WARNING LAMPS
Revision: November 20092006 QX56
Oil Pressure Warning Lamp Does Not Turn Off (Oil Pressure Is Normal)EKS00BCL
NOTE:
For oil pressure inspection, refer to LU-7, "
OIL PRESSURE CHECK" .
1. CHECK ENGINE OIL PRESSURE GAUGE OPERATION
Observe operation of engine oil pressure gauge.
Does engine oil pressure gauge function properly?
YES >> Replace the combination meter. Refer to IP-13, "COMBINATION METER" .
NO >> Go to DI-19, "
Engine Oil Pressure Signal Inspection" .

A/T INDICATORDI-41
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
A/T INDICATORPFP:24814
Wiring Diagram — AT/IND —EKS00BCM
WKWA3626E

DI-42
A/T INDICATOR
Revision: November 20092006 QX56
A/T Indicator Does Not IlluminateEKS00BCN
1. CHECK SELF-DIAGNOSIS OF COMBINATION METER
Perform combination meter self-diagnosis. Refer to DI-13, "
SELF-DIAGNOSIS FUNCTION" .
OK or NG
OK >> GO TO 2.
NG >> Replace the combination meter. Refer to IP-13, "
COMBINATION METER" .
2. CHECK TCM
Perform self-diagnosis of TCM. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" .
OK or NG
OK >> Replace the combination meter. Refer to IP-13, "COMBINATION METER" .
NG >> Refer to DI-13, "
SELF-DIAGNOSIS FUNCTION" .

WARNING CHIMEDI-43
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
WARNING CHIMEPFP:24814
Component Parts and Harness Connector LocationEKS00BCO
1. Fuse block (J/B)2. Fuse and fusible link box3. Fuse and relay box
4. Combination meter M24 5. Combination switch (lighting switch)
M28 6. BCM M18, M19, M20 (view with
instrument lower panel LH removed)
7. Front door switch LH B8 8. Key switch and key lock solenoid
M27 9. Seat belt buckle pre-tensioner
assembly LH (seat belt buckle
switch) B74
WKIA4594E

DI-44
WARNING CHIME
Revision: November 20092006 QX56
System DescriptionEKS00BCP
FUNCTION
Power is supplied at all times

through 50A fusible link (letter f , located in the fuse and fusible link box)

to BCM terminal 70, and

through 10A fuse [No. 19, located in the fuse block (J/B)]

to key switch and key lock solenoid terminal 3.
With ignition switch in ON or START position, power is supplied

through 10A fuse (No. 59, located in the fuse and relay box)

to BCM terminal 38.
Ground is supplied

to BCM terminal 67

through body grounds M57, M61, and M79.
NOTE:
When ignition key warning chime, light warning chime, and seat belt warning chime are required at the same
time, the priorities for each chime are the following.
1. Light warning chime
2. Ignition key warning chime
3. Seat belt warning chime
IGNITION KEY WARNING CHIME
With the key inserted in the ignition switch, the ignition switch in OFF position, and the driver's door open, the
warning chime will sound.
Power is supplied

through key switch and key lock solenoid terminal 4

to BCM terminal 37.
Ground is supplied

to BCM terminal 47

through front door switch LH terminal 2.
Front door switch LH is case grounded.
BCM detects key inserted into the ignition switch, and sends key warning signal to combination meter via CAN
communication lines. When the combination meter receives key warning signal, it sounds warning chime.
LIGHT WARNING CHIME
With the key removed from the ignition switch, the driver's door open, and the lighting switch (part of the com-
bination switch) in 1st or 2nd position, the warning chime will sound. [Except when headlamp battery saver
control operates (5 minutes after ignition switch is turned to OFF or ACC position) and headlamps do not illu-
minate.]
Signal is supplied

from combination switch (lighting switch) terminals 1, 2, 3, 4, 5, 6, 7, 8, 9 and 10

to BCM terminals 2, 3, 4, 5, 6, 32, 33, 34, 35 and 36.
NOTE:
BCM detected lighting switch in 1st or 2nd position. Refer to BCS-3, "
COMBINATION SWITCH READING
FUNCTION" .
Ground is supplied

to BCM terminal 47

through front door switch LH terminal 2.
Front door switch LH is case grounded.
BCM detects headlamps are illuminated, and sends light warning signal to combination meter CAN communi-
cation lines. When the combination meter receives light warning signal, it sounds warning chime.
SEAT BELT WARNING CHIME
When the ignition switch is turned ON with the seat belt unfastened [seat belt buckle pre-tensioner assembly
LH (seat belt buckle switch) unfastened], warning chime will sound for approximately 6 seconds.

WARNING CHIMEDI-45
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Ground is supplied

to combination meter terminal 27

through seat belt buckle pre-tensioner assembly LH (seat belt buckle switch) terminal 4.
Seat belt buckle pre-tensioner assembly LH (seat belt buckle switch) terminal 3 is grounded through body
grounds B7 and B19.
The combination meter sends seat belt buckle switch LH unfastened signal to BCM via CAN communication
line.
BCM receives seat belt buckle pre-tensioner assembly LH (seat belt buckle switch) unfastened signal from
combination meter via CAN communication line, and sends seat belt warning signal to the combination meter
via CAN communication line. When the combination meter receives the seat belt warning signal, it sounds the
warning chime. The BCM controls the (6 second) duration of the seat belt warning chime.
CAN Communication System DescriptionEKS00BCQ
Refer to LAN-26, "CAN COMMUNICATION" .

DI-46
WARNING CHIME
Revision: November 20092006 QX56
Wiring Diagram — CHIME —EKS00BCR
WKWA3627E

WARNING CHIMEDI-47
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
WKWA3064E

DI-48
WARNING CHIME
Revision: November 20092006 QX56
Terminals and Reference Value for BCMEKS00BCS
Terminal
No. Wire
color Item Condition
Reference value (V)
(Approx.)
Ignition
switch Measurement method
2 SB Combination switch input 5 ON

Light switch and wiper switch
OFF

Wiper dial position 4
3 G/Y Combination switch input 4 ON

Light switch and wiper switch
OFF

Wiper dial position 4
4 Y Combination switch input 3 ON

Light switch and wiper switch
OFF

Wiper dial position 4
5 G/B Combination switch input 2 ON

Light switch and wiper switch
OFF

Wiper dial position 4
6 V Combination switch input 1
32 R/G Combination switch output 5 ON

Light switch and wiper switch
OFF

Wiper dial position 4
33 R/Y Combination switch output 4 ON

Light switch and wiper switch
OFF

Wiper dial position 4
34 L Combination switch output 3 ON

Light switch and wiper switch
OFF

Wiper dial position 4
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E
SKIA5292E
SKIA5291E

WARNING CHIMEDI-49
C
DE
F
G H
I
J
L
M A
B
DI
Revision: November 2009 2006 QX56
Terminals and Reference Value for Combination MeterEKS00BCT
How to Proceed With Trouble DiagnosisEKS00BCU
1. Confirm the symptom or customer complaint.
2. Understand operation description and function description. Refer to DI-44, "
System Description" .
3. Perform the preliminary check. Refer to DI-50, "
Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the warning chime operate properly? If so, go to 6. If not, go to 3.
6. Inspection End.
35 O/B Combination switch output 2
ON

Light switch and wiper switch
OFF

Wiper dial position 4
36 R/W Combination switch output 1
37 B/R Key switch signal
OFFKey is removed
0
Key is inserted Battery voltage
38 W/L Ignition switch ON or START ON —Battery voltage
39 L CAN-H —— —
40 P CAN-L —— —
47 SB Front door switch LH signal OFF ON (open)
0
OFF (closed) 5
67 B Ground OFF— 0
70 W/B Battery power supply OFF— Battery voltage
Terminal
No. Wire
color Item Condition
Reference value (V)
(Approx.)
Ignition
switch Measurement method
SKIA5292E
Terminal
No. Wire
color Item Condition
Reference value (V)
(Approx.)
Ignition
switch Measurement method
11 L C A N - H —— —
12 P CAN-L —— —
17 B Ground OFF— 0
24 O/L Ignition switch ON or START ON —Battery voltage
27 O/B Seat belt buckle pre-ten-
sioner assembly (seat belt
buckle switch) LH
ONUnfastened (ON)
0
Fastened (OFF) Battery voltage
