service INFINITI QX56 2007 Factory Service Manual

HARNESS
PG-39
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
L
MA
B
PG
N
O
P
HARNESS
Harness LayoutINFOID:0000000003533846
HOW TO READ HARNESS LAYOUT
The following Harness Layouts use a map style grid to help locate
connectors on the drawings:
• Main Harness
• Engine Room Harness LH View (Engine Compartment)
• Engine Room Harness RH View (Engine Compartment)
• Engine Control Harness
• Chassis Harness and Rear Sonar Sensor Sub-harness
• Body Harness
• Body No. 2 Harness
To use the grid reference
1. Find the desired connector number on the connector list.
2. Find the grid reference.
3. On the drawing, find the crossing of the grid reference letter column and number row.
4. Find the connector number in the crossing zone.
5. Follow the line (if used) to the connector.
CONNECTOR SYMBOL
Main symbols of connector (in Harness Layout) are indicated below.
SEL252V
Connector typeWater proof type Standard type
Male Female Male Female
• Cavity: 4 or Less
• Relay connector
• Cavity: From 5 to 8
• Cavity: 9 or More
• Ground terminal etc.
—

PG-40
< SERVICE INFORMATION >
HARNESS
OUTLINE
WKIA4667E

HARNESS
PG-41
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
L
MA
B
PG
N
O
P
MAIN HARNESS
WKIA4668E

PG-42
< SERVICE INFORMATION >
HARNESS
ENGINE ROOM HARNESS (LH VIEW)
WKIA5809E

HARNESS
PG-43
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
L
MA
B
PG
N
O
P Engine Compartment
Refer to "ENGINE ROOM HARNESS (RH VIEW)" for continuation of engine room harness.
WKIA4670E

PG-44
< SERVICE INFORMATION >
HARNESS
WKIA3688E

HARNESS
PG-45
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
L
MA
B
PG
N
O
P Passenger Compartment
ENGINE ROOM HARNESS (RH VIEW)
WKIA4671E

PG-46
< SERVICE INFORMATION >
HARNESS
Engine Compartment
Refer to "ENGINE ROOM HARNESS (LH VIEW)" for continuation of engine room harness.
WKIA4672E

HARNESS
PG-47
< SERVICE INFORMATION >
C
D
E
F
G
H
I
J
L
MA
B
PG
N
O
P
AWMIA0860GB

PG-48
< SERVICE INFORMATION >
HARNESS
ENGINE CONTROL HARNESS
WKIA4674E
