navigation INFINITI QX56 2011 Factory Workshop Manual

DAS
SYSTEMDAS-71
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Operation Condition
ADAS control unit performs the control when the following conditions are satisfied.
 When the DCA system setting on the navigation screen is ON.
 When the dynamic driver assistance switch is turned to ON.
 When the brake pedal is not depressed.
 When the vehicle speed is above approximately 5 km/h (3 MPH).
 When the vehicle ahead is detected.
 When the ICC system is not set.
No Operation Condition
The ADAS control unit is not operat e when the system is under any condi tions of the no operation condition.
 When the brake pedal depressed.
 When the ICC system is set.
 When the system judges that the vehicle co mes to a standstill by the system control.
 When the vehicle ahead is not detected.
Operation Cancellation Condition
The ADAS control unit cancels the operation when the syst em is under any conditions of the operation cancel-
lation condition.
 When the dynamic driver assistance switch is turned to OFF.
 When the system malfunction occurs.
 When ABS or VDC (including the TCS) operates.
 When the VDC is turned OFF.
 When the SNOW mode switch is turned ON.
 When the 4WD shift switch is turned to not AUTO position.
 When driving into a strong light (i.e., sunlight).
 When the ICC sensor body window is dirty and the measurement of the distance between the vehicles
becomes difficult.
Operation At The Driver Operation
Give priority to the driver operation in the following situation.
When vehicle approaches a vehicle ahead If the driver is not depressing the acceler-
ator pedal, the system activates the
brakes to decelerate smoothly as neces-
sary
If the driver is depressing the accelerator
pedal, the system moves the accelerator
pedal upward to assist the driver to re-
lease the accelerator pedal
When brake operation by driver is required The system alerts the driver by a warning
chime and blinking the vehicle ahead de-
tection indicator. If the driver is depressing
the accelerator pedal after the warning,
the system moves the accelerator pedal
upward to assist the driver to switch to the
brake pedal
Deceleration control It transmits the brake fluid
pressure control signal to the ABS actuator and electric unit (control unit) via
CAN communication and performs the brake control
Accelerator pedal actuation
control It transmits the accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS
communication and controls the accelerator pedal in the upward directionJSOIA0222ZZ
JSOIA0094ZZ
JPOIA0170GB
Revision: 2010 May2011 QX56

DAS
OPERATIONDAS-73
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
OPERATION
Switch Name and FunctionINFOID:0000000006223503
Menu Displayed by Pressing Each SwitchINFOID:0000000006223504
SYSTEM DISPLAY
DISPLAY AND WARNING LAMP
System Control Condition Display
The DCA system switch indicator illuminates and the system is turned ON by pressing the dynamic driver
assistance switch at the system OFF.
JSOIA0365ZZ
No. Switch name Description
1 Dynamic driver assistance switch Turns the DCA system ON/OFF
(When the setting of the DCA system on the navigation screen is ON)
2 DCA system setting screen
(Navigation system settings screen) DCA system settings can be switched between ON and OFF
JSOIA0175ZZ
No. Switch name Description
1 ICC system warning lamp This indicates that an abnormal condition is present in DCA system
2 DCA system switch indicator Indicates that DCA system is ON
3 Vehicle ahead detection indicator Indicates whether it detects a vehicle ahead
NOTE:
The vehicle ahead detection indicator turns OFF when the no operation condition is sat-
isfied
Revision: 2010 May2011 QX56

DAS-84
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
LDP SYSTEM ON
[On/Off]×
Indicates [On/Off] status of LDP system
WARN REQ
[On/Off] ×
Indicates an ADAS control unit judged warning state (ON/OFF) of LDP system
READY signal
[On/Off] ×
Indicates LDP system settings
Camera lost
[Detect/Deviate/Both] ××Indicates a lane marker detection state judged from a lane marker detection signal
read by the ADAS control unit via ITS communication
(Lane camera unit transmits a lane marker signal via ITS communication)
Shift position
[Off, P, R, N, D, M/T1 -
7] ××
Indicates shift position read from ADAS control unit through CAN communication
(TCM transmits shift position signal through CAN communication)
Turn signal
[OFF/LH/RH/LH&RH] ××Indicates turn signal operation status read from ADAS control unit through CAN
communication (BCM transmits turn indicator signal through CAN communica-
tion)
SIDE G
[G] ××Indicates lateral G acting on the vehicle. This lateral G is judged from a side G
sensor signal read by ADAS control unit via CAN communication
(The ABS actuator and electric unit (control unit) transmits a side G sensor signal
via CAN communication)
STATUS signal
[Stnby/Warn/Cancl/
Off] ×
Indicates a control state of LDP system
Lane unclear
[On/Off] ××Indicates an ON/OFF state of the lane marker. The ON/OFF state is judged from
a detected lane condition signal read by the ADAS control unit via ITS communi-
cation
(The lane camera unit transmits a detected lane condition signal via ITS commu-
nication)
FUNC ITEM
[FUNC1] ×× × × Indicates systems which can be set to ON/OFF by selecting “Driver Assistance”
⇒
“Dynamic Assistance Settings” of the navigation system
FUNC1: Distance Control Assist (DCA), Lane Departure Prevention (LDP)
FUNC ITEM (NV-ICC)
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
FUNC ITEM (NV-
DCA)
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
DCA SELECT
[On/Off] ×× × × Indicates an ON/OFF state of the DCA system. The DCA system can be set to
ON/OFF by selecting
“Driver Assistance” ⇒ “Dynamic Assistance Settings” of the
navigation system
LDP SELECT
[On/Off] ×× × × Indicates an ON/OFF state of LDP system. LDP system can be set to ON/OFF by
selecting “Driver Assistance”
⇒ “Dynamic Assistance Settings” of the navigation
system
BSI SELECT
[On/Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI ICC SELECT
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI DCA SELECT
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
SYS SELECTABILITY
[On/Off] ×× × × Indicates the availability of ON/OFF switching for “Driver Assistance” items re-
ceived from the AV control unit via CAN communication
WARN SYS SW
[On/Off] ×× × ×
Indicates [On/Off] status of warning systems switch
BSW/BSI WARN LMP
[On/Off] ×
Indicates [On/Off] status of BSW warning lamp output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56

DAS-96
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
LDP ON INDStart the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) LDP ON indicator lamp ON On
LDP ON indicator lamp OFF Off
LANE DPRT W/L Drive the vehicle and activate
the LDW system or LDP sys-
tem Lane departure warning lamp ON On
Lane departure warning lamp OFF Off
LDW BUZER OUT-
PUT Drive the vehicle and activate
the LDW/LDP system or BSW
system When the buzzer of the following system operates
 LDW/LDP system
 BSW system
On
When the buzzer of the following system does not oper-
ate
 LDW/LDP system
 BSW system Off
LDP SYSTEM ON Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
READY signal Start the engine and press dy-
namic driver assistance switch
(When LDP system setting is
ON) When the LDP system is ON On
When the LDP system is OFF Off
Camera lost Drive the vehicle and activate
the LDW system, LDP system Both side lane markers are detected Detect
Deviate side lane marker is lost Deviate
Both side lane markers are lost Both
Shift position  Engine running
 While driving Displays the
shift position
Turn signal Turn signal lamps OFF
Off
Turn signal lamp LH blinking LH
Turn signal lamp RH blinking RH
Turn signal lamp LH and RH blinking LH&RH
SIDE G While driving Vehicle turning right Negative value
Vehicle turning left Positive value
WARN REQ Drive the vehicle and activate
the LDP system Lane departure warning is operating On
Lane departure warning is not operating Off
STATUS signal Drive the vehicle and activate
the LDP system When the LDP system is ON Stnby
When the LDP system is operating Warn
When the LDP system is canceled Cancl
When the LDP system is OFF Off
Lane unclear While driving Lane marker is unclear On
Lane marker is clear Off
FUNC ITEM Ignition switch ON FUNC1
FUNC ITEM (NV-ICC) Ignition switch ON Off
FUNC ITEM (NV-
DCA) Ignition switch ON
Off
DCA SELECT Ignition switch ON “Distance Control Assist” set with the navigation system
is ON
On
“Distance Control Assist” set with the navigation system
is OFF Off
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS
ADAS CONTROL UNITDAS-97
< ECU DIAGNOSIS INFORMATION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
TERMINAL LAYOUT
PHYSICAL VALUES
LDP SELECT Ignition switch ON “Lane Departure Prevention” set with the navigation
system is ON
On
“Lane Departure Prevention” set with the navigation
system is OFF Off
BSI SELECT NOTE:
The item is indicated, but not monitored Off
NAVI ICC SELECT NOTE:
The item is indicated, but not monitored Off
NAVI DCA SELECT NOTE:
The item is indicated, but not monitored
Off
SYS SELECTABILITY Ignition switch ON Items set with the navigation system can be switched
normally
On
Items set with the navigation system cannot be
switched normally Off
WARN SYS SW Ignition switch ON When warning systems switch is pressed On
When warning systems switch is not pressed Off
BSW/BSI WARN LMP Ignition switch ON BSW warning lamp ON On
BSW warning lamp OFF Off
BSW SYSTEM ON Ignition switch ON When the BSW system is ON
(Warning systems ON indicator ON)
On
When the BSW system is OFF
(Warning systems ON indicator OFF) Off
4WD SW Engine running 4WD shift switch position is in AUTO AUTO
4WD shift switch position is in 4H 4H
4WD shift switch position is in 4L 4L
Monitor item Condition Value/Status
JSOIA0213ZZ
Revision: 2010 May2011 QX56

DAS-128
< BASIC INSPECTION >[DCA]
ACTION TEST
ACTION TEST
DescriptionINFOID:0000000006223527
Always perform the DCA system action te
st to check that the system operates normally after replacing the ICC
sensor, replacing the accelerator pedal assemb ly, or repairing any DCA system malfunction.
CAUTION:
Perform the DCA system action test after checking that the ICC system operates normally because the
DCA system shares components with the ICC system.
Work ProcedureINFOID:0000000006223528
NOTE:
When the ICC system is set, the information display changes to the ICC system display.
1.ICC SYSTEM ACTION TEST
Perform the ICC system action test. Refer to CCS-77, "
Description".
>> GO TO 2.
2.CHECK DCA SYST EM SETTING
1. Start the engine.
2. After starting the engine wait for 30 seconds or more.
3. Check that the DCA syst em setting can be enabled/disabled on the navigation screen.
4. Turn OFF the ignition switch and wait for 5 seconds or more.
5. Check that the previous setting is saved when the engine starts again.
>> GO TO 3.
3.CHECK DYNAMIC DRIVER ASSISTANCE SWITCH
1. Start the engine.
2. After starting the engine wait for 30 seconds or more.
3. Enable the setting of the DCA system on the navigation screen.
4. Press the dynamic driver assistance switch (1).
5. Check that the DCA system switch indicator (2) on the informa- tion display illuminates.
6. Check that the DCA system switch indicator turns OFF when the system is turned OFF by pressing the dynamic driver assistance
switch.
7. Check that the DCA system switch indicator turns OFF when the engine starts again.
NOTE:
The DCA system switch indicato r does not illuminate even when the
dynamic driver assistance switch is turned ON within approximately
5 seconds after starting the engine.
If the accelerator pedal assembly is not replaced>>INSPECTION END
If the accelerator pedal assembly is replaced>>GO TO 4.
4.CHECK DCA SYSTEM OPERATION
Check that the accelerator pedal actuator operates by the “Active Test” items “ACCELERATOR PEDAL
ACTUATOR TEST1” and “ACCELERATOR PEDAL ACTU ATOR TEST2” of “ACCELE PEDAL ACT” with
CONSULT-III.
>> INSPECTION END
JSOIA0275ZZ
Revision: 2010 May2011 QX56

DAS
DISTANCE CONTROL ASSIST SYSTEM SYMPTOMSDAS-197
< SYMPTOM DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
SYMPTOM DIAGNOSIS
DISTANCE CONTROL A SSIST SYSTEM SYMPTOMS
Symptom TableINFOID:0000000006223650
Symptoms Reference page
Operation Switch does not turn ON
Refer to DAS-198, "
Description".
Switch does not turn OFF
DCA system setting cannot be turned ON on the
navigation screen Refer to DAS-200, "
Description".
DCA system setting cannot be turned OFF on the
navigation screen
DCA system not activated (switch is ON) Refer to DAS-201, "
Description".
Display/Chime Information display is not illuminated (vehicle
ahead indicator)
Refer to
MWI-29, "
On Board Diagnosis Function".
Chime does not sound Refer to DAS-203, "
Description".
Control No force generated for putting back the accelera-
tor pedal Refer to
DAS-205, "
Description".
Detection of lead
vehicle Frequently cannot detect the vehicle ahead
Refer to DAS-206, "
Description".
Detection zone is short
System misidentifies a vehicle even though there
is no vehicle ahead  Adjust laser beam aiming: Refer to
CCS-72, "
Descrip-
tion".
 Perform action test. Refer to DAS-128, "
Description".
System misidentifies a vehicle in the next lane
System does not detect the vehicle ahead at all Refer to DAS-208, "
Description".
Revision: 2010 May2011 QX56

DAS-198
< SYMPTOM DIAGNOSIS >[DCA]
SWITCH DOES NOT TURN ON /
SWITCH DOES NOT TURN OFF
SWITCH DOES NOT TURN ON / SWITCH DOES NOT TURN OFF
DescriptionINFOID:0000000006223651
The switch does not turn ON
 When the DCA system setting is ON, the DCA system switch indicator does not illuminate even if the
dynamic driver assistance switch is depressed.
The switch does not turn OFF
 The DCA system switch indicator does not turn OFF even if the dynamic driver assistance switch is pressed
when the DCA system switch indicator illuminates.
NOTE:
The system cannot be operated when setting conv entional (fixed speed) cruise control mode.
Diagnosis ProcedureINFOID:0000000006223652
1.CHECK DCA SYSTEM SETTING
1. Start the engine.
2. After starting the engine wait for 5 seconds or more.
3. Check that DCA system setti ng on the navigation screen is ON.
Is DCA system setting ON?
YES >> GO TO 2.
NO >> Enable the DCA system setting.
2.DYNAMIC DRIVER ASSISTA NCE SWITCH INSPECTION
1. Start the engine.
2. Check that “DYNA ASIST SW” operates normally in “DATA MONITOR” of “ICC/ADAS” with CONSULT-III.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 5.
3.CHECK DCA SYSTEM SWITCH INDICATOR CIRCUIT
1. Start the engine.
2. Select the active test item “DCA IN DICATOR” of “ICC/ADAS” with CONSULT-III.
3. Check if the DCA system switch indicator illuminates when the test item is operated.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 4.
4.PERFORM THE SELF-DIAGNOSIS OF COMBINATION METER
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the DTC is detected in self-d iagnosis results of “METER/M&A”. Refer to MWI-43, "
DTC Index".
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
5.CHECK STEERING SWITCH CIRCUIT
Check the steering switch circuit. Refer to DAS-138, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 7.
6.PERFORM THE SELF-DIAGNOSIS
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the DTC is detected in self-diagnosis results of “ICC/ADAS”. Refer to DAS-100, "
DTC Index".
Is any DTC detected?
YES >> GO TO 7.
Revision: 2010 May2011 QX56

DAS-200
< SYMPTOM DIAGNOSIS >[DCA]
DCA SYSTEM SETTINGS CANNOT BE TURNED ON/OFF ON THE NAVIGATION
SCREEN
DCA SYSTEM SETTINGS CANNOT BE TURNED ON/OFF ON THE NAVI-
GATION SCREEN
DescriptionINFOID:0000000006223653
 DCA system setting is not selectable on the navigation screen. NOTE:
When the ignition switch is in ACC posit ion, DCA system settings cannot be changed.
- “Distance Control Assist” is not indicated on the navigation screen.
- The switching between ON and OFF cannot be per formed by operating the navigation system.
- The item of “Distance Control Assist” on the navigation screen is not active.
 After turning ON the ignition switch or starting t he engine, DCA settings of the navigation system cannot be
selected for several tens of sec onds under the following conditions:
- After replacing AV control unit.
- After erasing connection histor y of the navigation system.
- After erasing self-diagnosis results.
 The DCA system setting differs from the one set at the previous driving. NOTE:
Turn OFF the ignition switch and wait for 5 seconds or more.
Diagnosis ProcedureINFOID:0000000006223654
1.CHECK DCA SYSTEM SETTING
1. Start the engine.
2. Check that the DCA syst em settings is selectable on the navigation screen.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.PERFORM THE SELF-DIAGNOSIS
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the DTC is detected in self-diagnosis results of “ICC/ADAS”, “MULTI AV” and “METER/M&A”.
Refer to the following.
- ICC/ADAS: DAS-100, "
DTC Index"
- MULTI AV: AV-57, "DTC Index"
- METER/M&A: WCS-30, "DTC Index"
Is any DTC detected?
YES >> Repair or replace malfunctioning parts.
NO >> INSPECTION END
3.CHECK DATA MONITOR OF ADAS CONTROL UNIT
Check that “DCA SELECT” operates normally in “D ATA MONITOR” of “ICC/ADAS” with CONSULT-III.
Is the inspection result normal?
YES >> Refer to AV-28, "On Board Diagnosis Function".
NO >> GO TO 4.
4.CHECK MULTIFUNCTION SWITCH
Operate the multifunction switch to check that the audio, navigation system, and air conditioner operate prop-
erly.
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> Repair or replace malfunctioning parts.
Revision: 2010 May2011 QX56

DAS-230
< SYSTEM DESCRIPTION >[FCW]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
LDP SYSTEM ON
[On/Off]×
Indicates [On/Off] status of LDP system
WARN REQ
[On/Off] ×
Indicates an ADAS control unit judged warning state (ON/OFF) of LDP system
READY signal
[On/Off] ×
Indicates LDP system settings
Camera lost
[Detect/Deviate/Both] ××Indicates a lane marker detection state judged from a lane marker detection signal
read by the ADAS control unit via ITS communication
(Lane camera unit transmits a lane marker signal via ITS communication)
Shift position
[Off, P, R, N, D, M/T1 -
7] ××
Indicates shift position read from ADAS control unit through CAN communication
(TCM transmits shift position signal through CAN communication)
Turn signal
[OFF/LH/RH/LH&RH] ××Indicates turn signal operation status read from ADAS control unit through CAN
communication (BCM transmits turn indicator signal through CAN communica-
tion)
SIDE G
[G] ××Indicates lateral G acting on the vehicle. This lateral G is judged from a side G
sensor signal read by ADAS control unit via CAN communication
(The ABS actuator and electric unit (control unit) transmits a side G sensor signal
via CAN communication)
STATUS signal
[Stnby/Warn/Cancl/
Off] ×
Indicates a control state of LDP system
Lane unclear
[On/Off] ××Indicates an ON/OFF state of the lane marker. The ON/OFF state is judged from
a detected lane condition signal read by the ADAS control unit via ITS communi-
cation
(The lane camera unit transmits a detected lane condition signal via ITS commu-
nication)
FUNC ITEM
[FUNC1] ×× × × Indicates systems which can be set to ON/OFF by selecting “Driver Assistance”
⇒
“Dynamic Assistance Settings” of the navigation system
FUNC1: Distance Control Assist (DCA), Lane Departure Prevention (LDP)
FUNC ITEM (NV-ICC)
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
FUNC ITEM (NV-
DCA)
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
DCA SELECT
[On/Off] ×× × × Indicates an ON/OFF state of the DCA system. The DCA system can be set to
ON/OFF by selecting
“Driver Assistance” ⇒ “Dynamic Assistance Settings” of the
navigation system
LDP SELECT
[On/Off] ×× × × Indicates an ON/OFF state of LDP system. LDP system can be set to ON/OFF by
selecting “Driver Assistance”
⇒ “Dynamic Assistance Settings” of the navigation
system
BSI SELECT
[On/Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI ICC SELECT
[Off] ×× × × NOTE:
The item is displayed, but it is not monitored
NAVI DCA SELECT
[Off] ×× × ×
NOTE:
The item is displayed, but it is not monitored
SYS SELECTABILITY
[On/Off] ×× × × Indicates the availability of ON/OFF switching for “Driver Assistance” items re-
ceived from the AV control unit via CAN communication
WARN SYS SW
[On/Off] ×× × ×
Indicates [On/Off] status of warning systems switch
BSW/BSI WARN LMP
[On/Off] ×
Indicates [On/Off] status of BSW warning lamp output
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Revision: 2010 May2011 QX56
