KEY SWITCH (INSERT) CHECK=NBEL0110S06
1 CHECK KEY SWITCH INPUT SIGNAL
Check voltage between smart entrance control unit terminal 32 and ground.
SEL307X
Refer to wiring diagram in EL-257.
OK or NG
OK©Key switch is OK.
NG©GO TO 2.
2 CHECK KEY SWITCH (INSERT)
Check continuity between terminals 1 and 2.
SEL308X
OK or NG
OK©Check the following.
I7.5A fuse [No. 24, located in fuse block (J/B)]
IHarness for open or short between key switch and fuse
IHarness for open or short between smart entrance control unit and key switch
NG©Replace key switch.
POWER DOOR LOCK
Trouble Diagnoses (Cont'd)
EL-264

DOOR LOCK/UNLOCK SWITCH CHECK=NBEL0110S03
1 CHECK DOOR LOCK/UNLOCK SWITCH INPUT SIGNAL
1. Disconnect smart entrance control unit connector.
2. Check continuity between control unit terminal 23 or 35 and ground.
SEL309X
Refer to wiring diagram in EL-257.
OK or NG
OK©Door lock/unlock switch is OK.
NG©GO TO 2.
2 CHECK DOOR LOCK/UNLOCK SWITCH
1. Disconnect door lock/unlock switch connector.
2. Check continuity between each door lock/unlock switch terminals.
IPower window main switch (Door lock/unlock switch LH)
SEL310X
IDoor lock/unlock switch RH
SEL311X
OK or NG
OK©Check the following.
IGround circuit for door lock/unlock switch
IHarness for open or short between door lock/unlock switch and smart entrance control
unit connector
NG©Replace door lock/unlock switch.
GI
MA
EM
LC
EC
FE
AT
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
IDX
POWER DOOR LOCK
Trouble Diagnoses (Cont'd)
EL-265

FRONT DOOR KEY CYLINDER SWITCH CHECK=NBEL0110S07
1 CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL (LOCK/UNLOCK SIGNAL)
Check voltage between smart entrance control unit terminals 30 or 41 and ground.
SEL312X
Refer to wiring diagram in EL-258.
OK or NG
OK©Door key cylinder switch LH is OK.
NG©GO TO 2.
2 CHECK DOOR KEY CYLINDER SWITCH
1. Disconnect door key cylinder switch connector.
2. Check continuity between door key cylinder switch terminals.
SEL313X
OK or NG
OK©Check the following.
IDoor key cylinder switch LH ground circuit
IHarness for open or short between smart entrance control unit and door key cylinder
switch LH
NG©Replace door key cylinder switch LH.
POWER DOOR LOCK
Trouble Diagnoses (Cont'd)
EL-266

BACK DOOR KEY CYLINDER SWITCH CHECK=NBEL0110S08
1 CHECK BACK DOOR KEY CYLINDER SWITCH INPUT SIGNAL (LOCK/UNLOCK SIGNAL)
Check voltage between smart entrance control unit terminals 30 or 41 and ground.
SEL314X
Refer to wiring diagram in EL-258.
OK or NG
OK©Back door key cylinder switch is OK.
NG©GO TO 2.
2 CHECK BACK DOOR KEY CYLINDER SWITCH
1. Disconnect back door key cylinder switch connector.
2. Check continuity between back door key cylinder switch terminals.
SEL315X
OK or NG
OK©Check the following.
IBack door key cylinder switch ground circuit
IHarness for open or short between smart entrance control unit and back door key cyl-
inder switch
NG©Replace back door key cylinder switch.
GI
MA
EM
LC
EC
FE
AT
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
IDX
POWER DOOR LOCK
Trouble Diagnoses (Cont'd)
EL-267

DOOR LOCK ACTUATOR CHECK=NBEL0110S04
