FUEL PUMP CIRCUIT
EC-637
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
FUEL PUMP CIRCUITPFP:17042
DescriptionUBS00HDB
SYSTEM DESCRIPTION
*: ECM determines the start signal status by the signals of engine speed and battery voltage.
The ECM activates the fuel pump for several seconds after the ignition switch is turned ON to improve engine
startability. If the ECM receives a engine speed signal from the camshaft position sensor (PHASE), it knows
that the engine is rotating, and causes the pump to operate. If the engine speed signal is not received when
the ignition switch is ON, the engine stalls. The ECM stops pump operation and prevents battery discharging,
thereby improving safety. The ECM does not directly drive the fuel pump. It controls the ON/OFF fuel pump
relay, which in turn controls the fuel pump.
COMPONENT DESCRIPTION
A turbine type design fuel pump is used in the fuel tank.
CONSULT-II Reference Value in Data Monitor ModeUBS00HDC
Specification data are reference values.
Sensor Input signal to ECM ECM Function Actuator
Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)Engine speed*
Fuel pump control Fuel pump relay
Battery Battery voltage*
Condition Fuel pump operation
Ignition switch is turned to ON. Operates for 1 second.
Engine running and crankingOperates.
When engine is stoppedStops in 1.5 seconds.
Except as shown aboveSto ps.
BBIA0402E
MONITOR ITEM CONDITION SPECIFICATION
FUEL PUMP RLY

For 1 second after turning ignition switch ON

Engine running or crankingON

Except above conditions OFF

IDX-2
ALPHABETICAL INDEX
Numerics
2-4WD shift solenoid valve ..... TF-94
, TF-152, TF-165
4WD - Wiring diagram ....................................... TF-24
4WD shift switch ................................................ TF-66
4WD solenoid valve ................ TF-90, TF-152, TF-165
4WD system description .................................... TF-15
4WD system diagram ........................................ TF-19
A
A/C air flow ...................................................... ATC-29
A/C compressor clutch removal and installation .. ATC-
180
A/C compressor mounting ............................. ATC-179
A/C compressor precaution ............................. ATC-11
A/C compressor special service tool ................ ATC-14
A/C control operation (auto A/C) ...................... ATC-26
A/C diagnostic work flow (auto A/C) .............. ATC-132
A/C evaporator ............................................... ATC-186
A/C HFC134a (R134a) system identification ..... ATC-7
A/C HFC134a (R134a) system precaution ........ ATC-5
A/C HFC134a (R134a) system service procedure ATC-
175
A/C HFC134a (R134a) system service tools ... ATC-14
A/C HFC134a system service equipment precaution ...
ATC-11
A/C lubricant (R134a) ...................................... ATC-22
A/C lubrication oil ............................................. ATC-22
A/C operational check ....................... ATC-57, ATC-60
A/C self-diagnoses (auto A/C) ........ ATC-55, ATC-132
A/C service data specification ........................ ATC-193
A/C trouble diagnoses (auto A/C) .................... ATC-33
A/C, A - Wiring diagram ................................... ATC-43
A/T fluid checking ...................... AT-13, AT-50, MA-22
A/T fluid cooler cleaning .................................... AT-13
A/T fluid replacement ............................. AT-13, MA-24
A/T fluid temperature sensor ........................... AT-126
A/T IND - Wiring diagram .................................... DI-40
A/T indicator ........................................................ DI-40
A/T shift lock system ........................................ AT-222
A/T trouble diagnoses ........................................ AT-41
A/T Wiring diagram AT - CAN ............................ AT-96
A/T Wiring diagram AT - FTS .......................... AT-127
A/T Wiring diagram AT - MAIN ........................ AT-168
A/T Wiring diagram AT - NONDTC .................. AT-177
A/T Wiring diagram AT - PNP/SW ................... AT-105
A/T Wiring diagram AT - STSIG ...................... AT-100
A/T Wiring diagram AT - VSS A/T ................... AT-110
ABS - Wiring diagram ..................................... BRC-16
ABS (anti-lock brake system) ........................... BRC-7
Accelerator control system ............................... ACC-2
Accelerator pedal position (APP) sensor . EC-591, EC-
597, EC-611
Accelerator pedal released position learning ..... EC-90
AF1B1-Wiring diagram EC-461, EC-470, EC-479, EC-
489, EC-500, EC-510, EC-522
AF1B2-Wiring diagram EC-463, EC-472, EC-481, EC-
491, EC-502, EC-512, EC-524
AF1HB1-Wiring diagram ................................. EC-387
AF1HB2-Wiring diagram ................................. EC-389
Aiming adjustment .................................. LT-30, LT-78
Air bag ............................................................... SRS-3
Air cleaner and air duct ..................................... EM-14
Air cleaner filter replacement ............................ MA-16
Air conditioner cut control ................................. EC-28
Air flow meter - See Mass air flow sensor EC-174, EC-
183
Air fuel ratio sensor 1 .. EC-459, EC-468, EC-477, EC-
487, EC-497, EC-507, EC-519
Air fuel ratio sensor 1 heater ........................... EC-386
Air mix. door motor .......................................... ATC-70
Ambient sensor ............................. ATC-137, ATC-148
Angular tightening application ............................. EM-3
APPS1 - Wiring diagram ................................. EC-593
APPS2 - Wiring diagram ................................. EC-599
APPS3 - Wiring diagram ................................. EC-613
ASC/BS - Wiring diagram ............................... EC-571
ASC/SW - Wiring diagram .............................. EC-554
ASCBOF - Wiring diagram .............................. EC-658
ASCD ................................................................ EC-29
ASCD (automatic speed control device) ........... ACS-3
ASCD brake switch ........................... EC-569, EC-657
ASCD indicator lamp ....................................... EC-664
ASCD steering switch ..................................... EC-552
ASCIND - Wiring diagram ............................... EC-665
ATP switch ............................ TF-107, TF-110, TF-115
AUDIO - Wiring diagram .................................... AV-10
AUT/DP - Wiring diagram .................................. SE-20
Auto air conditioner - Wiring diagram .............. ATC-43
Auto anti-dazzling inside mirror ........... GW-75, GW-76
Autolamp ............................................................ LT-47
Automatic amplifier ......................................... ATC-61
Automatic drive positioner .................................. SE-11
Automatic transmission number .......................... GI-48
AV and NAVI control unit ................................... AV-63
AV communication line ...................................... AV-87
B
Back door ........................................................... BL-99
Back door trim ..................................................... EI-32
Back sonar .......................................................... DI-58
BACK/L - Wiring diagram ................................. LT-106
Back-up lamp ................................................... LT-106
Ball joint (front) ................................................ FSU-15
Basic inspection ................................................ EC-72
Battery ................................................................. SC-4
Battery/Starting/Charging System Tester SC-6, SC-12,
SC-19
BCM (Body control module) .............................. BCS-3
Block heater ...................................................... EM-73
Blower motor ................................... ATC-93, ATC-152
Body alignment ................................................ BL-172
Body component parts ..................................... BL-161
Body construction ............................................ BL-171
Body exterior paint color .................................. BL-160
Body mounting ................................................. BL-159

IDX-3
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Body repair ....................................................... BL-160
Body sealing ..................................................... BL-168
Brake booster .................................................... BR-16
Brake fluid level ................................................. MA-28
Brake hydraulic line ........................................... BR-11
Brake inspection ................................................ MA-28
Brake lines and cables inspection ..................... MA-28
Brake master cylinder ....................................... BR-14
Brake switch ...................................... EC-569, EC-586
BRK/SW - Wiring diagram ............................... EC-587
Bulb specifications ........................................... LT-170
Bumper, front ...................................................... EI-13
Bumper, rear ....................................................... EI-15
C
Camshaft ........................................................... EM-43
Camshaft inspection .......................................... EM-46
Camshaft position sensor (PHASE) ................ EC-291
CAN - Wiring diagram EC-164, LAN-18, LAN-52, LAN-
92, LAN-128
CAN (Controller Area Network) BRC-10, SE-17, LAN-
16, LAN-50, LAN-90, LAN-126
CAN communication ... EC-31, EC-163, AT-95, TF-20,
TF-113
, BRC-10, SE-17, LAN-16, LAN-50, LAN-90,
LAN-126
Canister-See EVAP canister ............................. EC-35
Center case (Transfer) ....................... TF-152, TF-165
CHARGE - Wiring diagram ............................... SC-18
Charging system ............................................... SC-17
Chassis and body maintenance ........................ MA-21
Chassis and body maintenanceSchedule 1 ........ MA-8
Chassis and body maintenanceSchedule 2 ...... MA-10
CHIME - Wiring diagram ..................................... DI-44
Circuit breaker ................................................... PG-66
Clock ................................................................... DI-69
CLOCK - Wiring diagram .................................... DI-69
Closed loop control ........................................... EC-25
Closed loop control (Bank 1) ........................... EC-437
Closed loop control (Bank 2) ........................... EC-437
Clutch drum (Transfer) ....................... TF-152, TF-165
Clutch pressure switch (Transfer) ...... TF-152, TF-165
Coil spring (front) ............................................. FSU-10
Collision diagnosis .......................................... SRS-61
Combination lamp, front, removal and installation . LT-
32
Combination lamp, rear, removal and installation .. LT-
122
Combination meter ................................................ DI-5
Combination switch ............................................ LT-97
COMBSW - Wiring diagram ............................... LT-97
COMM - Wiring diagram ................................... AV-87
COMPAS - Wiring diagram ................................. DI-27
Compass ............................................................. DI-26
Component Location (auto A/C) ...................... ATC-39
Compressor clutch removal and installation . ATC-180
Compressor mounting ................................... ATC-179
Compressor precaution ................................... ATC-11
Compressor special service tool ..................... ATC-14
Condenser ..................................................... ATC-185
Connecting rod .................................................. EM-91
Connecting rod bearing clearance ..................... EM-91
Connecting rod bushing clearance .................... EM-91
Console box - See Instrument panel ................... IP-10
CONSULT for VDC ......................................... BRC-28
CONSULT general information ........................... GI-37
CONSULT-II for engine ................................... EC-126
Control units (terminal arrangement) ................. PG-71
Control valve (A/T) ............................................. AT-35
Control valve (Transfer) ...................... TF-152, TF-165
Controller Area Network (CAN) BRC-10, SE-17, LAN-
16, LAN-50, LAN-90, LAN-126
Converter housing installation ............ AT-246, AT-249
COOL/F - Wiring diagram ................................ EC-443
Coolant mixture ratio ......................................... MA-12
Coolant replacement ......................................... MA-13
Cooling circuit (engine) ........................................ CO-8
Cooling fan ........................................................ CO-15
Cooling fan control ........................................... EC-440
Cooling fan motor ............................................ EC-449
Cooling unit (A/C evaporator) ....... ATC-156, ATC-186
Corrosion protection ......................................... BL-165
Crankcase ventilation system - See Positive crankcase
ventilation .......................................................... EC-45
Crankshaft ......................................................... EM-74
Crankshaft position sensor (POS) ................... EC-284
Crash zone sensor .......................................... SRS-56
CVT shift lock system - Wiring diagram ........... AT-223
Cylinder block .................................................... EM-73
Cylinder block boring ......................................... EM-94
D
D/LOCK - Wiring diagram ................................... BL-19
Data link connector for Consult ......... EC-128, EC-140
Daytime light system .......................................... LT-33
Daytime running light - See Daytime light system .. LT-
33
Diagnosis sensor unit ...................................... SRS-59
Diagnostic trouble code (DTC) for OBD system . EC-8,
EC-53
Diagnostic trouble code (DTC) inspection priority chart
EC-101
Differential carrier assembly ............................ RFD-12
Differential carrier disassembly ....................... RFD-14
Differential gear oil replacement ........................ MA-25
Dimensions ......................................................... GI-49
Direct clutch solenoid valve ................ AT-148, AT-150
Display and amp.assembly .............................. ATC-61
Display Control Unit ......................................... AV-158
Dome light - See Interior lamp .......................... LT-129
Door glass .......................................... GW-68, GW-71
Door lock .......................................................... BL-131
Door mirror lamp ............................................... LT-129
Door trim .............................................................. EI-32
Door, front ........................................... BL-128, GW-68
Door, rear ........................................... BL-128, GW-71
Drive belt ........................................................... EM-12

IDX-7
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Rear bumper ....................................................... EI-15
Rear case (Transfer) .......................... TF-146, TF-179
Rear combination lamp removal and installation ... LT-
122
Rear cover packing replacement diff. .............. RFD-24
Rear door ........................................... BL-128, GW-71
Rear seat ......................................................... SE-104
Rear seat belt ...................................................... SB-6
Rear suspension ............................................. RSU-25
Rear view monitor ............................................... DI-71
Rear washer .................................................... WW-35
Rear window defogger ..................................... GW-77
Rear wiper ....................................................... WW-35
Refrigerant connection precaution .................... ATC-7
Refrigerant discharging evacuating charging ATC-175
Refrigerant general precaution .......................... ATC-6
Refrigerant lines ........... ATC-175, ATC-183, ATC-184
Refrigerant pressure sensor ............ EC-643, ATC-185
Relay box .......................................................... PG-78
Remote keyless entry system ............................ BL-44
Removal and installation (A/T) ........... AT-244, AT-247
Removal and installation (Transfer) ................. TF-143
Revolution sensor (A/T) ................................... AT-108
Ring gear diff. inspection ................................. RFD-13
Road wheel size ................................................. GI-49
Rocker cover ..................................................... EM-33
Room lamp ....................................................... LT-129
Room lamp - See Interior lamp ........................ LT-129
ROOM/L - Wiring diagram ................................ LT-135
RP/SEN - Wiring diagram ............................... EC-644
S
SAE J1979 - Service $01 - 09 ........................... EC-48
Seat belt inspection ............................... SB-10, MA-32
Seat belt pre-tensioner .................................... SRS-58
Seat belt, front ..................................................... SB-3
Seat belt, rear ...................................................... SB-6
Seat, front .......................................................... SE-97
Seat, rear ........................................................ SE-104
Self-diagnosis (Transfer) .................................... TF-50
SEN/PW - Wiring diagram ............................... EC-455
SHIFT - Wiring diagram ................................... AT-223
Shift control (Transfer) ....................... TF-147, TF-174
Shift lock system .............................................. AT-222
Shock absorber (front) .................................... FSU-10
Shock absorber (rear) ..................................... RSU-34
Side air bag (satellite) sensor .......................... SRS-57
Side bearing preload diff. ................................ RFD-19
Side curtain air bag ......................................... SRS-54
Side trim .............................................................. EI-35
SMJ (super multiple junction) ............................ PG-74
SONAR - Wiring diagram .................................... DI-61
Spare tire size .................................................... GI-49
Spark plug ......................................................... EM-27
Spark plug replacement .................................... MA-18
Specification value .......................................... EC-146
Speedometer ......................................................... DI-5
Spiral cable ..................................................... SRS-48
SROOF - Wiring diagram .................................. RF-13
SRS - See Supplemental Restraint System ...... SRS-5
SRS - Wiring diagram ...................................... SRS-12
SRS Trouble diagnoses ..................................... SRS-8
Stabilizer bar (front) ......................................... FSU-12
Stabilizer bar (rear) ......................................... RSU-41
Stall test (A/T) .................................................... AT-50
Standardized relay ............................................. PG-72
START - Wiring diagram ................................... SC-11
Starting system .................................................. SC-10
Steering gear, linkage and transfer gear inspection .....
MA-29
Steering linkage ................................................. PS-15
Steering wheel and column ................................. PS-7
Step lamp ......................................................... LT-130
Stop lamp ......................................................... LT-103
Stop lamp switch ................. EC-569, EC-586, EC-657
STOP/L - Wiring diagram ................................. LT-104
Strut (front) ...................................................... FSU-10
Sub-oil pump (Transfer) ...................... TF-152, TF-165
Sun gear (Transfer) ............................ TF-147, TF-174
Sun roof, electric ................................................ RF-10
Sunload sensor .............................................. ATC-143
Sunroof .............................................................. RF-23
Supplemental Restraint System ........................ SRS-5
Supplemental restraint system - Wiring diagram . SRS-
12
Symbols and abbreviations ..................... GI-10, GI-22
Symptom matrix chart ...................................... EC-104
System readiness test (SRT) code .................... EC-54
T
Tachometer .......................................................... DI-5
Tail lamp ........................................................... LT-108
TAIL/L - Wiring diagram .................................... LT-110
TCM circuit diagram .......................................... AT-49
TCM inspection table ......................................... AT-82
TCS - Wiring diagram ..................................... BRC-16
TCS (traction control system) ........................... BRC-7
TCS component parts and connector location BRC-14
TCS wheel sensors ........................................ BRC-14
Theft warning system - See Vehicle security (Theft warn-
ing) system ......................................................... BL-75
Thermometer ...................................................... DI-26
Three way catalyst ............................................. EM-19
Three way catalyst function (Bank 1) .............. EC-298
Three way catalyst function (Bank 2) .............. EC-298
Three way catalyst precautions ............................ GI-5
Throttle control motor ...................................... EC-410
Throttle control motor relay .............................. EC-405
Throttle position sensor (TPS) ... EC-201, EC-264, EC-
450, EC-452, EC-604
Throttle valve closed position learning .............. EC-90
Tie-rod ............................................................... PS-15
Timing chain ...................................................... EM-35
Tire rotation ....................................................... MA-28
Tire size .............................................................. GI-49
Tooth contact diff. ............................................ RFD-20

MA-22
CHASSIS AND BODY MAINTENANCE
Revision: October 20052005 QX56
6. Install the lower glove box in the instrument panel and secure it
with the two hinge pins.
Checking Exhaust SystemELS001BZ
Check exhaust pipes, muffler and mounting for improper attachment,
leaks, cracks, damage, loose connections, chafing or deterioration.
Checking A/T FluidELS001C0
1. Warm up the engine.
2. Check for any fluid leaks.
3. Remove the tightening bolt for the ATF level gauge.
4. Before driving, the fluid level can be checked at fluid tempera-
tures of 30° to 50°C (86° to 122°F) using the “COLD” range on
the ATF level gauge as follows:
a. Park the vehicle on a level surface and set the parking brake.
b. Start the engine and move the selector lever through each gear
position. Shift the selector lever into the “P” position.
c. Check the fluid level with the engine idling.
d. Remove the ATF level gauge and wipe it clean with a lint-free
paper.
CAUTION:
When wiping the fluid from the ATF level gauge, always use
a lint-free paper, not a cloth.
e. Re-insert the ATF level gauge into the charging pipe until the
cap contacts the top of the charging pipe as shown.
CAUTION:
To check fluid level, insert the ATF level gauge until the cap
contacts the top of the charging pipe, with the gauge
reversed from the normal inserted position.
f. Remove the ATF level gauge and note the fluid level. If the fluid
level is at low side of range, add fluid to the transmission
through the charging pipe.
CAUTION:
Do not overfill the transmission with fluid.
5. Drive vehicle for approximately 5 minutes in urban areas.
WLIA0027E
SM A211 A
WLIA0014E
SCIA1684E

CHASSIS AND BODY MAINTENANCE
MA-23
C
D
E
F
G
H
I
J
K
MA
B
MA
Revision: October 20052005 QX56
6. Drive the vehicle for at least five minutes or until the fluid temperature reaches approximately 65°C
(149°F).Use the CONSULT-II to monitor the fluid temperature as follows:
NOTE:
Fluid level will be greatly affected by temperature as shown. Therefore monitor the fluid temperature data
using the CONSULT-II.
a. Connect CONSULT-II to data link connector.
b. Select “MAIN SIGNALS” in “DATA MONITOR” mode for “A/T” with CONSULT-II.
c. Read out the value of “ATF TEMP 1”.
7. Re-check the fluid level at fluid temperatures of approximately
65°C (149°F) using the “HOT” range on the A/T fluid level gauge
as shown.
CAUTION:

When wiping the fluid from the ATF level gauge, always
use lint-free paper, not a cloth.

To check the fluid level, insert the ATF level gauge until
the cap contacts the top of the charging pipe, with the
gauge reversed from the normal inserted position as
shown.
8. Check the fluid condition.

If the fluid is very dark or smells burned, there may be an
internal problem with the transmission. Refer to AT - 4 1 ,
"TROUBLE DIAGNOSIS" . Flush the transmission cooling
system after repairing the transmission.

If the ATF contains frictional material (clutches, bands, etc.),
replace the radiator and flush the transmission cooler lines
using cleaning solvent and compressed air after repairing the
transmission.
9. Install the ATF level gauge in the fluid charging pipe and install the level gauge bolt. Tighten the level
gauge bolt to specification.
SLIA0016E
WLIA0014E
Level gauge bolt : Refer to AT-250, "Components" .
SCIA1684E

MA-24
CHASSIS AND BODY MAINTENANCE
Revision: October 20052005 QX56
Changing A/T FluidELS001C1
1. Run the engine to warm up the ATF.
2. Stop the engine.
3. Remove the bolt for the ATF level gauge.
4. Drain the ATF from the drain plug hole and refill the transmission
with new ATF. Always refill same volume with drained fluid and
use the dipstick to check the fluid level as shown. Add fluid as
necessary.

To flush out the old fluid from the coolers, pour new fluid into the charging pipe with the engine idling
and at the same time drain the old fluid from the auxiliary transmission oil cooler hose return line.

When the color of the fluid coming out of the auxiliary transmission oil cooler hose return line is about
the same as the color of the new fluid, flushing out the old fluid is complete. The amount of new trans-
mission fluid used for flushing should be 30% to 50% of the specified capacity.
CAUTION:

Use only Genuine NISSAN ATF Matic Fluid J. Do not mix with other fluid.

Using automatic transmission fluid other than Genuine NISSAN ATF Matic Fluid J will cause
deterioration in driveability and automatic transmission durability, and may damage the auto-
matic transmission, which is not covered by the warranty.

When filling the transmission with fluid, do not spill the ATF on any heat generating parts such
as the exhaust manifold.
5. Check the fluid level and condition. Refer to MA-22, "
Checking A/T Fluid" . If the fluid is still dirty, repeat
steps 2 through 5.
6. Install the ATF level gauge in the fluid charging pipe and install the level gauge bolt. Tighten the level
gauge bolt to specification.
Changing Transfer FluidELS001H0
DRAINING
1. Stop the engine.
2. Remove the drain plug and gasket to drain the transfer fluid as
shown.
3. Install the new gasket on the drain plug and install the drain plug
in the transfer. Tighten the drain plug to specification.
CAUTION:
Do not reuse the gasket.
WLIA0014E
Transmission fluid type and capacity : Refer to MA-11, "Fluids and Lubricants" .
Drain plug : Refer to AT-250, "
Components" .
Level gauge bolt : Refer to AT-250, "
Components" .
Drain plug : Refer to TF-144, "
COMPONENTS" .
SM A44 4B

PG-60
HARNESS
Revision: October 20052005 QX56
Wiring Diagram Codes (Cell Codes)EKS00BNE
Use the chart below to find out what each wiring diagram code stands for.
Refer to the wiring diagram code in the alphabetical index to find the location (page number) of each wiring
diagram.
Code Section Wiring Diagram Name
A/C,A ATC Auto Air Conditioner
A/SUSP RSU Rear Air Suspension
AF1B1 EC Air Fuel Ratio Sensor 1 (Bank 1)
AF1B2 EC Air Fuel Ratio Sensor 1 (Bank 2)
AF1HB1 EC Air Fuel Ratio Sensor 1 (Bank 1)
AF1HB2 EC Air Fuel Ratio Sensor 1 (Bank 2)
APPS1 EC Accelerator Pedal Position Sensor
APPS2 EC Accelerator Pedal Position Sensor
APPS3 EC Accelerator Pedal Position Sensor
ASC/BS EC ASCD Brake Switch
ASC/SW EC ASCD Steering Switch
ASCBOF EC ASCD Brake Switch
ASCIND EC ASCD Indicator
A/T AT A/T Assembly
AT/IND DI A/T Indicator Lamp
AUDIO AV Audio
AUTO/DP SE Automatic Drive Positioner
AUTO/L LT Auto Light Control
B/CLOS BL Back Door Auto Closure System
BACK/L LT Back-up Lamp
BRK/SW EC Brake Switch
CAN EC CAN Communication Line
CAN LAN CAN System
CHARGE SC Charging System
CHIME DI Warning Chime
CLOCK DI Clock
COOL/F EC Cooling Fan Control
COMBSW LT Combination Switch
COMM AV Audio Visual Communication System
COMPAS DI Compass and Thermometer
D/LOCK BL Power Door Lock
DEF GW Rear Window Defogger
DTRL LT Headlamp - With Daytime Light System
DVD AV DVD Entertainment System
ECM/PW EC ECM Power Supply for Back-Up
ECTS EC Engine Coolant Temperature Sensor
ETC1 EC Electric Throttle Control Function
ETC2 EC Throttle Control Motor Relay
ETC3 EC Throttle Control Motor
F/FOG LT Front Fog Lamp
F/PUMP EC Fuel Pump
FTTS EC Fuel Tank Temperature Sensor
FUELB1 EC Fuel Injection System Bank 1
FUELB2 EC Fuel Injection System Bank 2
H/AIM LT Headlamp Aiming Control
H/LAMP LT Headlamp
HORN WW Horn

SC-1
STARTING & CHARGING SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION SC
A
B
SC
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
Wiring Diagrams and Trouble Diagnosis .................. 2
PREPARATION ........................................................... 3
Special Service Tool ................................................. 3
Commercial Service Tools ........................................ 3
BATTERY .................................................................... 4
How to Handle Battery ............................................. 4
METHODS OF PREVENTING OVER-DIS-
CHARGE ............................................................... 4
CHECKING ELECTROLYTE LEVEL .................... 4
SPECIFIC GRAVITY CHECK ............................... 5
CHARGING THE BATTERY ................................. 6
Trouble Diagnoses with Battery/Starting/Charging
System Tester .......................................................... 6
DIAGNOSTIC RESULT ITEM CHART .................. 8
Removal and Installation .......................................... 9
REMOVAL ............................................................. 9
INSTALLATION ..................................................... 9
STARTING SYSTEM ................................................ 10
System Description ................................................ 10
Wiring Diagram — START — ..................................11
Trouble Diagnoses with Battery/Starting/Charging
System Tester ........................................................ 12
DIAGNOSTIC RESULT ITEM CHART ................ 12
WORK FLOW ...................................................... 13DIAGNOSTIC PROCEDURE 1 ........................... 14
DIAGNOSTIC PROCEDURE 2 ........................... 15
MINIMUM SPECIFICATION OF CRANKING
VOLTAGE REFERENCING COOLANT TEM-
PERATURE ......................................................... 16
Removal and Installation ........................................ 16
REMOVAL ........................................................... 16
INSTALLATION ................................................... 16
CHARGING SYSTEM ............................................... 17
System Description ................................................. 17
Wiring Diagram — CHARGE — ............................. 18
Trouble Diagnoses with Battery/Starting/Charging
System Tester ......................................................... 19
DIAGNOSTIC RESULT ITEM CHART ................ 20
WORK FLOW ...................................................... 21
DIAGNOSTIC PROCEDURE 1 ........................... 22
DIAGNOSTIC PROCEDURE 2 ........................... 23
DIAGNOSTIC PROCEDURE 3 ........................... 23
DIAGNOSTIC PROCEDURE 4 ........................... 24
DIAGNOSTIC PROCEDURE 5 ........................... 26
MALFUNCTION INDICATOR .............................. 27
Removal and Installation ........................................ 27
REMOVAL ........................................................... 27
INSTALLATION ................................................... 27
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 28
Battery .................................................................... 28
Starter ..................................................................... 28
Generator ............................................................... 28

PREPARATION
SC-3
C
D
E
F
G
H
I
J
L
MA
B
SC
Revision: October 20052005 QX56
PREPARATIONPFP:00002
Special Service ToolEKS00B76
Commercial Service ToolsEKS00B77
Tool number
(Kent-Moore No.)
Tool nameDescription
—
(J-44373)
Battery/Starting/Charging system
testerModel 620
SEL403X
Tool nameDescription
Power toolLoosening bolts and nuts
PBIC0190E
