Page 553 of 3419
ATC-158
HEATER & COOLING UNIT ASSEMBLY
Revision: October 20052005 QX56
7. Move the two front seats to the rearmost position on the seat track.
8. Remove the instrument panel and console panel. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
9. Remove the steering column. Refer to PS-10, "
STEERING COLUMN" .
10. Disconnect the instrument panel wire harness at the RH and LH in-line connector brackets, and the fuse
block (J/B) electrical connectors. Refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .
11. Disconnect the steering member from each side of the vehicle body.
12. Remove the front heater and cooling unit assembly with it attached to the steering member, from the vehi-
cle.
CAUTION:
Use care not to damage the seats and interior trim panels when removing the front heater and
cooling unit assembly with it attached to the steering member.
13. Remove the front heater and cooling unit assembly from the steering member.
Installation
Installation is in the reverse order of removal.
CAUTION:
Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.
After charging the refrigerant, check for leaks.
NOTE:
Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .
Recharge the A/C system. Refer to ATC-175, "Evacuating System and Charging Refrigerant" .
REAR HEATER AND COOLING UNIT ASSEMBLY
Removal
1. Discharge the refrigerant from the A/C system. Refer to ATC-175, "Discharging Refrigerant" .
2. Drain the coolant from the engine cooling system. Refer to MA-13, "
DRAINING ENGINE COOLANT" .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Disconnect the rear A/C pipes from the rear expansion valve.
5. Remove the rear RH interior trim panel. Refer to EI-35, "
BODY
SIDE TRIM" .
6. Disconnect the following electrical connectors:
Rear blower motor
Rear blower motor resistor
Rear air mix door motor
7. Disconnect the ducts from the rear heater and cooling unit
assembly.
8. Remove the rear heater and cooling unit assembly.
Installation
Installation is in the reverse order of removal.
CAUTION:
Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.
After charging the refrigerant, check for leaks.
NOTE:
Fill the engine cooling system with the specified coolant mixture. Refer to MA-14, "REFILLING ENGINE
COOLANT" .
Recharge the A/C system. Refer to ATC-175, "Evacuating System and Charging Refrigerant" .
Removal and Installation for Rear Heater Core PipesEJS00536
REMOVAL
1. Drain the coolant from the engine cooling system. Refer to CO-10, "DRAINING ENGINE COOLANT" .
2. Remove the upper and lower luggage RH side finisher. Refer to EI-35, "
BODY SIDE TRIM"
LJIA0021E
Page 1466 of 3419
DTC P0300 - P0308 MULTIPLE CYLINDER MISFIRE, NO. 1 - 8 CYLINDER MIS-
FIRE
EC-275
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: October 20052005 QX56
7. CHECK SPARK PLUG
Check the initial spark plug for fouling, etc.
OK or NG
OK >> Replace spark plug(s) with standard type one(s). For
spark plug type, refer to EM-27, "
SPARK PLUG (PLATI-
NUM-TIPPED TYPE)" .
NG >> 1. Repair or clean spark plug.
2. GO TO 8.
8. CHECK FUNCTION OF IGNITION COIL-III
1. Reconnect the initial spark plugs.
2. Crank engine for about 3 seconds, and recheck whether spark is generated between the spark plug and
the grounded portion.
OK or NG
OK >>INSPECTION END
NG >> Replace spark plug(s) with standard type one(s). For spark plug type, refer to MA-18, "
Changing
Spark Plugs" .
9. CHECK COMPRESSION PRESSURE
Check compression pressure. Refer to EM-58, "
CHECKING COMPRESSION PRESSURE" .
OK or NG
OK >> GO TO 10.
NG >> Check pistons, piston rings, valves, valve seats and cylinder head gaskets.
10. CHECK FUEL PRESSURE
1. Install all removed parts.
2. Release fuel pressure to zero. Refer to EC-93, "
FUEL PRESSURE RELEASE" .
3. Install fuel pressure gauge and check fuel pressure. Refer to EC-94, "
FUEL PRESSURE CHECK" .
OK or NG
OK >> GO TO 12.
NG >> GO TO 11.
11 . DETECT MALFUNCTIONING PART
Check the following.
Fuel pump and circuit (Refer to EC-637, "FUEL PUMP CIRCUIT" .)
Fuel pressure regulator (Refer to EC-94, "FUEL PRESSURE CHECK" .)
Fuel lines
Fuel filter for clogging
>> Repair or replace.
SEF 1 56 I
Spark should be generated.
At idle: Approximately 350 kPa (3.57 kg/cm
2 , 51 psi)
Page 1898 of 3419
FLOOR TRIM
EI-37
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: October 20052005 QX56
FLOOR TRIMPFP:74902
Removal and InstallationEIS004WS
1. Remove front seats. Refer to SE-97, "FRONT SEAT" .
Remove subwoofer. Refer to AV- 4 6 , "Removal and Installation of Subwoofer" .
Remove navigation display control unit. Refer to AV-158, "Removal and Installation of Display Control
Unit" .
2. Remove second row seats. Refer to SE-104, "
Second Row Outboard" and SE-104, "Second Row Cen-
ter" , if equipped.
3. Remove third row rear seat. Refer to SE-104, "
Third Row" .
4. Remove lower seat belt anchors. Refer to SB-3, "
SEAT BELTS" .
5. Remove lower body side trim. Refer to EI-35, "
BODY SIDE TRIM" .
6. Remove luggage lower side finishers (left / right). Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
7. Remove kicking plates. Refer to EI-35, "
BODY SIDE TRIM" .
8. Remove center console. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
9. Remove rear console, if equipped. Refer to IP-17, "
Rear Console" .
10. Remove rear lower finisher. Refer to EI-40, "
LUGGAGE FLOOR TRIM" .
11. Remove carpet.
12. Remove floor mat hooks from front carpet.
Installation is in the reverse order of removal.
1. Inspection hole cover 2. Seal 3. Carpet
4. Floor mat hook 5. Plastic clip
WIIA0267E
Page 1933 of 3419
EM-30Revision: October 2005
FUEL INJECTOR AND FUEL TUBE
2005 QX56
7. Remove the fuel injector from the fuel tube using the following
steps.
a. Spread open and remove the clip.
b. Remove the fuel injector from the fuel tube by pulling straight
out.
CAUTION:
Be careful with remaining fuel that may leak out from fuel
tube.
Do not damage injector nozzles during removal.
Do not bump or drop fuel injectors.
Do not disassemble fuel injectors.
8. Remove the fuel damper from each fuel tube.
INSTALLATION
1. Install the fuel damper to each fuel tube using the following
steps.
a. Apply engine oil to the new O-ring and set it into the cap of the
fuel tube.
CAUTION:
Handle O-ring with bare hands. Never wear gloves.
Lubricate O-ring with new engine oil.
Do not clean O-ring with solvent.
Make sure that O-ring and its mating part are free of for-
eign material.
When installing O-ring, do not scratch it with tool or fin-
gernails.
Do not twist or stretch the O-ring.
b. Make sure that the backup spacer is in the O-ring connecting surface of the fuel damper.
NOTE:
The backup spacer is part of the fuel damper assembly.
c. Insert the fuel damper until it seats on the fuel tube.
CAUTION:
Insert straight, making sure that the axis is lined up.
Do not pressure-fit with excessive force.
d. Install the cap, and then tighten the bolts evenly.
After tightening the bolts, make sure that there is no gap between the cap and fuel tube.
2. Install new O-rings to the fuel injector paying attention to the items below.
CAUTION:
Upper and lower O-ring are different.
KBIA2506E
Reference value :130 N (13.3 kg, 29.2 lb)
KBIA2473E
Page 1965 of 3419
EM-62Revision: October 2005
CYLINDER HEAD
2005 QX56
7. Remove the valve oil seal using Tool.
8. Replace the valve seat if necessary. Refer to EM-67, "
VALVE SEAT REPLACEMENT" .
9. Replace the valve guide if necessary. Refer to EM-67, "
VALVE SEAT REPLACEMENT" .
10. Remove the spark plug tube, as necessary.
Remove the spark plug tube out of the cylinder head using suitable tool.
CAUTION:
Do not damage the cylinder head.
Do not remove the spark plug tube unless absolutely necessary. Once removed, the spark
plug tube will be deformed and cannot be reused.
ASSEMBLY
1. Install the valve guide if necessary. Refer to EM-65, "VALVE GUIDE REPLACEMENT" .
2. Install the valve seat if necessary. Refer to EM-67, "
VALVE SEAT REPLACEMENT" .
3. Install the valve oil seal using Tool.
Apply new engine oil on the new valve oil seal joint and seal
lip.
Install the valve oil seal to the specified height "H".
4. Install the valves in their original position.
5. Install the valve spring seats.
6. Install the valve springs.
Install the narrow pitch end (Paint mark side) to the cylinder
head side.
7. Install the valve spring retainers.Tool number : KV10107902 (J-38959)
WBIA0478E
Tool number : KV10115600 (J-38958)
Height "H" (Without valve spring seat installed)
Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in)
WBIA0490E
SEM 08 5D
Page 1970 of 3419
CYLINDER HEAD
EM-67
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: October 20052005 QX56
VALVE SEAT CONTACT
After confirming that the dimensions of the valve guides and
valves are within specifications, perform this procedure.
Apply prussian blue (or white lead) onto the contacting surface
of the valve seat to check the condition of the valve contact on
the surface.
Check if the contact area band is continuous all around the cir-
cumference.
If not, grind to adjust the valve fit and check again. If the contact-
ing surface still has NG conditions even after the re-check,
replace the valve seat.
VALVE SEAT REPLACEMENT
When the valve seat is removed, replace it with oversized (0.5 mm, 0.020 in) valve seat.
1. Bore out the old seat until it collapses. Boring should not continue beyond the bottom face of the seat
recess in the cylinder head. Set the machine depth stop to ensure this.
2. Ream the cylinder head recess diameter for service valve seat.
Be sure to ream in circles concentric to the valve guide center.
This will enable valve seat to fit correctly.
3. Heat the cylinder head to 110° to 130°C (230° to 266°F) by
soaking it in heated oil.
4. Cool the valve seats well with dry ice. Force fit the valve seat into the cylinder head.
CAUTION:
Avoid directly touching cold valve seats.
Cylinder head contains heat. When working, wear protective equipment to avoid getting burned.
5. Finish the seat to the specified dimensions using suitable tool.
Refer to EM-103, "
Valve Seat" .
CAUTION:
When using valve seat cutter, firmly grip the cutter handle
with both hands. Then, press on the contacting surface all
around the circumference to cut in a single drive. Improper
pressure on the cutter or cutting many different times may
result in stage valve seat.
SBIA0322E
Oversize [0.5 mm (0.020 in)] (Service):
Intake : 38.500 - 38.516 mm (1.5157 - 1.5164 in)
Exhaust : 32.700 - 32.716 mm (1.2874 - 1.2880 in)
SEM 79 5A
SEM 00 8A
SEM 93 4C
Page 2277 of 3419
IP-16
INSTRUMENT PANEL ASSEMBLY
Revision: October 20052005 QX56
1. Remove instrument lower cover RH. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove glove box assembly. Refer to IP-14, "
Instrument Lower Cover RH and Glove Box" .
3. Remove instrument lower cover LH. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
4. Remove shift knob and A/T console finisher. Refer to IP-13, "
A/T Finisher" .
Remove cup holder insert.
Remove shift indicator.
5. Remove cluster lid D. Refer to IP-12, "
Cluster Lid D" .
6. Disconnect shift cable and electrical harness from control device.
7. Remove control device. Refer to AT-227, "
Control Device Removal and Installation" .
8. Remove screws from center console.
Disconnect electrical harnesses.
9. Move front seats forward and remove center console assembly in a rearward direction.
10. Remove tray and mat from console bin.
11. Remove latch from console lid.
12. Remove hinge from console lid. Remove console lid.
Remove console lid mat.
13. Remove console bin.
Disconnect electrical harness from DVD player, if equipped.
Remove hinge from console bin.
14. Remove rear upper finisher.
15. Remove rear cup holder assembly.
16. Remove upper side finishers LH/RH.
17. Remove screws on each side, disconnect clips and remove console covers LH/RH.
18. Remove rear finisher assembly.
Disconnect electrical connectors.
19. Remove power point assembly.
20. Remove mask and storage compartment.
21. Remove console front bracket.
22. Remove heat duct and console rear duct.
23. Remove console rear bracket.
Assembly is in the reverse order of disassembly.
1. Console lid assembly 2. A/T finisher 3. Tray
4. Storage compartment 5. Storage compartment mask 6. Console reinforcement assembly
7. Console front bracket 8. Upper side finisher LH 9. Console cover LH
10. Rear console duct 11. Power point assembly 12. Rear cup holder assembly
13. Rear finisher assembly 14. Console rear bracket 15. Heat duct
16. Rear upper finisher 17. Console bin mat 18. Console bin
19. Console cover RH 20. Upper side finisher RH 21. A/T transmission control
22. Mask 23. Cup holder insert
Page 2843 of 3419
RF-26
SUNROOF
Revision: October 20052005 QX56
SUNROOF UNIT
Removal
CAUTION:
Always work with a helper.
When taking sunroof unit out, use shop cloths to protect the seats and trim from damage.
After installing the sunroof unit and glass lid, be sure to check gap adjustment to ensure there is
no malfunction.
1. Remove headlining. Refer to EI-38, "
HEADLINING" .
2. Remove the sunroof glass lid. Refer to RF-26, "
GLASS LID" .
3. Remove overhead console bracket.
4. Disconnect the drain hoses.
5. Remove front sunroof bolts.
6. Remove rear sunroof bracket bolts.
7. Remove the side bolts and the sunroof unit.
Installation
1. Position the sunroof frame assembly and install the side bolts.
2. Install the rear brackets.
3. Install the front mounting bolts.
4. Connect drain hoses.
5. Install the overhead console bracket.
6. Install the sunroof glass lid. Refer to RF-26, "
GLASS LID" .
7. Install headlining. Refer to EI-38, "
HEADLINING" .
GLASS LID
Removal
1. Open sunshade.
2. Ensure glass lid is closed.
3. Remove side cover LH and RH.
4. Remove the screws securing glass lid to the sunroof frame
assembly.
5. Remove the glass lid assembly.
Installation
1. Position glass lid to sunroof assembly.
2. Install the glass lid assembly screws. (First tighten left front bolt, then tighten right rear bolt on glass lid to
prevent lid from moving while tightening other bolts.)
3. Adjust the sunroof glass. Refer to RF-23, "
Fitting Adjustment" .
4. Install side cover LH and RH.
WIND DEFLECTOR
Removal
1. Open the sunroof.
7. Front drain hoses 8. Sunroof motor assembly 9. Sunroof frame assembly
10. Overhead console bracket 11. Side cover LH 12. Side cover RH
WIIA0252E
Page 2915 of 3419
RSU-40
REAR LOWER LINK & COIL SPRING
Revision: October 20052005 QX56
8. Remove the rear lower link adjusting bolt and nut from the rear
suspension member using power tool, then remove the rear
lower link.
INSPECTION AFTER REMOVAL
Check the coil spring and rubber seats for deformation, cracks, or other damage and replace if necessary.
INSTALLATION
Installation is in the reverse order of removal.
Tighten the nuts and bolts to specification. Refer to RSU-25, "Components" .
When installing the upper and lower rubber seats for the rear
coil springs, the arrow embossed on the rubber seats must point
out toward the wheel and tire assembly.
After installing the rear lower link and coil spring, check the
wheel alignment and adjust if necessary. Refer to RSU-27,
"Wheel Alignment Inspection" .
LEIA0009E
LEIA0076E
Page 2933 of 3419
SB-10
SEAT BELTS
Revision: October 20052005 QX56
Seat Belt InspectionEHS00167
AFTER A COLLISION
WAR NIN G:
Inspect all seat belt assemblies including retractors and attaching hardware after any collision.
NISSAN recommends that all seat belt assemblies in use during a collision be replaced unless the col-
lision was minor and the belts show no damage and continue to operate properly. Failure to do so
could result in serious personal injury in an accident. Seat belt assemblies not in use during a colli-
sion should also be replaced if either damage or improper operation is noted. Seat belt pre-tensioners
should be replaced even if the seat belts are not in use during a frontal collision in which the air bags
are deployed.
Replace any seat belt retractor and belt assembly (including anchor bolts) if:
The seat belt was in use at the time of a collision (except for minor collisions and the belts, retractors and
buckles show no damage and continue to operate properly).
The seat belt was damaged in an accident. (i.e. torn webbing, bent retractor or guide).
The seat belt attaching point was damaged in an accident. Inspect the seat belt attaching area for damage
or distortion and repair as necessary before installing a new seat belt retractor and belt assembly.
Anchor bolts are deformed or worn out.
The seat belt pre-tensioner should be replaced even if the seat belts are not in use during the collision in
which the air bags are deployed.
PRELIMINARY CHECKS
1. Check the seat belt warning lamp/chime for proper operation as follows:
a. Switch ignition ON. The seat belt warning lamp should illuminate. Also, the seat belt warning chime should
sound for about seven seconds.
b. Fasten drivers seat belt. The seat belt warning lamp should go out and the chime (if sounding) should
stop.
2. If the air bag warning lamp is blinking, conduct self-diagnosis using CONSULT-II, and air bag warning
lamp. Refer to SRS-20, "
SRS Operation Check" .
3. Check that the seat belt retractor and belt assembly, seat belt anchor and buckle bolts are securely
attached.
4. Check the shoulder seat belt guide and shoulder belt height adjuster for front seats. Ensure guide swivels
freely and that belt lays flat and does not bind in guide. Ensure height adjuster operates properly and
holds securely.
5. Check retractor operation:
a. Fully extend the seat belt webbing and check for twists, tears or other damage.
b. Allow the seat belt to retract. Ensure that belt returns smoothly and completely into the retractor. If the
seat belt does not return smoothly, wipe the inside of the loops with a clean paper cloth, because dirt built
up in the loops of the upper anchors can cause the seat belts to retract slowly.
c. Fasten the seat belt. Check the seat belt returns smoothly and completely to the retractor. If the belt does
not return smoothly, the cause may be an accumulation of dust or dirt. Use the “SEAT BELT TAPE SET”
and perform the following steps.
Inspect the front seat belt through-anchor:
1. Pull the seat belt out to a length of 500 mm (19.69 in) or more.
2. Use a clip or other device to hold the seat belt at the center pillar belt opening.
3. Pass a thin wire through the through-anchor belt opening. Hold both ends of the wire and pull taut while
moving it up and down several times along the belt opening surface to remove dirt.
4. Any dirt that cannot be removed with the wire can be removed by cleaning the opening with a clean
cloth.
5. Apply tape at the point where the belt contacts the through-anchor belt opening.
NOTE:
Apply the tape so that there is no looseness or wrinkling.
6. Remove the clip holding the seat belt and check that the belt returns smoothly.
7. Repeat steps above as necessary to check the other seat belts.
