ECM
EC-95
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
P062B ECM Type1
 Engine torque is limited.
 Idle engine speed is increased.
 Fuel injector power supply shut-off.
 High fuel pressure limitation.
Typ e2
 Engine torque is limited.
 Fuel injection shut-off of malfunction cylinder.
 Mixture ratio feedback control does not function.
 Idle engine speed is increased.
P0643 Sensor power supply ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P1087
P1088 VVEL control function VVEL of no
rmal bank is controlled at VVEL angle of abnormal bank.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
P1089
P1092 VVEL control shaft position
sensor VVEL value is maintained at a fixed angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut
P1197 Out of gas  Engine torque is limited.
 VVEL value is maintained at a fixed angle.
P1608 VVEL control shaft position
sensor VVEL actuator motor relay is turned off, an
d VVEL value is become at a minimum angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
P1090
P1093 VVEL actuator motor VVEL of no
rmal bank is controlled at VVEL angle of abnormal bank.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
VVEL actuator motor relay is turned off, an d VVEL value is become at a minimum angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
P1091 VVEL actuator motor rela
y VVEL actuator motor relay is turned off, an d VVEL value is become at a minimum angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
P1197 Out of gas  Engine torque is limited.
 VVEL value is maintained at a fixed angle.
P2101 Electric throttle control
function ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2118 Throttle control motor ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P2119 Electric throttle control ac-
tuator
(When electric throttle control actuator does not function properly due to the return spring
malfunction:)
ECM controls the electric throttle actuator by regulating the throttle opening around the
idle position. The engine speed will not rise more than 2,000 rpm.
(When throttle valve opening angle in fail-safe mode is not in specified range:)
ECM controls the electric throttle control actuator because of regulating the throttle open-
ing to 20 degrees or less.
(When ECM detects the throttle valve is stuck open:)
While the vehicle is being driven, it slows down gradually by fuel cut. After the vehicle
stops, the engine stalls.
The engine can restart in the N or P position, and engine speed will not exceed 1,000 rpm
or more.
P1290
P2100
P2103 Throttle control motor relay ECM stops the electric throttle control actuator control, throttle valve is maintained at a
fixed opening (approx. 5 degrees) by the return spring.
P1606 VVEL control module VVEL
actuator motor relay is turned off, and VVEL value is become at a minimum angle.
Engine speed will not rise more than 3,500 rpm due to the fuel cut.
P1805 Brake switch ECM controls the electric throttle control
actuator by regulating the throttle opening to a
small range.
Therefore, acceleration will be poor.
Vehicle condition Driving condition
When engine is idling Normal
When accelerating Poor acceleration
DTC No. Detected items Engine operating condition in fail-safe mode
Revision: 2010 May2011 QX56

EC-96
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
DTC Inspection Priority Chart
INFOID:0000000006217732
If some DTCs are displayed at the same time, perfo rm inspections one by one based on the following priority
chart.
P2122
P2123
P2127
P2128
P2138 Accelerator pedal position
sensor
The ECM controls the electric throttle control actuator in regulating the throttle opening in
order for the idle position to be within +10 degrees.
The ECM regulates the opening speed of the throttle valve to be slower than the normal
condition.
Therefore, the acceleration will be poor.
P2539 Low fuel pressure sensor Engine torque is limited.
DTC No. Detected items Engine operating condition in fail-safe mode
Revision: 2010 May2011 QX56

ECM
EC-97
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Priority Detected items (DTC)
1  U0101 CAN communication line  U0113 U1003 CAN communication line
 U1001 CAN communication line
 U1024 VVEL CAN communication line
 P006A P0101 P0102 P0103 Mass air flow sensor
 P010A Manifold absolute pressure sensor
 P0112 P0113 P0127 Intake air temperature sensor
 P0116 P0117 P0118 P0125 Engine coolant temperature sensor
 P0122 P0123 P0222 P0223 P1225 P1226 P2135 Throttle position sensor
 P0128 Thermostat function
 P0181 P0182 P0183 Fuel tank temperature sensor
 P0196 P0197 P0198 Engine oil temperature sensor
 P0327 P0328 P0332 P0333 Knock sensor
 P0335 Crankshaft position sensor
 P0340 P0345 Camshaft position sensor
 P0460 P0461 P0462 P0463 Fuel level sensor
 P0500 Vehicle speed sensor
 P0527 Cooling fan speed sensor
 P0605 P0607 P0611 P062B ECM
 P0643 Sensor power supply
 P0700 TCM
 P0705 P0850 Transmission range switch
 P1089 P1092 P1608 VVEL control shaft position sensor
 P1197 Out of gas*
 P1220 Fuel pump control module (FPCM)
 P1421 P1423 P1424 Cold start control
 P1550 P1551 P1552 P1553 P1554 Battery current sensor
 P1556 P1557 Battery temperature sensor
 P1606 P1607 VVEL control module
 P1610 - P1615 NATS
 P2122 P2123 P2127 P2128 P2138 Accelerator pedal position sensor
 P2539 P2541 P2542 Low fuel pressure sensor
Revision: 2010 May2011 QX56

EC-98
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
NOTE:
*: If “P1197” is displayed with other DTC in priority 1, perform trouble diagnosis for “P1197” first.
DTC IndexINFOID:0000000006217733
×
:Applicable —: Not applicable
2  P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater
 P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater
 P0075 P0081 Intake valve timing control solenoid valve
 P0130 P0131 P0132 P0133 P0150 P0151 P0152 P015 3 P2A00 P2A03 Air fuel ratio (A/F) sensor 1
 P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2
 P0190 - P0193 FRP sensor
 P0441 EVAP control system purge flow monitoring
 P0443 P0444 P0445 EVAP canister purge volume control solenoid valve
 P0447 P0448 EVAP canister vent control valve
 P0451 P0452 P0453 EVAP control system pressure sensor
 P0550 Power steering pressure sensor
 P0603 ECM power supply
 P0710 P0717 P0720 P0729 P0730 P0731 P0732 P0733 P0734 P0735 P0740 P0744 P0745 P0750 P0775 P0780 P0795 P1730 P1734 P2713 P2722 P2731 P2807 A/T related sensors, solenoid valves and switches
 P1087 P1088 VVEL system
 P1090 P1093 VVEL actuator motor
 P1091 VVEL actuat or motor relay
 P1217 Engine over temperature (OVERHEAT)
 P1650 Starter motor relay 2
 P1651 Starter motor relay
 P2101 Electric throttle control function
 P2118 Throttle control motor
 P1805 Brake switch
 P2100 P2103 Throttle control motor relay
 P2101 Electric throttle control function
3  P0011 P0021 Intake valve timing control  P0087, P0088, P0090 FRP control system
 P008A Low fuel pressure control system
 P008B Low fuel pressure control system
 P0171 P0172 P0174 P0175 Fuel injection system function
 P0201 - P0208 Injector
 P0300 - P0308 Misfire
 P0420 P0430 Three way catalyst function
 P0456 EVAP control system (VERY SMALL LEAK)
 P0506 P0507 Idle speed control system
 P050E Cold start control
 P0524 Engine oil pressure
 P1148 P1168 Closed loop control
 P1212 TCS communication line
 P1421 Cold start control
 P1564 ASCD steering switch / ICC steering switch
 P1652 Starter motor system communication
 P2119 Electric throttle control actuator
 P1564 ASCD steering switch / ICC steering switch
 P1568 ICC command value
 P1572 ASCD brake switch / ICC brake switch
 P1574 ASCD vehicle speed sensor / ICC vehicle speed sensor
Priority Detected items (DTC)
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL
Reference
page
CONSULT-III
GST*
2ECM*3
U0101 0101 LOST COMM (TCM) — 1 ×EC-171
U0113 0113 CAN COMM CIRCUIT — 1 ×EC-173
U1001
1001*4CAN COMM CIRCUIT — 1 or 2 — EC-172
U1003 1003 CAN COMM CIRCUIT — 2 — EC-173
Revision: 2010 May2011 QX56

ECM
EC-99
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OU1024 1024 VVEL CAN COMM CIRCUIT — 1
×EC-175
P0000 0000 NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED. ——
Blinking*6—
P0011 0011 INT/V TIM CONT-B1 ×2 ×
EC-177
P0021 0021 INT/V TIM CONT-B2 ×2 ×
P0031 0031 A/F SEN1 HTR (B1) — 2 ×
EC-181
P0032 0032 A/F SEN1 HTR (B1) — 2 ×
P0037 0037 HO2S2 HTR (B1) — 2 ×
EC-184
P0038 0038 HO2S2 HTR (B1) — 2 ×
P0051 0051 A/F SEN1 HTR (B2) — 2 ×
EC-181
P0052 0052 A/F SEN1 HTR (B2) — 2 ×
P0057 0057 HO2S2 HTR (B2) — 2 ×
EC-184
P0058 0058 HO2S2 HTR (B2) — 2 ×
P006A 006A MAP-MAF CORELTION-B1 — 2 ×EC-187
P0075 0075 INT/V TIM V/CIR-B1 — 2 ×
EC-193
P0081 0081 INT/V TIM V/CIR-B2 — 2 ×
P0087 0087 LOW FUEL PRES — 2 ×
EC-195
P0088 0088 HIGH FUEL PRES — 2 ×
P008A 008A LOW FUEL PRES SYS — 2 ×EC-198
P008B 008B LOW FUEL PRES SYS — 2 ×EC-200
P0090 0090 FUEL PUMP — 2 ×EC-195
P0101 0101 MAF SEN/CIRCUIT-B1 — 2 ×EC-187
P0102 0102 MAF SEN/CIRCUIT-B1 — 1 ×
EC-201
P0103 0103 MAF SEN/CIRCUIT-B1 — 1 ×
P0106 0106 ABSL PRES SEN/CIRC — 2 ×EC-206
P010A 010A ABSL PRES SEN/CIRC — 2 ×EC-210
P0112 0112 IAT SEN/CIRCUIT-B1 — 2 ×
EC-213
P0113 0113 IAT SEN/CIRCUIT-B1 — 1 or 2 ×
P0116 0116 ECT SEN/CIRC — 2 ×EC-215
P0117 0117 ECT SEN/CIRC — 1 ×
EC-217
P0118 0118 ECT SEN/CIRC — 1 ×
P0122 0122 TP SEN 2/CIRC-B1 — 1 ×
EC-219
P0123 0123 TP SEN 2/CIRC-B1 — 1 ×
P0125 0125 ECT SENSOR — 2 ×EC-222
P0127 0127 IAT SENSOR-B1 — 2 ×EC-224
P0128 0128 THERMSTAT FNCTN — 2 ×EC-226
P0130 0130 A/F SENSOR1 (B1) ×2 ×EC-228
P0131 0131 A/F SENSOR1 (B1) — 2 ×EC-232
P0132 0132 A/F SENSOR1 (B1) — 2 ×EC-235
P0133 0133 A/F SENSOR1 (B1) ×2 ×EC-238
P0137 0137 HO2S2 (B1) ×2 ×EC-243
P0138 0138 HO2S2 (B1) ×2 ×EC-249
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

EC-100
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
P0139 0139 HO2S2 (B1)
×2×EC-257
P0150 0150 A/F SENSOR1 (B2) ×2×EC-228
P0151 0151 A/F SENSOR1 (B2) — 2 ×EC-232
P0152 0152 A/F SENSOR1 (B2) — 2 ×EC-235
P0153 0153 A/F SENSOR1 (B2) ×2×EC-238
P0157 0157 HO2S2 (B2) ×2×EC-243
P0158 0158 HO2S2 (B2) ×2×EC-249
P0159 0159 HO2S2 (B2) ×2×EC-257
P0171 0171 FUEL SYS-LEAN-B1 — 2 ×EC-263
P0172 0172 FUEL SYS-RICH-B1 — 2 ×EC-267
P0174 0174 FUEL SYS-LEAN-B2 — 2 ×EC-263
P0175 0175 FUEL SYS-RICH-B2 — 2 ×EC-267
P0181 0181 FTT SENSOR — 2 ×EC-271
P0182 0182 FTT SEN/CIRCUIT — 2 ×EC-274
P0183 0183 FTT SEN/CIRCUIT — 2 ×EC-274
P0190 0190 FUEL PRES SEN/CIRC — 1 ×EC-276
P0191 0191 FRP SENSOR A — 2 ×EC-279
P0192 0192 FRP SEN/CIRC — 2 ×EC-276
P0193 0193 FRP SEN/CIRC — 2 ×EC-276
P0196 0196 EOT SENSOR — 2 ×EC-283
P0197 0197 EOT SEN/CIRC — 2 ×
EC-285
P0198 0198 EOT SEN/CIRC — 2 ×
P0201 0201 INJECTOR CIRC-CYL1 — 2 ×
EC-287
P0202 0202 INJECTOR CIRC-CYL2 — 2 ×
P0203 0203 INJECTOR CIRC-CYL3 — 2 ×
P0204 0204 INJECTOR CIRC-CYL4 — 2 ×
P0205 0205 INJECTOR CIRC-CYL5 — 2 ×
P0206 0206 INJECTOR CIRC-CYL6 — 2 ×
P0207 0207 INJECTOR CIRC-CYL7 — 2 —
P0208 0208 INJECTOR CIRC-CYL8 — 2 —
P0222 0222 TP SEN 1/CIRC-B1 — 1 ×
EC-288
P0223 0223 TP SEN 1/CIRC-B1 — 1 ×
P0300 0300 MULTI CYL MISFIRE — 1 or 2 ×
EC-291
P0301 0301 CYL 1 MISFIRE — 1 or 2 ×
P0302 0302 CYL 2 MISFIRE — 1 or 2 ×
P0303 0303 CYL 3 MISFIRE — 1 or 2 ×
P0304 0304 CYL 4 MISFIRE — 1 or 2 ×
P0305 0305 CYL 5 MISFIRE — 1 or 2 ×
P0306 0306 CYL 6 MISFIRE — 1 or 2 ×
P0307 0307 CYL 7 MISFIRE — 1 or 2 ×
P0308 0308 CYL 8 MISFIRE — 1 or 2 ×
DTC*
1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

ECM
EC-101
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
OP0327 0327 KNOCK SEN/CIRC-B1 — 2 —
EC-297
P0328 0328 KNOCK SEN/CIRC-B1 — 2 —
P0332 0332 KNOCK SEN/CIRC-B2 — 2 —
P0333 0333 KNOCK SEN/CIRC-B2 — 2 —
P0335 0335 CKP SEN/CIRCUIT — 2×EC-299
P0340 0340 CMP SEN/CIRC-B1 — 2 ×
EC-303
P0345 0345 CMP SEN/CIRC-B2 — 2 ×
P0420 0420 TW CATALYST SYS-B1 ×2 ×
EC-307
P0430 0430 TW CATALYST SYS-B2 ×2 ×
P0441 0441 EVAP PURG FLOW/MON ×2 ×EC-312
P0443 0443 PURG VOLUME CONT/V — 2 ×EC-317
P0444 0444 PURG VOLUME CONT/V — 2 ×
EC-322
P0445 0445 PURG VOLUME CONT/V — 2 ×
P0447 0447 VENT CONTROL VALVE — 2 ×EC-325
P0448 0448 VENT CONTROL VALVE — 2 ×EC-329
P0451 0451 EVAP SYS PRES SEN — 2 ×EC-333
P0452 0452 EVAP SYS PRES SEN — 2 ×EC-336
P0453 0453 EVAP SYS PRES SEN — 2 ×EC-341
P0456 0456 EVAP VERY SML LEAK
×*82 ×EC-346
P0460 0460 FUEL LEV SEN SLOSH — 2 ×EC-352
P0461 0461 FUEL LEVEL SENSOR — 2 ×EC-353
P0462 0462 FUEL LEVL SEN/CIRC — 2 ×EC-355
P0463 0463 FUEL LEVL SEN/CIRC — 2 ×EC-355
P0500 0500
VEH SPEED SEN/CIRC*5—2 ×EC-356
P0506 0506 ISC SYSTEM — 2 ×EC-358
P0507 0507 ISC SYSTEM — 2 ×EC-360
P050E 050E COLD START CONTROL — 2 ×EC-362
P0524 0524 ENGINE OIL PRESSURE — 2 ×EC-364
P0527 0527 COOLING FAN SPD SEN — 2 — EC-367
P0550 0550 PW ST P SEN/CIRC — 2 —EC-371
P0603 0603 ECM BACK UP/CIRCUIT — 2×EC-374
P0605 0605 ECM — 1 or 2 × or — EC-376
P0607 0607 ECM — 1 ×EC-378
P0611 0611 FIC MODULE — 2 ×EC-379
P062B 062B ECM — 2 × or — EC-380
P0643 0643 SENSOR POWER/CIRC — 1 ×EC-381
P0705 0705 T/M RANGE SENSOR A — 2 ×TM-106
P0710 0710
FLUID TEMP SENSOR*7—2 ×TM-107
P0717 0717 INPUT SPEED SENSOR A — 2 ×TM-109
P0720 0720
OUTPUT SPEED SENSOR*5—2 ×TM-110
P0729 0729
6GR INCORRECT RATIO*7—2 ×TM-114
P0730 0730 INCORRECT GR RATIO — 2 ×TM-116
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

EC-102
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
P0731 0731
1GR INCORRECT RATIO*7—2 ×TM-118
P0732 0732
2GR INCORRECT RATIO*7—2 ×TM-120
P0733 0733
3GR INCORRECT RATIO*7—2 ×TM-122
P0734 0734
4GR INCORRECT RATIO*7—2 ×TM-124
P0735 0735
5GR INCORRECT RATIO*7—2 ×TM-126
P0740 0740 TORQUE CONVERTER — 2 ×TM-128
P0744 0744 TORQUE CONVERTER — 2 ×TM-129
P0745 0745 PC SOLENOID A — 2 ×TM-131
P0750 0750 SHIFT SOLENOID A — 2 ×TM-132
P0775 0775 PC SOLENOID B — 2 ×TM-133
P0780 0780 SHIFT — 1 ×TM-134
P0795 0795 PC SOLENOID C — 2 ×TM-136
P0850 0850 P-N POS SW/CIRCUIT — 2 ×EC-383
P1087 1087 VVEL SYSTEM-B1 — 1 ×EC-386
P1088 1088 VVEL SYSTEM-B2 — 1 ×EC-386
P1089 1089 VVEL POS SEN/CIRC-B1 — 1 ×EC-387
P1090 1090 VVEL ACTR MOT-B1 — 1 ×EC-390
P1091 1091 VVEL ACTR MOT PWR — 1 ×EC-393
P1092 1092 VVEL POS SEN/CIRC-B2 — 1 ×EC-387
P1093 1093 VVEL ACTR MOT-B2 — 1 ×EC-390
P1148 1148 CLOSED LOOP-B1 — 1 ×EC-396
P1168 1168 CLOSED LOOP-B2 — 1 ×EC-396
P1197 1197 FUEL RUN OUT — 2 — EC-397
P1212 1212 TCS/CIRC — 2 — EC-399
P1217 1217 ENG OVER TEMP — 1×EC-400
P1220 1220 FPCM — 1 — EC-403
P1225 1225 CTP LEARNING-B1 — 2 —EC-406
P1226 1226 CTP LEARNING-B1 — 2 —EC-407
P1421 1421 COLD START CONTROL — 2×EC-408
P1423 1423 COLD START CONTROL — 2 ×EC-410
P1424 1424 COLD START CONTROL — 2 ×EC-410
P1550 1550 BAT CURRENT SENSOR — 2 — EC-412
P1551 1551 BAT CURRENT SENSOR — 2 —EC-416
P1552 1552 BAT CURRENT SENSOR — 2 —EC-416
P1553 1553 BAT CURRENT SENSOR — 2 —EC-420
P1554 1554 BAT CURRENT SENSOR — 2 —EC-424
P1556 1556 BAT TMP SEN/CIRC — 2 —EC-428
P1557 1557 BAT TMP SEN/CIRC — 2 —EC-428
P1564 1564 ASCD SW — 1 —EC-431(with ASCD)
EC-434
(with ICC)
P1568 1568 ICC COMMAND VALUE — 1 — EC-437
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

ECM
EC-103
< ECU DIAGNOSIS INFORMATION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*1: 1st trip DTC No. is
the same as DTC No.
P1572 1572 ASCD BRAKE SW — 1 —
EC-438
(with ASCD)
EC-443
(with ICC)
P1574 1574 ASCD VHL SPD SEN — 1 — EC-447
(with ASCD)
EC-449
(with ICC)
P1606 1606 VVEL CONTROL MODULE — 1 or 2 × or — EC-451
P1607 1607 VVEL CONTROL MODULE — 1 ×EC-452
P1608 1608 VVEL SENSOR POWER/CIRC — 1 ×EC-453
P1610 1610 LOCK MODE — 2 — SEC-53
P1611 1611 ID DISCORD IMMU-ECM — 2 —SEC-54
P1612 1612 CHAIN OF ECM-IMMU — 2 — SEC-55
P1613 1613 ECM INT CIRC-IMMU — 2 —SEC-48
P1614 1614 CHAIN OF IMMU-KEY — 2 —SEC-56
P1615 1615 DIFFERENCE OF KEY — 2 —SEC-48
P1650 1650 STR MTR RELAY 2 — 2×SEC-48
P1651 1651 STR MTR RELAY — 2 ×SEC-48
P1652 1652 STR MTR SYS COMM — 1 ×SEC-48
P1730 1730 INTERLOCK — 2 ×TM-140
P1734 1734
7GR INCORRECT RATIO*7—2 ×TM-142
P1805 1805 BRAKE SW/CIRCUIT — 2 — EC-455
P2100 2100 ETC MOT PWR-B1 — 2×EC-458
P2101 2101 ETC FNCTN/CIRC-B1 — 1 ×EC-460
P2103 2103 ETC MOT PWR — 1 ×EC-458
P 2 11 8 2 11 8 E T C M O T- B 1 — 1 ×EC-464
P 2 11 9 2 11 9 E T C A C T R - B 1 — 1 ×EC-466
P2122 2122 APP SEN 1/CIRC — 1 ×EC-468
P2123 2123 APP SEN 1/CIRC — 1 ×EC-468
P2127 2127 APP SEN 2/CIRC — 1 ×EC-471
P2128 2128 APP SEN 2/CIRC — 1 ×EC-471
P2135 2135 TP SENSOR-B1 — 1 ×EC-475
P2138 2138 APP SENSOR — 1 ×EC-478
P2539 2539 LOW FUEL PRES SEN — 2 ×EC-483
P2541 2541 LOW FUEL PRES SEN — 2 ×EC-483
P2542 2542 LOW FUEL PRES SEN — 2 ×EC-483
P2713 2713 PRESS CONTROL SOL D — 2 ×TM-147
P2722 2722 PRESS CONTROL SOL E — 2 ×TM-148
P2731 2731 PRESS CONTROL SOL F — 2 ×TM-149
P2807 2807 PRESS CONTROL SOL G — 2 ×TM-150
P2A00 2A00 A/F SENSOR1 (B1) — 2 ×EC-487
P2A03 2A03 A/F SENSOR1 (B2) — 2 ×EC-487
DTC*1
Items
(CONSULT-III screen terms) SRT code Trip MIL Reference
page
CONSULT-III
GST*
2ECM*3
Revision: 2010 May2011 QX56

EC-104
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
*5: When the fail safe operations for both self-diagnoses occur, the MIL illuminates.
*6: When the ECM is in the mode that displays SRT status, MIL may blink. For the details, refer to “How to Display SRT Status”.
*7: When erasing this DTC, al ways use CONSULT-III or GST.
*8: SRT code will not be set if the self-diagnostic result is NG.
Test Value and Test LimitINFOID:0000000006217734
The following is the information specified in Service $06 of ISO 15031-5.
The test value is a parameter used to determine whether a system/circuit diagnostic test is OK or NG while
being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the
maximum or minimum value and is compared with the test value being monitored.
These data (test value and test limit) are specified by On Board Monitor ID (OBDMID), Test ID (TID), Unit and
Scaling ID and can be displayed on the GST screen.
The items of the test value and test limit will be di splayed with GST screen which items are provided by the
ECM. (e.g., if bank 2 is not applied on this v ehicle, only the items of bank 1 are displayed)
ItemOBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
HO2S 01H
Air fuel ratio (A/F) sensor 1
(Bank 1) P0131 83H 0BH
Minimum sensor output voltage for test
cycle
P0131 84H 0BH Maximum sensor output voltage for test
cycle
P0130 85H 0BH Minimum sensor output voltage for test
cycle
P0130 86H 0BH Maximum sensor output voltage for test
cycle
P0133 87H 04H Response rate: Response ratio (Lean to
Rich)
P0133 88H 04H Response rate: Response ratio (Rich to
Lean)
P2A00 89H 84H The amount of shift in air fuel ratio
P2A00 8AH 84H The amount of shift in air fuel ratio P0130 8BH 0BH Difference in sensor output voltage
P0133 8CH 83H Response gain at the limited frequency
02H Heated oxygen sensor 2
(Bank 1) P0138 07H 0CH
Minimum sensor output voltage for test
cycle
P0137 08H 0CH Maximum sensor output voltage for test
cycle
P0138 80H 0CH Sensor output voltage
P0139 81H 0CH Difference in sensor output voltage
03H Heated oxygen sensor 3
(Bank 1) P0143 07H 0CH
Minimum sensor output voltage for test
cycle
P0144 08H 0CH Maximum sensor output voltage for test
cycle
P0146 80H 0CH Sensor output voltage
P0145 81H 0CH Difference in sensor output voltage
Revision: 2010 May2011 QX56
