POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000001735461
Refer to BCS-32, "Diagnosis Procedure".
BCM : Special Repair RequirementINFOID:0000000001735462
1. REQUIRED WORK WHEN REPLACING BCM
Initialize control unit. Refer to CONSULT-III Operation Manual.
>> Work end.
DRIVER SEAT CONTROL UNIT
DRIVER SEAT CONTROL UN IT : Diagnosis ProcedureINFOID:0000000001735463
NOTE:
Do not disconnect the battery negative terminal and the driver seat control unit connector until DTC is con-
firmed with CONSULT-III.
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Check voltage between driver seat control unit harness connec- tor and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the following. • Repair or replace harness between driver seat control unit and fuse block (J/B).
• Circuit breaker.
2. CHECK GROUND CIRCUIT
Check continuity between the driver seat control unit harness con-
nector and ground.
Is the inspection result normal?
YES >> Driver seat control unit power supply and ground circuit are OK.
NO >> Repair or replace harness.
Te r m i n a l s
Power
source ConditionVoltage (V)
(Approx.)
(+)
(–)
Driver seat
control unit connector Te r m i n a l
B202 6
Ground START
power sup-
ply Ignition
switch
START Battery
voltage
B203 33
Battery
power sup- ply Ignition
switch OFF
40
LIIA1897E
Driver seat control unit
connector Te r m i n a l
Ground Continuity
B202 32
Ye s
B203 48
PIIA4542E
Revision: March 2010 2008 QX56

SEAT MEMORY INDICATOR LAMPADP-103
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
K L
M A
B
ADP
N
O P
Check voltage between seat memory switch harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Check the following. •Fuse
• Harness for open or short between memory indicator and fuse.
3. CHECK MEMORY INDICATOR
Refer to ADP-103, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace seat memory switch.
4. CHECK INTERMITTENT INCIDENT
Refer to GI-38, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace automatic driv e positioner control unit.
NO >> Repair or replace the malfunctioning part.
Component InspectionINFOID:0000000001735550
1. CHECK SEAT MEMORY INDICATOR
1. Disconnect seat memory switch.
2. Check continuity between seat memory switch terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace seat memory switch.
Seat memory switch connector Te r m i n a l s
Voltage (V)
(Approx.)
(+) (–)
D5 5Ground Battery voltage
PIIA4595E
Te r m i n a l
Continuity
Seat memory switch
(+) (-)
6 5Y es
7
ALJIA0200ZZ
Revision: March 2010 2008 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-63
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
POWER SUPPLY AND GROUND CIRCUIT
AV CONTROL UNIT
AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000001696097
1.CHECK FUSES
Check that the following AV control unit fuses are not blown.
Are the fuses OK?
YES >> GO TO 2
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect AV control unit connectors M42 and M45.
2. Check voltage between the AV control unit connectors M42 and M45 and ground.
Are the voltage results as specified?
YES >> GO TO 3
NO >> • Check connector housings for disconnected or loose terminals.
• Repair harness or connector.
3.GROUND CIRCUIT CHECK
Unit Terminals Signal name Fuse No.
AV control unit 19
Battery power 31
66 Battery power 31
68 Battery power 31
7 Ignition switch ACC or ON 4
69 Ignition switch ACC or ON 4
79 Ignition switch ON or START 12
(+)
(-) OFF ACC ON
Connector Terminal
M42 7Ground0V
Battery
voltage Battery
voltage
19 Ground Battery
voltage Battery
voltage Battery
voltage
M45 66 Ground
Battery
voltage Battery
voltage Battery
voltage
68 Ground Battery
voltage Battery
voltage Battery
voltage
69 Ground 0V Battery
voltage Battery
voltage
79 Ground 0V 0V Battery
voltage
AWNIA1554ZZ
Revision: March 2010 2008 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-65
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector.
3. Check continuity between display unit harness connector M93 and ground.
Does continuity exist?
YES >> Inspection end.
NO >> Repair harness or connector.
A/C AND AV SWITCH ASSEMBLY
A/C AND AV SWITCH ASSEMB LY : Diagnosis ProcedureINFOID:0000000001696099
1.CHECK FUSE
Check that the A/C and AV switch assembly fuse is not blown.
Is the fuse OK?
YES >> GO TO 2
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect A/C and AV switch assembly connector M98.
2. Check voltage between the A/C and AV switch assembly con- nector M98 and ground.
Are the voltage results as specified?
YES >> GO TO 3
NO >> • Check connector housings for disconnected or loose terminals.
• Repair harness or connector.
3.GROUND CIRCUIT CHECK
1. Ignition OFF.
2. Check continuity between A/C and AV switch assembly harness
connector M98 and ground.
Are the continuity results as specified?
YES >> Inspection End.
NO >> Repair A/C and AV switch assembly ground.
(+) (-)Continuity
Connector Terminal
M93 1
Ground Yes
13
ALNIA0407GB
Unit Terminal Signal name Fuse No.
A/C and AV switch assembly 2Ignition switch ACC or ON 4
(+)
(-) OFF ACC ON
Connector Terminal
M98 2 Ground 0V Battery
voltage Battery
voltage
ALNIA0315GB
(+) (-) Continuity
Connector Terminal
M98 1 Ground Yes
ALNIA0316GB
Revision: March 2010 2008 QX56

AV-66
< COMPONENT DIAGNOSIS >[AUDIO SYSTEM]
POWER SUPPLY AND GROUND CIRCUIT
BOSE SPEAKER AMP
BOSE SPEAKER AMP
: Diagnosis ProcedureINFOID:0000000001696100
1.CHECK FUSE
Check that the BOSE speaker amp. fuse is not blown.
Are the fuses OK?
YES >> GO TO 2
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speak er amp. connector.
3. Check voltage between BOSE speaker amp. harness connector M112 terminal 11 and ground.
Is battery voltage present?
YES >> GO TO 3
NO >> Check harness between BOSE speaker amp. and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speak er amp. connector.
3. Check continuity between BOSE speaker amp. harness connec- tor M112 terminal 12 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
WOOFER
WOOFER : Diagnosis ProcedureINFOID:0000000001696101
1.CHECK FUSE
Check that the subwoofer fuse is not blown.
Is the fuse OK?
YES >> GO TO 2
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Unit Terminal Signal name Fuse No.
BOSE speaker amp. 11Battery power 31
(+)
(-) Voltage (approx.)
Connector Terminal
M112 11 Ground Battery voltage
ALNIA0339GB
(+) (-)Continuity
Connector Terminal
M112 12Ground Yes
ALNIA0340GB
Unit Terminal Signal name Fuse No.
Subwoofer 6Battery power 17
Revision: March 2010 2008 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-67
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
1. Turn ignition switch OFF.
2. Disconnect subwoofer connector.
3. Check voltage between subwoofer harness connector B72 ter- minal 6 and ground.
Is battery voltage present?
YES >> GO TO 3
NO >> Check harness between subwoofer and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between subwoofer harness connector B72 terminal 5 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
REAR VIEW CAMERA CONTROL UNIT
REAR VIEW CAMERA CONTROL UNIT : Diagnosis ProcedureINFOID:0000000001696102
1.CHECK FUSE
Check that the following fuses of the rear view camera control unit are not blown.
Are the fuses OK?
YES >> GO TO 2
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between rear view camera control unit harness con-
nector B73 and ground.
Are the voltage readings as specified?
YES >> GO TO 3
NO >> Check harness between rear view camera control unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear view camera control unit connector.
(+) (-) Voltage (approx.)
Connector Terminal
B72 6 Ground Battery voltage
ALNIA0367GB
(+) (-)Continuity
Connector Terminal
B72 5Ground Yes
ALNIA0368GB
Unit Terminals Signal name Fuse No.
Rear view camera control unit 1
Battery power 31
2 Ignition switch ACC or ON 4
Signal nameConnector
No. Te r m i n a l
No. Ignition switch
position Value (Approx.)
Battery po wer supply
B731OFF
Battery voltage
ACC power supply 2 ACC
ALLIA0244ZZ
Revision: March 2010 2008 QX56

AV
POWER SUPPLY AND GROUND CIRCUITAV-69
< COMPONENT DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
3. Check voltage between rear view camera control unit harness connector B73 and ground.
Is voltage reading approximately 6 volts?
YES >> Inspection End.
NO >> Replace rear view camera control unit. Refer to AV-184,
"Removal and Installation".
4.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear view camera harness connector.
3. Check continuity between rear view camera harness connector D504 terminal 2 and ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair harness or connector.
DVD PLAYER
DVD PLAYER : Diagnosis ProcedureINFOID:0000000001696104
1.CHECK FUSE
Check that the DVD player fuse is not blown.
Is the fuse OK?
YES >> GO TO 2
NO >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse.
2.POWER SUPPLY CIRCUIT CHECK
1. Disconnect DVD player connector M205.
2. Check voltage between the DVD player connector M205 and ground.
Are the voltage results as specified?
YES >> GO TO 3
NO >> • Check connector housings for disconnected or loose terminals. • Repair harness or connector.
Signal name Connector
No. Te r m i n a l
No. Transmission
position Value (Approx.)
Camera ON signal B73 8 Reverse 6V
ALLIA0247ZZ
Signal nameContinuity
Ground Yes
ALLIA0248ZZ
UnitTerminal Signal name Fuse No.
DVD player 21
Battery power 31
24 Ignition switch ACC or ON 4
(+)
(-) OFF ACC ON
Connector Terminal
M205 21
Ground Batter
voltage Battery
voltage Battery
voltage
24 0VBattery
voltage Battery
voltage
ALNIA0325GB
Revision: March 2010 2008 QX56

AV
NORMAL OPERATING CONDITIONAV-153
< SYMPTOM DIAGNOSIS > [AUDIO SYSTEM]
C
D
E
F
G H
I
J
K L
M B A
O P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000001696149
AUDIO SYSTEM
The majority of the audio troubles are the result of outside causes (bad CD, electromagnetic interference,
etc.).
Noise
The following noise results from variations in field strength, such as fading noise and multi-path noise, or
external noise from trains and other sources. It is not a malfunction.
• Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun-
tains or buildings blocking the signal.
• Multi-path noise: This noise results from the waves sent directly from the broadcast station arriving at the antenna at a different time from the waves which reflect off mountains or buildings.
The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and opera-
tion of each piece of electrical equipment, and determine the cause.
NOTE:
The source of the noise can be found easily by listening to the noise while removing the fuses of electrical
components, one by one.
Type of Noise and Possible Cause
NAVIGATION SYSTEM
Basic Operation
Vehicle Mark
Occurrence condition Possible cause
Occurs only when engine is ON. A continuous growling noise occurs. The speed of
the noise varies with changes in the engine speed. • Ignition components
The occurrence of the noise is linked with the operation of the fuel pump. • Fuel pump condenser
Noise only occurs when various
electrical components are oper-
ating. A cracking or snapping sound occurs with the op-
eration of various switches.
• Relay malfunction, audio unit malfunction
The noise occurs when various motors are operat-
ing. • Motor case ground
•Motor
The noise occurs constantly, not just under certain conditions. • Rear defogger coil malfunction
• Open circuit in printed heater
• Poor ground of antenna feeder line
A cracking or snapping sound occurs while the vehicle is being driven, especially when
it is vibrating excessively. • Ground wire of body parts
• Ground due to improper part installation
• Wiring connections or a short circuit
Symptom
Cause Remedy
No image is shown. Display brightness adjustment is set fully to DARK
side. Adjust the display brightness.
No guide sound is heard.
Audio guide volume is too low or
too high. Volume control is set to OFF, MIN or MAX. Adjust the audio guide volume.
Audio guidance is not available while the vehicle is
driving on a dark pink route.
System is not malfunctioning.
Screen is too dark.
Motion of the image is too slow. Temperature inside the vehicle is low.
Wait until the temperature inside the vehicle
reaches the proper temperature.
Small black or bright spots appear
on the screen. Symptom peculiar to a liquid crystal display (dis-
play unit). System is not malfunction.
Revision: March 2010
2008 QX56

BCS-32
< COMPONENT DIAGNOSIS >[BCM]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001696439
1. CHECK FUSES AND FUSIBLE LINK
Check that the following fuses and fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Does continuity exist?
YES >> INSPECTION END
NO >> Repair or replace harness.
Terminal No. Signal nameFuses and fusible link No.
57 Battery power supply 22 (15A)
70 F (50A)
11 Ignition ACC or ON 4 (10A)
38 Ignition ON or START 59 (10A)
ConnectorTe r m i n a l s
Power
source Condition Voltage (V) (Ap-
prox.)
(+) (-)
M18 11 Ground
ACC
power
supply Ignition
switch
ACC or
ON Battery voltage
38 Ground Ignition
power
supply Ignition
switch ON or START Battery voltage
M20 57 Ground
Battery
power
supply Ignition
switch OFF Battery voltage
70 Ground Battery
power
supply Ignition
switch
OFF Battery voltage
LIIA2415E
BCM
GroundContinuity
Connector Terminal
M20 67 Yes
LIIA0915E
Revision: March 2010 2008 QX56

CCS
DTC 90 STOP LAMP RLY FIXCCS-33
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
K L
M B
N P A
2. Check continuity between ICC brake hold relay harness connec- tor E134 (B) terminal 3 and IC C unit harness connector B17 (A)
terminal 29.
3. Check continuity between ICC unit harness connector B17 (A) terminal 29 and ground.
Are continuity test results as specified?
YES >> GO TO 7
NO >> • Repair harness between ICC brake hold relay and ICC brake switch. • Repair harness between ICC brake switch and ICC unit.
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
7.CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between ICC brake hold relay harness connector E134 terminal 4 and ground.
Does battery voltage exist?
YES >> Replace ICC unit. Refer to CCS-70, "ICC Unit". Erase
DTC and perform ICC system running test. Refer to
CCS-8, "
ACTION TEST : ICC System Running Test".
NO >> • Check fuse or ICC brake hold relay power supply sys- tem harness.
• Erase DTC and perform ICC system running test. Refer to CCS-8, "
ACTION TEST : ICC Sys-
tem Running Test".
8.CHECK STOP LAMP SWITCH
1. Turn ignition switch OFF.
2. Check stop lamp switch.
Does stop lamp switch operate normally?
YES >> GO TO 9
NO >> Replace stop lamp switch. Erase DTC and perform ICC system running test. Refer to CCS-8,
"ACTION TEST : ICC System Running Test".
9.CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Disconnect stop lamp switch connector.
2. When brake pedal is not depressed, make sure that stop lamp does not illuminate.
Does the ICC brake hold relay check OK?
YES >> Replace ICC unit. Refer to CCS-70, "ICC Unit". Erase DTC and perform ICC system running test.
Refer to CCS-8, "
ACTION TEST : ICC System Running Test".
NO >> GO TO 10
10.CHECK ICC BRAKE HOLD RELAY Continuity should exist.
Continuity should not exist.
ALOIA0008ZZ
Battery voltage should exist
ALOIA0009ZZ
Revision: March 2010
2008 QX56
