REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
REMOVAL AND INSTALLATIONPFP:00000
Removal and Installation/Precautions for ReplacementNKS0049F
REMOVAL OF BATTERY
When the battery is removed, the possible route line center position of rear view monitor may not be in the cor-
rect position. Perform the center position correction with the following procedure.
1. Fully turn the steering wheel to left/right.
2. Drive 100 m (328.1 ft) or more at vehicle speed 30 km/h (18.6 MPH) or more.
Audio Unit NKS0049G
REMOVAL
1. Remove cluster lid C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws (A) and remove audio unit (2) in conjunction
with unified meter and A/C amp (1).
3. Remove screws (A) and (B)
4. Remove meter and A/C amp (1), audio unit (2) and bracket (3).
CAUTION:
Be careful not to allow foreign material to enter from CD
slot.
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
Unified meter and A/C amp screws are different from other securing screws. Never confuse them
when installing.
Front Door SpeakerNKS0049H
REMOVAL
1. Remove front door finisher. Refer to EI-34, "DOOR FINISHER" .
2. Remove screws (A) and remove front door speaker (1).
INSTALLATION
Installation is the reverse order of removal.
SKIB4268E
SKIB4269E
SKIB4270E

REMOVAL AND INSTALLATION
AV-127
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
Rear Door Speaker NKS0049I
REMOVAL
1. Remove rear door finisher. Refer to EI-34, "DOOR FINISHER" .
2. Remove screws (A) and remove rear door speaker (1).
INSTALLATION
Installation is the reverse order of removal.
Tw e e t e r NKS0049J
REMOVAL
1. Remove front door finisher. Refer to EI-34, "DOOR FINISHER" .
2. Remove door sash inner cover (front). Refer to EI-34, "
DOOR FINISHER" .
3. Remove screws (A), and disconnect connector (1).
4. Remove tweeter (2).
INSTALLATION
Installation is the reverse order of removal.
Center SpeakerNKS0049K
REMOVAL
1. Remove upper ventilator grill. Refer to ATC-145, "REMOVAL" .
2. Remove screws (A) and disconnect connector.
3. Remove center speaker (1).
INSTALLATION
Installation is the reverse order of removal.
SKIB4271E
SKIB4272E
SKIB4345E

AV-128
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
Seat SpeakerNKS0049L
REMOVAL
1. Remove seat speaker grill as shown in the figure.
CAUTION:
Never reuse seat speaker grill. The pawl is broken when
removing.
2. Remove front seat back trim and pad. Refer to SE-168,
"Removal and Installation" .
3. Remove screws (A) and disconnect connector (1).
4. Remove seat speaker (2).
INSTALLATION
Installation is the reverse order of removal.
Rear Surround SpeakerNKS0049M
REMOVAL
1. Remove rear parcel shelf finisher. Refer to EI-42, "Removal and Installation" .
2. Remove screws (A) and disconnect connector.
3. Remove rear surround speaker (1).
INSTALLATION
Installation is the reverse order of removal.
WooferNKS0049N
REMOVAL
1. Remove rear parcel shelf finisher. Refer to EI-42, "Removal and Installation" .
SKIB3584J
SKIB4346E
SKIB4347E

REMOVAL AND INSTALLATION
AV-129
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
2. Remove screws (A) and disconnect connector.
3. Remove woofer (1).
INSTALLATION
Installation is the reverse order of removal.
BOSE AmpNKS0049O
: Vehicle front
REMOVAL
1. Remove trunk front finisher. Refer to EI-56, "Removal and Installation for Trunk Room Trim" .
2. Remove screws (A), and disconnect connector.
3. Remove BOSE amp (1).
INSTALLATION
Installation is the reverse order of removal.
AudioPilot® MicrophoneNKS0049P
REMOVAL
1. Remove steering column lower cover. Refer to IP-11, "Removal and Installation of Instrument Panel &
Pad" .
2. Remove screws (A) and disconnect connector.
3. Remove Microphone (2) from steering column lower cover (1).
INSTALLATION
Installation is the reverse order of removal.
Satellite Radio TunerNKS0049Q
REMOVAL
1. Remove trunk front finisher. Refer to EI-56, "Removal and Installation for Trunk Room Trim" .
2. Remove rear parcel shelf finisher. Refer to EI-42, "
Removal and Installation" .
SKIB4348E
SKIB4349E
SKIB4350E

AV-130
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
3. Remove screws (A).
4. Disconnect connector and remove satellite radio tuner (1) from
trunk room side.
5. Disconnect screws (A), and remove bracket (1).
INSTALLATION
Installation is the reverse order of removal.
Antenna AmpNKS0049R
REMOVAL
1. Remove rear pillar finisher (RH). Refer to EI-37, "Removal and Installation" .
2. Disengaged the clip (A) to separate glass terminal (1).
3. Remove screw (B) and remove antenna amp (2) from vehicle.
INSTALLATION
Installation is the reverse order of removal.
Satellite Radio AntennaNKS0049S
: Vehicle front
REMOVAL
1. Remove rear pillar finisher. Refer to EI-37, "Removal and Installation" .
2. Remove personal lamp. Refer to LT- 2 8 9 , "
REMOVAL AND INSTALLATION" .
3. Remove assist grip (rear). Refer to EI-52, "
Removal and Installation" .
4. Remove rear display cover. Refer to AV- 2 8 3 , "
Rear Display Unit" .
5. Remove head lining assembly (rear) to obtain work space between the head lining assembly and vehicle.
SKIB4396E
SKIB8875E
SKIB4344E

REMOVAL AND INSTALLATION
AV-131
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
6. Remove nut (A), and then disconnect connector (1).
7. Remove satellite radio antenna.
INSTALLATION
Installation is the reverse order of removal.
AV ( N AV I ) C o n t r o l U n i tNKS0049U
REMOVAL
1. Remove glove box cover. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screws (A), and remove knee assist protector assem-
bly (1).
3. Remove screws (A), and disconnect connector.
4. Remove AV (NAVI) control unit (1).
5. Remove screws (A) and remove bracket (1).
INSTALLATION
Installation is the reverse order of removal.
SKIB4394E
Roof antenna mounting nut : 6.0 N·m (0.61 kg-m, 53 in-lb)
SKIB4273E
SKIB4274E
SKIB4275E

AV-132
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
Front Display Unit (Base System)NKS0049V
REMOVAL
1. Remove upper ventilator grille. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove multifunction switch. Refer to AV- 1 3 3 , "
Multifunction Switch" .
3. Remove screws (A) and screws (B).
4. Disconnect connector, and remove display (1).
5. Remove screws (A) separate front display unit (1) from bracket
(2).
INSTALLATION
Installation is the reverse order of removal.
Front Display Unit (BOSE System)NKS0049W
REMOVAL
1. Remove upper ventilator grille. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove multifunction switch. Refer to ATC-123, "
Removal and Installation of Multifunction Switch" .
3. Remove screw (A).
4. Remove screws (B) and disconnect connector, and remove dis-
play (1).
5. Remove screws (A) separate front display (1) unit from bracket
(2).
SKIB4360E
SKIB4361E
SKIB4373E
SKIB4391E

REMOVAL AND INSTALLATION
AV-133
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
INSTALLATION
Installation is the reverse order of removal.
Multifunction SwitchNKS0049X
REMOVAL
1. Remove instrument panel finisher B and C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove screw (A).
3. Disengage tabs (B) and connector to separate multifunction
switch (1) from instrument panel.
INSTALLATION
Installation is the reverse order of removal.
Preset SwitchNKS0049Y
REMOVAL
1. Remove cluster lid C. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disengage tabs (A) to separate preset switch (1) from cluster lid
C (2).
INSTALLATION
Installation is the reverse order of removal.
SKIB4276E
SKIB4277E

AV-134
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
REMOVAL AND INSTALLATION
Revision: 2007 April2007 M35/M45
Steering SwitchNKS0049Z
REMOVAL
1. Refer to SRS-42, "DRIVER AIR BAG MODULE" .
INSTALLATION
Installation is the reverse order of removal.
DVD PlayerNKS004A0
REMOVAL
1. Remove cup holder. Refer to IP-11, "Removal and Installation of Instrument Panel & Pad" .
2. Disconnect sub harness connector.
3. Remove sub harness connectors (A) from bracket.
4. Remove metal clips (A) and 8 pawls. Then remove DVD player
cover (1).
5. Remove screws (B) and remove DVD player (2).
1. Air bag 2. Steering switch 3. Screw
4. Spring 5. Bracket 6. Screw
SKIB4278E
PKIC0931E
PKIC0932E

REMOVAL AND INSTALLATION
AV-135
[WITHOUT MOBILE ENTERTAINMENT SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2007 April2007 M35/M45
6. Remove screws (A) and remove brackets (1).
INSTALLATION
Installation is the reverse order of removal.
SKIB4358E
