Page 50 of 3383
![INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-37
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
NOTE: DTC 55 will display when no malfunction is detected.
DTC 11 CONTROL UNITEKS00](/img/42/57028/w960_57028-49.png "INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-37
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
NOTE: DTC 55 will display when no malfunction is detected.
DTC 11 CONTROL UNITEKS00")
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-37
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
NOTE: DTC 55 will display when no malfunction is detected.
DTC 11 CONTROL UNITEKS00BM0
1. DIAGNOSTIC CHECK
Are any items other than “DTC 11 CONTROL UNIT ” indicated on self-diagnosis display?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NO >> Replace ICC unit. Refer to ACS-59, "
ICC Unit" . Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
DTC 12 VDC CONTROL UNITEKS00BM1
1. DIAGNOSIS CHECK
With CONSULT-II
Perform self-diagnosis of ABS actuator and electric unit (control unit). Is malfunction indicated?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK CONNECTOR ICC UNIT AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
1. Turn ignition switch OFF.
2. Disconnect ICC unit, and ABS actuator and electric unit (control unit) connectors, and connect them securely again. Erase DTC, then perform self-diagnosis of ICC system again.
OK or NG
OK >> Poor connector connection. Check connector housing for disconnected, loose, bent and collapsed terminals. If any malfunction is detected, repair as necessary. Erase DTC and perform ICC sys-
tem running test. Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of
ICC system again.
NG >> GO TO 3.
98 GEAR POSITION ×××
TCM malfunction
A/T turbine revolution sensor
malfunction
A/T vehicle speed sensor mal-
functionACS-49
102 LASER STAIN
×× ×ICC sensor body window has
contaminationACS-49
103 LASER SENSOR FAIL
×× ×ICC sensor internal malfunctionACS-50
104 LASER AIMING INCMP ×× ×Laser beam aiming of ICC sensor
is not adjustedACS-50
107 LASER COMM FAIL
×× ×
CAN data received by ICC sen-
sor is strange (from ICC unit,
combination meter or ECM)ACS-51
109 LASER HIGH TEMP
×× ×Temperature around ICC sensor
is excessively highACS-51
DTC
No. CONSULT-II screen terms ICC sys-
tem
warning lamp Fail-safe
Malfunctions detected where... Refer-
ence
page
Vehicle-
to-vehi-cle dis- tance
control mode Conven-
tional
(fixed
speed) cruise
control
mode Brake
assist
(with pre- view
function)
Page 51 of 3383
![INFINITI QX56 2006 Factory User Guide ACS-38
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
3. CHECK HARNESS BETWEEN ICC UNIT AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
1. Turn ignition switch O](/img/42/57028/w960_57028-50.png "INFINITI QX56 2006 Factory User Guide ACS-38
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
3. CHECK HARNESS BETWEEN ICC UNIT AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
1. Turn ignition switch O")
ACS-38
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
3. CHECK HARNESS BETWEEN ICC UNIT AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)
1. Turn ignition switch OFF.
2. Disconnect ICC unit and ABS actuator and electric unit (control
unit) connectors.
3. Check continuity between ICC unit harness connector B13 ter- minal 10, and ABS actuator and electric unit (control unit) con-
nector E125 terminal 7.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase
DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >>
Repair harness between ICC unit, and ABS actuator and electric unit (control unit).
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
DTC 20 CAN COMM CIRCUITEKS00BM2
1. CHECK CAN COMMUNICATION
With CONSULT-II
1. Perform self-diagnosis.
2. Print self-diagnostic result.
>> After printing self-diagnostic result, GO TO “CAN system”. Refer to LAN-3, "
Precautions When
Using CONSULT-II" .
DTC 31 POWER SUPPLY CIR1, DTC 34 POWER SUPPLY CIR2EKS00BM3
1. CHECK ICC UNIT CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect ICC unit connectors and connect them securely again. Erase DTC, then perform self-diagno- sis of ICC system again.
OK or NG
OK >> GO TO 2.
NG >>
Poor connector connection.
Check connector. Check connector housing for disconnected, loose, bent, and collapsed termi-
nals. If any malfunction is detected, repair as as necessary. Erase DTC and perform ICC sys-
tem running test. Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of
ICC system again.
2. CHECK POWER SUPPLY CIRCUIT FOR ICC UNIT
1. Turn ignition switch ON.
2. Check voltage between ICC unit harness connector B17 termi- nal 33, 42 and ground.
OK or NG
OK >> GO TO 3.
NG >>
Repair ICC unit power supply harness.
Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then
perform self-diagnosis of ICC system again.
Continuity should exist.
WKIA3616E
Battery voltage should exist.
SKIA1173E
Page 52 of 3383
![INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-39
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
3. CHECK GROUND CIRCUIT FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC](/img/42/57028/w960_57028-51.png "INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-39
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
3. CHECK GROUND CIRCUIT FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC")
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-39
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
3. CHECK GROUND CIRCUIT FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connectors.
3. Check continuity between ICC unit harness connector B13 ter- minals 19, 20, and connector B17 terminal 46 and ground.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase
DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-
diagnosis of ICC system again.
NG >>
Repair ICC unit ground harness.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
DTC 41 VHCL SPEED SE CIRCEKS00BM4
1. PERFORM ICC UNIT SELF-DIAGNOSIS
Perform self-diagnosis. Is “DTC 43 VDC/TCS/ABS CIRC ” or “DTC 20 CAN COMM CIRCUIT ” indicated in self-
diagnosis item display?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. CHECK A/T VEHICLE SPEED SENSOR
With CONSULT-II
With data monitor, check “VHCL SPD AT”.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >>
Check TCM.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
DTC 43 VDC/TCS/ABS CIRCEKS00BM5
1. DIAGNOSIS CHECK 1
With CONSULT-II
Perform self-diagnosis. Is “CAN COMM CIRCUIT” indicated?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NO >> GO TO 2.
2. DIAGNOSIS CHECK 2
With CONSULT-II
Perform self-diagnosis of ABS actuator and electric unit (control unit). Is malfunction indicated?
YES or NO
YES >> Repair or replace as necessary. Erase DTC and perform ICC system running test. Refer to ACS-
9, "ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NO >> Replace ICC unit. Refer to ACS-59, "
ICC Unit" . Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
Continuity should exist.
SKIA6650E
Page 53 of 3383
![INFINITI QX56 2006 Factory User Guide ACS-40
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
DTC 45 BRAKE SW/STOP L SWEKS00BM6
1. CHECK CONNECTORS FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect](/img/42/57028/w960_57028-52.png "INFINITI QX56 2006 Factory User Guide ACS-40
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
DTC 45 BRAKE SW/STOP L SWEKS00BM6
1. CHECK CONNECTORS FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect")
ACS-40
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
DTC 45 BRAKE SW/STOP L SWEKS00BM6
1. CHECK CONNECTORS FOR ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit connectors and connect them securely again. Erase DTC, then perform self-diagno- sis of ICC system again.
OK or NG
OK >>Poor connector connection.
Check connectors. Check connectors housing for disconnected, loose, bent, and collapsed ter-
minals. If any malfunction is detected, repair as necessary. Erase DTC and perform ICC system
running test. Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC
system again.
NG >> GO TO 2.
2. CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH
With CONSULT-II
With data monitor, check if “STOP LAMP SW” and “BRAKE SW ” are operating normally.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >>
BRAKE SW: GO TO 3.
STOP LAMP SW: GO TO 5.
3. ICC BRAKE SWITCH INSTALLATION AND ADJUSTMENT INSPECTION
Check ICC brake switch for proper installation and adjust if necessary. Refer to BR-6, "
BRAKE PEDAL" .
OK or NG
OK >> GO TO 4.
NG >> After adjustment, erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System
Running Test" . Then perform self-diagnosis of ICC system again.
4. CHECK ICC BRAKE SWITCH
Check ICC brake switch. Refer to ACS-58, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >> Replace ICC brake switch. Erase DTC and perform ICC system running test. Refer to ACS-9,
"ICC System Running Test" . Then perform self-diagnosis of ICC system again.
5. CHECK STOP LAMP ILLUMINATION
Check stop lamp illumination.
OK or NG
OK >> GO TO 6.
NG >>
Check stop lamp circuit. Refer to LT- 1 0 6 , "STOP LAMP" .
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
Page 54 of 3383
![INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-41
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
6. CHECK ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Remove ICC brake hold](/img/42/57028/w960_57028-53.png "INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-41
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
6. CHECK ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Remove ICC brake hold")
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-41
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
6. CHECK ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Remove ICC brake hold relay.
3. Check continuity between ICC brake hold relay terminals.
OK or NG
OK >> GO TO 7.
NG >> Replace ICC brake hold relay. Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System
Running Test" . Then perform self-diagnosis of ICC sys-
tem again.
7. CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Disconnect ICC unit and stop lamp switch connectors.
2. Check continuity between ICC unit harness connector B17 ter- minal 38 and ICC brake hold relay harness connector E134 ter-
minal 7.
3. Check continuity between ICC unit harness connector B17 ter- minal 38 and stop lamp switch harness connector E38 terminal
4.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase
DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test" . Then
perform self-diagnosis of ICC system again.
NG >>
Repair harness between ICC unit and ICC brake hold relay or stop lamp switch.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
DTC 46 OPERATION SW CIRCEKS00BM7
1. CHECK ECM CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect ECM connector and connect it securely again. Erase DTC, then perform self-diagnosis of ICC system again.
OK or NG
OK >>Poor connector connection.
Check connector. Check connector housing for disconnected, loose, bent, and collapsed termi-
nals. If any malfunction is detected, repair as as necessary. Erase DTC and perform ICC sys-
tem running test. Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of
ICC system again.
NG >> GO TO 2. 7 - 6 Continuity should not exist.
4 - 3 Continuity should exist.
SKIA6651E
Continuity should exist.
Continuity should exist.
WKIA3403E
Page 55 of 3383
![INFINITI QX56 2006 Factory User Guide ACS-42
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
2. CHECK ICC STEERING SWITCH
Check ICC steering switch. Refer to ACS-58, "
ICC Steering Switch" .
OK or NG
OK](/img/42/57028/w960_57028-54.png "INFINITI QX56 2006 Factory User Guide ACS-42
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
2. CHECK ICC STEERING SWITCH
Check ICC steering switch. Refer to ACS-58, \"
ICC Steering Switch\" .
OK or NG
OK")
ACS-42
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
2. CHECK ICC STEERING SWITCH
Check ICC steering switch. Refer to ACS-58, "
ICC Steering Switch" .
OK or NG
OK >> GO TO 3.
NG >> Replace ICC steering switch assembly. Refer to ACS-59, "
ICC Steering Switch" . Erase DTC and
perform ICC system running test. Refer to ACS-9, "
ICC System Running Test" . Then perform
self-diagnosis of ICC system again.
3. CHECK ICC STEERING SWITCH SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM and spiral cable connectors.
3. Check continuity between ECM harness connectors E16 and F54 terminals 67, 99 and spiral cable harness connector M30
terminals 33, 34.
OK or NG
OK >> GO TO 4.
NG >>
Repair harness between ECM and spiral cable.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
4. CHECK ICC STEERING SWITCH SIGNAL CIRCUIT
1. Disconnect remaining spiral cable connector.
2. Check continuity between spiral cable (A) (to vehicle) terminals 33, 34 and spiral cable (B) (to switch) terminals 14,15.
OK or NG
OK >> Replace ECM. Erase DTC and perform ICC system run- ning test. Refer to ACS-9, "
ICC System Running Test" .
Then perform self-diagnosis of ICC system again.
NG >>
Replace spiral cable. Refer to SRS-48, "Removal and
Installation" .
Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then
perform self-diagnosis of ICC system again.
DTC 74 LASER BEAM OFF CNTREKS00BM8
1. DIAGNOSTIC CHECK
1. Adjust laser beam aiming. Refer to ACS-12, "
LASER BEAM AIMING ADJUSTMENT" . Erase DTC and
perform ICC system running test. Refer to ACS-9, "
ICC System Running Test" .
2. Perform self-diagnosis of ICC system. Is DTC 74 LASER BEAM OFF CNTR indicated?
YES or NO
YES >>Replace ICC sensor and adjust laser beam aiming. Refer to ACS-59, "ICC Sensor" .
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
NO >> Inspection end. 67 - 33, 99 - 34
Continuity should exist.
WKIA1928E
34 - 14, 33 - 15Continuity should exist.
WKIA4572E
Page 56 of 3383
![INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-43
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
DTC 90 STOP LAMP RLY FIXEKS00BM9
1. CHECK ICC UNIT CONNECTOR
1. Turn ignition swit](/img/42/57028/w960_57028-55.png "INFINITI QX56 2006 Factory User Guide TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-43
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
DTC 90 STOP LAMP RLY FIXEKS00BM9
1. CHECK ICC UNIT CONNECTOR
1. Turn ignition swit")
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSACS-43
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
DTC 90 STOP LAMP RLY FIXEKS00BM9
1. CHECK ICC UNIT CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect and check ICC unit connector.
OK or NG
OK >> GO TO 2.
NG >>
Connector malfunction.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of system.
2. CHECK STOP LAMP SWITCH AND ICC BRAKE SWITCH
With CONSULT-II
1. Connect ICC unit connector and turn ignition switch ON.
2. With data monitor, check that “STOP LAMP SW” and “BRAKE SW ” operate normally.
OK or NG
OK >> GO TO 11.
NG >>
BRAKE SW: GO TO 3.
STOP LAMP SW: GO TO 8.
3. CHECK AND ADJUST ICC BRAKE SWITCH
Check ICC brake switch for proper installation and adjust if necessary. Refer to BR-6, "
BRAKE PEDAL" .
OK or NG
OK >> GO TO 4.
NG >> After adjustment, erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System
Running Test" . Then perform self-diagnosis of ICC system again.
4. CHECK ICC BRAKE SWITCH
Check ICC brake switch. Refer to ACS-58, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> GO TO 5.
NG >> Replace ICC brake switch. Erase DTC and perform ICC system running test. Refer to ACS-9,
"ICC System Running Test" . Then perform self-diagnosis of ICC system again.
5. CHECK ICC BRAKE HOLD RELAY
Disconnect ICC brake hold relay and check continuity between ICC
brake hold relay terminal 4 and terminal 3.
OK or NG
OK >> GO TO 6.
NG >> Replace ICC brake hold relay. Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System
Running Test" . Then perform self-diagnosis of ICC sys-
tem again.
Continuity should exist.
SKIA6658E
Page 57 of 3383
![INFINITI QX56 2006 Factory User Guide ACS-44
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
6. CHECK HARNESS THROUGH ICC BRAKE HOLD RELAY, ICC BRAKE SWITCH, ICC UNIT
1. Disconnect ECM and ICC unit harn](/img/42/57028/w960_57028-56.png "INFINITI QX56 2006 Factory User Guide ACS-44
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
6. CHECK HARNESS THROUGH ICC BRAKE HOLD RELAY, ICC BRAKE SWITCH, ICC UNIT
1. Disconnect ECM and ICC unit harn")
ACS-44
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
6. CHECK HARNESS THROUGH ICC BRAKE HOLD RELAY, ICC BRAKE SWITCH, ICC UNIT
1. Disconnect ECM and ICC unit harness connectors.
2. Check continuity between ICC brake hold relay harness connec- tor E134 terminal 4 and ICC unit harness connector B17 termi-
nal 29.
3. Check continuity between ICC unit harness connector B17 ter- minal 29 and ground.
OK or NG
OK >> GO TO 7.
NG >>
Repair harness between ICC brake hold relay and
ICC brake switch.
Repair harness between ICC brake switch and ICC unit.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
7. CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between ICC brake hold relay harness connector E134 terminal 3 and ground.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase
DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-
diagnosis of ICC system again.
NG >>
Check fuse or ICC brake hold relay power supply sys-
tem harness.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
8. CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF.
2. Check stop lamp switch. Refer to ACS-58, "
ICC Brake Switch and Stop Lamp Switch" .
OK or NG
OK >> GO TO 9.
NG >> Replace stop lamp switch. Erase DTC and perform ICC system running test. Refer to ACS-9,
"ICC System Running Test" . Then perform self-diagnosis of ICC system again.
9. CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Disconnect stop lamp switch connector.
2. When brake pedal is not depressed, make sure that stop lamp does not illuminate.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC system again.
NG >> GO TO 10. Continuity should exist.
Continuity should not exist.
WKIA1929E
Battery voltage should exist
WKIA3618E
Page 59 of 3383
![INFINITI QX56 2006 Factory User Guide ACS-46
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
13. CHECK ICC UNIT STANDARD VOLTAGE
With CONSULT-II
1. Connect connectors of ICC unit and stop lamp switch.](/img/42/57028/w960_57028-58.png "INFINITI QX56 2006 Factory User Guide ACS-46
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
13. CHECK ICC UNIT STANDARD VOLTAGE
With CONSULT-II
1. Connect connectors of ICC unit and stop lamp switch.")
ACS-46
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
13. CHECK ICC UNIT STANDARD VOLTAGE
With CONSULT-II
1. Connect connectors of ICC unit and stop lamp switch.
2. While performing active test (STOP LAMP: STP LMP DRIVE ON) with CONSULT-II, check voltage between ICC unit harness
connector B17 terminal 47 and ground.
OK or NG
OK >> GO TO 14.
NG >> Replace ICC unit. Refer to ACS-59, "
ICC Unit" . Erase
DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-
diagnosis of ICC system again.
14. CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
Check voltage between ICC brake hold relay harness connector
E134 terminal 6 and ground.
OK or NG
OK >> GO TO 15.
NG >>
Check fuse or ICC brake hold relay power supply har-
ness.
Erase DTC and perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test" . Then
perform self-diagnosis of ICC system again.
15. CHECK HARNESS BETWEEN ICC BRAKE HOLD RELAY AND ICC UNIT
1. Turn ignition switch OFF.
2. Disconnect ICC unit harness connectors.
3. Check continuity between ICC brake hold relay harness connec- tor E134 terminal 7 and ICC unit harness connector B17 termi-
nal 38.
4. Check continuity between ICC unit harness connector B17 ter- minal 38 (R/G) and ground.
OK or NG
OK >> GO TO 16.
NG >>
Repair harness between ICC brake hold relay and ICC unit or between ICC brake hold relay
and stop lamp switch.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
47 - Ground
Battery voltage should exist
(during active test)
SKIA3075E
6 - Ground Battery voltage should exist
WKIA1931E
7 - 38 Continuity should exist.
38 - Ground Continuity should not exist.
WKIA1932E
Page 61 of 3383
![INFINITI QX56 2006 Factory User Guide ACS-48
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
DTC 96 NP RANGEEKS00BMB
1. CHECK ICC UNIT CONNECTORS
1. Turn ignition switch OFF.
2. Disconnect ICC unit harne](/img/42/57028/w960_57028-60.png "INFINITI QX56 2006 Factory User Guide ACS-48
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
DTC 96 NP RANGEEKS00BMB
1. CHECK ICC UNIT CONNECTORS
1. Turn ignition switch OFF.
2. Disconnect ICC unit harne")
ACS-48
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: November 20092006 QX56
DTC 96 NP RANGEEKS00BMB
1. CHECK ICC UNIT CONNECTORS
1. Turn ignition switch OFF.
2. Disconnect ICC unit harness connectors and connect them securely again. Erase DTC, then perform self- diagnosis of ICC system again.
OK or NG
OK >> GO TO 2.
NG >>
Poor connector connection.
Check connector. Check connector housing for disconnected, loose, bent, and collapsed termi-
nals. If any malfunction is detected, repair as necessary. Erase DTC and perform ICC system
running test. Refer to ACS-9, "
ICC System Running Test" . Then perform self-diagnosis of ICC
system again.
2. CHECK NP RANGE SWITCH SIGNAL
With CONSULT-II
With data monitor, check that “NP RANGE SW ” operates normally.
OK or NG
OK >> Perform TCM diagnosis. Refer to AT- 8 6 , "SELF-DIAGNOSTIC RESULT MODE" .
NG >> GO TO 3.
3. CHECK HARNESS BETWEEN ICC UNIT AND TCM
1. Turn ignition switch OFF.
2. Disconnect ICC unit harness connectors and A/T assembly har- ness connector.
3. Check continuity between ICC unit harness connector B13 ter- minal 7 and A/T assembly harness connector F9 terminal 9.
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase
DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test" . Then perform self-
diagnosis of ICC system again.
NG >>
Repair harness between ICC unit and TCM.
Erase DTC and perform ICC system running test. Refer to ACS-9, "ICC System Running Test"
. Then perform self-diagnosis of ICC system again.
DTC 97 AT CIRCUITEKS00BMC
1. CHECK A/T CIRCUIT
With CONSULT-II
With TCM diagnosis, check that shift operates normally. Refer to AT- 1 0 5 , "
DTC P0705 PARK/NEUTRAL
POSITION SWITCH" .
OK or NG
OK >> Replace ICC unit. Refer to ACS-59, "ICC Unit" . Erase DTC and perform self-diagnosis of ICC
system again.
NG >>
Perform TCM diagnosis.
Erase DTC and perform self-diagnosis of ICC system again.
7 - 9 Continuity should exist.
SKIA5982E
