SRS-28
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
NOTE:
Follow the procedures in numerical order when repairing malfunctioning parts. Confirm whether malfunction is
eliminated using air bag warning lamp or CONSULT-II each time repair is finished. If malfunction is still
observed, proceed to the next step. When malfunction is eliminated, further repair work is not required.
DIAGNOSTIC PROCEDURE 3
Final Check of SRS Using CONSULT-II—Diagnosis Mode
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunction might be detected
in self-diagnosis depending on control unit which carry out CAN communication.
1. After repairing SRS, connect both battery cables.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “AIR BAG”.
If "AIR BAG" is not indicated, refer to GI-39, "
CONSULT-II Data
Link Connector (DLC) Circuit" .
SIDE COLLISION
DETECTION
[B1210]
Side or curtain air bag modules are deployed. 1. Refer to SRS-61, "COLLISION
DIAGNOSIS" .
ROLLOVER DETECTION
[B1211]

Curtain air bag module and seat belt pre-tensioner are
deployed.1. Refer to SRS-61, "COLLISION
DIAGNOSIS" . Diagnostic item ExplanationRepair order
Recheck SRS at each replacement
BBIA0369E
BCIA0029E
BCIA0030E

SRS-32
TROUBLE DIAGNOSIS
Revision: October 20052005 QX56
6. Touch “SELF-DIAG [PAST]”.
7. If diagnostic codes are displayed on “SELF-DIAG [PAST]”, go to
step 10.
If no malfunction is detected on “SELF-DIAG [PAST]”, touch
“BACK” and go back to “SELECT DIAG MODE”.
8. Touch “TROUBLE DIAG RECORD”.
NOTE:
With “TROUBLE DIAG RECORD”, diagnosis results previ-
ously erased by a reset operation can be displayed.
9. Diagnostic code is displayed on “TROUBLE DIAG RECORD”.
10. Touch “PRINT”.
11. Compare diagnostic codes to SRS-33, "
CONSULT-II Diagnostic
Code Chart ("SELF-DIAG [PAST]" or "TROUBLE DIAG
RECORD")" .
12. Touch “BACK” key of CONSULT-II until “SELECT SYSTEM”
appears.
13. Turn ignition switch OFF, then turn off and disconnect CON-
SULT-II, and both battery cables.
BCIA0031E
WHIA0152E
SRS7 02
BCIA0031E
WHIA0153E

TROUBLE DIAGNOSIS
SRS-33
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: October 20052005 QX56
14. Repair the system as outlined by the “Repair order” in “Intermittent Malfunction Diagnostic Code Chart”,
that corresponds to the self-diagnostic result. For replacement procedure of component parts, refer to the
Removal and Installation procedure for the appropriate component.
15. Go to SRS-28, "
DIAGNOSTIC PROCEDURE 3" , for final checking.
CONSULT-II Diagnostic Code Chart ("SELF-DIAG [PAST]" or "TROUBLE DIAG RECORD")
Diagnostic item ExplanationRepair order
Recheck SRS at each replacement
NO DTC IS DETECTEDWhen malfunction is
indicated by the “AIR
BAG” warning lamp in
User mode.

Low battery voltage (Less than
9V)
Go to SRS-28, "DIAGNOSTIC PRO-
CEDURE 3" .

Self-diagnostic result “SELF-DIAG
[PAST]” (previously stored in the
memory) might not be erased
after repair.

Intermittent malfunction has been
detected in the past.

Go to SRS-31, "DIAGNOSTIC PRO-
CEDURE 4 (CONTINUED FROM
DIAGNOSTIC PROCEDURE 2)" .

Go to SRS-31, "DIAGNOSTIC PRO-
CEDURE 5" .

No malfunction is detected. —
DRIVER AIRBAG MODULE
[OPEN]
[B1049] or [B1054]

Driver air bag module circuit is open (including the spiral
cable).1. Visually check the wiring harness
connection.
2. Replace the harness if it has visible
damage.
3. Replace driver air bag module.
4. Replace the spiral cable.
5. Replace the air bag diagnosis sen-
sor unit.
6. Replace the related harness. DRIVER AIRBAG MODULE
[VB-SHORT]
[B1050] or [B1055]

Driver air bag module circuit is shorted to some power sup-
ply circuit (including the spiral cable).
DRIVER AIRBAG MODULE
[GND-SHORT]
[B1051] or [B1056]

Driver air bag module circuit is shorted to ground (including
the spiral cable).
DRIVER AIRBAG MODULE
[SHORT]
[B1052] or [B1057]

Driver air bag module circuits are shorted to each other.
ASSIST A/B MODULE
[OPEN]
[B1065] or [B1070]

Front passenger air bag module circuit is open. 1. Visually check the wiring harness
connection.
2. Replace the harness if it has visible
damage.
3. Replace front passenger air bag
module.
4. Replace the air bag diagnosis sen-
sor unit.
5. Replace the related harness. ASSIST A/B MODULE
[VB-SHORT]
[B1066] or [B1071]

Front passenger air bag module circuit is shorted to some
power supply circuit.
ASSIST A/B MODULE
[GND-SHORT]
[B1067] or [B1072]

Front passenger air bag module circuit is shorted to
ground.
ASSIST A/B MODULE
[SHORT]
[B1068] or [B1073]

Front passenger air bag module circuits are shorted to
each other.
CRASH ZONE SEN
[UNIT FAIL]
[B1033] or [B1034]
CRASH ZONE SEN
[COMM FAIL]
[B1035]

Crash zone sensor 1. Visually check the wiring harness
connection.
2. Replace the harness if it has visible
damage.
3. Replace the crash zone sensor.
4. Replace the air bag diagnosis sen-
sor unit.
5. Replace the related harness.

SRS-46
DRIVER AIR BAG MODULE
Revision: October 20052005 QX56
DRIVER AIR BAG MODULEPFP:K8510
Removal and InstallationEHS0016X
REMOVAL
CAUTION:

Do not attempt to repair or replace damaged direct-connect SRS component connectors. If a
driver air bag direct-connect harness connector is damaged, the spiral cable must be replaced.

Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at
least 3 minutes.

When servicing the SRS, do not work from directly in front of air bag module.
1. Remove the left and right side lids and bolts.
2. Lift the driver air bag module from the steering wheel.
3. Disconnect the horn connector and air bag harness, then remove the driver air bag module.

For removal/installation of the direct-connect SRS connectors, refer to SRS-7, "Direct-connect SRS
Component Connectors" .
CAUTION:

When servicing the SRS, do not work from directly in front of air bag module.
1. Horn harness 2. Steering wheel hook 3. Inflator harness
4. Side lids RH/LH 5. Driver air bag module 6. Steering wheel
WHIA0159E
WHIA0184E

SRS-48
SPIRAL CABLE
Revision: October 20052005 QX56
SPIRAL CABLEPFP:25554
Removal and InstallationEHS0016Y
REMOVAL
CAUTION:

Before servicing the SRS, turn ignition switch OFF, disconnect both battery cables and wait at
least 3 minutes.

When servicing the SRS, do not work from directly in front of air bag module.
1. Set the front wheels in the straight-ahead position.
2. Remove driver air bag module. Refer to SRS-46, "
Removal and Installation" .
3. Remove the steering wheel center nut.
4. Remove the steering wheel using Tool.
5. Remove the column cover upper and lower.
WHIA0233E
1. Steering wheel 2. Lighting and turn signal switch 3. Wiper and washer switch
4. Spiral cable 5. Driver air bag module connector 6. Column cover upper
7. Column assembly 8. Column cover lower 9. Screw (Do not remove)
10. Screw
Tool number: A: J-1859A
B: J-42578
WHIA0124E

FRONT PASSENGER AIR BAG MODULE
SRS-51
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: October 20052005 QX56
FRONT PASSENGER AIR BAG MODULEPFP:K8515
Removal and InstallationEHS0016Z
The passenger air bag module originally installed in the vehicle uses direct-connect style harness connectors.
Service replacement passenger air bag modules use tab-locking style harness connectors. If the passenger
air bag module is replaced or if the direct-connect harness connectors are damaged, the vehicle wiring har-
ness must be modified to allow connection of the service replacement passenger air bag module. Refer to
SRS-52, "
WIRING HARNESS MODIFICATION" for wiring harness modification procedure.
REMOVAL
CAUTION:

Do not attempt to repair or replace damaged direct-connect front passenger air bag module con-
nectors. If a direct-connect harness connector is damaged, the front passenger air bag must be
replaced and the wiring harness modified.

Before servicing SRS, turn the ignition switch off, disconnect both battery cables and wait at least
3 minutes.

Always work from the side of or under front passenger air bag module.
1. Remove the glove box. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
2. Remove 2 nuts (through glove box opening) retaining front pas-
senger air bag module to instrument panel crossmember.
3. Disconnect the air bag module electrical connectors.

For removal/installation of the direct-connect SRS connec-
tors, refer to SRS-7, "
Direct-connect SRS Component Con-
nectors" .
4. Remove the instrument panel assembly from the vehicle. Refer
to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
5. Remove front passenger air bag module nuts and remove air
bag module from the instrument panel assembly.
CAUTION:

When servicing the SRS, do not work from directly in front
of air bag module.

Always place front passenger air bag module with caution
label side facing upward.

Do not insert any foreign objects (screwdriver, etc.) into air
bag module or harness connectors.

Do not disassemble air bag module.

Do not use old nuts after removal; replace with new nuts.

Do not expose the front passenger air bag module to tem-
peratures exceeding 90°C (194°F).

Replace the air bag module if it has been dropped or sus-
tained an impact.

Do not allow oil, grease or water to come in contact with the
air bag module.

For removal/installation of the direct-connect SRS connec-
tors, refer to SRS-7, "
Direct-connect SRS Component Con-
nectors" .
INSTALLATION
Original Passenger Air Bag Module
To install, reverse the removal procedure.
WHIA0110E
W H I A 0111 E
SBF 8 14 E

SRS-52
FRONT PASSENGER AIR BAG MODULE
Revision: October 20052005 QX56

For removal/installation of the direct-connect SRS connectors, refer to SRS-7, "Direct-connect SRS Com-
ponent Connectors" .
CAUTION:

Always work from the side of or under front passenger air bag module.

After the work is completed, perform self-diagnosis to check that no malfunction is detected.
Refer to SRS-20, "
SRS Operation Check" .
Service Replacement Passenger Air Bag Module
1. Install the front passenger air bag module to the instrument
panel pad assembly.
2. Install the instrument panel assembly. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
3. Connect the front passenger air bag module harness connector to yellow 4-pin service replacement air
bag connector and fasten connector to mounting bracket.
CAUTION:

Always work from the side of or under front passenger air bag module.

After the work is completed, perform self-diagnosis to check that no malfunction is detected.
Refer to SRS-20, "
SRS Operation Check" .
WIRING HARNESS MODIFICATION
The passenger air bag module originally installed in the vehicle uses direct-connect style harness connectors.
Service replacement passenger air bag modules use tab-locking style harness connectors. If the passenger
air bag module is replaced or if the direct-connect harness connectors are damaged, the vehicle wiring har-
ness must be modified to allow connection of the service replacement passenger air bag module.
NOTE:
The wiring harness modification is to be performed only if the vehicle is equipped with the original passenger
air bag which uses direct-connect harness connectors. If the passenger air bag is to be replaced in a vehicle
that has already had the service replacement passenger air bag installed, the wiring harness modification is
not required.
CAUTION:

Do not attempt to repair or replace damaged direct-connect front passenger air bag module con-
nectors. If a direct-connect harness connector is damaged, the front passenger air bag must be
replaced and the wiring harness modified.

Before servicing SRS, turn the ignition switch off, disconnect both battery cables and wait at least
3 minutes.

Always work from the side of or under front passenger air bag module.

After the work is completed, perform self-diagnosis to check that no malfunction is detected.
Refer to SRS-20, "
SRS Operation Check" .
1. Locate the yellow and orange direct-connect passenger air bag module harness connectors.
2. Use wire cutters to cut back both previously used direct-connect passenger air bag module harness con-
nectors from the vehicle wiring harness approximately 50 mm (1.9 in) from the connectors.
3. Remove approximately 150 mm (5.9 in) of the vehicle harness covering from the cut end.
WHIA0110E

SRS-54
SIDE CURTAIN AIR BAG MODULE
Revision: October 20052005 QX56
SIDE CURTAIN AIR BAG MODULEPFP:985P0
Removal and InstallationEHS00171
REMOVAL
CAUTION:

Do not attempt to repair or replace damaged direct-connect SRS component connectors. If a
direct-connect harness connector is damaged, the harness must be replaced.

Before servicing the SRS, turn the ignition switch off, disconnect both battery cables and wait at
least 3 minutes.

When servicing the SRS, do not work from directly in front of air bag module.
1. Remove headlining. Refer to EI-38, "
Removal and Installation" .
2. Disconnect front and rear side curtain air bag module connectors.

For removal/installation of the direct-connect SRS connectors, refer to SRS-7, "Direct-connect SRS
Component Connectors" .
3. Remove the bolts in order starting at the front or rear, and remove the side curtain air bag module.
CAUTION:

When servicing the SRS, do not work from directly in front of air bag module.

Do not insert any foreign objects (screwdriver, etc.) into air bag module or harness connectors.

Do not disassemble air bag module.

Do not expose the air bag module to temperatures exceeding 90°C (194°F).

Replace side curtain air bag module if it has been dropped
or sustained an impact.

Do not allow oil, grease or water to come in contact with the
air bag module.
INSTALLATION
To install, reverse the removal procedure.

For removal/installation of the direct-connect SRS connectors, refer to SRS-7, "Direct-connect SRS Com-
ponent Connectors" .
LHIA0079E
SBF 8 14 E

SRS-56
CRASH ZONE SENSOR
Revision: October 20052005 QX56
CRASH ZONE SENSORPFP:98531
Removal and InstallationEHS00172
REMOVAL
CAUTION:

Before servicing the SRS, turn the ignition switch off, disconnect both battery cables and wait at
least 3 minutes.
1. Remove front grille. Refer to EI-17, "
FRONT GRILLE" .
2. Disconnect the crash zone sensor harness connector.
3. Remove crash zone sensor nuts.
CAUTION:

Replace crash zone sensor if it has been dropped or sustained an impact.

Do not disassemble crash zone sensor.
INSTALLATION
To install, reverse the removal procedure.

After the work is complete, perform self-diagnosis to check that no malfunction is detected. Refer to SRS-
20, "SRS Operation Check" .
LHIA0056E

SIDE AIR BAG (SATELLITE) SENSOR
SRS-57
C
D
E
F
G
I
J
K
L
MA
B
SRS
Revision: October 20052005 QX56
SIDE AIR BAG (SATELLITE) SENSORPFP:98830
Removal and InstallationEHS00173
REMOVAL
CAUTION:

Before servicing the SRS, turn the ignition switch off, disconnect both battery cables and wait at
least 3 minutes.
1. Remove seat belt pre-tensioner. Refer to SB-3, "
Removal and
Installation of Front Seat Belt" .
2. Remove side air bag (satellite) sensor nuts.
3. Disconnect the side air bag (satellite) sensor harness connector.
CAUTION:

Do not use old nuts after removal; replace with new nuts.

Check side air bag (satellite) sensor to ensure it is free of deformities, dents, cracks or rust. If it
shows any visible signs of damage, replace it with new one.

Do not disassemble side air bag (satellite) sensor.

Replace side air bag (satellite) sensor if it has been dropped or sustained an impact.
INSTALLATION
To install, reverse the removal procedure.

After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to
SRS-20, "
SRS Operation Check" .
LHIA0062E
