TIMING CHAIN
EM-39
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
INSTALLATION
NOTE:

The above figure shows the relationship between the mating mark on each timing chain and that of the
corresponding sprocket, with the components installed.

To install the timing chain and associated parts, start with those on the right bank. The procedure for
installing parts on the left bank is omitted because it is the same as that for installation on the right bank.
1. Make sure the crankshaft key and dowel pin of each camshaft
are facing in the direction as shown.
2. Install the camshaft sprockets.

Install the intake and exhaust camshaft sprocket by selec-
tively using the groove of dowel pin according to the bank.
(Common part used for both banks.)

Lock the hexagonal part of the camshaft in the same way as
for removal, and tighten the bolts.
KBIA2514E
SBIA0356E
KBIA2480E

EM-42Revision: October 2005
TIMING CHAIN
2005 QX56
b. Install the bolts in the numerical order shown.
12. Install the crankshaft pulley.

Install the key of the crankshaft.

Insert the pulley by lightly tapping it.
CAUTION:
Do not tap pulley on the side surface where the belt is installed (outer circumference).
13. Tighten the crankshaft pulley bolt.

Lock the crankshaft using suitable tool, then tighten the bolt.

Perform the following steps for angular tightening:
a. Apply engine oil onto the threaded parts of the bolt and seating area.
b. Select the one most visible notch of the four on the bolt flange.
Corresponding to the selected notch, put a mating mark (such
as paint) on the crankshaft pulley.
14. Rotate the crankshaft pulley in normal direction (clockwise when
viewed from engine front) to check for parts interference.
15. Installation of the remaining components is in the reverse order
of removal.
WBIA0468E
Crankshaft pulley bolt torque
Step 1 : 93.1 N·m (9.5 kg-m, 69 ft-lb)
Step 2 : additional 90° (angle tightening)
KBIA2519E

EM-56Revision: October 2005
OIL SEAL
2005 QX56
Removal and Installation of Front Oil SealEBS00LMC
REMOVAL
1. Remove the radiator. Refer to CO-12, "Removal and Installation" .
2. Remove cooling fan. Refer to CO-15, "
Removal and Installation (Crankshaft Driven Type)" .
3. Remove the crankshaft pulley. Refer to EM-35, "
TIMING CHAIN" .
4. Remove the front oil seal using suitable tool.
CAUTION:
Do not damage front cover and oil pump drive spacer.
INSTALLATION
1. Apply new engine oil to both the oil seal lip and dust seal lip of the new front oil seal.
2. Install the front oil seal.

Install the front oil seal so that each seal lip is oriented as
shown.

Press-fit until the height of the front oil seal is level with the
mounting surface using suitable tool.
CAUTION:

Do not damage front timing chain case and crankshaft.

Press-fit straight and avoid causing burrs or tilting oil
seal.
3. Installation of the remaining components is in the reverse order of removal.
Removal and Installation of Rear Oil SealEBS00LMD
REMOVAL
1. Remove the transmission assembly. Refer to AT-244, "Removal and Installation (4x2)" or AT-247,
"Removal and Installation (4x4)" .
a. Remove the drive plate.

Holding the crankshaft pulley bolt, lock the crankshaft and remove the drive plate bolts.

Remove the bolts diagonally.
CAUTION:

Do not damage the drive plate. Especially, avoid deforming and damaging the signal plate
teeth (circumference position).

Place the drive plate with the signal plate surface facing other than downward.
SBIA0359E
SEM 71 5A
PBIC2931E

EM-58Revision: October 2005
CYLINDER HEAD
2005 QX56
CYLINDER HEADPFP:11041
On-Vehicle ServiceEBS00LME
CHECKING COMPRESSION PRESSURE
1. Warm up the engine thoroughly. Then stop the engine.
2. Release the fuel pressure. Refer to EC-93, "
FUEL PRESSURE RELEASE" .
CAUTION:
Leave the fuel pump fuse disconnected until step 7.
3. Remove the spark plug from each cylinder. Refer to EM-27, "
REMOVAL" .
4. Connect the engine tachometer (not required in use of CONSULT-II).
5. Install the compression tester with Tool into the spark plug hole.
6. With the accelerator pedal fully depressed, turn the ignition
switch to “START” for cranking. When the gauge pointer stabi-
lizes, read the compression pressure and engine rpm. Perform
these steps to check each cylinder.
Unit: kPa (kg/cm2 , psi) /rpm
CAUTION:
Always use a fully charged battery to obtain specified engine speed.

If the engine speed is out of the specified range, check the battery liquid for proper gravity. Check the
engine speed again with normal battery gravity.

If the compression pressure is below the minimum value, check the valve clearances and parts associ-
ated with the combustion chamber (valve, valve seat, piston, piston ring, cylinder bore, cylinder head,
cylinder head gasket). After checking, measure the compression pressure again.

If some cylinders have low compression pressure, pour a small amount of engine oil into the spark plug
hole of the cylinder to re-check it for compression.
–If the added engine oil improves the compression, the piston rings may be worn out or damaged. Check
the piston rings and replace if necessary.
–If the compression pressure remains at a low level despite the addition of engine oil, the valves may be
malfunctioning. Check the valves for damage. Replace the valve or valve seat accordingly.

If two adjacent cylinders have respectively low compression pressure and their compression remains
low even after the addition of engine oil, the gaskets may be leaking, or a valve in adjacent cylinders
may be damaged. Inspect and repair as required.
7. Install the components in the reverse order of removal.
8. Start the engine and confirm that it runs smoothly.
9. Perform trouble diagnosis. If DTC appears, erase it. Refer to EC-95, "
TROUBLE DIAGNOSIS" . Tool number : EG15050500 (J-45402)
Standard MinimumDeference limit
between cylinders
1,520 (15.5, 220) / 200 1,324 (13.5, 192) / 200 98 (1.0, 14) / 200
WBIA0605E

ENGINE ASSEMBLY
EM-71
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
CAUTION:

Be careful not to damage the drive plate. Especially
avoid deforming and damaging of the signal plate teeth
(circumference position).

Place the drive plate with the signal plate surface fac-
ing other than downward.

Keep magnetic materials away from the signal plate.
CAUTION:
Use an engine stand that has a load capacity [approximately 240kg (529 lb) or more] large enough
for supporting the engine weight.

If the load capacity of the stand is not adequate, remove the following parts beforehand to
reduce the potential risk of overturning the stand.
–Remove the fuel tube and fuel injector assembly. Refer to EM-29, "REMOVAL" .
–Remove the intake manifold. Refer to EM-15, "REMOVAL" .
–Remove the ignition coil. Refer to EM-26, "REMOVAL" .
–Remove the rocker cover. Refer to EM-33, "REMOVAL" .
–Other removable brackets.
CAUTION:
Before removing the hanging chains, make sure the engine stand is stable and there is no risk of
overturning.
31. Remove the alternator. Refer to SC-27, "
REMOVAL" .
32. Remove the engine mounting insulator and bracket using power tool.
KBIA2491E

EM-74Revision: October 2005
CYLINDER BLOCK
2005 QX56
* Refer to GI-45, "Recommended Chemical Products and Sealants" .
DISASSEMBLY
NOTE:
Explained here is how to disassemble with engine stand supporting transmission surface. When using differ-
ent type of engine stand, note steps may be different.
1. Remove engine assembly and mount to engine stand. Refer to EM-69, "
REMOVAL" .
CAUTION:
Before removing the hanging chains, make sure engine stand is stable and there is no risk of over-
turning.
2. Drain engine oil. Refer to LU-8, "
Changing Engine Oil" .
3. Drain engine coolant by removing the cylinder block drain plugs
“A”, “B”, “C” and “D” as shown.
4. Remove the following components and associated parts (The parts referred to in step 1 are not included
here.)

Oil pan and oil strainer. Refer to EM-22, "REMOVAL" .

Crankshaft pulley, front cover and timing chain. Refer to EM-36, "REMOVAL" .

Camshaft. Refer to EM-43, "REMOVAL" .

Cylinder head. Refer to EM-59, "REMOVAL" .
5. Remove knock sensor.
CAUTION:
Carefully handle sensor, avoiding shocks.
6. Check connecting rod side clearance. Refer to EM-89, "
CONNECTING ROD SIDE CLEARANCE" .
7. Remove piston and connecting rod assembly as follows.
a. Position the crankshaft pin corresponding to the connecting rod to be removed onto bottom dead center.
b. Remove connecting rod cap.
1. Knock sensor sub-harness 2. Knock sensor 3. Cylinder block
4. Main bearing 5. Top ring 6. Second ring
7. Oil ring 8. Crankshaft key 9. Piston
10. Connecting rod 11. Snap ring 12. Piston pin
13. Connecting rod bearing 14. Connecting rod bearing cap 15. Main bearing cap
16. Thrust bearing 17. Main bearing 18. Crankshaft
19. Pilot converter 20. Thrust bearing 21. Side bolt
22. Drive plate 23. Reinforcement plate 24. Rear oil seal retainer
25. Rear oil seal 26. Transmission 27. O-ring
28. Crankshaft position sensor (POS) 29. Gasket 30. Cylinder block heater
31. Connector cap
WBIA0419E

CYLINDER BLOCK
EM-77
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
ASSEMBLY
1. Fully air-blow the coolant and oil passages in the cylinder block, cylinder bore, and crankcase to remove
any foreign material.
CAUTION:
Use goggles to protect your eyes.
2. Install each plug to the cylinder block (only screw-type plugs are
shown).

Apply liquid gasket.
Use Genuine Thread Sealant or equivalent. Refer to GI-
45, "Recommended Chemical Products and Sealants".

Replace copper washers with new ones.

Tighten each plug as specified below.
3. Install main bearings and thrust bearings.
a. Remove any dust, dirt, and oil on the bearing mating surfaces of
the cylinder block and the main bearing caps.
b. Install thrust bearings to both sides of the No. 3 journal housing
on the cylinder block and main bearing caps.

Install thrust bearings with the oil groove facing the crankshaft
arm (outside).

Install thrust bearings with a protrusion in the center on the
main bearing caps.
c. Install main bearings paying attention to the direction.

Install the one with oil holes onto the cylinder block and the
one without oil holes onto the main bearing cap.

Before installing bearings, apply engine oil to bearing surface
(inside). Do not apply oil to the back surface, but thoroughly
clean it.

When installing, align the bearing stopper to the notch.

Ensure the oil holes on the cylinder block and those on the
corresponding bearing are aligned.
4. Install pilot converter to the crankshaft using suitable tool.
5. Install crankshaft to the cylinder block.

While turning crankshaft by hand, make sure it turns
smoothly.
Part Washer Tightening torque
A Yes 53.9 N·m (5.5 kg-m, 40 ft-lb)
B No 19.6 N·m (2.0 kg-m, 15 ft-lb)
C Yes 62.7 N·m (6.4 kg-m, 46 ft-lb)
D Yes 62.7 N·m (6.4 kg-m, 46 ft-lb)
WBIA0419E
PBIC0093E
PBIC0094E
EMP0569D

EM-80Revision: October 2005
CYLINDER BLOCK
2005 QX56
12. Install the connecting rod bearings to the connecting rod and
connecting rod cap.

When installing the connecting rod bearings, apply engine oil
to the bearing surface (inside). Do not apply oil to the back
surface, but thoroughly clean it.

When installing, align the connecting rod bearing stopper pro-
trusion with the cutout of the connecting rod to install.

Check that the oil holes on the connecting rod and those on
the corresponding bearing are aligned.
13. Install the piston and connecting rod assembly to the crankshaft
using Tool.

Position the crankshaft pin corresponding to the connecting
rod to be installed onto bottom dead center.

Apply engine oil sufficiently to the cylinder bore, piston, and
crankshaft pin.

Match the cylinder position with the cylinder No. on the con-
necting rod to install.

Install the piston with the front mark on the piston crown fac-
ing the front of the engine.
CAUTION:
Be careful not to damage the crankshaft pin, resulting from an interference of the connecting
rod big end.
14. Install connecting rod cap.

Match the stamped cylinder number marks on the connecting
rod with those on the cylinder cap to install.
15. Tighten connecting rod bolts using Tool.

Apply engine oil to threads and seats of connecting rod bolts.

After tightening bolts, make sure the crankshaft rotates
smoothly.

Check connecting rod side clearance. Refer to EM-89, "CON-
NECTING ROD SIDE CLEARANCE"
PBIC0266E
Tool number : EM03470000 (J-8037)
WBIA0626E
KBIA2536E
Tool number : KV10112100 (BT-8653-A
Connecting rod bolts
Step 1 : 19.6 N·m (1.5 kg-m, 11 ft-lb)
Step 2 : 90° clockwise
WBIA0627E

EM-92Revision: October 2005
CYLINDER BLOCK
2005 QX56
Piston Pin Diameter

Measure diameter of piston pin using suitable tool.
Connecting Rod Bushing Oil Clearance (Small End)
(Connecting rod small end oil clearance) = (Inside diameter of con-
necting rod small end) – (Piston pin diameter)

If measured value exceeds the standard, replace the connecting
rod assembly and/or piston and piston pin assembly.

If replacing the piston and piston pin assembly, refer to the Table
for Selective Fitting for Piston to select the piston corresponding
to the applicable bore grade of the cylinder block to be used.
Refer to EM-83, "
HOW TO SELECT PISTON" .
Factory installed parts grading:

Only grade 0 is available.
Unit: mm (in)
CYLINDER BLOCK DISTORTION

Remove any oil, scale, gasket, sealant and carbon deposits from the cylinder block surface.
CAUTION:
Do not allow any debris to enter the oil or coolant passages.

Measure block upper face for distortion in six directions as
shown.

If measurement exceeds the limit, replace cylinder block.Standard : 21.989 - 21.995 mm (0.8657 - 0.8659 in)
PBIC0 117 E
Standard : 0.005 - 0.017 mm (0.0002 - 0.0007 in)
KBIA2536E
Grade 0
Connecting rod bushing inside diameter22.000 - 22.006
(0.8661 - 0.8664)
Piston pin diameter21.989 - 21.995
(0.8657 - 0.8659)
Piston pin hole diameter21.993 - 21.999
(0.8659 - 0.8661)
KBIA2496E
Standard : 0.03 mm (0.0012 in)
Limit : 0.1 mm (0.004 in)
SEM 12 3C

FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY
FL-7
C
D
E
F
G
H
I
J
K
L
MA
FL
Revision: October 20052005 QX56
Disconnect the quick connector as follows:

Hold the sides of the connector, push in tabs and pull out the
tube.

If the connector and the tube are stuck together, push and pull
several times until they start to move. Then disconnect them
by pulling.
CAUTION:

The quick connector can be disconnected when the tabs
are completely depressed. Do not twist the quick connec-
tor more than necessary.

Do not use any tools to disconnect the quick connector.

Keep the resin tube away from heat. Be especially careful
when welding near the tube.

Prevent any acid liquids such as battery electrolyte, from
getting on the resin tube.

Do not bend or twist the resin tube during connection.

Do not remove the remaining retainer on the hard tube (or
the equivalent) except when the resin tube or the retainer
is replaced.

When the resin tube or hard tube, or the equivalent, is
replaced, also replace the retainer with a new one (white
colored retainer).

To keep the quick connector clean and to avoid damage
and contamination from foreign materials, cover the
quick connector with plastic bags or suitable material as
shown.
SF E5 62 A
PBIC1268E
PBIC0163E
