INFINITI QX50 2015 Quick Reference Guide

9
Outside Mirror Control Switch
To select the right or left side mirror, turn the control
switch
1 right or left.
To adjust the mirror angle, move the control switch

1 up, down, right or left.
To prevent accidentally moving the mirror, turn and
set the switch to the middle (neutral) position.
REVERSE TILT-DOWN FEATURE (if so equipped)

When backing up the vehicle, the right or left outside mirror can be sel\
ected to automatically
turn downward to provide better rear visibility.
1. Push the ignition switch to the ON position.
2. Move the shift lever to the R (REVERSE) position.
3. Choose the right or left outside mirror by operating the outside mirr\
or control switch
1.
4. The selected outside mirror surface moves downward.

When one of the following conditions has occurred, the outside mirror su\
rface will return to
its original position:
• The shift lever is moved to any position other than R (REVERSE).
• The outside mirror control switch is set to the center (neutral) posit\
ion.
• The ignition switch is pushed to the OFF position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Automatic Drive Positioner (if so equipped)

Two positions for the driver’s seat, steering column
and outside mirrors can be stored in the automatic
drive positioner memory.

Follow this procedure to set the memory positions:
• Confirm the shift lever is in the P (PARK) position.
• Push the ignition switch to the ON position.
• Adjust the driver’s seat, steering column and outside mirrors to the \
desired positions using
the adjusting switches for each feature.
• Push the SET switch and within 5 seconds push the memory switch (1 or 2) for at
least 1 second.
• The indicator light on the memory switch you select will illuminate for \
approximately
5 seconds.
• The driver’s seat, steering column and outside mirror positions are n\
ow set to your preference.

These memorized positions can also be linked to your INFINITI Intelligen\
t Key.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1
1923534_15c_Infiniti_QX50_QRG_122314.indd 912/23/14 1:05 PM

10
first drive features
Starting/Stopping the Engine
It is important to make sure the INFINITI Intelligent
Key is with you (that is, in your pocket or purse).

Depress the brake pedal.
• If the brake pedal is not depressed, pushing the
ignition switch once enters the ACC mode.
• If the ignition switch is pushed a second time, the
vehicle will enter the ON mode.

Move the shift lever to the P (PARK) position.

Push the ignition switch to start the engine.
TURNING THE ENGINE OFF

Move the shift lever to the P (PARK) position and apply the parking brake.

Press the ignition switch START/STOP button to turn the engine off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
Headlight Control Switch
HEADLIGHT CONTROL

Turn the headlight control switch to the
position
1 to turn on the front parking, side

marker, tail, license plate and instrument panel
lights. Turn the switch to the
position 2 to

turn on the headlights.
AUTOLIGHT SYSTEM

The autolight system will automatically turn the headlights on when it i\
s dark and off when
it is light. The system will keep the headlights on for a period of time\
after you turn the
ignition off and all the doors are closed.

To activate the autolight system, turn the headlight control switch to t\
he AUTO position 3,
then push the ignition switch to ON. To deactivate the autolight system, turn the headlight
control switch to the OFF,
position 1 or
position 2.
HIGH BEAM SELECT

Push the headlight control switch forward
4 to

select the high beam function. The blue indicator
light
illuminates in the instrument panel. Pull
the headlight switch back to the original position to
select the low beam. The blue indicator extinguishes.

Pull and release the headlight control switch 5 to

flash the headlight high beams on and off.
3
1
2
4
5
1923534_15c_Infiniti_QX50_QRG_122314.indd 1012/23/14 1:05 PM

11
Windshield Wiper and Washer Switch
Move the lever to one of the following positions to operate the windshie\
ld wipers:

1 Mist (MIST) - One sweep operation of the front wipers.

2 Intermittent (INT) - Operates the speed-sensing front wipers intermittently. The
intermittent operation speed can be adjusted by
twisting the time control ring
3 to increase or
decrease wiper speed.

4 Low (LO) - Front wipers operate at a continuous
low-speed.

5 High (HI) - Front wipers operate at a continuous
high-speed.

6 Front Washer
- Pull the lever toward you to
activate the front washer. The front wipers will
operate several times.
WIPER DRIP

Once the wiper spray cycle is finished, there will be a
short delay. Then the wipers will sweep one more time
to clear off any remaining drips from the windshield.
REAR WINDSHIELD WIPER AND WASHER

7 Intermittent (INT) - Rear wiper operates
intermittently.

8 Low (ON) - Rear wiper operates at a continuous
low-speed.

9 Rear Washer
- Push the lever forward to
activate the rear washer. The rear wiper will operate several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
FOG LIGHT SWITCH

The headlights must be in the auto, or the low
beams
position for the fog lights to operate.

Turn the switch (inside collar) to the position 6
to turn the fog lights on.

Turn the switch (inside collar)
to the OFF position to

turn the fog lights off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
6
MIST
OFF
INT
LO
HI1
2
3
4
5
INT
ON7
8
6
9
1923534_15c_Infiniti_QX50_QRG_122314.indd 1112/23/14 1:05 PM

12
first drive features
Automatic Climate Controls
1 AUTO BUTTON/DRIVER’S SIDE TEMPERATURE CONTROL DIAL

The auto mode may be used year-round. Press the AUTO button to turn the system on
and the system will automatically control the inside temperature (autom\
atic cooling and/
or dehumidified heating), air flow distribution and fan speed.

Turn the driver’s side temperature control dial to the left for coole\
r air or right for warmer air.
2 DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL

Press the DUAL button to turn the passenger’s side temperature controls on or off. T\
his
will allow the passenger’s side temperature to be adjusted independen\
tly from the
driver’s side by turning the passenger’s side temperature control \
dial.

Turn the passenger’s side temperature control dial left for cooler ai\
r or right for warmer air.
3 FAN SPEED CONTROL BUTTONS

To manually adjust the fan speed, press the button to increase the fan speed or
press the
button to decrease the fan speed.
4 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS

Press the defroster control button
to turn the system on. The A/C automatically turns

on when the defroster mode is selected. This feature removes humidity fr\
om the air.

Turn the temperature control dial
1 to set the desired temperature.
To defrost the front and side windows quickly, set the temperature contr\
ols and fan speed
controls to their maximum settings.
5 MODE BUTTON

Press the MODE button
to cycle through the following air flow outlets:

Air flows from the center and side vents.

Air flows from the center, side and foot vents.

Air flows mainly from the foot vents.

Air flows from the defroster and foot vents.
6 DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS

Press the rear window defroster button to turn the system on or off.

This function automatically turns off after approximately 15 minutes.
123
45
67
8
9
1923534_15c_Infiniti_QX50_QRG_122314.indd 1212/23/14 1:05 PM

13
7 INTAKE AIR CONTROL BUTTON
AIR RECIRCULATION

Press the intake air control button
to recirculate interior air inside the vehicle. The indicator

light on the
side will illuminate. This system is used to avoid outside odors and to\
help
adjust the inside vehicle temperature more effectively.

The air recirculation mode cannot be activated when the climate control \
system is in the
front defroster mode

or front defroster and foot vent mode .
OUTSIDE AIR CIRCULATION

Press the intake air control button again to draw outside air into the p\
assenger
compartment. The indicator light on the

side will illuminate.
AUTOMATIC INTAKE AIR CONTROL

In the auto mode, the intake air will be controlled automatically. To ma\
nually control the
intake air, press the intake air control button. To return to the automa\
tic control mode,
press the intake air control button for about 2 seconds.
8
A/C BUTTON

Press the A/C button to turn the air conditioner system on or off. This system helps \
cool
and dehumidify the air inside the cabin and defog the windows.
9 OFF BUTTON

Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)” and the “Monitor, climate, audio, phone and voice recognition
systems (section 4)” of your Owner’s Manual.
1923534_15c_Infiniti_QX50_QRG_122314.indd 1312/23/14 1:05 PM

14
first drive features
FM/AM/SiriusXM®* Satellite Radio with CD/DVD Player
(with Navigation System - if so equipped)
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB

Press the ON•OFF button to turn the system on or off.

Turn the VOL (volume) knob right or left to increase or decrease the volume.
2 SEEK•CAT AND TRACK BUTTONS


To scan quickly through each broadcasting station, press the SEEK•CAT button or the
TRACK button to stop at the next or previous broadcast station.

For satellite radio, press the SEEK•CAT button or the TRACK button to switch to
the first channel of the next or previous category.

Press the SEEK•CAT button or the TRACK button to change tracks on a CD.

Press and hold the SEEK•CAT button or the TRACK button to fast forward or rewind a
track on a CD.
3 AUDIO BUTTON/TUNE/FOLDER CONTROL KNOB

To manually tune the radio, turn the TUNE/FOLDER control knob left or right.

Press the AUDIO button to go to the audio settings screen.
4 STATION PRESET BUTTONS

Twelve stations can be set for the FM band, six for the AM band and eigh\
teen for
satellite radio.

To store a station in a preset, you must first select a radio band by pr\
essing the
AM•FM/SAT button
5, then tune to the desired AM, FM or XM satellite radio station.

Then press and hold the desired station preset button (1-6) until the preset number
is updated on the display and the sound is briefly muted. The channel indic\
ator will then
display and the sound will resume. Programing is now complete.

To retrieve a previously set station, select the radio band where the pr\
eset was stored
then press the corresponding station select button (1-6).
*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional\
satellite radio subscription service.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4\
)” of your Owner’s Manual.
123
4
5
1923534_15c_Infiniti_QX50_QRG_122314.indd 1412/23/14 1:05 PM

15
Conventional (Fixed Speed) Cruise Control
The cruise control system enables you to set a
constant cruising speed once the vehicle has
reached 25 MPH (40 km/h).

The system will automatically maintain the set speed
until you tap the brake pedal, accelerate, cancel or
turn the system off.

To activate the cruise control, push the ON/OFF
switch
1. The CRUISE indicator light in the
instrument panel will illuminate.

To set a cruising speed, accelerate the vehicle to the desired speed, pu\
sh the COAST/SET
switch

2 and release. The SET indicator light
in the instrument panel will illuminate. Take
your foot off the accelerator pedal. Your vehicle will maintain the set \
speed.

To reset at a faster cruising speed, push and hold the ACCEL/RES switch 3. When the
vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch 2. Release the
switch when the vehicle slows to the desired speed.

To cancel the preset speed, tap the brake pedal or push the CANCEL switch 4.

To turn off cruise control, push the ON/OFF switch
1. Both the CRUISE indicator light and
the SET indicator light
in the instrument panel will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
4
2
USB/iPod® Interface

The USB jack
1 is located in the center console
under the armrest.

When a compatible USB memory device or iPod® is
plugged into the USB jack, compatible audio and
video files stored on the device can be
played through the vehicle’s audio system
and front display.
For more information, refer to the “Monitor, climate, audio,
phone and voice recognition systems (section 4)” of your
Owner’s Manual.
3
1
1
1923534_15c_Infiniti_QX50_QRG_122314.indd 1512/23/14 1:05 PM

16
Intelligent Cruise Control (ICC) System (if so equipped)
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE

To set Vehicle-To-Vehicle Distance Control mode,
press the CRUISE ON/OFF button
1 for less
than 1.5 seconds. The CRUISE indicator light 2

will illuminate.

Accelerate to the desired speed.

Push down on the COAST/SET switch 3 and release
it. Cruise control will be set to the desired speed.

Press the distance button
4 repeatedly to change
the set distance between long, middle and short.

When a vehicle is not detected ahead of you in the
lane, the set distance and set vehicle speed indicator
lights will illuminate
5 in set mode.
When a vehicle is detected ahead of you in the lane,
the vehicle ahead detection, set distance and set
vehicle speed indicator lights will illuminate
6 in set mode.

To reset at a faster cruising speed, push up and hold the ACCEL/RES
switch

7. When the vehicle attains the desired speed, release
the switch.

To reset at a slower cruising speed, push down and hold the COAST/SET switch 3. Release
the switch when the vehicle slows to the desired speed.

To cancel the preset speed, push the CANCEL switch
8 or tap the brake pedal. The set
vehicle speed indicator 5 will extinguish.
To turn off cruise control, press the CRUISE ON/OFF button 1. The CRUISE indicator
light
2 in the instrument panel will extinguish.
To set conventional (fixed speed) cruise control mode:

While cruise control is off, press the CRUISE ON/OFF
button 1
and hold it down for more
than 1.5 seconds. The CRUISE indicator light will illuminate.

Accelerate to the desired speed.

Push down on the COAST/SET switch and release it. The SET indicator light will illuminate.
Cruise control should be set to the desired speed.
To switch between the two cruise control modes:

When one of the two cruise modes is in use, you must turn the system off\
, and then turn it on
again to select the other cruise control mode.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
8
7
first drive features
1
2
3
4
5
6
1923534_15c_Infiniti_QX50_QRG_122314.indd 1612/23/14 1:05 PM

17
Power Outlets

The power outlets are used for powering electrical

accessories such as cellular phones. They are
rated at 12V, 120W (10A) maximum.


Power outlets are located on the instrument panel

1 and inside the center console 2.

To use a power outlet, open the cap.

For more information, refer to the “Starting and driving (section 5)” of your
Owner’s Manual.
1
2
1923534_15c_Infiniti_QX50_QRG_122314.indd 1712/23/14 1:05 PM

18
Bluetooth® Hands-free Phone System
A cellular telephone should not be used
while driving so full attention may be given to
vehicle operation.*
SYSTEM OPERATING TIPS

Press the or but ton to interrupt the voice
prompts at any time and speak a command af ter
the tone.

To use the system faster, you may speak the second
level commands with the main menu command on the
main menu. For example, press the
or button and after the tone, say “Call Redial”.

The “Help” command can be used to hear a list of available command\
s at any time.
Trip Computer
When the
button
1 is pressed, the following

modes will appear on the vehicle information
display
2:
• MPG – Displays the current fuel consumption.
•
MPG/MPH – Displays the average fuel

consumption and speed since the last reset.
·
To reset the displayed MPG/MPH, press and

hold the
button 3 for more than one
second. Both elapsed time/miles will reset at the
same time.
•
TIME/MILES – Displays the elapsed time and
total distance the vehicle has been driven since the last reset.
·
To reset the elapsed time/miles, press and hold the
button 3 for more than one
second. Both elapsed time/miles will reset at the same time.
•
RANGE – Displays the estimated distance to empty (dte) the vehicle can b\
e driven

before refueling.
•
OUTSIDE TEMP – Displays the exterior air temperature including a low temperature

warning feature.
•
SETTING – Allows you to set reminders for alerts and maintenance intervals o\
r change the
language and units used in the system.
· Press the

button
3 to cycle through the various setting modes.

· Press the

button
1 to choose the selected menu.
• WARNING – Displays when a warning is present.

Press the button 3
for approximately 1 second to reset the currently displayed trip
odometer to zero.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
system guide
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
Bluetooth®
Controls
1
2
3
1923534_15c_Infiniti_QX50_QRG_122314.indd 1812/23/14 1:05 PM
