TROUBLE DIAGNOSIS FOR SYSTEM
TF-83
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
2. CHECK GROUND CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector.
3. Check continuity between transfer control unit harness connec-
tor E142 terminals 3 (B), 6 (B), E143 terminal 45 (B) and ground.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair open circuit or short to ground or short to power
in harness or connectors.
3. CHECK ACTUATOR MOTOR POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Remove transfer shift high relay and transfer shift low relay. Refer to TF-22, "
Location of Electrical Parts" .
3. Check voltage between transfer shift high relay harness connec-
tor E46 terminal 5 (R), transfer shift low relay harness connector
E47 terminal 5 (R) and ground.
4. Turn ignition switch “ON”. (Do not start engine.)
5. Check voltage between transfer shift high relay harness connec-
tor E46 terminal 5 (R), transfer shift low relay harness connector
E47 terminal 5 (R) and ground.
OK or NG
OK >> GO TO 4.
NG >> Check the following. If any items are damaged, repair or
replace damaged parts.
20A fuse No. 57 located in the fuse and relay box. Refer to PG-4, "POWER SUPPLY ROUTING
CIRCUIT" .
Harness for short or open between battery, transfer shift high relay harness connector E46 ter-
minal 5 (R) and transfer shift low relay harness connector E47 terminal 5 (R). Continuity should exist.
SDIA2691E
Connector Terminal (Wire color) Voltage (Approx.)
E46 5 (R) - Ground
Battery voltage
E47 5 (R) - Ground
SDIA2707E
Connector Terminal (Wire color) Voltage (Approx.)
E46 5 (R) - Ground
Battery voltage
E47 5 (R) - Ground
SDIA2706E
Page 3234 of 3419
TROUBLE DIAGNOSIS FOR SYSTEM
TF-91
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
2-4WD SolenoidEDS002IH
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.
DIAGNOSTIC PROCEDURE
1. CHECK 4WD SHIFT SWITCH SYSTEM
Perform self-diagnosis. Refer to TF-50, "
Self-diagnostic Procedure" .
Is the "4WD MOD SW [P1814]" (with CONSULT-II) or "Flickering pattern: 16 (without CONSULT-II) detected?
YES >> Perform trouble diagnosis for 4WD shift switch. Refer to TF-62, "4WD Shift Switch" .
NO >> GO TO 2.
Monitored item Content Condition Display value
2-4WD SOL [ON/OFF]Condition of 2-4WD shift
solenoid valve
Vehicle stopped
Engine running
A/T selector lever “N”
position
Brake pedal depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
ON 4WD shift switch: 4H
4WD shift switch: 4LO
4WD shift switch: AUTO
(“Wait” function is operat-
ing.)OFF
4WD shift switch: 4H
(“Wait” function is operat-
ing.)OFF
2-4WD SOL MON [ON/
OFF]Check signal for transfer
control unit signal output
Vehicle stopped
Engine running
A/T selector lever “N”
position
Brake pedal depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
ON 4WD shift switch: 4H
4WD shift switch: 4LO
4WD shift switch: AUTO
(“Wait” function is operat-
ing.)OFF
4WD shift switch: 4H
(“Wait” function is operat-
ing.)OFF
Te r m i n a lWire
colorItem Condition Data (Approx.)
1 GR 2-4WD shift solenoid valve
Vehicle stopped
Engine running
A/T selector
lever “N” position
Brake pedal
depressed4WD shift switch: 2WD 0V
4WD shift switch: AUTO, 4H or 4LO Battery voltage
Page 3235 of 3419
TF-92
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: October 20052005 QX56
2. CHECK 2-4WD SHIFT SOLENOID SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR” mode for “ALL MODE AWD/4WD” with CONSULT-II.
3. Read out the value of “2-4WD SOL” and “2-4WD SOL MON”.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminal and ground.
OK or NG
OK >> GO TO 7.
NG >> GO TO 3.
Monitored
itemConditionDisplay
value
2-4WD SOL
Vehicle stopped
Engine running
A/T selector lever “N”
position
Brake pedal
depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
ON 4WD shift switch: 4H
4WD shift switch: 4LO
4WD shift switch: AUTO
(“Wait” function is operat-
ing.)OFF
4WD shift switch: 4H (“Wait”
function is operating.)OFF
2-4WD SOL
MON
Vehicle stopped
Engine running
A/T selector lever “N”
position
Brake pedal
depressed4WD shift switch: 2WD OFF
4WD shift switch: AUTO
ON 4WD shift switch: 4H
4WD shift switch: 4LO
4WD shift switch: AUTO
(“Wait” function is operat-
ing.)OFF
4WD shift switch: 4H (“Wait”
function is operating.)OFF
SDIA2727E
ConnectorTe r m i n a l
(Wire
color)ConditionVoltage
(Approx.)
E142 1 (GR) -
Ground
Vehicle stopped
Engine running
A/T selector lever
“N” position
Brake pedal
depressed4WD shift switch:
2WD0V
4WD shift switch:
AUTO, 4H or 4LOBattery
voltageSDIA2728E
Page 3236 of 3419
TROUBLE DIAGNOSIS FOR SYSTEM
TF-93
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
3. CHECK 4WD SHIFT SWITCH SIGNAL
1. Turn ignition switch “ON”. (Do not start engine.)
2. Check voltage between transfer control unit harness connector
terminals and ground.
OK or NG
OK >> GO TO 4.
NG >> Check 4WD shift switch. Refer to TF-66, "
COMPONENT INSPECTION" .
4. CHECK HARNESS BETWEEN 4WD SHIFT SWITCH AND TRANSFER TERMINAL CORD ASSEMBLY
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect 4WD shift switch harness connector and transfer terminal cord assembly harness connector.
3. Check continuity between 4WD shift switch harness connector
M141 terminal 4 (G/R) and transfer terminal cord assembly har-
ness connector F56 terminal 5 (G/R).
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND TRANSFER TERMINAL CORD
ASSEMBLY
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and transfer terminal cord assembly harness connec-
tor.
3. Check continuity between transfer control unit harness connec-
tor E142 terminal 1 (GR) and transfer terminal cord assembly
harness connector F56 terminal 4 (GR).
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
ConnectorTe r m i n a l
(Wire color)ConditionVoltage
(Approx.)
M1414 (G/R) -
ground4WD shift switch: AUTO, 4H or 4LO Battery voltage
4WD shift switch: 2WD 0V
SDIA2729E
Continuity should exist.
SDIA2731E
Continuity should exist.
SDIA2732E
Page 3239 of 3419
TF-96
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: October 20052005 QX56
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Te r m i n a lWire
colorItem Condition Data (Approx.)
14 LG Transfer motor relay
Accelerator
pedal depressed
Vehicle stopped
Engine running
Brake pedal
depressed4WD shift switch: 2WD Battery voltage
4WD shift switch: AUTO or 4LO (A/T
selector lever “P” or “N” position)Battery voltage
(0V for approx.
2 sec. after
shifting to “P”
and “N”.)
4WD shift switch: AUTO or 4LO (Except
for A/T selector lever “P” or “N” position)0V
4WD shift switch: 4H (A/T selector lever
“P” position)Battery voltage
(0V for approx.
2 sec. after
shifting to “P”.)
4WD shift switch: 4H (Except for A/T
selector lever “P” position)0V
41 R Transfer motor relay monitor
Accelerator
pedal depressed
Vehicle stopped
Engine running
Brake pedal
depressed4WD shift switch: 2WD 0V
4WD shift switch: AUTO or 4LO (A/T
selector lever “P” or “N” position)0V
(Battery volt-
age for approx.
2 sec. after
shifting to “P”
and “N”.)
4WD shift switch: AUTO or 4LO (Except
for A/T selector lever “P” or “N” position)Battery voltage
4WD shift switch: 4H (A/T selector lever
“P” position)0V
(Battery volt-
age for approx.
2 sec. after
shifting to “P”.)
4WD shift switch: 4H (Except for A/T
selector lever “P” position)Battery voltage
Page 3241 of 3419
TF-98
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: October 20052005 QX56
2. Check voltage between transfer control unit harness connector
terminal and ground.
OK or NG
OK >> GO TO 7.
NG >> GO TO 2.
ConnectorTe r m i n a l
(Wire
color)Condition Voltage (Approx.)
E142 14 (LG) -
Ground
Accelera-
tor pedal
depressed
Vehicle
stopped
Engine
running
Brake
pedal
depressed4WD shift switch:
2WDBattery voltage
4WD shift switch:
AUTO or 4LO (A/T
selector lever “P” or
“N” position)Battery voltage
(0V for approx. 2
sec. after shifting
to “P” and “N”.)
4WD shift switch:
AUTO or 4LO
(Except for A/T
selector lever “P” or
“N” position)0V
4WD shift switch:
4H (A/T selector
lever “P” position)Battery voltage
(0V for approx. 2
sec. after shifting
to “P”.)
4WD shift switch:
4H (Except for A/T
selector lever “P”
position)0V
E143 41 (R) -
Ground
Accelera-
tor pedal
depressed
Vehicle
stopped
Engine
running
Brake
pedal
depressed4WD shift switch:
2WD0V
4WD shift switch:
AUTO or 4LO (A/T
selector lever “P” or
“N” position)0V
(Battery voltage
for approx. 2 sec.
after shifting to
“P” and “N”.)
4WD shift switch:
AUTO or 4LO
(Except for A/T
selector lever “P” or
“N” position)Battery voltage
4WD shift switch:
4H (A/T selector
lever “P” position)0V
(Battery voltage
for approx. 2 sec.
after shifting to
“P”.)
4WD shift switch:
4H (Except for A/T
selector lever “P”
position)Battery voltage
SDIA2735E
Page 3242 of 3419
TROUBLE DIAGNOSIS FOR SYSTEM
TF-99
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
2. CHECK TRANSFER MOTOR RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Connect transfer control unit harness connector.
3. Disconnect transfer motor relay.
4. Check voltage between transfer motor relay harness connector
terminals and ground.
5. Turn ignition switch “ON”. (Do not start engine.)
6. Check voltage between transfer motor relay harness connector
terminals and ground.
OK or NG
OK >> GO TO 3.
NG >> Check the following. If any items are damaged, repair or
replace damaged parts.
20A fuse No. 58 located in the fuse and relay box. Refer to PG-4, "POWER SUPPLY ROUTING
CIRCUIT" .
10A fuse No. 26 located in the fuse and fusible link box. Refer to PG-4, "POWER SUPPLY
ROUTING CIRCUIT"
Harness for short or open between battery and transfer motor relay harness connector E154
terminal 5 (G/R).
Harness for short or open between transfer shut off relay harness connector E69 terminal 5 (Y/
R) and transfer motor relay harness connector E153 terminal 2 (Y/R).
Battery and ignition switch. Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" .
3. CHECK TRANSFER MOTOR RELAY
1. Turn ignition switch “OFF”.
2. Remove transfer motor relay. Refer to TF-22, "
Location of Electrical Parts" .
3. Apply 12V direct current between transfer motor relay terminals
1 and 2.
4. Check continuity between relay terminals 3 and 5.
OK or NG
OK >> GO TO 4.
NG >> Replace the transfer motor relay.
Connector Terminal (Wire color) Voltage (Approx.)
E153 2 (Y/R) - Ground 0V
E154 5 (G/R) - Ground Battery voltage
WDIA0169E
Connector Terminal (Wire color) Voltage (Approx.)
E153 2 (Y/R) - Ground
Battery voltage
E154 5 (G/R) - Ground
WDIA0170E
Condition Continuity
12V direct current supply between terminals 1 and 2 Yes
OFF No
LDIA0098E
Page 3248 of 3419
TROUBLE DIAGNOSIS FOR SYSTEM
TF-105
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
Clutch Pressure SwitchEDS002IK
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Monitored item [Unit] Content Condition Display value
CL PRES SW [ON /
OFF]Condition of clutch pres-
sure switch
Vehicle stopped
Engine running
A/T selector lever “D” position
4WD shift switch: AUTO or 4H (“Wait” function is not
operating.)ON
Vehicle stopped
Engine running
4WD shift switch: 2WD (“Wait” function is not oper-
ating.)OFF
Te r m i n a lWire
colorItem Condition Data (Approx.)
34 BR Clutch pressure switch
Vehicle stopped
Engine running
A/T selector
lever “D” position4WD shift switch: AUTO or 4H (“Wait”
function is not operating.)0V
Vehicle stopped
Engine running4WD shift switch: 2WD (“Wait” function is
not operating.)Battery voltage
Page 3249 of 3419
TF-106
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: October 20052005 QX56
DIAGNOSTIC PROCEDURE
1. CHECK CLUTCH PRESSURE SWITCH SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR” mode for “ALL MODE AWD/4WD” with CONSULT-II.
3. Read out ON/OFF switching action of the “CL PRES SW” while
operating 4WD shift switch.
Without CONSULT-II
1. Start engine.
2. Check voltage between transfer control unit harness connector
terminals and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND CLUTCH PRESSURE SWITCH
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and the transfer terminal cord assembly harness con-
nector.
3. Check continuity between transfer control unit harness connec-
tor E143 terminal 34 (BR) and transfer terminal cord assembly
harness connector F56 terminal 7 (BR)
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Condition Display value
Ignition switch: ON
A/T selector lever “D”
position4WD shift switch: AUTO or 4H
(“Wait” function is not operating.)ON
Ignition switch: ON4WD shift switch: 2WD (“Wait”
function is not operating.)OFF
ConnectorTerminal
(Wire
color)ConditionVoltage
(Approx.)
E14334 (BR) -
Ground
Ignition switch: ON
A/T selector lever
“D” position4WD shift switch:
AUTO or 4H
(“Wait” function is
not operating.)0V
Ignition switch: ON4WD shift switch:
2WD (“Wait” func-
tion is not operat-
ing.)Battery
voltage
WDIA0141E
SDIA2746E
Continuity should exist.
SDIA2747E
Page 3251 of 3419
TF-108
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: October 20052005 QX56
Line Pressure SwitchEDS0 02 IL
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
TRANSFER CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Monitored item [Unit] Content Condition Display value
LINE PRES SW [ON/
OFF]Condition of line pressure
switch
A/T selector lever “D” position
4WD shift switch: 2WD, AUTO or 4HON
Except the above
The vehicle has been
left at room tempera-
ture for 5 minutes and
more with ignition
switch in “OFF” posi-
tion.Ignition switch: ON
A/T selector lever: "P"
or "N" position
4WD shift switch: other
than AUTOOFF
TerminalWire
colorItem Condition Data (Approx.)
35 BR/W Line pressure switch
Ignition switch: ON
A/T selector lever “D” posi-
tion4WD shift switch: AUTO 0V
Except the above
The vehicle has been left at
room temperature for 5 min-
utes and more with ignition
switch in “OFF” position.
Ignition switch: ON
A/T selector lever: "P" or "N"
position
4WD shift switch: other than
AUTOBattery voltage
