ELECTRICAL COMPONENT INSPECTION
Revision: November 20092006 QX56
ELECTRICAL COMPONENT INSPECTIONPFP:00000
ICC Steering SwitchEKS00BMS
1. Disconnect ICC steering switch.
2. Check resistance between terminals 14 and 15 while depressing
each switch.
ICC Brake Switch and Stop Lamp SwitchEKS00BMT
Check each switch after adjusting brake pedal. Refer to BR-6,
"BRAKE PEDAL" .
Parking Brake SwitchEKS00BMU
ICC Steering Switch (A) ConditionResistance [
Ω]
(Approx.)
ON/OFF Depressed 0
Released 5,456
DISTANCE Depressed 741
Released 5,456
ACCEL/RES Depressed 2,586
Released 5,456
COAST/SET Depressed 1,406
Released 5,456
CANCEL Depressed 309
Released 5,456
WKIA4573E
Continuity
ICC brake switch Stop lamp switch
When brake pedal is depressed No Yes
When brake pedal is released Yes No
WKIA3405E
Continuity to ground
Parking brake pedal depressed Yes
Parking brake pedal released No
WKIA1918E

REMOVAL AND INSTALLATIONACS-59
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
REMOVAL AND INSTALLATIONPFP:00000
ICC UnitEKS00BMV
ICC SensorEKS00BMW
CAUTION:
Perform the laser beam aiming procedure every time the ICC sensor is removed or installed. Refer to
ACS-12, "
LASER BEAM AIMING ADJUSTMENT" .
ICC Steering SwitchEKS00BMX
Replace ICC steering switch as switch kit assembly. Refer to AV- 5 9 , "STEERING WHEEL AUDIO CONTROL
SWITCHES" .
1. Rear inner side panel LH (shown
with finisher removed) 2. ICC unit harness connector 3. ICC unit
⇐ Vehicle front
WKIA4607E
1. ICC sensor bracket 2. ICC frame bracket3. ICC sensor
4. Frame side rail ⇐Vehicle front
WKIA4608E

ACS-60
[ICC]
REMOVAL AND INSTALLATION
Revision: November 20092006 QX56

AP-1
ADJUSTABLE PEDAL
I BODY
CONTENTS
C
DE
F
G H
J
K L
M
SECTION
A
B
AP
Revision: November 2009 2006 QX56
ADJUSTABLE PEDAL SYSTEM ..........................
..... 2
Adjustable Pedal ................................................. ..... 2

AP-2
ADJUSTABLE PEDAL SYSTEM
Revision: November 20092006 QX56
ADJUSTABLE PEDAL SYSTEMPFP:98800
Adjustable PedalEIS005XL
For adjustable pedal information, refer to SE-11, "AUTOMATIC DRIVE POSITIONER" .
