DTC INFINITI QX56 2007 Factory Service Manual

INDEX FOR DTC
EC-11
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P OP0448 0448 VENT CONTROL VALVEEC-386
P0451 0451 EVAP SYS PRES SENEC-392
P0452 0452 EVAP SYS PRES SENEC-395
P0453 0453 EVAP SYS PRES SENEC-401
P0455 0455 EVAP GROSS LEAKEC-408
P0456 0456 EVAP VERY SML LEAKEC-415
P0460 0460 FUEL LEV SEN SLOSHEC-423
P0461 0461 FUEL LEVEL SENSOREC-425
P0462 0462 FUEL LEVL SEN/CIRCEC-427
P0463 0463 FUEL LEVL SEN/CIRCEC-427
P0500 0500
VEH SPEED SEN/CIRC*5EC-429
P0506 0506 ISC SYSTEMEC-431
P0507 0507 ISC SYSTEMEC-433
P0550 0550 PW ST P SEN/CIRCEC-435
P0603 0603 ECM BACK UP/CIRCUITEC-440
P0605 0605 ECMEC-444
P0643 0643 SENSOR POWER/CIRCEC-447
P0700 0700 TCMAT- 9 8
P0705 0705 PNP SW/CIRCAT- 9 9
P0710 0710 ATF TEMP SEN/CIRCAT- 11 9
P0720 0720
VEH SPD SEN/CIR AT*5AT- 1 0 5
P0740 0740 TCC SOLENOID/CIRCAT- 111
P0744 0744 A/T TCC S/V FNCTNAT- 11 3
P0745 0745 L/PRESS SOL/CIRCAT- 11 5
P0850 0850 P-N POS SW/CIRCUITEC-452
P1140 1140 INTK TIM S/CIRC-B1EC-457
P1145 1145 INTK TIM S/CIRC-B2EC-457
P1148 1148 CLOSED LOOP-B1EC-466
P1168 1168 CLOSED LOOP-B2EC-466
P1211 1211 TCS C/U FUNCTNEC-467
P1212 1212 TCS/CIRCEC-468
P1217 1217 ENG OVER TEMPEC-469
P1225 1225 CTP LEARNINGEC-477
P1226 1226 CTP LEARNINGEC-479
P1421 1421 COLD START CONTROLEC-481
P1550 1550 BAT CURRENT SENSOREC-483
P1551 1551 BAT CURRENT SENSOREC-489
P1552 1552 BAT CURRENT SENSOREC-489
P1553 1553 BAT CURRENT SENSOREC-495
P1554 1554 BAT CURRENT SENSOREC-501
P1564 1564 ASCD SWEC-507 (Models with ICC)
EC-513
(Models with ASCD) DTC*
1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3

EC-12
< SERVICE INFORMATION >
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: 2WD models
*7: Models with ICC
Alphabetical IndexINFOID:0000000003531579
NOTE:
•If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-145
.
P1568 1568
ICC COMMAND VALUE*7EC-519
P1572 1572 ASCD BRAKE SWEC-520 (Models with ICC)
EC-528
(Models with ASCD)
P1574 1574
ASCD VHL SPD SEN*
6EC-535 (Models with ICC)
EC-537
(Models with ASCD)
P1610 - P1615 1610 - 1615 NATS MALFUNCTIONBL-116
P1710 1710 ATF TEMP SEN/CIRCAT- 11 9
P1730 1730 A/T INTERLOCKAT- 1 2 6
P1752 1752 I/C SOLENOID/CIRCAT- 1 3 0
P1754 1754 I/C SOLENOID FNCTNAT- 1 3 2
P1757 1757 FR/B SOLENOID/CIRCAT- 1 3 4
P1759 1759 FR/B SOLENOID FNCTAT- 1 3 6
P1762 1762 D/C SOLENOID/CIRCAT- 1 3 8
P1764 1764 D/C SOLENOID FNCTNAT- 1 4 0
P1767 1767 HLR/C SOL/CIRCAT- 1 4 2
P1769 1769 HLR/C SOL FNCTNAT- 1 4 4
P1772 1772 LC/B SOLENOID/CIRCAT- 1 4 6
P1774 1774 LC/B SOLENOID FNCTAT- 1 4 8
P1805 1805 BRAKE SW/CIRCUITEC-539
P2100 2100 ETC MOT PWREC-543
P2101 2101 ETC FUNCTION/CIRCEC-548
P2103 2103 ETC MOT PWREC-543
P2118 2118 ETC MOTEC-554
P2119 2119 ETC ACTREC-559
P2122 2122 APP SEN 1/CIRCEC-561
P2123 2123 APP SEN 1/CIRCEC-561
P2127 2127 APP SEN 2/CIRCEC-567
P2128 2128 APP SEN 2/CIRCEC-567
P2135 2135 TP SENSOREC-574
P2138 2138 APP SENSOREC-581
P2A00 2A00 A/F SENSOR1 (B1)EC-588
P2A03 2A03 A/F SENSOR1 (B2)EC-588
DTC*1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC
EC-13
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
•If DTC U1010 is displayed with other DTC, first perform the trouble diagnosis for DTC U1010. Refer to
EC-147
.
Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3
A/F SEN1 HTR (B1) P0031 0031EC-163
A/F SEN1 HTR (B1) P0032 0032EC-163
A/F SEN1 HTR (B2) P0051 0051EC-163
A/F SEN1 HTR (B2) P0052 0052EC-163
A/F SENSOR1 (B1) P0130 0130EC-225
A/F SENSOR1 (B1) P0131 0131EC-234
A/F SENSOR1 (B1) P0132 0132EC-242
A/F SENSOR1 (B1) P0133 0133EC-250
A/F SENSOR1 (B1) P2A00 2A00EC-588
A/F SENSOR1 (B2) P0150 0150EC-225
A/F SENSOR1 (B2) P0151 0151EC-234
A/F SENSOR1 (B2) P0152 0152EC-242
A/F SENSOR1 (B2) P0153 0153EC-250
A/F SENSOR1 (B2) P2A03 2A03EC-588
A/T INTERLOCK P1730 1730AT- 1 2 6
A/T TCC S/V FNCTN P0744 0744AT- 11 3
APP SEN 1/CIRC P2122 2122EC-561
APP SEN 1/CIRC P2123 2123EC-561
APP SEN 2/CIRC P2127 2127EC-567
APP SEN 2/CIRC P2128 2128EC-567
APP SENSOR P2138 2138EC-581
ASCD BRAKE SW P1572 1572EC-520 (Models with ICC)
EC-528
(Models with ASCD)
ASCD SW P1564 1564EC-507
(Models with ICC)
EC-513
(Models with ASCD)
ASCD VHL SPD SEN*
6P1574 1574EC-535 (Models with ICC)
EC-537
(Models with ASCD)
BAT CURRENT SENSOR P1550 1550EC-483
BAT CURRENT SENSOR P1551 1551EC-489
BAT CURRENT SENSOR P1552 1552EC-489
BAT CURRENT SENSOR P1553 1553EC-495
BAT CURRENT SENSOR P1554 1554EC-501
ATF TEMP SEN/CIRC P0710 0710AT- 11 9
BRAKE SW/CIRCUIT P1805 1805EC-539
CAN COMM CIRCUIT U1000
1000*4EC-145
CAN COMM CIRCUIT U1001
1001*4EC-145
CKP SEN/CIRCUIT P0335 0335EC-336
CLOSED LOOP-B1 P1148 1148EC-466
CLOSED LOOP-B2 P1168 1168EC-466
CMP SEN/CIRC-B1 P0340 0340EC-342
COLD START CONTROL P1421 1421EC-481

EC-14
< SERVICE INFORMATION >
INDEX FOR DTC
CONTROL UNIT(CAN) U1010 1010EC-147
CTP LEARNING P1225 1225EC-477
CTP LEARNING P1226 1226EC-479
CYL 1 MISFIRE P0301 0301EC-325
CYL 2 MISFIRE P0302 0302EC-325
CYL 3 MISFIRE P0303 0303EC-325
CYL 4 MISFIRE P0304 0304EC-325
CYL 5 MISFIRE P0305 0305EC-325
CYL 6 MISFIRE P0306 0306EC-325
CYL 7 MISFIRE P0307 0307EC-325
CYL 8 MISFIRE P0308 0308EC-325
D/C SOLENOID FNCTN P1764 1764AT- 1 4 0
D/C SOLENOID/CIRC P1762 1762AT- 1 3 8
ECM P0605 0605EC-444
ECM BACK UP/CIRCUIT P0603 0603EC-440
ECT SEN/CIRC P0117 0117EC-205
ECT SEN/CIRC P0118 0118EC-205
ECT SENSOR P0125 0125EC-217
ENG OVER TEMP P1217 1217EC-469
ETC ACTR P2119 2119EC-559
ETC FUNCTION/CIRC P2101 2101EC-548
ETC MOT P2118 2118EC-554
ETC MOT PWR P2100 2100EC-543
ETC MOT PWR P2103 2103EC-543
EVAP GROSS LEAK P0455 0455EC-408
EVAP PURG FLOW/MON P0441 0441EC-354
EVAP SMALL LEAK P0442 0442EC-359
EVAP SYS PRES SEN P0451 0451EC-392
EVAP SYS PRES SEN P0452 0452EC-395
EVAP SYS PRES SEN P0453 0453EC-401
EVAP VERY SML LEAK P0456 0456EC-415
FR/B SOLENOID FNCT P1759 1759AT- 1 3 6
FR/B SOLENOID/CIRC P1757 1757AT- 1 3 4
FTT SEN/CIRCUIT P0182 0182EC-314
FTT SEN/CIRCUIT P0183 0183EC-314
FTT SENSOR P0181 0181EC-310
FUEL LEV SEN SLOSH P0460 0460EC-423
FUEL LEVEL SENSOR P0461 0461EC-425
FUEL LEVL SEN/CIRC P0462 0462EC-427
FUEL LEVL SEN/CIRC P0463 0463EC-427
FUEL SYS-LEAN-B1 P0171 0171EC-292
FUEL SYS-LEAN-B2 P0174 0174EC-292
Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC
EC-15
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P OFUEL SYS-RICH-B1 P0172 0172EC-301
FUEL SYS-RICH-B2 P0175 0175EC-301
HLR/C SOL FNCTN P1769 1769AT- 1 4 4
HLR/C SOL/CIRC P1767 1767AT- 1 4 2
HO2S2 (B1) P0137 0137EC-260
HO2S2 (B1) P0138 0138EC-270
HO2S2 (B1) P0139 0139EC-282
HO2S2 (B2) P0157 0157EC-260
HO2S2 (B2) P0158 0158EC-270
HO2S2 (B2) P0159 0159EC-282
HO2S2 HTR (B1) P0037 0037EC-170
HO2S2 HTR (B1) P0038 0038EC-170
HO2S2 HTR (B2) P0057 0057EC-170
HO2S2 HTR (B2) P0058 0058EC-170
I/C SOLENOID FNCTN P1754 1754AT- 1 3 2
I/C SOLENOID/CIRC P1752 1752AT- 1 3 0
IAT SEN/CIRCUIT P0112 0112EC-201
IAT SEN/CIRCUIT P0113 0113EC-201
IAT SENSOR P0127 0127EC-220
ICC COMMAND VALUE*7P1568 1568EC-519
INT/V TIM CONT-B1 P0011 0011EC-149
INT/V TIM CONT-B2 P0021 0021EC-149
INT/V TIM V/CIR-B1 P0075 0075EC-178
INT/V TIM V/CIR-B2 P0081 0081EC-178
INTK TIM S/CIRC-B1 P1140 1140EC-457
INTK TIM S/CIRC-B2 P1145 1145EC-457
ISC SYSTEM P0506 0506EC-431
ISC SYSTEM P0507 0507EC-433
KNOCK SEN/CIRC-B1 P0327 0327EC-332
KNOCK SEN/CIRC-B1 P0328 0328EC-332
KNOCK SEN/CIRC-B2 P0332 0332EC-332
KNOCK SEN/CIRC-B2 P0333 0333EC-332
L/PRESS SOL/CIRC P0745 0745AT- 11 5
LC/B SOLENOID FNCT P1774 1774AT- 1 4 8
LC/B SOLENOID/CIRC P1772 1772AT- 1 4 6
MAF SEN/CIRCUIT P0101 0101EC-186
MAF SEN/CIRCUIT P0102 0102EC-194
MAF SEN/CIRCUIT P0103 0103EC-194
MULTI CYL MISFIRE P0300 0300EC-325
NATS MALFUNCTION P1610 - P1615 1610 - 1615BL-116
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000 — Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

EC-16
< SERVICE INFORMATION >
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur, the MIL illuminates.
*6: 2WD models
*7: Models with ICCP-N POS SW/CIRCUIT P0850 0850EC-452
PNP SW/CIRC P0705 0705AT- 9 9
PURG VOLUME CONT/V P0443 0443EC-366
PURG VOLUME CONT/V P0444 0444EC-373
PURG VOLUME CONT/V P0445 0445EC-373
PW ST P SEN/CIRC P0550 0550EC-435
SENSOR POWER/CIRC P0643 0643EC-447
TCC SOLENOID/CIRC P0740 0740AT- 111
TCM P0700 0700AT- 9 8
TCS C/U FUNCTN P1211 1211EC-467
TCS/CIRC P1212 1212EC-468
THERMSTAT FNCTN P0128 0128EC-223
TP SEN 1/CIRC P0222 0222EC-318
TP SEN 1/CIRC P0223 0223EC-318
TP SEN 2/CIRC P0122 0122EC-210
TP SEN 2/CIRC P0123 0123EC-210
TP SENSOR P2135 2135EC-574
TW CATALYST SYS-B1 P0420 0420EC-349
TW CATALYST SYS-B2 P0430 0430EC-349
VEH SPD SEN/CIR AT*5P0720 0720AT- 1 0 5
VEH SPEED SEN/CIRC*5P0500 0500EC-429
VENT CONTROL VALVE P0447 0447EC-379
VENT CONTROL VALVE P0448 0448EC-386
Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

PRECAUTIONS
EC-19
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
•After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.
•When measuring ECM signals with a circuit tester, never allow
the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
•Do not use ECM ground terminals when measuring input/out-
put voltage. Doing so may result in damage to the ECM's tran-
sistor. Use a ground other than ECM terminals, such as the
ground.
•B1 indicates the bank 1, B2 indicates the bank 2 as shown in
the figure.
SEF217U
SEF348N
PBIB1144E

EC-48
< SERVICE INFORMATION >
ON BOARD DIAGNOSTIC (OBD) SYSTEM
ON BOARD DIAGNOSTIC (OBD) SYSTEM
IntroductionINFOID:0000000003531604
The ECM has an on board diagnostic system, which detects malfunctions related to engine sensors or actua-
tors. The ECM also records various emission-related diagnostic information including:
The above information can be checked using procedures listed in the table below.
×: Applicable —: Not applicable
*: When DTC and 1st trip DTC simultaneously appear on the display, they cannot be clearly distinguished from each other.
The malfunction indicator lamp (MIL) on the instrument panel lights up when the same malfunction is detected
in two consecutive trips (Two trip detection logic), or when the ECM enters fail-safe mode. (Refer to EC-88,
"Fail-Safe Chart".)
Two Trip Detection LogicINFOID:0000000003531605
When a malfunction is detected for the first time, 1st trip DTC and 1st trip Freeze Frame data are stored in the
ECM memory. The MIL will not light up at this stage. <1st trip>
If the same malfunction is detected again during the next drive, the DTC and Freeze Frame data are stored in
the ECM memory, and the MIL lights up. The MIL lights up at the same time when the DTC is stored. <2nd
trip> The “trip” in the “Two Trip Detection Logic” means a driving mode in which self-diagnosis is performed
during vehicle operation. Specific on board diagnostic items will cause the ECM to light up or blink the MIL,
and store DTC and Freeze Frame data, even in the 1st trip, as shown below.
×: Applicable —: Not applicable
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by lighting up MIL when there is
malfunction on engine control system.
Emission-related diagnostic information Diagnostic service
Diagnostic Trouble Code (DTC) Service $03 of SAE J1979
Freeze Frame data Service $02 of SAE J1979
System Readiness Test (SRT) code Service $01 of SAE J1979
1st Trip Diagnostic Trouble Code (1st Trip DTC) Service $07 of SAE J1979
1st Trip Freeze Frame data
Test values and Test limits Service $06 of SAE J1979
Calibration ID Service $09 of SAE J1979
DTC 1st trip DTCFreeze
Frame data1st trip Freeze
Frame dataSRT code SRT status Test value
CONSULT-II×× × × × ×—
GST×× ×—×××
ECM××*— — —×—
ItemsMIL DTC 1st trip DTC
1st trip 2nd trip
1st trip
displaying2nd trip
displaying1st trip
displaying2nd trip
display-
ing BlinkingLighting
upBlinkingLighting
up
Misfire (Possible three way catalyst
damage) — DTC: P0300 - P0308 is
being detected×———— —×—
Misfire (Possible three way catalyst
damage) — DTC: P0300 - P0308 is
being detected——×——×——
One trip detection diagnoses (Re-
fer to EC-49, "
Emission-related Di-
agnostic Information".)—×——×———
Except above — — —×—××—

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-49
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected and demands the
driver to repair the malfunction.
Emission-related Diagnostic InformationINFOID:0000000003531606
EMISSION-RELATED DIAGNOSTIC INFORMATION ITEMS
×:Applicable —: Not applicable
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTe s t v a l u e /
Test limit
(GST only)Trip MILRefer-
ence page CONSULT-II
GST*
2ECM*3
CAN COMM CIRCUIT U1000
1000*5—— 1×EC-145
CAN COMM CIRCUIT U1001
1001*5——1 or 2
2*10—EC-145
CONTROL UNIT(CAN) U1010 1010 — — 1×EC-147
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000———
Flashing*7EC-63
INT/V TIM CONT-B1 P0011 0011 — — 2×EC-149
INT/V TIM CONT-B2 P0021 0021 — — 2×EC-149
A/F SEN1 HTR (B1) P0031 0031 —×2×EC-163
A/F SEN1 HTR (B1) P0032 0032 —×2×EC-163
HO2S2 HTR (B1) P0037 0037 —×2×EC-170
HO2S2 HTR (B1) P0038 0038 —×2×EC-170
A/F SEN1 HTR (B2) P0051 0051 —×2×EC-163
A/F SEN1 HTR (B2) P0052 0052 —×2×EC-163
HO2S2 HTR (B2) P0057 0057 —×2×EC-170
HO2S2 HTR (B2) P0058 0058 —×2×EC-170
INT/V TIM V/CIR-B1 P0075 0075 — — 2×EC-178
INT/V TIM V/CIR-B2 P0081 0081 — — 2×EC-178
MAF SEN/CIRCUIT P0101 0101 — — 2×EC-186
MAF SEN/CIRCUIT P0102 0102 — — 1×EC-194
MAF SEN/CIRCUIT P0103 0103 — — 1×EC-194
IAT SEN/CIRCUIT P0112 0112 — — 2×EC-201
IAT SEN/CIRCUIT P0113 0113 — — 2×EC-201
ECT SEN/CIRC P0117 0117 — — 1×EC-205
ECT SEN/CIRC P0118 0118 — — 1×EC-205
TP SEN 2/CIRC P0122 0122 — — 1×EC-210
TP SEN 2/CIRC P0123 0123 — — 1×EC-210
ECT SENSOR P0125 0125 — — 2×EC-217
IAT SENSOR P0127 0127 — — 2×EC-220
THERMSTAT FNCTN P0128 0128 — — 2×EC-223
A/F SENSOR1 (B1) P0130 0130 —×2×EC-225
A/F SENSOR1 (B1) P0131 0131 —×2×EC-234
A/F SENSOR1 (B1) P0132 0132 —×2×EC-242

EC-50
< SERVICE INFORMATION >
ON BOARD DIAGNOSTIC (OBD) SYSTEM
A/F SENSOR1 (B1) P0133 0133××2×EC-250
HO2S2 (B1) P0137 0137××2×EC-260
HO2S2 (B1) P0138 0138××2×EC-270
HO2S2 (B1) P0139 0139××2×EC-282
A/F SENSOR1 (B2) P0150 0150 —×2×EC-225
A/F SENSOR1 (B2) P0151 0151 —×2×EC-234
A/F SENSOR1 (B2) P0152 0152 —×2×EC-242
A/F SENSOR1 (B2) P0153 0153××2×EC-250
HO2S2 (B2) P0157 0157××2×EC-260
HO2S2 (B2) P0158 0158××2×EC-270
HO2S2 (B2) P0159 0159××2×EC-282
FUEL SYS-LEAN-B1 P0171 0171 — — 2×EC-292
FUEL SYS-RICH-B1 P0172 0172 — — 2×EC-301
FUEL SYS-LEAN-B2 P0174 0174 — — 2×EC-292
FUEL SYS-RICH-B2 P0175 0175 — — 2×EC-301
FTT SENSOR P0181 0181 — — 2×EC-310
FTT SEN/CIRCUIT P0182 0182 — — 2×EC-314
FTT SEN/CIRCUIT P0183 0183 — — 2×EC-314
TP SEN 1/CIRC P0222 0222 — — 1×EC-318
TP SEN 1/CIRC P0223 0223 — — 1×EC-318
MULTI CYL MISFIRE P0300 0300 — — 2×EC-325
CYL 1 MISFIRE P0301 0301 — — 2×EC-325
CYL 2 MISFIRE P0302 0302 — — 2×EC-325
CYL 3 MISFIRE P0303 0303 — — 2×EC-325
CYL 4 MISFIRE P0304 0304 — — 2×EC-325
CYL 5 MISFIRE P0305 0305 — — 2×EC-325
CYL 6 MISFIRE P0306 0306 — — 2×EC-325
CYL 7 MISFIRE P0307 0307 — — 2×EC-325
CYL 8 MISFIRE P0308 0308 — — 2×EC-325
KNOCK SEN/CIRC-B1 P0327 0327 — — 2 —EC-332
KNOCK SEN/CIRC-B1 P0328 0328 — — 2 —EC-332
KNOCK SEN/CIRC-B2 P0332 0332 — — 2 —EC-332
KNOCK SEN/CIRC-B2 P0333 0333 — — 2 —EC-332
CKP SEN/CIRCUIT P0335 0335 — — 2×EC-336
CMP SEN/CIRC-B1 P0340 0340 — — 2×EC-342
TW CATALYST SYS-B1 P0420 0420××2×EC-349
TW CATALYST SYS-B2 P0430 0430××2×EC-349
EVAP PURG FLOW/MON P0441 0441××2×EC-354
EVAP SMALL LEAK P0442 0442××2×EC-359
PURG VOLUME CONT/V P0443 0443 — — 2×EC-366
PURG VOLUME CONT/V P0444 0444 — — 2×EC-373
PURG VOLUME CONT/V P0445 0445 — — 2×EC-373
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTest value/
Test limit
(GST only)Trip MILRefer-
ence page CONSULT-II
GST*
2ECM*3
