HAZARD SWITCH
Removal and InstallationINFOID:0000000003776229
REMOVAL
1. Remove cluster lid C. Refer to IP-16, "Removal and Installation".
2. While pressing the tab, push out the hazard switch.
INSTALLATION
Installation is in the reverse order of removal.
WKIA1402E
Revision: December 20092009 QX56

EXL-154
< REMOVAL AND INSTALLATION >
PUDDLE LAMP
PUDDLE LAMP
Removal and InstallationINFOID:0000000005864680
REMOVAL
1. Depress tab (1) on outer edge of puddle lamp housing.
2. Lower outer edge and slide puddle lamp housing out of door mirror.
3. Twist puddle lamp socket (1) counterclockwise to remove frompuddle lamp housing (2).
INSTALLATION
Installation is in the reverse order of removal.
Bulb ReplacementINFOID:0000000005864681
REMOVAL
1. Remove puddle lamp housing. Refer to EXL-154, "Removal and Installation".
2. Pull puddle lamp bulb (2) straight out from puddle lamp socket (1) to remove.
INSTALLATION
Installation is in the reverse order of removal.
LKIA0671E
LKIA0672E
LKIA0673E
Revision: December 20092009 QX56

LICENSE PLATE LAMPEXL-155
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
LICENSE PLATE LAMP
Bulb ReplacementINFOID:0000000003776230
LICENSE PLATE LAMP
Removal
1. Remove back door lower finisher. Refer to EXT-24, "Removal and Installation".
2. Turn bulb socket counterclockwise to remove it.
3. Pull bulb from socket.
Installation
Installation is in the reverse order of removal.
Removal and InstallationINFOID:0000000003776231
LICENSE PLATE LAMP
Removal
1. Remove back door lower finisher. Refer to INT-21, "Removal and Installation".
2. Remove license plate lamp screws.
3. Remove license plate lamp.
Installation
Installation is in the reverse order of removal.
Revision: December 20092009 QX56

EXL-156
< REMOVAL AND INSTALLATION >
STOP LAMP
STOP LAMP
Bulb ReplacementINFOID:0000000003776232
HIGH-MOUNTED STOP LAMP
NOTE:
High-mounted stop lamp bulbs are not serviceable.
STOP LAMP
Refer to EXL-156, "Removal and Installation".
Removal and InstallationINFOID:0000000003776233
HIGH-MOUNTED STOP LAMP
Removal
1. Remove back door upper finisher. Refer to INT-21, "Removal and Installation".
2. Remove 2 nuts and remove high-mounted stop lamp.
Installation
Installation is in the reverse order of removal.
STOP LAMP
Refer to EXL-157, "Removal and Installation".
WKIA1397E
Revision: December 20092009 QX56

REAR COMBINATION LAMPEXL-157
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
REAR COMBINATION LAMP
Bulb ReplacementINFOID:0000000003776234
REMOVAL
1. Remove rear combination lamp bolts.
2. Pull rear combination lamp to remove.
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb.
INSTALLATION
Installation is in the reverse order of removal.
Removal and InstallationINFOID:0000000003776235
REMOVAL
1. Remove rear combination lamp bolts.
2. Pull rear combination lamp to remove.
3. Disconnect rear combination lamp connector.
INSTALLATION
Installation is in the reverse order of removal.
WKIA1393E
WKIA1393E
Revision: December 20092009 QX56

EXL-158
< SERVICE DATA AND SPECIFICATIONS (SDS)
BULB SPECIFICATIONS
SERVICE DATA AND SPECIFICATIONS (SDS)
BULB SPECIFICATIONS
HeadlampINFOID:0000000003776236
*: Always check with the Parts Department for the latest parts information.
Exterior LampINFOID:0000000003776237
*: Always check with the Parts Department for the latest parts information.Item
Wattage (W)*
Low 35
High 60/65
ItemWattage (W)*
Front combination lamp Parking lamp (inner)
7
Parking lamp (outer) 7
Side marker lamp (front) 7
Rear combination lamp Stop/Tail lamp
LED*
Side marker lamp (rear) *
Turn signal lamp 27
Back-up lamp *
Turn/fog lamp Fog
55
Turn 21
License plate lamp *
High-mounted stop lamp LED*
Revision: December 20092009 QX56
