BRC-22
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
EBD
Component Parts Location
INFOID:0000000001691097
1. Front wheel sensor LH E18 Front wheel sensor RH E117 2. Delta stroke sensor E114
3. Brake fluid level switch E21
4. Active booster E49 5. Front pressure sensor E316. Rear pressure sensor E32
7. ABS actuator and el ectric unit (con-
trol unit) E125 8. Stop lamp switch E38
9. Combination meter M23, M24
AWFIA0713GB
Revision: March 2010 2008 QX56

EBD
BRC-23
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000001691098
10. Yaw rate/side/decel G sensor M108 11. Rear wheel sensor LH C11 Rear wheel sensor RH C1012. Steering angle sensor M17
13. VDC OFF switch M253 14. Stop lamp relay E12
Component parts Reference
ABS actuator and electric unit (control unit)Pump
BRC-38, "
Description"Motor
Actuator relayBRC-56, "
Description"
Solenoid valveBRC-48, "Description"
Wheel sensor BRC-29, "Description"
ABS warning lampBRC-83, "Description"
Brake warning lampBRC-84, "Description"
Revision: March 2010 2008 QX56

BRC-24
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
CONSULT-III Function (ABS)INFOID:0000000001686255
FUNCTION
CONSULT-III can display each diagnostic item us ing the diagnostic test modes shown following.
SELF-DIAG RESULTS MODE
Operation Procedure
1. Before performing the self-diagnosis, start engine and drive vehicle at 30 km/h (19 MPH) or more for
approximately 1 minute.
How to Erase Self-d iagnosis Results
1. After erasing DTC memory, start engine and drive vehicle at 30 km/h (19 MPH) or more for approximately
1 minute as the final inspection, and make sure that the ABS warning lamp, VDC OFF indicator lamp,
SLIP indicator lamp and brake warning lamp turn OFF.
CAUTION:
If memory cannot be erased, pe rform applicable diagnosis.
NOTE:
• When the wheel sensor malfunctions, after inspecting the wheel sensor system, the ABS warning lamp,
VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp will not turn OFF even when the
system is normal unless the vehicle is driving at approximately 30 km/h (19 MPH) or more for approxi-
mately 1 minute.
• Brake warning lamp will turn ON in case of parking brake operation (when switch is ON) or of brake fluid level switch operation (when brake fluid is insufficient).
• VDC OFF switch should not stay “ON” position.
Display Item List
Refer to BRC-100, "DTC No. Index".
DATA MONITOR MODE
Display Item List
Diagnostic test mode Function
Work support This mode enables a technician to adjust some devices faster and more accurately by following
the indications on CONSULT-III.
Self-diagnostic results Self-diagnostic results can be read and erased quickly.
Data monitor Input/Output data in the ABS actuator and electric unit (control unit) can be read.
Active test Diagnostic test mode is which CONSULT-III drives some actuators apart from the ABS actuator
and electric unit (control unit) and also shifts some parameters in a specified range.
ECU part number ABS actuator and electric unit (control unit) part number can be read.
CAN diagnostic support monitor The results of transmit/receive diagnosis of CAN communication can be read.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
GEAR ××× Gear position judged by transmis-
sion range switch signal is dis-
played.
FR RH SENSOR
(km/h, MPH) ××× Wheel speed calculated by front RH
wheel sensor signal is displayed.
FR LH SENSOR
(km/h, MPH) ××× Wheel speed calculated by front LH
wheel sensor signal is displayed.
RR RH SENSOR
(km/h, MPH) ×××
Wheel speed calculated by rear RH
wheel sensor signal is displayed.
Revision: March 2010
2008 QX56

BRC-26
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
CV1
(ON/OFF) ––× Front side switch-over solenoid
valve (cut valve) (ON/OFF) status is
displayed.
CV2
(ON/OFF) ––× Rear side switch-over solenoid
valve (cut-valve) (O
N/OFF) status is
displayed.
SV1
(ON/OFF) ––× Front side switch-over solenoid
valve (suction valve) (ON/OFF) sta-
tus is displayed.
SV2
(ON/OFF) ––× Rear side switch-over solenoid
valve (suction valve) (ON/OFF) sta-
tus is displayed.
VDC FAIL SIG
(ON/OFF) ––× VDC fail signal (ON/OFF) status is
displayed.
TCS FAIL SIG
(ON/OFF) ––× TCS fail signal (ON/OFF) status is
displayed.
ABS FAIL SIG
(ON/OFF) ––×
ABS fail signal (ON/OFF) status is
displayed.
EBD FAIL SIG
(ON/OFF) ––× EBD fail signal (ON/OFF) status is
displayed.
FLUID LEV SW
(ON/OFF) ×
– ×Brake fluid level switch (ON/OFF)
status is displayed.
EBD SIGNAL
(ON/OFF) ––×
EBD operation (ON/OFF) status is
displayed.
ABS SIGNAL
(ON/OFF) ––× ABS operation (ON/OFF) status is
displayed.
TCS SIGNAL
(ON/OFF) ––× TCS operation (ON/OFF) status is
displayed.
VDC SIGNAL
(ON/OFF) ––×
VDC operation (ON/OFF) status is
displayed.
EBD WARN LAMP –– ×Brake warning lamp (ON/OFF) sta-
tus is displayed.
SLCT LVR POSI ××× Shift position judged by transmis-
sion range switch signal.
R POSI SIG ––×Shift position judged by transmis-
sion range switch signal.
2WD/4WD ––×It recognizes on software whether it
is 2WD and whether it is in 4WD
state.
BST OPER SIG ––×Active booster operation (ON/OFF)
st
atus is
di

splayed.
PRESS SENSOR ×– ×Brake pressure detected by pres-
sure sensor is displayed.
CRANKING SIG ––×The input state of the key SW
START position signal is displayed.
PRESS SEN 2 ––×Brake pressure detected by pres-
sure sensor is displayed.
DELTA S SEN ––×The amount of stroke sensor move-
ments in the active booster detected
by DELTA S SEN is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
Revision: March 2010 2008 QX56

BRC-28
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS MOTOR• Touch “ON” and “OFF” on screen. Make sure motor relay and actuator relay operates as shown in table
below.
BOOSTER DRIVE
• Touch “UP” and “DOWN” on the screen. Check that booster drive operates as shown in table below.
CAUTION:
Perform active test subject to the conditions below.
• Do not operate brake pedal during active test.
• Make sure the engine revo lution is over 500 rpm.
• Make sure the vehicle is not moving.
RR RH SOL
RR RH ABS SOLE-
NOID (ACT) RR RH IN SOL
OFF ON ON OFF OFF OFF
RR RH OUT SOL OFF OFF ON* OFF OFF OFF
RR LH SOL
RR LH ABS SOLE-
NOID (ACT) RR LH IN SOL
OFF ON ON OFF OFF OFF
RR LH OUT SOL OFF OFF ON* OFF OFF OFF
REAR SOL RR RH IN SOL
OFF ON ON OFF OFF OFF
RR RH OUT SOL OFF OFF ON* OFF OFF OFF
RR LH IN SOL OFF ON ON OFF OFF OFF
RR LH OUT SOL OFF OFF ON* OFF OFF OFF
Operation ONOFF
MOTOR RELAY ONOFF
ACTUATOR RLY ONON
Operation UPDOWN
STOP LAMP SW ONOFF
BST OPER SIG ONOFF
PRESS SENSOR 50 ± 5 bar 0 bar
PRESS SEN 2 50 ± 5 bar 0 bar
STP OFF RLY OFFOFF
Operation
ABS solenoid valve
ABS solenoid valve (ACT)
UP KEEP DOWN UP ACTUA-
TOR UP ACTUA-
TOR KEEP
Revision: March 2010 2008 QX56

BRC-58
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1142 PRESS SENSOR
C1142 PRESS SENSOR
DescriptionINFOID:0000000001686311
The front and rear pressure sensors convert the brake flui
d pressure to an electric signal and transmit it to the
ABS actuator and electric unit (control unit).
DTC LogicINFOID:0000000001686312
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.CHECK SELF-DIAGNOSIS RESULTS
Check the self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> Proceed to diagnosis procedure. Refer to BRC-58, "Diagnosis Procedure".
NO >> Inspection End
Diagnosis ProcedureINFOID:0000000001686313
FRONT PRESSURE SENSOR INSPECTION PROCEDURE
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the front pressure sensor connector E31 and ABS actuator and electric unit (control unit) con-
nector E125 and inspect the terminals for def ormation, disconnection, looseness, or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair connector.
2.FRONT PRESSURE SENSOR CIRCUIT INSPECTION
1. Measure the continuity betw een the ABS actuator and electric
unit (control unit) harness connector E125 (A) and front pres-
sure sensor harness connector E31 (B).
2. Measure the continuity between the ABS actuator and electric unit (control unit) harness connector E125
(A) and body ground.
DTC Display item Malfunction detected condition Possible cause
C1142 PRESS SEN CIRCUIT Pressure sensor signal line is open or shorted, or pres-
sure sensor is malfunctioning. • Harness or connector
• Pressure sensor
• ABS actuator and electric unit
(control unit)
Self-diagnosis results
PRESS SEN CIRCUIT
ABS actuator and electric unit (control unit) Front pressure sensor
Continuity
Connector Terminal Connector Terminal
A: E125 18
B: E31 3
Ye s
19 1
20 2
AWFIA0021ZZ
Revision: March 2010 2008 QX56

C1142 PRESS SENSORBRC-59
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or connector.
3.FRONT PRESSURE SENSOR INSPECTION
1. Reconnect the front pressure sensor and ABS actuator and electric unit (control unit) connectors.
2. Use “DATA MONITOR” to check if the status of “PRESS SENSOR” is normal.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace the front pressure sensor.
REAR PRESSURE SENSOR INSPECTION PROCEDURE
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the rear pressure sensor connector E32 and ABS actuator and electric unit (control unit) con-
nector E125 and inspect the terminals for defo rmation, disconnection, looseness, or damage.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair connector.
2.REAR PRESSURE SENSOR CIRCUIT INSPECTION
1. Measure the continuity betw een the ABS actuator and electric
unit (control unit) harness connector E125 (A) and rear pressure
sensor harness connector E32 (B).
2. Measure the continuity between t he ABS actuator and electric unit (control unit) harness connector E125
(A) and body ground.
ABS actuator and electric unit (control
unit) —Continuity
Connector Terminal
A: E125 18
Ground No
19
20
Condition PRESS SENSOR
(DATA MONITOR)
With ignition switch turned ON and brake pedal released. Approx. 0 bar
With ignition switch turned ON and brake pedal depressed. Positive value
ABS actuator and electric unit (control unit) Rear pressure sensor
Continuity
Connector Terminal Connector Terminal
A: E125 21
B: E32 1
Ye s
22 3
23 2
ABS actuator and electric unit (control unit) —Con tin uit y
Connector Terminal
A: E125 21
Ground No
22
23
AWFIA0022ZZ
Revision: March 2010 2008 QX56

BRC-60
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1142 PRESS SENSOR
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace harness or connector.
3.REAR PRESSURE SENSOR INSPECTION
1. Reconnect the rear pressure sensor and ABS act uator and electric unit (control unit) connectors.
2. Use “DATA MONITOR” to check if t he status of “PRESS SEN2” is normal.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace the rear pressure sensor.
Component InspectionINFOID:0000000001686314
1.CHECK DATA MONITOR
On “DATA MONITOR”, select “PRESS SENSOR” and “PRESS SEN2” and check the brake fluid pressure.
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-58, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000001691156
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Condition PRESS SEN2
(DATA MONITOR)
With ignition switch turned ON and brake pedal released. Approx. 0 bar
With ignition switch turned ON and brake pedal depressed. Positive value
Condition PRESS SENSOR
and PRESS SEN2
(DATA MONITOR)
With ignition switch turned ON and brake pedal released. Approx. 0 bar
With ignition switch turned ON and brake pedal depressed. Positive value
Revision: March 2010 2008 QX56

C1155 BRAKE FLUID LEVEL SWITCHBRC-65
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
YES >> GO TO 3
NO >> Repair or replace malfunctioning components.
3.CHECK BRAKE FLUID LEVEL SWITCH GROUND
Check continuity between brake fluid level switch harness connector
E21 and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace malfunctioning components.
4.CHECK BRAKE FLUID LEVEL SWITCH
Check continuity between brake fluid level switch terminals.
Is the inspection result normal?
YES >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control unit). Refer to BRC-116, "
Removal and
Installation".
NO >> Replace brake fluid level switch.
Component InspectionINFOID:0000000001686324
1.CHECK BRAKE FLUID LEVEL SWITCH
1. Turn ignition switch OFF.
2. Disconnect brake fluid level switch connector.
3. Check continuity between brake fluid level switch terminals.
Is the inspection result normal?
YES >> Inspection End
NO >> Replace brake fluid level switch.
Special Repair RequirementINFOID:0000000001691158
1.ADJUSTMENT OF STEERING AN GLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
Brake fluid level switch
—Continuity
Connector Terminal
E21 2Ground Yes
AWFIA0026ZZ
Brake fluid level switch
ConditionContinuity
Te r m i n a l
1 − 2 When brake fluid is full in the reser-
voir tank.
No
When brake fluid is empty in the
reservoir tank. Ye s
ALFIA0026ZZ
Brake fluid level switch
ConditionContinuity
Te r m i n a l
1 − 2 When brake fluid is full in the reser-
voir tank.
No
When brake fluid is empty in the
reservoir tank. Ye s
ALFIA0026ZZ
Revision: March 2010
2008 QX56

BRC-66
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1155 BRAKE FLUID LEVEL SWITCH
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Revision: March 2010 2008 QX56
