drive) or manual shift
mode. Always depress the brake pedal
until shifting is completed. Failure to do
so could cause you to lose control and
have an accident.
O Cold engine idle speed is high, so use
caution when shifting into a forward or
reverse gear before the engine has
warmed up.
O On slippery roads, do not downshift.
This may cause a loss of control. O Never shift to P (Park) or R (Reverse)
while vehicle is moving forward. Never
shift to P (Park) or D (Drive) while vehicle
is moving rearward. Failure to do so
could cause you to lose control and have
an accident.
CAUTION When stopping the vehicle on an uphill
grade, do not hold the vehicle by depressing
the accelerator pedal. The foot brake should
be used for this purpose.DRIVING THE VEHICLE
5-12 Starting and driving
w 06.1.4/V35-D/V5.0
X

To move the selector lever,
: Push the button while depressing
the brake pedal,
: Push the button,
: Just move the selector lever.
Shifting After starting the engine, fully depress the
brake pedal and shift the selector lever
from the P (Park) to R (Reverse), N (Neu-
tral), D (Drive), or Manual shift mode posi-
tion.
Push the button to shift into the P (Park)
or R (Reverse) position. All other positions can be selected without pushing the
button.
WARNING Apply the parking brake if the selector lever
is in any position while the engine is not run-
ning. Failure to do so could cause the vehicle
to move unexpectedly or roll away and result
in serious personal injury or property
damage.
If the key is turned to the OFF or ACC po-
sition for any reason while the vehicle is
in the R (Reverse), N (Neutral), or any D
(Drive) position, the key cannot be turned
to the LOCK position and be removed
from the ignition switch. Move the se-
lector lever to the P (Park) position, then
the key can be turned to the LOCK posi-
tion.
P (Park):
Use this selector position when the vehicle
is parked or when starting the engine.
Make sure the vehicle is completely
stopped. The brake pedal must be de-
pressed and the selector lever button
pushed in to move the selector lever from the N (Neutral) position or any drive position
to the P (Park) position. Apply the parking
brake. When parking on a hill, first depress
the foot brake pedal, apply the parking
brake, then move the lever to the P (Park)
position.
CAUTION Use this position only when the vehicle is
completely stopped.
R (Reverse):
Use this position to back up. Always be
sure the vehicle is completely stopped be-
fore selecting the R (Reverse) position.
The brake pedal must be depressed and
the selector lever button pushed in to
move the selector lever from the P (Park), N
(Neutral) or any drive position to the R (Re-
verse) position.
N (Neutral):
Neither forward nor reverse gear is en-
gaged. The engine can be started in this
position. You may shift to the N (Neutral)
position and restart a stalled engine while
the vehicle is moving.SSD0413
Starting and driving
5-13
w 06.1.4/V35-D/V5.0
X

O If the warning light remains on after the
above operation, have your vehicle
checked by an INFINITI dealer as soon as
possible.
O The power train may be damaged if you
continue driving with the warning light
blinking rapidly.
WARNING O Do not stop or park the vehicle over flam-
mable materials such as dry grass,
waste paper or rags. They may ignite and
cause a fire.
O Never leave the engine running while the
vehicle is unattended.
O Never leave children unattended inside
the vehicle. O Safe parking procedures require that
both the parking brake be set and the
transmission placed into P (Park).
Failure to do so could cause the vehicle
to move unexpectedly or roll away and
result in an accident.
O Make sure the shift lever has been
pushed as far forward as it can go and
cannot be moved without depressing the
button at the end of the lever. SD1006MA
PARKING/PARKING ON HILLS
5-24 Starting and driving
w 06.1.4/V35-D/V5.0
X
