maintenance INFINITI M HYBRID 2013 Quick Reference Guide

3**Laws in some communities may restrict the use of text-to-speech. check local regulations before using this feature.


emergency c all (if so equipped) – this service provides emergency assistance by connecting
subscriber to an Infiniti c onnection Specialist.
• In case of an emergency, press the in-vehicle
telematics SOS button

01 .
• A Response Specialist will provide assistance based
on the situation described by the vehicle’s occupant.

enhanced Roadside Assistance (if so equipped) –
Roadside Assistance can be accessed by touching
the Infiniti c onnection key on the Info menu, the

key (if available on the map screen) or by pressing the
SOS button.
• this service allows subscribers to receive assistance for a non-emergency incident such as
towing or a third party response.
• If warranted, Roadside Assistance may also be used in conjunction with the emergency
Assistance service by pressing the SOS button.

My Schedule – Access your personal online Google c alendar™, hear details read via text-to-
speech** and select locations as a destination via the navigation system.

Report Stolen vehicle – A Response Specialist will attempt to obtain location information
from a reported stolen vehicle and provide that information to local law enforcement agencies
to assist in the recovery of your stolen vehicle.

Remote door Lock/unlock – Remotely access your vehicle via Infiniti c onnection Response
Specialist or designated website to remotely lock or unlock your vehicle.

Alarm notification – this system will notify you when the factory-installed vehicle alarm
system has been activated.

Scheduled Maintenance notification – Receive scheduled maintenance notifications based
on mileage data provided by your vehicle.

Maintenance Alert – Receive notification of a vehicle system malfunction that triggers
instrument panel warning lights.

destination Assistance – Receive point-of-interest assistance via guided IvR (Interactive
v oice Response), Response Specialist or Infiniti c onnection web portal.

destination Send-to vehicle – Find and download point-of interest information from
GoogleMaps™.

connected Search – Select “c onnected Search” from the d estination menu on the vehicle’s
navigation system to conduct a point-of-interest search within a certain distance of the
vehicle’s location.

drive Zone – Monitor the movement of your vehicle within a specified region. Set up boundaries
in the Monitoring section of the Infiniti c onnection web portal.

Max Speed Alert – Set up a maximum speed on the Infiniti c onnection web portal. you will
receive notifications if your vehicle exceeds the max speed setting.

Mobile Information Service (if so equipped) – Receive the latest news headlines, stock
quotes and sports scores by setting up preferences on the Mobile Information Service page
in the Infiniti c onnection web portal.
01

7
Tire Pressure Monitoring System (TPMS)
A CHECk tIRE PRESSURE warning message will
appear in the dot matrix liquid crystal display

01
and the low tire pressure warning light
02 will

illuminate when one or more tires are low on
pressure and air is needed.
• The tire pressures should be checked when the
tires are cold. the tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mile (1.6km) at moderate speeds.

After tire pressures are adjusted, drive the vehicle
at speeds above 16 MpH (25km/h). the CHECk tIRE
PRESSURE warning message and low tire pressure
warning light will disappear.

when the low tire pressure warning light flashes
for 1 minute and then remains on, the tpMS is not
functioning properly. Have the system checked by
an InFInItI retailer.

tire pressure rises and falls depending on the heat caused by the vehicle’s operation and the
outside temperature. Low outside temperature can lower the temperature of the air inside the
tire, which can cause a lower tire inflation pressure. this may cause the low tire pressure
warning light to illuminate. If the warning light illuminates in low ambient temperature, check
the tire pressure in your tires.
• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

the tire and Loading Information label contains valuable information. please refer to section 9,
“technical and consumer information”, in your Owner’s Manual for the location of the tire and
Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, “Starting and driving (section 5)” and the “Maintenance
and do-it-yourself (section 8)” of your Owner’s Manual.
01
02
Infiniti Drive Mode Selector
t urn the switch to the following position to select the
corresponding drive mode:
01 Standard (•) - For standard or normal
driving.
02 SPOR
t - the engine and transmission will adjust,
resulting in higher engine rpm and a more aggressive
shift pattern. In this mode, fuel economy may be reduced.
03 SNOW – u
sed on snowy roads or slippery areas. In this mode, engine output is controlled to
avoid wheel spin.
04 ECO
– Adjusts engine and transmission points to enhance fuel economy.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
0102
03
04

9
first drive features
INFINITI Intelligent Key™ System
the InFInItI Intelligent k ey™ system allows you to
lock or unlock your vehicle, open your trunk and start
the engine.
nO te: It is important to make sure the Intelligent k ey is
with you (that is, in your pocket or purse).

the operating range of the Intelligent k ey is within
31.5 in (80 cm) from each request switch.

to lock the vehicle, push either door handle request
switch

01 once or press the
button
02 on the keyfob.

to unlock the vehicle, perform one of the following procedures:
• Push either door handle request switch

01 once;
the corresponding
door will unlock. p ush the door handle request switch
01 again within
1 minute; all other doors will unlock, or
• Press the

button
03 on the keyfob to unlock the driver’s side door.
press the
button again; all other doors will unlock.

to open the trunk, press the button
04 for more than 1 second.

the Intelligent k ey can also be used to activate the panic alarm by pressing
and holding the

button
05 for more than 1 second. Once activated, the
panic alarm and headlights will stay on for 25 seconds.
InteLLIGent key BAtteRy dIScHARGe

If the battery of the Intelligent k ey is discharged, or
environmental conditions interfere with the Intelligent
k ey operation, start the engine according to the
following procedure:
1. Move the shift lever to the P (P ARk) position.
2. Firmly apply the foot brake.
3. touch the ignition switch with the Intelligent k ey and a chime will sound.
4. w ithin 10 seconds after the chime sounds, push the ignition switch while depressing the
brake pedal and the engine will start.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, “Starting and driving (section 5)” and
the “Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
01
02
03
04
05

2013 Infiniti M Hybrid Delivery Checklist
Heating, Ventilation and Air Conditioning
Demonstrate Yes
1. CLIMA tE button

2. Fan Speed control

3. Mode control
4. A/c function
5. d
efrost and d efog operation (include recirculation button)
All information, specifications, photographs and illustrations are those in effect at the time of printing. InFInItI

reserves the right to change specifications or design without notice and without obligation. For additional
information, see your InFInItI retailer or contact nISSAn north America, Inc. See your Owner’s Manual for
important warnings and details on vehicle operation and maintenance.
QR3e Hy51u0
printing: April 2012 (03)
printed in uSA
Owner’s Signature date

Sales consultant’s Signature date

Sales Manager’s Signature date
Cruise Control Ye s
1. Activate cruise control

2. Set cruise control

3.
Reset at a faster cruising speed
4.
Reset at a slower cruising speed
5.
cancel cruise control
6. turn off cruise control
Headlight Control
Ye s
01 Activate the front parking, side marker,
tail and license plate lights
02 Activate the headlights
03 Activate the Autolight System
04 Activate the high beams
05 Flash the high beams
06 Activate the fog lights
03
01
02
04
05
06

20
system guide
Trip Computer
when the
button
01 is pressed, the following
modes will appear on the dot matrix liquid crystal
display

02 :
• MPG – displays the current fuel consumption.
• MPG/MPH – displays the average fuel consumption
and speed since the last reset.
• tIME/MILES – displays the elapsed time and total
distance the vehicle has been driven since the
last reset.
• RANGE – displays the estimated distance to empty
(dte) the vehicle can be driven before refueling.
• OUtSIDE tEMP – displays the exterior air
temperature including a low temperature
warning feature.
• SEttING – Allows you to set reminders for alerts and maintenance intervals or change the
language and units used in the system.
— press the

button
03 to cycle through the various setting modes.

— press the

button
01 to choose the selected menu.

• WARNING – If there are any.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
Bluetooth® Hands-free Phone System

with an overhead microphone and sound
transmitted through the audio system speakers,
the Bluetooth
® Hands-free phone System utilizes
Bluetooth wireless technology and voice recognition
to provide hands-free cellular phone communication.

A cellular telephone should not be used while driving
so full attention may be given to vehicle operation.*
S yS teM OpeRA tInG tIpS

close all windows. Surrounding noises may interfere
with system operation and performance.

press the
or
button on the steering wheel to

activate voice recognition.

wait for the tone before speaking.

Begin speaking a command within 5 seconds of the tone.
03
01
02
Bluetooth® Controls
*Some jurisdictions prohibit the use of cellular telephones while driving. Microphone

printing: April 2012 (03) / QR
3e Hy51u0 / printed in uSA
this Quick Reference Guide is intended to provide an overview of some of the unique features
of your new vehicle. See your Owner’s Manual, which contains important safety warnings and
information about the operation and maintenance of your vehicle, for complete details. nissan
north America, Inc. reserves the right to make changes, at anytime, without prior notice, in prices,
colors, materials, equipment, specifications, and models and to discontinue models or equipment.
due to continuous product development and other pre- and post-production factors, actual vehicle,
materials and specifications may vary. Some vehicles are shown with optional equipment. See
the actual vehicle for complete accuracy. Specifications, options and accessories may differ in
Hawaii, u.S. territories and other countries. For additional information on availability, options or
accessories, see your InFInItI retailer or contact nissan north America, Inc.
