BRC-6
< BASIC INSPECTION >[VDC/TCS/ABS]
DIAGNOSIS AND REPAIR WORKFLOW
2.PERFORM THE SELF-DIAGNOSIS
Check the DTC display with the self-diagnosis function. Refer to BRC-23, "
CONSULT-III Function (ABS)".
Is there any DTC displayed?
YES >> GO TO 3
NO >> GO TO 4
3.PERFORM THE SYSTEM DIAGNOSIS
Perform the diagnosis applicable to the displayed DTC. Refer to BRC-100, "
DTC No. Index".
>> GO TO 7
4.CHECK THE SYMPTOM THAT IS NOT CONSIDERED A SYSTEM MALFUNCTION
Check that the symptom is a normal operation that is not considered a system malfunction. Refer to BRC-109,
"Description".
Is the symptom a normal operation?
YES >> Inspection End
NO >> GO TO 5
5.CHECK THE WARNING LAMP AND I NDICATOR LAMP FOR ILLUMINATION
Check that the warning lamp and indicator lamp illuminate.
• ABS warning lamp: Refer to BRC-82, "
Description".
• Brake warning lamp: Refer to BRC-83, "
Description".
• VDC OFF indicator lamp: Refer to BRC-84, "
Description".
• SLIP indicator lamp: Refer to BRC-86, "
Description".
Is ON/OFF timing normal?
YES >> GO TO 6
NO >> GO TO 2
6.PERFORM THE DIAGNOSIS BY SYMPTOM
Perform the diagnosis applicable to the symptom.
>> GO TO 7
7.REPAIR OR REPLACE THE MALFUNCTIONING PARTS
Repair or replace the specified malfunctioning parts.
>> GO TO 8
8.FINAL CHECK
Perform the self-diagnosis again, and check that the malfunction is repaired completely. After checking, erase
the self-diagnosis memory. Refer to BRC-23, "
CONSULT-III Function (ABS)".
Is no other DTC present and the repair completed?
YES >> Inspection End
NO >> GO TO 3
Revision: April 20092010 QX56

VDC
BRC-13
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000005147949
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit)Pump
BRC-37, "
Description"Motor
Actuator relayBRC-55, "
Description"
Solenoid valveBRC-47, "Description"
VDC switch-over valve
(CV1, CV2, SV1, SV2)BRC-69, "Description"
Wheel sensor
BRC-28, "Description"
Yaw rate/side/decel G sensorBRC-39, "Description"
Steering angle sensorBRC-60, "Description"
VDC OFF switchBRC-80, "Description"
ABS warning lampBRC-82, "Description"
Brake warning lampBRC-83, "Description"
VDC OFF indicator lampBRC-84, "Description"
SLIP indicator lampBRC-86, "Description"
Front pressure sensor
BRC-57, "Description"Rear pressure sensor
Active boosterBRC-72, "
Description"
Delta stroke sensorBRC-75, "Description"
Revision: April 20092010 QX56

BRC-16
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
TCS
Component Description
INFOID:0000000005206965
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit) Pump
BRC-37, "
Description"Motor
Actuator relayBRC-55, "
Description"
Solenoid valveBRC-47, "Description"
VDC switch-over valve
(CV1, CV2, SV1, SV2)BRC-69, "Description"
Wheel sensor
BRC-28, "Description"
Yaw rate/side/decel G sensorBRC-39, "Description"
Steering angle sensorBRC-60, "Description"
VDC OFF switchBRC-80, "Description"
ABS warning lampBRC-82, "Description"
Brake warning lampBRC-83, "Description"
VDC OFF indicator lampBRC-84, "Description"
SLIP indicator lampBRC-86, "Description"
Front pressure sensor
BRC-57, "Description"Rear pressure sensor
Active boosterBRC-72, "
Description"
Delta stroke sensorBRC-75, "Description"
Revision: April 20092010 QX56

ABS
BRC-19
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
Component DescriptionINFOID:0000000005147957
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit)Pump
BRC-37, "
Description"Motor
Actuator relayBRC-55, "
Description"
Solenoid valveBRC-47, "Description"
Wheel sensor BRC-28, "Description"
ABS warning lampBRC-82, "Description"
Brake warning lampBRC-83, "Description"
Revision: April 20092010 QX56

BRC-22
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
EBD
Component Description
INFOID:0000000005206968
7. VDC OFF switch M253 8. Active booster E499. Delta stroke sensor E114
10. Brake fluid level switch E21 11. Front pressure sensor E31 12. Rear pressure sensor E32
Component parts Reference
ABS actuator and electric unit (control unit) Pump
BRC-37, "
Description"Motor
Actuator relayBRC-55, "
Description"
Solenoid valveBRC-47, "Description"
Wheel sensor BRC-28, "Description"
ABS warning lampBRC-82, "Description"
Brake warning lampBRC-83, "Description"
Revision: April 20092010 QX56

DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
BRC-23
< FUNCTION DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
DIAGNOSIS SYSTEM [ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
CONSULT-III Function (ABS)INFOID:0000000005147962
FUNCTION
CONSULT-III can display each diagnostic item using the diagnostic test modes shown following.
SELF DIAGNOSTIC RESULT MODE
Operation Procedure
1. Before performing the self-diagnosis, start engine and drive vehicle at 30 km/h (19 MPH) or more for
approximately 1 minute.
How to Erase Self-diagnosis Results
1. After erasing DTC memory, start engine and drive vehicle at 30 km/h (19 MPH) or more for approximately 1 minute as the final inspection, and make sure t hat the ABS warning lamp, VDC OFF indicator lamp,
SLIP indicator lamp and brake warning lamp turn OFF.
CAUTION:
If memory cannot be erased, perform applicable diagnosis.
NOTE:
• When the wheel sensor malfunctions, after inspecting the wheel sensor system, the ABS warning lamp,
VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp will not turn OFF even when the
system is normal unless the vehicle is driving at approximately 30 km/h (19 MPH) or more for approxi-
mately 1 minute.
• Brake warning lamp will turn ON in case of parking brake operation (when switch is ON) or of brake fluid level switch operation (when brake fluid is insufficient).
• VDC OFF switch should not stay “ON” position.
Display Item List
Refer to BRC-100, "DTC No. Index".
DATA MONITOR MODE
Display Item List
Diagnostic test mode Function
Work support This mode enables a technician to adjust some devices faster and more accurately by following
the indications on CONSULT-III.
Data Monitor Input/Output data in the ABS actuator and electric uni t (control unit) can be read.
Active Test Diagnostic test mode is which CONSULT-III driv
es some actuators apart from the ABS actuator
and electric unit (control unit) and also shifts some parameters in a specified range.
Self Diagnostic Result Self-diagnostic results can be read and erased quickly.
CAN diag support monitor The results of transmit/receive diagnosis of CAN communication can be read.
ECU Identification ABS actuator and electric unit (control unit) part number can be read.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
FR LH SENSOR
(km/h, mph) ×× × Wheel speed (km/h, mph) calculated by front LH
wheel sensor signal is displayed.
FR RH SENSOR
(km/h, mph) ×× ×
Wheel speed (km/h, mph) calculated by front RH
wheel sensor signal is displayed.
RR LH SENSOR
(km/h, mph) ×× × Wheel speed (km/h, mph) calculated by rear LH
wheel sensor signal is displayed.
RR RH SENSOR
(km/h, mph) ×× × Wheel speed (km/h, mph) calculated by rear RH
wheel sensor signal is displayed.
Revision: April 20092010 QX56

BRC-24
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
DECEL G-SEN
(G) ×× × Longitudinal acceleration (G) detected by decel G-
sensor is displayed.
FR RH IN SOL
(On/Off) –
×× Front RH IN ABS solenoid (On/Off) status is dis-
played.
FR RH OUT SOL
(On/Off) –
×× Front RH OUT ABS solenoid (On/Off) status is dis-
played.
FR LH IN SOL
(On/Off) –
×× Front LH IN ABS solenoid (On/Off) status is displayed.
FR LH OUT SOL
(On/Off) –
×× Front LH OUT ABS solenoid (On/Off) status is dis-
played.
RR RH IN SOL
(On/Off) –
×× Rear RH IN ABS solenoid (On/ Off) status is displayed.
RR RH OUT SOL
(On/Off) –
×× Rear RH OUT ABS solenoid (On/Off) status is dis-
played.
RR LH IN SOL
(On/Off) –
×× Rear LH IN ABS solenoid (On/ Off) status is displayed.
RR LH OUT SOL
(On/Off) –
×× Rear LH OUT ABS solenoid (On/Off) status is dis-
played.
EBD WARN LAMP
(On/Off) ––
×Brake warning lamp (On/Off) status is displayed.
STOP LAMP SW
(On/Off) ×× ×
Stop lamp switch (On/Off) status is displayed.
MOTOR RELAY
(On/Off) –
×× ABS motor relay signal (On/Of f) status is displayed.
ACTUATOR RLY
(On/Off) –
×× ABS actuator relay signal (On/ Off) status is displayed.
ABS WARN LAMP
(On/Off) –
×× ABS warning lamp (On/Off) status is displayed.
OFF LAMP
(On/Off) –
×× VDC OFF Lamp (On/Off) status is displayed.
OFF SW
(On/Off) ×× ×
VDC OFF switch (On/Off) status is displayed.
SLIP LAMP
(On/Off) –
×× SLIP indicator lamp (On/Off) status is displayed.
BATTERY VOLT
(V) ×× ×
Voltage (V) supplied to ABS actuator and electric unit
(control unit) is displayed.
GEAR
(1 , 2

, 3, 4, 5) ×× × Gear position (1, 2, 3, 4, 5) judged by transmission
range switch signal is displayed.
SLCT LVR POSI
(P, N, D) ×× × Shift position (P, N, D) judged by transmission range
switch signal.
ENGINE SPEED
(rpm) ×× ×
Engine speed (rpm) judged by CAN communication
signal is displayed.
YAW R AT E S E N
(d/s) ×× × Yaw rate (d/s) detected by yaw rate sensor is dis-
played.
R POSI SIG
(On/Off) ––
×Reverse shift position (On/Off) judged by PNP switch
signal.
4WD FAIL REQ
(On/Off) ––
×Transfer control unit fail-safe mode (On/Off) is dis-
played.
N POSI SIG
(On/Off) ––
×Shift position judged by transmission range switch
signal.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
Revision: April 20092010 QX56

BRC-26
< FUNCTION DIAGNOSIS >[VDC/TCS/ABS]
DIAGNOSIS SYSTEM [
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL
UNIT)]
×: Applicable
–: Not applicable
ACTIVE TEST MODE
CAUTION:
• Do not perform active test while driving vehicle.
• Make sure to completely bleed air from brake system.
• The active test cannot be performed with the ABS warning lamp, VDC OFF indicator lamp, SLIP indi-
cator lamp or brake warning lamp on.
• ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp are on
during active test.
NOTE:
• When active test is performed while depressing the pedal, the pedal depression amount will change. This is
normal. (Only solenoid valve and ABS motor.)
• “TEST IS STOPPED” is displayed 10 seconds after operation start.
• After “TEST IS STOPPED” is display ed, to perform test again, touch BACK.
Test Item
SOLENOID VALVE• When performing an active test of the ABS function, select the “MAIN SIGNAL S” for each test item.
• For ABS solenoid valve, touch “Up”, “Keep”, and “D own” on the display screen. For ABS solenoid valve
(ACT), touch “Up”, “ACT UP”, “ACT KEEP” and confirm that solenoid valves operate as shown in the table
below.
RELEASE SW NC
(On/Off) ––
×Release switch signal (On/Off) status is displayed.
“Off” indicates that the brake pedal is depressed. “On”
indicates that the brake pedal is released.
OHB FAIL
(On/Off) ––
×OHB fail status is displayed.
HBA FAIL
(On/Off) ––
×HBA fail status is displayed.
OHB SIG
(On/Off) ––
×OHB operation (On/Off) status is displayed.
HBA SIG
(On/Off) ––
×HBA operation (On/Off) status is displayed.
STP OFF RLY
(On/Off) ––
×Stop lamp relay signal (On/Off) status is displayed.
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS SELECTION
FROM MENU
Operation ABS solenoid valve ABS solenoid valve (ACT)
Up Keep Down Up ACT UP ACT KEEP
FR RH SOL FR RH IN SOL Off On On — —
—
FR RH OUT SOL Off Off On* — — —
FR LH SOL FR LH IN SOL Off On On — —
—
FR LH OUT SOL Off Off On* — — —
RR RH SOL RR RH IN SOL Off On On — —
—
RR RH OUT SOL Off Off On* — — —
RR LH SOL RR LH IN SOL Off On On — —
—
RR LH OUT SOL Off Off On* — — —
FR RH ABS SOLENOID (ACT) FR RH IN SOL — — — Off Off Off
FR RH OUT SOL — — — Off Off Off
CV1 ———OffOnOn
SV1
— — — Off On* Off
Revision: April 20092010 QX56

BRC-82
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000005148069
×
: ON –: OFF
Component Function CheckINFOID:0000000005148070
1.CHECK ABS WARNING LAMP OPERATION
Check that the lamp illuminates for approximately 2 seconds after the ignition switch is turned ON.
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-82, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000005148071
1.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-23, "
CONSULT-III Function
(ABS)".
Is the inspection result normal?
YES >> GO TO 2
NO >> Check items displayed by self-diagnosis.
2.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-22, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electr ic unit (control unit). Refer to BRC-116, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-100, "
Removal and Installation".
Special Repair RequirementINFOID:0000000005194925
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replac ing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Condition ABS warning lamp
Ignition switch OFF –
For 2 seconds after turning ON ignition switch ×
2 seconds later after turning ON ignition switch –
ABS function is malfunctioning. ×
EBD function is malfunctioning. ×
Revision: April 20092010 QX56

BRAKE WARNING LAMPBRC-83
< COMPONENT DIAGNOSIS > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
BRAKE WARNING LAMP
DescriptionINFOID:0000000005148072
× : ON –: OFF
NOTE:
• 1: Brake warning lamp will turn on in case of parking brake op eration (when switch is ON) or of brake fluid level switch operation
(when brake fluid is insufficient).
• 2: After starting engine, brake warning lamp is turned off.
Component Function CheckINFOID:0000000005148073
1.BRAKE WARNING LAMP OPERATION CHECK
Check that the lamp illuminates after the ignition switch is turned ON, and turns OFF after the engine is
started.
Is the inspection result normal?
YES >> Inspection End
NO >> Go to diagnosis procedure. Refer to BRC-83, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000005148074
1.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-23, "
CONSULT-III Function
(ABS)".
Is the inspection result normal?
YES >> GO TO 2
NO >> Check items displayed by self-diagnosis.
2.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-22, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit). Refer to BRC-116, "Removal and Installa-
tion".
NO >> Replace combination meter. Refer to MWI-100, "
Removal and Installation".
Special Repair RequirementINFOID:0000000005194926
1.ADJUSTMENT OF STEERING AN GLE SENSOR NEUTRAL POSITION
Always perform neutral position adjustment for the st eering angle sensor when replacing the ABS actuator
and electric unit (control unit). Refer to BRC-8, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL
POSITION : Description".
>> GO TO 2
2.CALIBRATION OF DECEL G SENSOR
Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit).
Refer to BRC-9, "
CALIBRATION OF DECEL G SENSOR : Description".
>> END
Condition Brake warning lamp (Note 1)
Ignition switch OFF –
Ignition switch ON × (Note 2)
EBD function is malfunctioning. ×
Revision: April 20092010 QX56
