ACS-4
[ICC]
PRECAUTIONS
Revision: 2006 January2006 M35/M45
[ICC]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NKS004CC
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NING :
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for ICC System ServiceNKS004CD
Do not look straight into the laser beam discharger when adjusting laser beam aiming.
Turn the MAIN switch OFF in conditions similar to driving, such as free rollers or a chassis dynamometer.
Do not use the ICC sensor integrated unit removing from vehicle. Never disassemble and remodel.
Erase DTC when replacing parts of ICC system, then check the operation of ICC system after adjusting
laser beam aiming if necessary.

ACS-10
[ICC]
ACTION TEST
Revision: 2006 January2006 M35/M45
ACTION TESTPFP:00000
ICC System Running TestNKS004CL
NOTE:
ICC system can set VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE and CONVENTIONAL (FIXED
SPEED) CRUISE CONTROL MODE when selector lever is in “D” and “M” position.
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
NOTE:
When there is no vehicle ahead, drive at the set speed steadily.
When there is a vehicle ahead, control to maintain distance from the vehicle ahead, watching its speed.
Set Checking
1. Press the MAIN switch for less than 1.5 seconds.
2. Drive the vehicle between 25 MPH (40 km/h for CANADA models) and 90 MPH (144 km/h for CANADA
models).
3. Push down the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
The set vehicle speed is displayed on the dot matrix LCD in the combination meter.
Check For Increase Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed increases by 1 MPH (1 km/h for CANADA models) as RESUME/ACCELERATE
switch is pushed up.
NOTE:
The maximum set speed of the vehicle-to-vehicle distance control mode is 90 MPH (144 km/h for CANADA
models).
Check For Decrease Of Cruising Speed
1. Set vehicle-to-vehicle distance control mode at desired speed.
2. Check if the set speed decreases by 1 MPH (1 km/h for CANADA models) as SET/COAST switch is
pushed down.
NOTE:
Vehicle-to-vehicle distance control mode is automatically cancelled when the driving speed lowers to 20
MPH (32 km/h for CANADA models) due to the deceleration of the vehicle ahead.
The minimum set speed of the vehicle-to-vehicle distance control mode is 25 MPH (40 km/h for CANADA
models).
Check For Cancellation Of Vehicle-To-Vehicle Distance Control Mode (Normal Driving Condi-
tion) In The Following Cases:
1. When the brake pedal is depressed after the system is turned ON.
2. When the selector lever is shifted to the “N” (Neutral) position.
3. When the MAIN switch is turned OFF.
4. When CANCEL switch is operated.
Check For Restoring Speed That Is Set By Vehicle-To-Vehicle Distance Control Mode Before
Cancellation
1. Cancel the system by depressing the brake pedal. Then, check if the speed before cancellation is
restored when pushing up RESUME/ACCELERATE switch with 25 MPH (40 km/h for CANADA models)
or above.
2. Cancel the system by shifting the selector lever to “N”. Then, check if the speed set before the cancella-
tion is restored when RESUME/ACCELERATE switch is pushed up.
3. Check if the speed previously set is restored when RESUME/ACCELERATE switch is operated with driv-
ing 25 MPH (40 km/h for CANADA models), after canceling vehicle-to-vehicle distance control mode by
operating the CANCEL switch.

ACTION TEST
ACS-11
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
Check For MAIN Switch
1. Start engine. Then, check if the following operations are per-
formed correctly.
2. Vehicle-to-vehicle distance control mode is displayed in combi-
nation meter and “CRUISE” is illuminated when MAIN switch is
pressed “ON” for less than 1.5 seconds and ready for operation.
The illumination goes off when MAIN switch is turned to OFF.
3. “CRUISE” illumination and dot matrix LCD go off when the igni-
tion switch is turned to OFF while MAIN switch is ON (“CRUISE”
illumination is ON and vehicle-to-vehicle distance control mode
is ready for operation).
Check For RESUME/ACCELERATE, SET/COAST, CANCEL Switches
1. Check if RESUME/ACCELERATE, SET/COAST, CANCEL switches are operated smoothly.
2. Check if switches come up as hand is released from the switches.
Check For Distance Switch
1. Start engine.
2. Press the MAIN switch for less than 1.5 seconds.
3. Press the DISTANCE switch.
4. Check if the set distance indicator changes display in order of:
(Long)
(Middle)(Short).
NOTE:
The set distance indicator shows (Long) immediately after the engine starts.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Set Checking
1. Press the MAIN switch for more than 1.5 seconds.
2. Drive the vehicle between 25 MPH (40 km/h for CANADA models) and 90 MPH (144 km/h for CANADA
models).
3. Push down the SET/COAST switch.
4. Confirm that the desired speed is set as hand is released from the SET/COAST switch.
NOTE:
The set vehicle speed is not displayed on the dot matrix LCD in the combination meter.
PKIB8348E
PKIB8349E

ACS-12
[ICC]
ACTION TEST
Revision: 2006 January2006 M35/M45
Check For Increase Of Cruising Speed
1. Set the conventional (fixed speed) cruise control mode at desired speed.
2. Check if the set speed increases by 1 MPH (1.6 km/h for CANADA models) as RESUME/ACCELERATE
switch is pushed up.
NOTE:
If the RESUME/ACCELERATE switch is kept pushing up during cruise control driving, the vehicle speed
increases until the switch is released.
The maximum set speed is 90 MPH (144 km/h for CANADA models).
Check For Decrease Of Cruising Speed
1. Set the conventional (fixed speed) cruise control mode at desired speed.
2. Check if the set speed decreases by 1 MPH (1.6 km/h for CANADA models) as SET/COAST switch is
pushed down.
NOTE:
Conventional (fixed speed) cruise control mode is automatically cancelled when the driving speed lowers
to 20 MPH (32 km/h for CANADA models).
The lowest set speed is 25 MPH (40 km/h for CANADA models).
Check For Cancellation Of Conventional (Fixed Speed) Cruise Control Mode (Normal Driving
Condition) In The Following Cases:
Refer to ACS-10, "Check For Cancellation Of Vehicle-To-Vehicle Distance Control Mode (Normal Driving Con-
dition) In The Following Cases:" .
Check For Restoring Speed That Is Set By Conventional (Fixed Speed) Cruise Control Mode
Before ICC Cancellation
Refer to ACS-10, "Check For Restoring Speed That Is Set By Vehicle-To-Vehicle Distance Control Mode
Before Cancellation" .
Check For MAIN Switch
1. Start engine. Then, check if the following operations are per-
formed correctly.
2. “CRUISE” lamp illuminates and dot matrix LCD goes off when
MAIN switch is pressed “ON” for more than 1.5 seconds, and
then ready for operation. The illumination goes off when MAIN
switch is turned to OFF.
3. “CRUISE” illumination go off when the ignition switch is turned to
OFF while MAIN switch is ON.
Check For RESUME/ACCELERATE, SET/COAST, CANCEL Switches
1. Check if RESUME/ACCELERATE, SET/COAST, CANCEL switches are operated smoothly.
2. Check if switches come up as hand is released from the switches.
PKIB5342J

ACS-18
[ICC]
LASER BEAM AIMING ADJUSTMENT
Revision: 2006 January2006 M35/M45
When “COMPLETED THE VERTICAL AIMING OF LASER
BEAM” appears on screen, touch “END”.
CAUTION:
Be sure that the margin of “U/D CORRECT” is within
4 with
ICC sensor integrated unit is untouched.
10. Confirm that “ADJUSTING AUTOMATIC HORIZONTAL LASER
BEAM AIMING” is on screen and wait for a while (maximum: 10
seconds).
11. Confirm that “NORMALLY COMPLETED” is displayed on CON-
SULT-II and close the aiming adjustment procedure by touching
“END”.
CAUTION:
Complete all the procedures once “LASER BEAM ADJUST”
mode is entered in CONSULT-II. When the procedure is dis-
continued, the ICC system is inoperable.
CHECK AFTER THE ADJUSTMENT
Test the ICC system operation by ICC system running test. Refer to ACS-10, "ICC System Running Test" .
PKIB8362E
PKIB8363E
PKIB8364E

ACS-28
[ICC]
TROUBLE DIAGNOSIS - GENERAL DESCRIPTION
Revision: 2006 January2006 M35/M45
CONSULT-II Function (ICC)NKS004CX
DESCRIPTION
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “ICC” on “SELECT SYSTEM” screen.
If “ICC” is not indicated, go to GI-40, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
Test mode Function Reference page
WORK SUPPORT
Monitors aiming direction to facilitate laser beam aiming operation.
Indicates causes of automatic cancellation of the ICC system.ACS-29
SELF-DIAGNOSTIC RESULTS Displays malfunctioning system memorized in ICC sensor integrated unit.ACS-30
DATA MONITOR Displays real-time input/output data of ICC sensor integrated unit.ACS-30
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.LAN-20
ACTIVE TEST Enables operation check of electrical loads by sending driving signal to them.ACS-33
ECU PART NUMBER Displays part number of ICC sensor integrated unit. —
SKIB3794E
BCIA0029E
BCIA0030E

TROUBLE DIAGNOSIS - GENERAL DESCRIPTION
ACS-33
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
ACTIVE TEST
CAUTION:
Never perform the active test while driving.
“ACTIVE TEST” cannot be started while ICC system warning lamp illuminates.
1. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
2. Touch any of “ICC BUZZER”, “METER LAMP” and “STOP
LAMP” on selection screen.
3. Touch necessary item and “START”.
4. “ACTIVE TEST” screen will be shown.
ICC BUZZER
Touch “TEST START” and “RESET” in “MODE2” to check if ICC
warning chime operates as in the following chart.
METER LAMP
Start engine.
Touch “ON” and “OFF” to check if MAIN switch indicator lamp
and ICC system warning lamp illuminate as in the following
chart.
STOP LAMP
Touch “ON” and “OFF” to check if stop lamp operates as in the fol-
lowing chart.
PKIB8366E
BUZZER O/P ON OFF
Buzzer sound Beep Not activated
PKIB8368E
METER LAMP ON OFF
MAIN switch indicator lamp
ICC system warning lampIlluminated OFF
PKIB8370E
STP LMP DRIVE ON OFF
Stop lamp Lamp ON Lamp OFF
PKIB8369E

ACS-34
[ICC]
TROUBLE DIAGNOSIS - GENERAL DESCRIPTION
Revision: 2006 January2006 M35/M45
Self-Diagnostic FunctionNKS004CY
WITH CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-10, "ACTION
TEST" .
2. Stop vehicle, turn ignition switch OFF, then connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. With engine started, touch “START (NISSAN BASED VHCL)”, “ICC”, “SELF-DIAG RESULTS” on CON-
SULT-II screen in this order.
CAUTION:
If “ICC” cannot be shown after several attempts, the ICC sensor integrated unit may have had mal-
function. Repair or replace it. Refer to GI-40, "
CONSULT-II Data Link Connector (DLC) Circuit" .
4. “DTC RESULTS” and “TIME” are indicated on “SELF-DIAG RESULTS”. “TIME” is used as a reference
data of diagnosis. It shows when malfunction is detected.
NOTE:
“TIME” shows the following.
0: malfunction is detected at present (from malfunction detection to ignition switch OFF).
CAN communication ([U1000], [U1010])
1 ~ 39: Displays when it is normal at present and finds malfunction in the past. It increases like
0
12...3839 after returning to the normal condition whenever IGN OFFON. If it is over 39, it is
fixed to 39 until the self-diagnostic results are erased. It returns to 0 when malfunction is detected again
in the process.
Other than CAN communication (other than [U1000], [U1010])
1 ~ 49: Displays when it is normal at present and finds malfunction in the past. It increases like
0
12...4849 after returning to the normal condition whenever IGN OFFON. If it is over 49, it is
fixed to 49 until the self-diagnostic results are erased. It returns to 0 when malfunction is detected again
in the process.
If “NO DTC...” is shown, check ICC system warning lamp. If any malfunction is indicated, GO TO step 5.
5. According to ACS-39, "
Diagnostic Trouble Code (DTC) Chart" , perform appropriate check, and repair or
replace malfunctioning part as necessary.
6. Turn ignition switch OFF.
7. Start engine and touch “START (NISSAN BASED VHCL)”, “ICC”, “SELF-DIAG RESULTS” and “ERASE”
on CONSULT-II display in turn to erase the memory.
CAUTION:
If the memory does not erase, go to 5.
8. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system
warning lamp does not illuminate.
WITHOUT CONSULT-II
1. Go to operation check after asking the customer for symptom information. Refer to ACS-10, "ACTION
TEST" .
2. Stop the vehicle and turn ignition switch OFF.
3. Start engine.
4. From 5 seconds through 15 seconds after start engine, press
RESUME/ACCELERATE switch 5 times, and SET/COAST
switch 5 times.
CAUTION:
Never turn the MAIN switch ON.
When operation above is not completed from 5 seconds
through 15 seconds, start again from above go to 3.
If self-diagnosis mode cannot be started after several
attempts, the ICC sensor integrated unit may have had
malfunction. Repair or replace it. Refer to ACS-36, "
SELF-
DIAGNOSIS BY DOT MATRIX LCD WILL NOT RUN" .PKIB8371E

TROUBLE DIAGNOSIS - GENERAL DESCRIPTION
ACS-35
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
5. When self-diagnosis mode is started, DTC are shown on set vehicle speed indicator.
CAUTION:
DTC will disappear after 5 minutes.
When more than one malfunction is detected, a maximum of 3 code numbers can be stored; the
latest malfunction will be displayed first.
6. Check ACS-39, "
Diagnostic Trouble Code (DTC) Chart" , and repair or replace if necessary.
7. After repair, erase DTC stored in the ICC sensor integrated unit.
8. DTC 55 will be shown.
9. Turn ignition switch OFF to exit the diagnosis.
10. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system
warning lamp (Orange) does not illuminate.
Self-Diagnostic Erasing Method
1. Stop the vehicle and turn ignition switch OFF.
2. Start engine and start self-diagnosis.
3. During self-diagnosis mode, press CANCEL switch 5 times, and
DISTANCE switch 5 times in this order.
CAUTION:
Press them within 10 seconds after pressing CANCEL
switch at first.
When operation is not completed within 10 seconds, start
again from step 2 above.
4. DTC 55 will be shown.
CAUTION:
DTC of an existing malfunction will not be erased.
5. Turn ignition switch OFF to exit the diagnosis.
6. Perform ICC system running test (drive vehicle with ICC system ON), and make sure that ICC system
warning lamp (Orange) does not illuminate.
PKIB8372E
PKIB8373E
