TROUBLE DIAGNOSIS FOR SYMPTOMSAT-183
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
THROTTLE POSITION SENSOR" , AT- 1 5 9 , "DTC P1841 ATF PRESSURE SWITCH 1" , AT- 1 4 3 ,
"DTC P1757 FRONT BRAKE SOLENOID VALVE" , AT- 9 6 , "DTC U1000 CAN COMMUNICATION
LINE" .
NO >> GO TO 2.
2. ENGINE IDLE SPEED
Check the engine idle speed. Refer to EC-76, "
Idle Speed and Ignition Timing Check" .
OK or NG
OK >> GO TO 3.
NG >> Repair.
3. CHECK CONTROL CABLE
Check the control cable.

Refer to AT- 2 2 7 , "Checking of A/T Position" .
OK or NG
OK >> GO TO 4.
NG >> Adjust control cable. Refer to AT- 2 2 7 , "
Adjustment of A/
T Position" .
4. CHECK A/T FLUID LEVEL
Check the A/T fluid level. Refer to AT- 1 2 , "
Checking Automatic
Transmission Fluid (ATF)" .
OK or NG
OK >> GO TO 5.
NG >> Refill ATF.
5. CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “D” position. Refer
to AT- 5 2 , "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 8.
NG - 1 >> Line pressure high: GO TO 6.
NG - 2 >> Line pressure low: GO TO 7.
LCIA0345E
SAT638A
SAT494G

AT-184
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 1 2 , "
Checking Automatic
Transmission Fluid (ATF)" .
OK or NG
OK >> GO TO 10.
NG >> GO TO 9.
9. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.1).
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
10. CHECK SYMPTOM
Check again. Refer to AT- 5 5 , "
Check at Idle" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 11.
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-187
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
5. DETECT MALFUNCTIONING ITEM
1. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
2. Check the following items:
–Reverse brake. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
6. CHECK LINE PRESSURE
Check the line pressure with the engine idling. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 9.
NG - 1 >> Line pressure high. GO TO 7.
NG - 2 >> Line pressure low. GO TO 8.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
8. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
SAT494G

AT-190
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
5. CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “D” position. Refer
to AT- 5 2 , "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 8.
NG - 1 >> Line pressure high. GO TO 6.
NG - 2 >> Line pressure low. GO TO 7.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 9.
NG >> GO TO 12.
SAT494G
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-193
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
8. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 9.
NG >> GO TO 12.
9. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.23).
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
10. CHECK SYMPTOM
Check again. Refer to AT- 5 6 , "
Cruise Test - Part 1" , AT- 5 8 , "Cruise Test - Part 2" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 11.
11 . PERFORM TCM INSPECTION
1. Perform TCM input/output signals inspection. Refer to AT- 8 3 , "
TCM Input/Output Signal Reference Val-
ues" .
2. If NG, recheck A/T assembly harness connector terminals for damage or loose connection with harness connector.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-195
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
5. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
7. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 8.
NG >> GO TO 11.
8. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.10).
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
9. CHECK SYMPTOM
Check again. Refer to AT- 5 6 , "
Cruise Test - Part 1" , AT- 5 8 , "Cruise Test - Part 2" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 10.
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-197
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
4. CHECK LINE PRESSURE
Check line pressure at the engine stall point. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 7.
NG - 1 >> Line pressure high. GO TO 5.
NG - 2 >> Line pressure low. GO TO 6.
5. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
7. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 8.
NG >> GO TO 11.
SAT494G
SCIA5199E

TROUBLE DIAGNOSIS FOR SYMPTOMSAT-199
DE
F
G H
I
J
K L
M A
B
AT
Revision: November 2009 2006 QX56
P1705 THROTTLE POSITION SENSOR" , AT- 111 , "DTC P0720 VEHICLE SPEED SENSOR A/T
(REVOLUTION SENSOR)" , AT- 1 3 2 , "DTC P1721 VEHICLE SPEED SENSOR MTR" .
NO >> GO TO 3.
3. CHECK A/T FLUID LEVEL
Check A/T fluid level. Refer to AT- 1 2 , "
Checking Automatic Trans-
mission Fluid (ATF)" .
OK or NG
OK >> GO TO 4.
NG >> Refill ATF.
4. CHECK LINE PRESSURE
Check line pressure at the engine stall point. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 7.
NG - 1 >> Line pressure high. GO TO 5.
NG - 2 >> Line pressure low. GO TO 6.
5. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
SAT638A
SAT494G

AT-202
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
5. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
7. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 8.
NG >> GO TO 11.
8. DETECT MALFUNCTIONING ITEM

Check the malfunction items. If any items are damaged, repair or replace damaged parts. Refer to AT- 6 1 ,
"Symptom Chart" (Symptom No.13).
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
9. CHECK SYMPTOM
Check again. Refer to AT- 5 6 , "
Cruise Test - Part 1" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 10.
SCIA5199E

AT-204
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: November 20092006 QX56
3. CHECK LINE PRESSURE
Check line pressure at the engine stall point. Refer to AT- 5 2 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 6.
NG - 1 >> Line pressure high. GO TO 4.
NG - 2 >> Line pressure low. GO TO 5.
4. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
5. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 6 4 , "
Disassembly" .
3. Check the following items:
–Oil pump assembly. Refer to AT- 2 8 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 6 4 , "Disassembly" .
–Transmission case. Refer to AT- 2 6 4 , "Disassembly" .
OK or NG
OK >> GO TO 7.
NG >> Repair or replace damaged parts.
6. CHECK A/T FLUID CONDITION
1. Remove oil pan. Refer to AT- 2 3 0 , "
Control Valve With TCM and A/T Fluid Temperature Sensor 2" .
2. Check A/T fluid condition. Refer to AT- 5 1 , "
Fluid Condition
Check" .
OK or NG
OK >> GO TO 7.
NG >> GO TO 10.
SAT494G
SCIA5199E
