DAS-492
< DTC/CIRCUIT DIAGNOSIS >[BSW]
U0126 STRG SEN CAN 1
U0126 STRG SEN CAN 1
DTC LogicINFOID:0000000006228233
DTC DETECTION LOGIC
NOTE:
If DTC “U0126” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-486,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the BSW system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U0126” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U0126” detected as the current malfunction?
YES >> Refer to DAS-492, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228234
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “U0126” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-486, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U0126 (130) STRG SEN CAN CIR1 If ADAS control unit detects an error signal
that is received from steering angle sensor via
CAN communication
Steering angle sensor
Revision: 2010 May2011 QX56
