FRONT WIPER INTERMITTENT OPERATION SWITCH POSITION CANNOT BE ADJUSTED
Inspection Procedure
1. COMBINATION SWITCH TO BCM INSPECTION
Select "BCM" on CONSULT-II. With "WIPER" data monitor, check
that "INT VOLUME" changes in order from 1 to 7 according to opera-
tion of the intermittent switch dial position.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "Removal and Installa-
tion of BCM" .
NG >> Replace wiper switch. Refer to WW-33, "
Removal and
Installation of Wiper and Washer Switch" .
WIPERS DO NOT WIPE WHEN FRONT WASHER OPERATES
Inspection Procedure
1. COMBINATION SWITCH TO BCM INSPECTION
Select "BCM" on CONSULT-II. With "WIPER" data monitor, check
that "FR WASHER SW" turns ON-OFF according to operation of
front washer switch.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "Removal and Installa-
tion of BCM" .
NG >> Replace wiper switch. Refer to WW-33, "
Removal and
Installation of Wiper and Washer Switch" .
FRONT WIPERS OPERATE FOR 10 SECONDS, STOP FOR 20 SECONDS, AND AFTER
REPEATING THIS OPERATION FIVE TIMES, THEY BECOME INOPERATIVE
CAUTION:

When auto stop signal has not varied for 10 seconds or longer while IPDM E/R is operating front
wipers, IPDM E/R considers front wipers locked and stops wiper output, which causes this symp-
tom.

This status can be checked by using IPDM E/R "DATA MONITOR". Under this condition, "WIP
PROT" reads "BLOCK".
Inspection Procedure
1. IPDM E/R TO FRONT WIPER MOTOR (1) INSPECTION
With CONSULT-II
Select "IPDM E/R" with CONSULT-II. With data monitor, confirm that
"WIP AUTO STOP" changes from "ACT P" to "STOP P" according to
wiper operation.
Without CONSULT-II
GO TO 2.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-28, "Removal and
Installation of IPDM E/R" .
NG >> GO TO 2.
WKIA1018E
WKIA1018E
SKIA5301E

REAR WIPER AND WASHER SYSTEM
WW-35
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
REAR WIPER AND WASHER SYSTEMPFP:28710
Components Parts and Harness Connector LocationEKS00BEB
System DescriptionEKS00BEC

The wiper switch (combination switch) is composed of a combination of 5 output terminals and 5 input ter-
minals. Terminal combination status is read by the BCM (body control module) when switch is turned ON.

The BCM controls rear wiper ON and INT (intermittent) operation.
Power is supplied at all times

through 50A fusible link (letter f , located in fusible link box)

to BCM terminal 70.
With the ignition switch in ON or START position, power is supplied

through 10A fuse [No. 9, located in fuse block (J/B)]

to combination switch terminal 14, and

through 10A fuse (No. 59, located in the fuse and relay box)

to BCM terminal 38.
Ground is supplied

to BCM terminal 67 and

to combination switch terminal 12

through grounds M57, M61 and M79.
WKIA3462E

WW-36
REAR WIPER AND WASHER SYSTEM
Revision: October 20052005 QX56
REAR WIPER OPERATION
When the ignition switch is in the ON or START position, and the rear wiper switch is in the ON position, the
BCM detects a rear wiper ON request through the combination switch (wiper switch) reading function.
The BCM will first check the status of the glass hatch ajar switch before supplying power to the rear wiper
motor. If the glass hatch ajar switch is closed (ground) the BCM will not turn on the rear wiper motor. If the
glass hatch ajar switch is open (not grounded) the BCM will control the rear wiper motor as follows.
The BCM controls rear wiper motor operation by switching direction of current flow between the two rear wiper
motor output circuits.
Power is supplied to output circuit 1 for forward operation (counterclockwise sweep),

through BCM terminal 55

to rear wiper motor terminal 4.
Ground is supplied

to rear wiper motor terminal 6

through BCM terminal 54

through BCM terminal 67

through grounds M57, M61 and M79.
With output circuit 1 power and ground supplied, the rear wiper motor operates in a counterclockwise sweep
direction until auto stop switch 1 closes (full sweep position). Auto stop switch 1 supplies ground

to BCM terminal 44

through rear wiper motor terminal 2

through rear wiper motor terminal 5

through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 1 and turns on output circuit 2.
Power is supplied to output circuit 2 for reverse operation (clockwise sweep),

through BCM terminal 54

to rear wiper motor terminal 6.
Ground is supplied

to rear wiper motor terminal 4

through BCM terminal 55

through BCM terminal 67

through grounds M57, M61 and M79.
With output circuit 2 power and ground supplied the rear wiper motor operates in a clockwise sweep direction
until auto stop switch 2 closes (full sweep position). Auto stop switch 2 supplies ground

to BCM terminal 26

through rear wiper motor terminal 1

through rear wiper motor terminal 3

through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 2 and turns on output circuit 1. This pro-
cess repeats until the rear wiper switch or ignition switch is turned off.
If the ignition switch is turned to OFF during operation, the rear wiper motor will immediately stop. If the igni-
tion switch is turned ON after this condition, and the BCM does not receive a rear wiper switch ON or INT sig-
nal, the BCM will operate the rear wiper to the auto stop position.
If the BCM does not receive a change in status in either auto stop switch 1 or auto stop switch 2 within a 5 sec-
ond period of output circuit 1 or output circuit 2 operation, the BCM will turn off output circuit 1 and output cir-
cuit 2.
If the BCM detects the rear door glass ajar signal during rear wiper motor operation, the BCM will operate the
rear wiper motor to the auto stop position. Once the rear door glass ajar signal returns to open (not grounded)
for 5 or more seconds, the BCM will resume rear wiper motor operation.
INTERMITTENT OPERATION
The rear wiper motor operates the wiper arm at low speed approximately every 7 seconds.
When the wiper switch is in the rear wiper INT position, the BCM detects a rear wiper INT request through the
combination switch (wiper switch) reading function.

REAR WIPER AND WASHER SYSTEM
WW-37
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
The BCM controls rear wiper motor operation by switching direction of current flow between the two rear wiper
motor output circuits.
Power is supplied to output circuit 1 for forward operation (counterclockwise sweep),

through BCM terminal 55

to rear wiper motor terminal 4.
Ground is supplied

to rear wiper motor terminal 6

through BCM terminal 54

through BCM terminal 67

through grounds M57, M61 and M79.
With output circuit 1 power and ground supplied, the rear wiper motor operates in a counterclockwise sweep
direction until auto stop switch 1 closes (full sweep position). Auto stop switch 1 supplies ground

to BCM terminal 44

through rear wiper motor terminal 2

through rear wiper motor terminal 5

through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 1 and turns on output circuit 2.
Power is supplied to output circuit 2 for reverse operation (clockwise sweep),

through BCM terminal 54

to rear wiper motor terminal 6.
Ground is supplied

to rear wiper motor terminal 4

through BCM terminal 55

through BCM terminal 67

through grounds M57, M61 and M79.
With output circuit 2 power and ground supplied the rear wiper motor operates in a clockwise sweep direction
until auto stop switch 2 closes (full sweep position). Auto stop switch 2 supplies ground

to BCM terminal 26

through rear wiper motor terminal 1

through rear wiper motor terminal 3

through grounds B117 and B132.
When the BCM receives this ground signal it turns off output circuit 2 and starts the timing function of 7 sec-
onds. After approximately 7 seconds the BCM turns on output circuit 1. This process repeats until the rear
wiper switch or ignition switch is turned off.
AUTO STOP OPERATION
When the rear wiper switch is turned off, the BCM will continue the cycle of output circuit 1 or output circuit 2
until auto stop switch 1 and auto stop switch 2 are both in the closed position. When the BCM receives ground
signals from auto stop switch 1 and auto stop switch 2 simultaneously, output circuit 1 and output circuit 2 are
both turned off.
REAR WASHER OPERATION
When the ignition switch is in the ON or START position, and the front and rear washer switches are OFF, the
front and rear washer motor is supplied power

through 10A fuse (No. 9, located in the fuse block J/B)

through combination switch (wiper switch) terminal 14

through combination switch (wiper switch) terminal 11

to front and rear washer motor terminal 2, and

through combination switch (wiper switch) terminal 13

to front and rear washer motor terminal 1.
When the rear wiper switch is in rear washer position, the BCM detects a rear washer signal by BCM wiper
switch reading function. Combination switch ground is supplied

to front and rear washer motor terminal 1

REAR WIPER AND WASHER SYSTEM
WW-41
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
Terminals and Reference Values for BCMEKS00BEE
Te r m i -
nal No.Wire
colorSignal nameMeasuring condition
Reference Value (V)
(Approx.) Ignition
switchOperation or condition
2 SB Combination switch input 5 ON

Light switch and wiper switch OFF

Wiper dial position 4
3 G/Y Combination switch input 4 ON

Light switch and wiper switch OFF

Wiper dial position 4
4 Y Combination switch input 3 ON

Light switch and wiper switch OFF

Wiper dial position 4
5 G/B Combination switch input 2 ON

Light switch and wiper switch OFF

Wiper dial position 4
6 V Combination switch input 1 ON
26 Y/LRear wiper auto stop
switch 2ONRise up position (rear wiper arm on
stopper)0V
A Position (full clockwise stop
position)0V
Forward sweep (counterclockwise
direction)Fluctuating
B Position (full counterclockwise stop
position)Battery voltage
Reverse sweep (clockwise direction) Fluctuating
32 R/G Combination switch output 5 ON

Light switch and wiper switch OFF

Wiper dial position 4
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E

WW-42
REAR WIPER AND WASHER SYSTEM
Revision: October 20052005 QX56
33 R/Y Combination switch output 4 ON
Light switch and wiper switch OFF

Wiper dial position 4
34 L Combination switch output 3 ON

Light switch and wiper switch OFF

Wiper dial position 4
35 O/B Combination switch output 2 ON

Light switch and wiper switch OFF

Wiper dial position 4
36 R/W Combination switch output 1 ON
38 W/L Ignition switch (ON) ON — Battery voltage
42 GRGlass hatch ajar switch
signalONHatch glass closed Battery voltage
Hatch glass open 0V
44 ORear wiper auto stop
switch 1ONRise up position (rear wiper arm on
stopper)0V
A Position (full clockwise stop
position)Battery voltage
Forward sweep (counterclockwise
direction)Fluctuating
B Position (full counterclockwise stop
position)0V
Reverse sweep (clockwise direction) Fluctuating
54 Y Rear wiper output circuit 2 ONRise up position (rear wiper arm on
stopper)0V
A Position (full clockwise stop
position)0V
Forward sweep (counterclockwise
direction)0V
B Position (full counterclockwise stop
position)Battery voltage
Reverse sweep (clockwise direction) Battery voltage Te r m i -
nal No.Wire
colorSignal nameMeasuring condition
Reference Value (V)
(Approx.) Ignition
switchOperation or condition
SKIA5292E
SKIA5291E
SKIA5292E

REAR WIPER AND WASHER SYSTEM
WW-43
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
How to Proceed With Trouble DiagnosisEKS00BEF
1. Confirm the symptoms and customer complaint.
2. Understand operation description and function description. Refer to WW-35, "
System Description" .
3. Perform the Preliminary Check. Refer to WW-43, "
Preliminary Inspection" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the rear wiper operate normally? If YES: GO TO 6. If NO: GO TO 4.
6. Inspection End.
Preliminary InspectionEKS00BEG
INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT
Inspection procedure
1. CHECK FUSE
Check if wiper or washer fuse is blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of problem before installing new fuse. Refer to PG-4,
"POWER SUPPLY ROUTING CIRCUIT" .
55 SB Rear wiper output circuit 1 ONRise up position (rear wiper arm on
stopper)0V (except battery voltage at ini-
tial rear wiper ON to lift arm off
stop)
A Position (full clockwise stop
position)Battery voltage
Forward sweep (counterclockwise
direction)Battery voltage
B Position (full counterclockwise stop
position)0V
Reverse sweep (clockwise direction) 0V
67 B Ground ON — 0V
70 W/B Battery power OFF — Battery voltage Te r m i -
nal No.Wire
colorSignal nameMeasuring condition
Reference Value (V)
(Approx.) Ignition
switchOperation or condition
Unit Power source Fuse No.
Front and rear washer motor Ignition ON or START 9
BCMIgnition ON or START 59
Battery f

REAR WIPER AND WASHER SYSTEM
WW-49
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
7. CHECK COMBINATION SWITCH INPUT SIGNAL
Select "BCM" on CONSULT-II. With "WIPER" data monitor, make
sure "RR WIPER INT", "RR WIPER ON" turn ON-OFF according to
operation of wiper switch.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "Removal and Installa-
tion of BCM" .
NG >> Check the wiper switch. Refer to WW-7, "
COMBINA-
TION SWITCH READING FUNCTION" .
Rear Wiper Stop Position Is IncorrectEKS00BEJ
1. CHECK AUTO STOP SWITCH INPUT SIGNALS
Select "BCM" on CONSULT-II. With "WIPER" data monitor, make
sure "RR WIPER STOP" and "RR AUTO STOP 2" turn ON-OFF
according to wiper operation.
OK or NG
OK >> Replace BCM. Refer to BCS-20, "Removal and Installation of BCM" .
NG >> GO TO 2.
2. CHECK AUTO STOP CIRCUITS FOR SHORT TO GROUND
1. Turn ignition switch to OFF.
2. Disconnect BCM and rear wiper motor connectors.
3. Check continuity between BCM harness connector terminals
and ground.
OK or NO
OK >> GO TO 3.
NO >> Repair harness or connector.When wiper switch is in
INT position: RR WIPER INT ON
When wiper switch is in
ON position: RR WIPER ON ON
SKIA4243E
When wiper switch is OFF
and arm on stop: RR WIPER STOP ON
: RR AUTO STOP 2 ON
When wiper switch is ON
and arm in position A: RR WIPER STOP OFF
: RR AUTO STOP 2 ON
When wiper switch is ON
counterclockwise sweep: RR WIPER STOP OFF
: RR AUTO STOP 2 OFF
When wiper switch is ON
and arm in position B: RR WIPER STOP ON
: RR AUTO STOP 2 OFF
When wiper switch is ON
clockwise sweep: RR WIPER STOP OFF
: RR AUTO STOP 2 OFF
When wiper switch is ON
and arm in position A: RR WIPER STOP ON
: RR AUTO STOP 2 OFF
WKIA1418E
Te r m i n a l s
Continuity
ConnectorTe r m i n a l
(wire color)
M18 26 (Y/L)
Ground No
M19 44 (O)
WKIA2096E

REAR WIPER AND WASHER SYSTEM
WW-53
C
D
E
F
G
H
I
J
L
MA
B
WW
Revision: October 20052005 QX56
Removal and Installation of Rear Wiper Motor EKS00BEO
REMOVAL
1. Remove rear wiper arm. Refer to WW-52, "Removal and Instal-
lation of Rear Wiper Arm, Adjustment of Rear Wiper Arm Stop
Location" .
2. Remove pivot cap.
3. Remove back door finisher lower. Refer to EI-42, "
BACK DOOR
TRIM" .
4. Remove the glass hatch latch assembly. Refer to BL-135,
"BACK DOOR LOCK" .
5. Disconnect rear wiper motor connector.
6. Remove rear wiper motor mounting bolts, and remove rear
wiper motor.
INSTALLATION
CAUTION:

Do not drop the wiper motor or cause it to contact other parts.
WKIA5018E
1. Wiper arm cover 2. Wiper arm and blade 3. Pivot cap
4. Rear wiper motor 5. Wiper arm stop
LKIA0416E

WW-54
REAR WIPER AND WASHER SYSTEM
Revision: October 20052005 QX56
1. Clean up the pivot area as illustrated. This will reduce possibility
of wiper arm looseness.
2. Install rear wiper motor to the vehicle.
3. Connect rear wiper motor connector.
4. Install glass hatch latch assembly and adjust as necessary.
Refer to BL-135, "
BACK DOOR LOCK" .
5. Install back door finisher lower. Refer to EI-42, "
BACK DOOR
TRIM" .
6. Attach pivot cap.
7. Attach wiper arm. Refer to WW-52, "
Removal and Installation of
Rear Wiper Arm, Adjustment of Rear Wiper Arm Stop Location" .
Rear Washer Nozzle AdjustmentEKS00BEP

This vehicle is equipped with a non-adjustable rear washer nozzle.

If not satisfied with washer fluid spray coverage, confirm that the washer nozzle is installed correctly.

If the washer nozzle is installed correctly, and the washer fluid spray coverage is not satisfactory, replace
the washer nozzle.
Rear Washer Tube LayoutEKS00BEQ
Removal and Installation of Rear Washer NozzleEKS00BER
REMOVAL
1. Remove the rear spoiler. Refer to EI-26, "REAR SPOILER" .
2. Remove rear washer tube from nozzle.
3. Release retaining clips, and remove washer nozzle.
INSTALLATION
Installation is in the reverse order of removal.
SEL024J
WKIA1925E
LKIA0418E
