SQUEAK AND RATTLE TROUBLE DIAGNOSESEI-7
C
DE
F
G H
J
K L
M A
B
EI
Revision: November 2009 2006 QX56
80845-71L00: 30 mm (1.18 in) thick, 30×50 mm (1.18 ×1.97 in)
FELT CLOTH TAPE
Used to insulate where movement does not occur. Ideal for instrument panel applications.
68370-4B000: 15× 25 mm (0.59×0.98 in) pad/68239-13E00: 5 mm (0.20 in) wide tape roll. The following
materials not found in the kit can also be used to repair squeaks and rattles.
UHMW (TEFLON) TAPE
Insulates where slight movement is present. Ideal for instrument panel applications.
SILICONE GREASE
Used instead of UHMW tape that will be visible or not fit.
Note: Will only last a few months.
SILICONE SPRAY
Use when grease cannot be applied.
DUCT TAPE
Use to eliminate movement.
CONFIRM THE REPAIR
Confirm that the cause of a noise is repaired by test driving the vehicle. Operate the vehicle under the same
conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
Generic Squeak and Rattle TroubleshootingEIS0062W
Refer to Table of Contents for specific component removal and installation information.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between:
1. The cluster lid A and instrument panel
2. Acrylic lens and combination meter housing
3. Instrument panel to front pillar garnish
4. Instrument panel to windshield
5. Instrument panel pins
6. Wiring harnesses behind the combination meter
7. A/C defroster duct and duct joint
These incidents can usually be located by tapping or moving the components to duplicate the noise or by
pressing on the components while driving to stop the noise. Most of these incidents can be repaired by apply-
ing felt cloth tape or silicone spray (in hard to reach areas). Urethane pads can be used to insulate wiring har-
ness.
CAUTION:
Do not use silicone spray to isolate a squeak or rattle. If you saturate the area with silicone, you will
not be able to recheck the repair.
CENTER CONSOLE
Components to pay attention to include:
1. Shifter assembly cover to finisher
2. A/C control unit and cluster lid C
3. Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Pay attention to the:
1. Finisher and inner panel making a slapping noise
2. Inside handle escutcheon to door finisher
3. Wiring harnesses tapping
4. Door striker out of alignment causing a popping noise on starts and stops
Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate
many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks from
the NISSAN Squeak and Rattle Kit (J-43980) to repair the noise.
Page 1857 of 3383
EI-8
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Revision: November 20092006 QX56
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for:
1. Trunk lid bumpers out of adjustment
2. Trunk lid striker out of adjustment
3. The trunk lid torsion bars knocking together
4. A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) caus-
ing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following:
1. Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
2. Sun visor shaft shaking in the holder
3. Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these
incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of
these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for:
1. Loose harness or harness connectors.
2. Front console map/reading lamp lens loose.
3. Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when
the noise is present. These conditions should be duplicated when verifying and isolating the cause of the
noise.
Cause of seat noise include:
1. Headrest rods and holder
2. A squeak between the seat pad cushion and frame
3. The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the con-
ditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component
or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then
transmitted into the passenger compartment.
Causes of transmitted underhood noise include:
1. Any component installed to the engine wall
2. Components that pass through the engine wall
3. Engine wall mounts and connectors
4. Loose radiator installation pins
5. Hood bumpers out of adjustment
6. Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best
method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM
or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or
insulating the component causing the noise.
Page 1881 of 3383
EI-32
DOOR FINISHER
Revision: November 20092006 QX56
DOOR FINISHERPFP:80900
Removal and InstallationEIS004WQ
Front Door
REMOVAL
1. Disconnect the negative battery cable.
2. Remove power window switch assembly.
Disconnect harness connectors.
3. Remove pull handle cover.
Remove screws behind pull handle cover.
4. Remove cap from pull handle escutcheon and remove screw.
5. Remove pull handle escutcheon.
Remove screws behind pull handle escutcheon.
6. Remove armrest.
WIIA0965E
1. Power window switch assembly 2. Armrest 3. Front door finisher LH
4. Pull handle cover 5. Pull handle escutcheon 6. Cap
7. Door lock knob 8. Step lamp 9. Seat memory switch
Page 1882 of 3383
DOOR FINISHEREI-33
C
DE
F
G H
J
K L
M A
B
EI
Revision: November 2009 2006 QX56
Remove screw behind armrest.
7. Remove memory seat switch.
Disconnect harness connector.
8. Remove step lamp.
Disconnect harness connector.
9. Remove door finisher and disconnect lock cable and handle cable from door handle assembly. Refer to BL-131, "
FRONT DOOR LOCK" .
10. Remove door lock knob.
INSTALLATION
Installation is in the reverse order of removal.
Rear Door
REMOVAL
1. Disconnect the negative battery cable.
2. Remove power window switch assembly.
WIIA0966E
1. Power window switch assembly 2. Armrest 3. Rear door finisher LH
4. Pull handle cover 5. Cap6. Pull handle escutcheon
7. Door lock knob 8. Step lamp9. Rear door tweeter
Page 1883 of 3383
EI-34
DOOR FINISHER
Revision: November 20092006 QX56
Disconnect harness connector.
3. Remove pull handle cover.
Remove screws behind pull handle cover.
4. Remove cap from pull handle escutcheon and remove screw.
5. Remove pull handle escutcheon.
Remove screws behind pull handle escutcheon.
6. Remove armrest.
Remove screws behind armrest.
7. Remove step lamp.
Disconnect harness connector.
8. Remove door finisher and disconnect lock cable and handle cable from door handle assembly. Refer to BL-134, "
REAR DOOR LOCK" .
9. Remove door lock knob.
10. Remove rear door tweeter.
INSTALLATION
Installation is in the reverse order of removal.
Page 1890 of 3383
LUGGAGE FLOOR TRIMEI-41
C
DE
F
G H
J
K L
M A
B
EI
Revision: November 2009 2006 QX56
REMOVAL
1. Remove 2nd and 3rd row seat belts. Refer to SB-3, "SEAT BELTS" .
2. Remove third row seat belt buckles.
3. Remove third row seat assembly. Refer to SE-105, "
THIRD SEAT" .
4. Remove back door weatherstrip. Refer to EI-42, "
BACK DOOR TRIM" .
5. Remove rear luggage room lamp. Refer to EI-38, "
HEADLINING" .
Disconnect harness from lamp.
6. Remove rear upper finisher. Refer to EI-38, "
HEADLINING" .
7. Remove rear door kicking plates. Refer to EI-35, "
BODY SIDE TRIM" .
8. Remove rear lower finisher.
9. Disconnect door open/close link. Refer to BL-135, "
BACK DOOR LOCK" .
10. Remove cargo net hooks.
11. Remove luggage side lower finishers LH/RH.
Disconnect power point, RH side.
12. Remove coat hooks.
13. Remove luggage side upper finishers LH/RH.
Disconnect harness to door open/close switch, LH side.
14. Remove tie down hooks LH/RH.
15. Remove floor side finishers LH/RH.
16. Remove luggage floor board.
17. Remove storage box.
18. Remove front luggage floor bracket.
19. Remove rear luggage box bracket.
INSTALLATION
Installation is in the reverse order of removal.
1. Rear lower finisher cap 2. Rear lower finisher3. Cap upper seat belt finisher RH
4. Luggage side finisher RH 5. Metal clip6. Plastic clip
7. Luggage side finisher lower RH 8. Luggage floor board 9. Latch luggage floor board
10. Leak check cap 11. Cup holder12. Tie down hook
13. Floor side finisher RH 14. Power point assembly 15. Cargo net hook
16. Rear luggage box bracket 17. Front luggage floor bracket 18. Storage box
19. Floor side finisher LH 20. Luggage side finisher upper LH 21. Luggage side finisher lower LH
22. Lid luggage side lower 23. Coat hook24. Cap lower seat belt finisher
25. Back door open/close switch 26. Cap luggage side upper 27. Cap upper seat belt finisher LH
Page 1891 of 3383
EI-42
BACK DOOR TRIM
Revision: November 20092006 QX56
BACK DOOR TRIMPFP:90900
Removal and InstallationEIS004WV
REMOVAL
1. Disconnect door open/close link. Refer to BL-135, "BACK DOOR LOCK" .
2. Open back door glass.
3. Remove inside weatherstrip around back door glass.
4. Remove assist handle.
5. Release clips and remove back door lower finisher.
6. Release clips and remove back door upper finisher.
7. Release clips and remove back door side finishers LH and RH.
Installation is in the reverse order of removal.
1. Back door upper finisher 2. Back door glass weatherstrip 3. Back door side finisher RH
4. Back door lower finisher 5. Back door bumper 6. Back door pull handle
7. Back door mask 8. Back door side finisher LH
WIIA0971E
Page 1893 of 3383
EM-2Revision: November 20092006 QX56
TIMING CHAIN .......................................................
... 37
Removal and Installation ..................................... ... 37
REMOVAL ........................................................ ... 38
INSPECTION AFTER REMOVAL ..................... ... 40
INSTALLATION ................................................. ... 41
CAMSHAFT ............................................................ ... 46
Removal and Installation ..................................... ... 46
REMOVAL ........................................................ ... 46
INSPECTION AFTER REMOVAL ..................... ... 50
INSTALLATION ................................................. ... 52
Valve Clearance ................................................... ... 55
INSPECTION .................................................... ... 55
ADJUSTMENT ................................................. ... 58
OIL SEAL ............................................................... ... 60
Removal and Installation of Valve Oil Seal .......... ... 60
REMOVAL ........................................................ ... 60
INSTALLATION ................................................. ... 60
Removal and Installation of Front Oil Seal .......... ... 61
REMOVAL ........................................................ ... 61
INSTALLATION ................................................. ... 61
Removal and Installation of Rear Oil Seal ........... ... 61
REMOVAL ........................................................ ... 61
INSTALLATION ................................................. ... 62
CYLINDER HEAD .................................................. ... 63
On-Vehicle Service .............................................. ... 63
CHECKING COMPRESSION PRESSURE ......... 63
Removal and Installation ..................................... ... 64
REMOVAL ........................................................ ... 64
INSPECTION AFTER REMOVAL ..................... ... 65
INSTALLATION ................................................. ... 65
Disassembly and Assembly ................................. ... 66
DISASSEMBLY ................................................ ... 66
ASSEMBLY ...................................................... ... 67
Inspection After Disassembly .............................. ... 68
CYLINDER HEAD DISTORTION ..................... ... 68
VALVE DIMENSIONS ....................................... ... 69
VALVE GUIDE CLEARANCE ........................... ... 69
VALVE GUIDE REPLACEMENT ...................... ... 70
VALVE SEAT CONTACT .................................. ... 71
VALVE SEAT REPLACEMENT ........................ ... 71
VALVE SPRING SQUARENESS ...................... ... 73
VALVE SPRING DIMENSIONS AND VALVE
SPRING PRESSURE LOAD ............................ ... 73
ENGINE ASSEMBLY ................................................ 74 Removal and Installation ..................................... ... 74
REMOVAL ........................................................ ... 74
INSTALLATION ................................................. ... 76
INSPECTION AFTER INSTALLATION ............. ... 76CYLINDER BLOCK ................................................
... 78
Disassembly and Assembly ................................. ... 78
DISASSEMBLY ................................................. ... 79
ASSEMBLY ....................................................... ... 82
How to Select Piston and Bearing ....................... ... 87
DESCRIPTION ................................................. ... 87
HOW TO SELECT PISTON .............................. ... 87
HOW TO SELECT CONNECTING ROD BEAR-
ING .................................................................... ... 88
HOW TO SELECT MAIN BEARING ................. ... 90
Inspection After Disassembly ............................... ... 94
CRANKSHAFT END PLAY ............................... ... 94
CONNECTING ROD SIDE CLEARANCE ........ ... 94
PISTON AND PISTON PIN CLEARANCE ........ ... 94
PISTON RING SIDE CLEARANCE .................. ... 95
PISTON RING END GAP ................................. ... 95
CONNECTING ROD BEND AND TORSION .... ... 96
CONNECTING ROD BEARING (BIG END) ..... ... 96
CONNECTING ROD BUSHING OIL CLEAR-
ANCE (SMALL END) ........................................ ... 96
CYLINDER BLOCK DISTORTION ................... ... 97
MAIN BEARING HOUSING INSIDE DIAMETER ... 98
PISTON TO CYLINDER BORE CLEARANCE . ... 98
CRANKSHAFT JOURNAL DIAMETER ............ ... 99
CRANKSHAFT PIN DIAMETER ....................... .100
OUT-OF-ROUND AND TAPER OF CRANK-
SHAFT .............................................................. .100
CRANKSHAFT RUNOUT ................................. .100
CONNECTING ROD BEARING OIL CLEAR-
ANCE ................................................................ .100
MAIN BEARING OIL CLEARANCE .................. .101
CRUSH HEIGHT OF MAIN BEARING ............. .102
CRUSH HEIGHT OF CONNECTING ROD
BEARING .......................................................... .102
MAIN BEARING CAP BOLT DIAMETER .......... .102
CONNECTING ROD BOLT DIAMETER ........... .103
SERVICE DATA AND SPECIFICATIONS (SDS) ... .104
Standard and Limit ............................................... .104
GENERAL SPECIFICATIONS .......................... .104
DRIVE BELTS ................................................... .104
EXHAUST MANIFOLD ..................................... .104
CAMSHAFT AND CAMSHAFT BEARING ........ .105
CYLINDER HEAD ............................................. .107
CYLINDER BLOCK ........................................... .109
PISTON, PISTON RING AND PISTON PIN ..... .110
CONNECTING ROD ......................................... .110
CRANKSHAFT .................................................. . 111
MAIN BEARING ................................................ .112
Page 1894 of 3383
PRECAUTIONSEM-3
C
DE
F
G H
I
J
K L
M A
EM
Revision: November 2009 2006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EBS00REI
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Drain Engine CoolantEBS00REJ
Drain engine coolant when engine is cooled.
Precautions for Disconnecting Fuel PipingEBS00REK
Before starting work, make sure no fire or spark producing items are in the work area.
Release fuel pressure before disconnecting and disassembly.
After disconnecting pipes, plug openings to stop fuel leakage.
Precautions for Removal and DisassemblyEBS00REL
When instructed to use special service tools, use the specified tools. Always be careful to work safely,
avoid forceful or uninstructed operations.
Exercise maximum care to avoid damage to mating or sliding surfaces.
Cover openings of engine system with tape or the equivalent, if necessary, to seal out foreign materials.
Mark and arrange disassembly parts in an organized way for easy troubleshooting and assembly.
When loosening nuts and bolts, as a basic rule, start with the one furthest outside, then the one diagonally
opposite, and so on. If the order of loosening is specified, do exactly as specified. Power tools may be
used where noted in the step.
Precautions for Inspection, Repair and ReplacementEBS00REM
Before repairing or replacing, thoroughly inspect parts. Inspect new replacement parts in the same way, and
replace if necessary.
Precautions for Assembly and InstallationEBS00REN
Use torque wrench to tighten bolts or nuts to specification.
When tightening nuts and bolts, as a basic rule, equally tighten in several different steps starting with the
ones in center, then ones on inside and outside diagonally in this order. If the order of tightening is speci-
fied, do exactly as specified.
Replace with new gasket, packing, oil seal or O-ring.
Thoroughly wash, clean, and air-blow each part. Carefully check engine oil or engine coolant passages for
any restriction and blockage.
Avoid damaging sliding or mating surfaces. Completely remove foreign materials such as cloth lint or dust.
Before assembly, oil sliding surfaces well.
Release air within route when refilling after draining engine coolant.
Page 1902 of 3383
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTINGEM-11
C
DE
F
G H
I
J
K L
M A
EM
Revision: November 2009 2006 QX56
Use the Chart Below to Help You Find the Cause of the Symptom.EBS00RET
1. Locate the area where noise occurs.
2. Confirm the type of noise.
3. Specify the operating condition of engine.
4. Check specified noise source.
If necessary, repair or replace these parts.
A: Closely related B: Related C: Sometimes related—: Not related
Location of
noise Type of
noise Operating condition of engine
Source of noise Check item Refer-
ence page
Before
warm- up After
warm- up When
start- ing When
idling When
racing While
driv- ing
Top of
engine
Rocker
cover
Cylinder
head Ticking or
clicking
CA
—AB —Tappet noise Valve clearance EM-69
Rattle C A—ABC Camshaft
bearing noiseCamshaft journal clear-
ance
Camshaft runout EM-50EM-50
Crankshaft
pulley
Cylinder
block (Side
of engine)
Oil panSlap or
knock
—
A— BB —Piston pin
noise Piston and piston pin
clearance
Connecting rod bush-
ing clearance EM-95
EM-97
Slap or
rap
A
—— BBA Piston slap
noisePiston-to-bore clear-
ance
Piston ring side clear-
ance
Piston ring end gap
Connecting rod bend
and torsion EM-99EM-95
EM-95
EM-96
Knock A B C B B B
Connecting
rod bearing
noiseConnecting rod bush-
ing oil clearance (Small
end)
Connecting rod bear-
ing clearance (Big end)
EM-97EM-96
Knock A B
—ABC Main bearing
noiseMain bearing oil clear-
ance
Crankshaft runout EM-101EM-100
Front of
engine
Chain case
cover
Front coverTapping
or ticking
AA
—BBB Timing chain
and chain
tensioner
noiseTiming chain cracks
and wear
Timing chain tensioner
operation
EM-40
EM-37
Front of
engineSqueak-
ing or
fizzing
AB
—B— CDrive belts
(Sticking or
slipping) Drive belts deflection
EM-13
Creaking A B A B A B Drive belts
(Slipping)Idler pulley bearing
operation
Squall
Creaking AB
—BAB Water pump
noiseWater pump operation CO-19,
"INSPEC-
TION
AFTER
REMOVA
L"
