WW-74
< PRECAUTION >
PRECAUTION
PRECAUTION
PRECAUTION
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000004884200
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000004884201
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
Revision: March 2010 2008 QX56

PRECAUTIONWW-75
< PRECAUTION >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of al l control units using CONSULT-III.
Revision: March 2010 2008 QX56

WW-76
< ON-VEHICLE REPAIR >
FRONT WIPER ARM
ON-VEHICLE REPAIR
FRONT WIPER ARM
Front Wiper ArmsINFOID:0000000001601860
REMOVAL AND INSTALLATION
Removal
1. Remove wiper arm covers and wiper arm nuts.
2. Remove front RH wiper arm and front LH wiper arm.
3. Remove front RH blade assembly and front LH blade assembly.
Installation
1. Operate wiper motor one full cycle, then turn "OFF" (Auto Stop).
2. Clean up the pivot area as shown. This will reduce possibility ofwiper arm looseness.
3. Install front RH blade assembly and front LH blade assembly on the wiper arms .
4. Install front RH wiper arm and front LH wiper arm.
5. Tighten wiper arm nuts to specified torque, and install wiper arm covers. Refer to WW-77, "
Wiper Motor
and Linkage".
6. Ensure that wiper blades stop within proper clearance. Refer to WW-76, "
Front Wiper Arms".
FRONT WIPER ARM ADJUSTMENT
1. Operate wiper motor one full cycle, then turn "OFF" (Auto Stop).
2. Lift the wiper blade up and then rest it onto glass surface, check
the blade clearance "L1" and "L2".
3. Remove wiper arm covers and wiper arm nuts.
4. Adjust front wiper arms on wiper motor pivot shafts to obtain above specified blade clearances.
5. Tighten wiper arm nuts to specified torque, and install wiper arm covers. Refer to WW-77, "
Wiper Motor
and Linkage".
SEL024J
Clearance "L1" : 41.5 - 56.5 mm (1.634 - 2.224 in)
Clearance "L2" : 52.5 - 67.5 mm (2.067 - 2.657 in)
SEL543TA
Revision: March 2010 2008 QX56

FRONT WIPER DRIVE ASSEMBLYWW-77
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
FRONT WIPER DRIVE ASSEMBLY
Wiper Motor and LinkageINFOID:0000000001601861
REMOVAL AND INSTALLATION
Removal
1. Remove the cowl top. Refer to EXT-18, "Removal and Installation".
2. Remove wiper frame bolts, and remove wiper frame assembly.
3. Remove wiper motor from wiper frame assembly.
Installation
CAUTION:
• Do not drop the wiper motor or cause it to contact other parts.
• Check the grease conditions of the motor arm and wiper link joint(s). Apply grease if necessary.
1. Connect wiper motor to connector. Turn the wiper switch ON to operate wiper motor, then turn the wiper switch OFF (auto stop).
2. Disconnect wiper motor connector.
3. Install wiper motor to wiper frame assembly, and install wiper frame assembly.
4. Install cowl top. Refer to EXT-18, "
Removal and Installation".
5. Ensure that wiper blades stop within proper clearance. Refer to WW-76, "
Front Wiper Arms".
ALLIA0369GB
1. Wiper arm covers2. Wiper arm nuts3. Front RH wiper arm and blade assembly
4. Wiper frame bolts 5. Wiper frame assembly 6. Wiper motor to frame bolts
7. Wiper motor spacer 8. Wiper motor9. Front LH wiper arm and blade assembly
Revision: March 2010 2008 QX56

WW-78
< ON-VEHICLE REPAIR >
FRONT WASHER TUBE
FRONT WASHER TUBE
Washer Tube LayoutINFOID:0000000001601863
WKIA4465E
1. Rear washer nozzle2. Washer nozzles3. Washer fluid reservoir
Revision: March 2010 2008 QX56

FRONT WASHER NOZZLEWW-79
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
FRONT WASHER NOZZLE
Washer Nozzle AdjustmentINFOID:0000000001601862
• This vehicle is equipped with non-adjustable washer nozzles.
• If not satisfied with washer fluid spray coverage, confirm that the washer nozzle is installed correctly.
• If the washer nozzle is installed correctly, and the washer fluid spray coverage is not satisfactory, replace washer nozzle.
PKIA2552E
Revision: March 2010 2008 QX56

WW-80
< ON-VEHICLE REPAIR >
WASHER TANK
WASHER TANK
Washer Fluid ReservoirINFOID:0000000001601865
REMOVAL AND INSTALLATION
Removal
1. Remove side washer fluid reservoir screw (2).• Front and rear washer motor (1).
2. Remove front and rear washer motor connector.
3. Remove washer fluid level sensor connector.
4. Disconnect front and rear washer hoses.
5. Remove front washer fluid reservoir screw (2).
6. Remove washer fluid reservoir (1) from the vehicle.
Installation
Installation is in the reverse order of removal.
ALLIA0372ZZ
LKIA0412E
WKIA4563E
Revision: March 2010 2008 QX56

FRONT WASHER PUMPWW-81
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
FRONT WASHER PUMP
Washer MotorINFOID:0000000001601866
REMOVAL AND INSTALLATION
Removal
1. Remove washer fluid reservoir. Refer to WW-80, "Washer Fluid Reservoir".
2. Remove washer motor (1) in the direction of the arrow as shown, and remove from washer fluid reservoir (2).
Installation
Installation is in the reverse order of removal.
CAUTION:
When installing front and rear washer motor, there should be no packing twists, etc.
WKIA4564E
Revision: March 2010 2008 QX56

WW-82
< ON-VEHICLE REPAIR >
FRONT WIPER AND WASHER SWITCH
FRONT WIPER AND WASHER SWITCH
Wiper and Washer SwitchINFOID:0000000001601864
REMOVAL AND INSTALLATION
Removal
1. Remove steering column covers.
2. Remove wiper washer switch connector.
3. Pinch tabs at wiper and washer switch base and slide switchaway from steering column to remove.
Installation
Installation is in the reverse order of removal.
WKIA0071E
Revision: March 2010 2008 QX56

REAR WIPER AND WASHER SYSTEMWW-83
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
J
K
M A
B
WW
N
O P
REAR WIPER AND WASHER SYSTEM
Rear Wiper ArmINFOID:0000000001601879
REMOVAL AND INSTALLATION
Removal
1. Remove wiper arm cover, and remove rear wiper arm nut.
2. Remove the wiper arm.
3. Remove wiper blade.
Installation
1. Operate rear wiper motor one full cycle, then turn "off " (Auto Stop).
2. Clean up the pivot area as illustrated. This will reduce the possi- bility of wiper arm looseness.
3. Install wiper blade.
4. Install rear wiper arm so that the arm rests in the stopper and tighten rear wiper arm nut to specification.
5. Install wiper arm cover.
Rear Wiper MotorINFOID:0000000001601880
REMOVAL AND INSTALLATION
LKIA0608E
Rear wiper arm nut : 10.2 N·m (1.0 kg-m, 8 ft-lb)
SEL024J
