VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
Symptom ChartEIS002SN
*1: Make sure the system is in the armed phase.PROCEDURE
Diagnostic procedure
SYMPTOM
1Vehicle security
system cannot be
set by ····Door switch Refer to BL-93, "
Door Switch Check" .
Lock/unlock switch Refer to BL-100, "
Door Lock/Unlock Switch Check" .
Door outside keyRefer to BL-98, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
BCM If the above systems are “OK”, replace BCM.
Security indicator does not turn “ON”.Refer to BL-97, "
Combination Meter (Security Indicator Lamp) Check" .
If the above systems are “OK”, replace BCM.
2*1 Vehicle secu-
rity system does
not alarm when
····Any door, hood or glass hatch
is opened.Refer to BL-93, "
Door Switch Check" .
Refer to BL-95, "
Hood Switch Check" .
If the above systems are “OK”, replace BCM.
3Vehicle security
alarm does not
activate.Horn alarmRefer to BL-100, "
Vehicle Security Horn Alarm Check" .
If the above systems are “OK”, check horn system.
Refer to WW-56, "
HORN" .
Headlamp alarmRefer to BL-100, "
Vehicle Security Headlamp Alarm Check" .
If the above systems are “OK”, replace BCM.
4Vehicle security
system cannot be
canceled by ····Door outside keyRefer to BL-98, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
If the above systems are “OK”, check main power window and door lock/
unlock switch.
KeyfobCheck remote keyless entry function. Refer toBL-65, "
Keyfob Battery and
Function Check"
If the above systems are “OK”, replace BCM.

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-93
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Door Switch CheckEIS003ES
1. CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-II
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", "BACK DOOR
SW", "TRNK OPN MNTR") in DATA MONITOR mode with CONSULT–II.Refer to BL-27, "
DATA MONITOR" .

When doors are open:

When doors are closed:
Without CONSULT-II
Check voltage between BCM connector M18 or M19 terminals 12,
13, 42, 43, 47, 48 and ground.
OK or NG
OK >> Door switch circuit is OK.
NG >> GO TO 2.DOOR SW-DR : ON
DOOR SW-AS : ON
DOOR SW-RL : ON
DOOR SW-RR : ON
BACK DOOR SW : ON
TRNK OPN MNTR : ON
DOOR SW-DR : OFF
DOOR SW-AS : OFF
DOOR SW-RL : OFF
DOOR SW-RR : OFF
BACK DOOR SW : OFF
TRNK OPN MNTR : OFF
WIIA0466E
Connector ItemTerminals (Wire color)
ConditionVoltage (V)
(Approx.)
( + ) ( – )
M19Glass hatch
ajar switch42 (GR)
GroundOpen
↓
Closed0
↓
Battery voltage Back door
latch (door
ajar switch)43 (R/B)
Front door
switch LH47 (SB)
Rear door
switch LH48 (R/Y)
M18Front door
switch RH12 (R/L)
Rear door
switch RH13 (GR)
LIIA1451E

BL-94
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
2. CHECK DOOR SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door or hatch switch and BCM.
3. Check continuity between door switch connector (B) B8 (front LH), B108 (front RH), B18 (rear LH), B116
(rear RH) terminal 2 or back door latch connector (C) D503 terminal 7 or glass hatch ajar switch connector
(D) D707 terminal + and BCM connectors (A) M18, M19 terminals 12, 13, 42, 43, 47 and 48.
4. Check continuity between door switch connector (B) B8 (front
LH), B108 (front RH), B18 (rear LH), B116 (rear RH) terminal 2,
back door latch connector (C) D503 terminal 7 or glass hatch
ajar switch connector (D) D707 terminal + and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR SWITCHES
FRONT, REAR DOORS AND GLASS HATCH
Check continuity between door switch connector (A) B8 (front LH),
B108 (front RH), B18 (rear LH), B116 (rear RH) terminal 2, glass
hatch ajar switch connector (B) D707 terminal + and ground while
pressing switch (closing glass hatch) and releasing switch (opening
glass hatch).
BACK DOOR
Check continuity between back door latch connector (A) D503 termi-
nals 7 and 8 while pressing (closing back door) and releasing (open-
ing back door) switch.
OK or NG
OK >> (Front, rear doors and glass hatch) Switch circuit is OK.
OK >> (Back door) GO TO 4.
NG >> Replace door switch.2 (R/L) - 12 (R/L) : Continuity should exist.
2 (GR) - 13 (GR) : Continuity should exist.
2 (SB) - 47 (SB) : Continuity should exist.
2 (R/Y) - 48 (R/Y) : Continuity should exist.
7 (R/W) - 43 (R/B) : Continuity should exist.
+ (GR) - 42 (GR) : Continuity should exist.
2 (SB, R/L, R/Y or GR) -
Ground : Continuity should not exist.
7 (R/W) - Ground : Continuity should not exist.
+ (GR) - Ground : Continuity should not exist.
WIIA0751E
Door switch is pressed
(or glass hatch closed) : Continuity should not exist.
Door switch is released
(or glass hatch open) : Continuity should exist.
WIIA0753E
Back door is open : Continuity should exist.
Back door is closed : Continuity should not exist.
WIIA0752E

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-95
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
4. CHECK BACK DOOR SWITCH GROUND
Check continuity between back door latch connector terminal 8 and
ground.
OK or NG
OK >> Back door switch circuit is OK.
NG >> Repair or replace harness.
Hood Switch CheckEIS0039U
1. CHECK HOOD SWITCH
Check hood switch and hood fitting condition.
OK or NG
OK >> GO TO 2.
NG >> Adjust installation of hood switch.
2. CHECK HOOD SWITCH INPUT SIGNAL
With CONSULT-II
Check "HOOD SW" in "DATA MONITOR" mode with CONSULT-II.
Without CONSULT-II
Check voltage between IPDM E/R harness connector E122 terminal
41 and ground.
OK or NG
OK >> Hood switch circuit is OK.
NG >> GO TO 3.8 (B) - Ground : Continuity should exist.
LIIA0828E
When hood is open : HOOD SW ON
When hood is closed : HOOD SW OFF
LIIA0038E
ConnectorTerminal (Wire color)
Condition of
hoodVoltage (V)
(Approx.)
(+) (-)
E122 41 (Y/B) GroundOpen 0
Closed Battery voltage
WIIA0601E

BL-96
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
3. CHECK HOOD SWITCH
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R connector E122 and hood switch connector.
3. Check continuity between IPDM E/R connector (A) E122 termi-
nal 41 and hood switch connector (B) E8 terminal 2.
4. Check continuity between IPDM E/R connector (A) E122 termi-
nal 41 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK HOOD SWITCH
Check continuity between hood switch connector E8 terminals 1 and 2.
OK or NG
OK >> Repair or replace harness between hood switch and
grounds E9, E15 and E24.
NG >> Replace hood switch.41 (Y/B) - 2 (Y/B) : Continuity should exist.
41 (Y/B) - ground : Continuity should not exist.
WIIA0761E
Terminals Condition of hood switch Continuity
1- 2Pressed No
Released Yes
LIIA1932E

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-97
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
Combination Meter (Security Indicator Lamp) CheckEIS002SP
1. SECURITY INDICATOR LAMP ACTIVE TEST
With CONSULT-II
Check "THEFT IND” in "ACTIVE TEST" mode with CONSULT-II.
Without CONSULT-II
1. Disconnect BCM.
2. Check voltage between BCM harness connector M18 terminal
23 and ground.
OK or NG
OK >> Security indicator lamp is OK.
NG >> GO TO 2.
2. SECURITY INDICATOR LAMP CHECK
Check security indicator lamp condition.
Refer to DI-5, "
COMBINATION METERS" .
OK or NG
OK >> GO TO 3.
NG >> Replace combination meter (security indicator lamp). Refer to DI-25, "
Removal and Installation of
Combination Meter" .
LIIA0044E
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (-)
M18 23 (G/O) GroundON 0
OFFBattery volt-
age
LIIA0523E

BL-98
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
3. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and combination meter (security indicator lamp).
3. Check continuity between BCM connector (A) M18 terminal 23
and combination meter (security indicator lamp) harness con-
nector (B) M24 terminal 28.
4. Check continuity between BCM connector (A) M18 terminal 23
and ground.
OK or NG
OK >> Check the following:

10A fuse [No. 19, located in fuse block (J/B)]

Harness for open or short between combination meter (security indicator lamp) and fuse
NG >> Repair or replace harness.
Front Door Lock Assembly LH (Key Cylinder Switch) CheckEIS002SQ
1. CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH)
With CONSULT-II
Check front door lock assembly LH (key cylinder switch) ("KEY CYL LK-SW") and ("KEY CYL UN-SW) in
DATA MONITOR mode in CONSULT–II.Refer to BL-27, "
DATA MONITOR" .

When key inserted in front key cylinder is turned to LOCK:

When key inserted in front key cylinder is turned to UNLOCK:
Without CONSULT-II
Check voltage between main power window and door lock/unlock switch connector D7 terminals 4, 6 and
ground.
OK or NG
OK >> Front door lock assembly LH (key cylinder switch) signal is OK.
NG >> GO TO 2.23 (G/O) - 28 (G/O) : Continuity should exist.
23 (G/O) - ground : Continuity should not exist.
LIIA2253E
KEY CYL LK-SW : ON
KEY CYL UN-SW : ON
LIIA0188E
Connec-
torTerminals (Wire
color)Condition of key cylinder
switchVoltage (V)
(Approx.)
( + ) ( – )
D74 (L)
GroundNeutral/Unlock 5
Lock 0
6 (R)Neutral/Lock 5
Unlock 0
LIIA0566E

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-99
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: August 20072004 QX56
2. CHECK DOOR KEY CYLINDER SWITCH LH GROUND HARNESS
Check continuity between front door lock assembly LH (key cylinder
switch) connector (A) D14 terminal 5 and body ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3. CHECK DOOR KEY CYLINDER SWITCH LH
Check continuity between front door lock assembly LH (key cylinder
switch) terminals.
OK or NG
OK >> GO TO 4.
NG >> Replace front door lock assembly LH (key cylinder switch). Refer to BL-132, "
Removal and Instal-
lation" .
4. CHECK DOOR KEY CYLINDER HARNESS
Check continuity between main power window and door lock/unlock
switch connector (A) D7 terminals 4, 6 and front door lock assembly
LH (key cylinder switch) connector (B) D14 terminals 1, 6 and body
ground.
OK or NG
OK >> Replace main power window and door lock/unlock switch.
NG >> Repair or replace harness.
Connector Terminal (wire color) Continuity
D14 5 (B) – Ground Yes
WIIA0755E
Terminals Condition Continuity
1 – 5 Key is turned to UNLOCK or neutral. No
Key is turned to LOCK. Yes
5 – 6Key is turned to LOCK or neutral. No
Key is turned to UNLOCK. Yes
LIIA1573E
ConnectorTe r m i n a l s
(wire color)ConnectorTe r m i n a l s
(wire color)Continuity
A: Main
power win-
dow and
door lock/
unlock
switch4 (L) B: Front
door lock
assembly
LH (key
cylinder
switch)1 (L) Yes
6 (R) 6 R) Yes
4 (L),
6 (R)Ground No
WIIA0756E

BL-100
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: August 20072004 QX56
Vehicle Security Horn Alarm CheckEIS002SR
1. CHECK HORN OPERATION
Check if horn sounds with horn switch.
Does horn operate?
Yes >> Check harness for open or short between IPDM E/R and horn relay.
No >> Check horn circuit. Refer to WW-56, "
HORN" .
Vehicle Security Headlamp Alarm Check EIS002SS
1. CHECK VEHICLE SECURITY HEADLAMP ALARM OPERATION
Check if headlamps operate with lighting switch.
Do headlamps come on when turning switch ON?
Yes >> Headlamp alarm is OK.
No >> Check headlamp system. Refer to LT- 6 , "
HEADLAMP (FOR USA)" or LT-34, "HEADLAMP (FOR
CANADA) - DAYTIME LIGHT SYSTEM -" .
Door Lock/Unlock Switch Check EIS002ST
1. CHECK DOOR LOCK/UNLOCK SWITCH INPUT SIGNAL
Check if power door lock operates with door lock/unlock switch.
Do doors lock/unlock when using each door lock/unlock switch?
Yes >> Door lock/unlock switch is OK.
No >> Refer to BL-34, "
Door Lock/Unlock Switch Check" .

BL-102
AUTOMATIC BACK DOOR SYSTEM
Revision: August 20072004 QX56
System DescriptionEIS002SV
The automatic back door system consists of a one piece unit that combines the back door control unit along
with the back door motor, back door clutch and the back door encoder. The back door latch contains a lock
function that can control the two functions of automatic back door latch closure and electrical opener with a
single motor when you close the back door to the halfway-state.

Back door auto closure
When the back door is closed to the halfway state (half-latch) position, the motor automatically drives to
rotate the latch lever and pull it in from half latched to full latched.

Power back door
With the back door closed, press the power liftgate switch or press the remote keyless entry button, or pull
the back door handle with the back door unlocked, the back door latch motor opens the locking plate and
releases the latch. The back door motor then raises the door to the full open position.
With the back door fully open, press the power liftgate switch, remote keyless entry button or the back
door close switch, the back door motor closes the door to the half-latch state. The back door latch motor
then drives the latch to the full close position.
At the onset of each power open or power close application, the hazard lamps will flash 3 times and the
warning chime will sound 3 times lasting a total of 2 seconds.
OPERATION DESCRIPTION
Power Liftgate Switch Operation (Fully Closed → Fully Open Operation)

When the power liftgate switch is pressed, back door control unit terminal 23 receives the signal.

The back door control unit checks the A/T selector lever (P position) through terminal 18, vehicle speed
through terminal 21, ignition status through terminal 7, glass hatch is closed through terminal 17 and bat-
tery voltage is present through terminal 3.

When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a 5 volt signal through terminal 6 and grounds terminal 9 to sound the warning chime, sends
a signal to the BCM through terminal 4 to flash the hazard lamps and unlocks the back door latch through
terminal 12.

The back door control unit supplies power to the magnetic clutch and the back door motor and moves the
back door in the open direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)

When the back door is opened to the full-open position, the full-open position is detected by the encoder,
and the back door control unit switches the back door motor OFF and the magnetic clutch is pulsed and
then turned OFF.

The back door is held in the fully open position by the gas stays.
Remote Keyless Entry Operation (Fully Closed → Fully Open Operation)

When the remote keyless entry button is pressed for at least 0.5 seconds, back door control unit terminal
21 receives the signal.

The back door control unit checks the A/T selector lever (P position) through terminal 18, vehicle speed
through terminal 21, ignition status through terminal 7, glass hatch is closed through terminal 17 and bat-
tery voltage is present through terminal 3.

When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a 5 volt signal through terminal 6 and grounds terminal 9 to sound the warning chime, sends
a signal to the BCM through terminal 4 to flash the hazard lamps and unlocks the back door latch through
terminal 12.

The back door control unit supplies power to the magnetic clutch and the back door motor and moves the
back door in the open direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)

When the back door is opened to the full-open position, the full-open position is detected by the encoder,
and the back door control unit switches the back door motor OFF and the magnetic clutch is pulsed and
then turned OFF.

The back door is held in the fully open position by the gas stays.
