diagram INFINITI QX56 2011 Factory Service Manual

SE-60
< WIRING DIAGRAM >
CLIMATE CONTROLLED SEAT SYSTEM
JCJWM1524GB
Revision: 2010 May2011 QX56

CLIMATE CONTROLLED SEAT SYSTEM
SE-61
< WIRING DIAGRAM >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
JCJWM1525GB
Revision: 2010 May2011 QX56

SE-62
< WIRING DIAGRAM >
CLIMATE CONTROLLED SEAT SYSTEM
JCJWM1526GB
Revision: 2010 May2011 QX56

CLIMATE CONTROLLED SEAT SYSTEM
SE-63
< WIRING DIAGRAM >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
JCJWM1527GB
Revision: 2010 May2011 QX56

SE-64
< WIRING DIAGRAM >
CLIMATE CONTROLLED SEAT SYSTEM
JCJWM1528GB
Revision: 2010 May2011 QX56

CLIMATE CONTROLLED SEAT SYSTEM
SE-65
< WIRING DIAGRAM >
C
D E
F
G H
I
K L
M A
B
SE
N
O P
JCJWM1529GB
Revision: 2010 May2011 QX56

SEC-1
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
C
D
E
F
G H
I
J
L
M
SECTION SEC
A
B
SEC
N
O P
CONTENTS
SECURITY CONTROL SYSTEM
WITH INTELLIGE NT KEY SYSTEM
PRECAUTION ................ ...............................
5
PRECAUTIONS .............................................. .....5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
Precaution Necessary for Steering Wheel Rota-
tion after Battery Disconnect .....................................
5
Precaution for Procedure without Cowl Top Cover ......6
SYSTEM DESCRIPTION ..............................7
COMPONENT PARTS ................................... .....7
Component Parts Location .................................. ......7
Component Description .............................................8
A/T Shift Selector (Detention Switch) ........................8
BCM ..........................................................................8
ECM ..........................................................................9
IPDM E/R ..................................................................9
NATS Antenna Amp. .................................................9
TCM ..........................................................................9
Combination Meter ....................................................9
Door Switch ...............................................................9
Hood Switch ..............................................................9
Inside Key Antenna ...................................................9
Intelligent Key ............................................................9
Push-button Ignition Switch .....................................10
Remote Keyless Entry Receiver .............................10
Security Indicator Lamp ..........................................10
Starter Control Relay ...............................................10
Starter Relay ...........................................................10
Steering Lock Relay ................................................10
Steering Lock Unit ...................................................10
Stop Lamp Switch ...................................................10
Transmission Range Switch ....................................10
Vehicle Information Display .....................................11
SYSTEM .............................................................12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION ............................................................. ....
12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION : System Diagram ................................
12
INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION : System Description ............................
12
INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS ....14
INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS : System Diagram .........................................
15
INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS : System Description .....................................
15
VEHICLE SECURITY SYSTEM .................................17
VEHICLE SECURITY SYSTEM : System Dia-
gram .................................................................... ....
17
VEHICLE SECURITY SYSTEM : System Descrip-
tion ...........................................................................
18
DIAGNOSIS SYSTEM (BCM) ...........................21
COMMON ITEM ..................................................... ....21
COMMON ITEM : CONSULT-III Function (BCM -
COMMON ITEM) .....................................................
21
INTELLIGENT KEY ................................................ ....22
INTELLIGENT KEY : CONSULT-III Function
(BCM - INTELLIGENT KEY) ....................................
22
THEFT ALM ........................................................... ....26
THEFT ALM : CONSULT-III Function (BCM -
THEFT) ................................................................ ....
26
IMMU ...................................................................... ....27
IMMU : CONSULT-III Function (BCM - IMMU) ........27
DIAGNOSIS SYSTEM (IPDM E/R) ...................28
CONSULT-III Function (IPDM E/R) .........................28
ECU DIAGNOSIS INFORMATION ..............30
ECM, IPDM E/R, BCM .......................................30
List of ECU Reference ......................................... ....30
Revision: 2010 May2011 QX56

SEC-2
WIRING DIAGRAM .....................................31
SECURITY CONTROL SYSTEM .................... ...31
Wiring Diagram .................................................... ...31
BASIC INSPECTION ...................................48
DIAGNOSIS AND REPAIR WORK FLOW ..... ...48
Work Flow ............................................................ ...48
ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT ................................................
51
ECM ........................................................................ ...51
ECM : Description ...................................................51
ECM : Work Procedure ...........................................51
BCM ........................................................................ ...51
BCM : Description ...................................................51
BCM : Work Procedure ...........................................51
DTC/CIRCUIT DIAGNOSIS ...................... ...53
P1610 LOCK MODE ....................................... ...53
Description ........................................................... ...53
DTC Logic ...............................................................53
Diagnosis Procedure ..............................................53
P1611 ID DISCORD, IMMU-ECM ......................54
DTC Logic ............................................................ ...54
Diagnosis Procedure ..............................................54
P1612 CHAIN OF ECM-IMMU ...........................55
DTC Logic ............................................................ ...55
Diagnosis Procedure ..............................................55
P1614 CHAIN OF IMMU-KEY ...........................56
DTC Logic ............................................................ ...56
Diagnosis Procedure ..............................................56
B2192 ID DISCORD, IMMU-ECM ......................60
DTC Logic ............................................................ ...60
Diagnosis Procedure ..............................................60
B2193 CHAIN OF ECM-IMMU ...........................61
DTC Logic ............................................................ ...61
Diagnosis Procedure ..............................................61
B2195 ANTI-SCANNING ...................................62
DTC Logic ............................................................ ...62
Diagnosis Procedure ..............................................62
B2196 DONGLE UNIT .......................................63
Description ........................................................... ...63
DTC Logic ...............................................................63
Diagnosis Procedure ..............................................63
B2198 NATS ANTENNA AMP. .........................65
DTC Logic ............................................................ ...65
Diagnosis Procedure ..............................................65
B2013 STEERING LOCK UNIT .........................69
DTC Logic ............................................................ ...69
Diagnosis Procedure ............................................ ...69
B2014 CHAIN OF STRG-IMMU ........................70
DTC Logic ............................................................ ...70
Diagnosis Procedure ...............................................70
B2555 STOP LAMP ...........................................73
DTC Logic ............................................................ ...73
Diagnosis Procedure ...............................................73
Component Inspection ............................................74
B2556 PUSH-BUTTON IGNITION SWITCH .....76
DTC Logic ............................................................ ...76
Diagnosis Procedure ...............................................76
Component Inspection ............................................77
B2557 VEHICLE SPEED ...................................78
DTC Logic ............................................................ ...78
Diagnosis Procedure ...............................................78
B2601 SHIFT POSITION ...................................79
DTC Logic ............................................................ ...79
Diagnosis Procedure ...............................................79
Component Inspection ............................................81
B2602 SHIFT POSITION ...................................82
DTC Logic ............................................................ ...82
Diagnosis Procedure ...............................................82
Component Inspection ............................................83
B2603 SHIFT POSITION ...................................85
DTC Logic ............................................................ ...85
Diagnosis Procedure ...............................................85
Component Inspection ............................................87
B2604 SHIFT POSITION ...................................89
DTC Logic ............................................................ ...89
Diagnosis Procedure ...............................................89
B2605 SHIFT POSITION ...................................91
DTC Logic ............................................................ ...91
Diagnosis Procedure ...............................................91
B2608 STARTER RELAY .................................93
DTC Logic ............................................................ ...93
Diagnosis Procedure ...............................................93
B2609 STEERING STATUS ..............................95
DTC Logic ............................................................ ...95
Diagnosis Procedure ...............................................95
B260B STEERING LOCK UNIT ........................98
DTC Logic ............................................................ ...98
Diagnosis Procedure ...............................................98
B260C STEERING LOCK UNIT ........................99
DTC Logic ............................................................ ...99
Diagnosis Procedure ...............................................99
B260D STEERING LOCK UNIT .......................100
DTC Logic ............................................................ .100
Diagnosis Procedure .............................................100
Revision: 2010 May2011 QX56

SEC-12
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM
SYSTEM
INTELLIGENT KEY SYSTEM
/ENGINE START FUNCTION
INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION : System Diagram
INFOID:0000000006226178
INTELLIGENT KEY SYSTEM/ENGINE STAR T FUNCTION : System Description
INFOID:0000000006226179
SYSTEM DESCRIPTION
 The engine start function of Intelligent Key system makes it possible to start and stop the engine without
using the key, based on the electronic ID verification. The electronic ID verification is performed between
BCM and Intelligent Key when the push-button ignition swit ch is pressed while the Intelligent Key is within
the detection area of inside key antenna.
NOTE:
The driver should carry the Intelligent Key at all times.
 Intelligent Key has 2 IDs [Intelligent Key ID and IVIS (NATS) ID]. It can perform the door lock/unlock opera-
tion and the push-button ignition switch operation when the registered Intelligent Key is carried.
 When Intelligent Key battery is discharged, engine c an be started by operating push-button ignition switch
after contacting Intelligent Key backside to push-button igni tion switch. At that time, the IVIS (NATS) ID veri-
fication is performed.
 If the ID is successfully verified, when push-button igni tion switch is pressed, steering lock is released and
the engine can be started.
JMKIA5239GB
Revision: 2010 May2011 QX56

SYSTEMSEC-15
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
L
M A
B
SEC
N
O P
INFINITI VEHICLE IMMOBILIZE R SYSTEM-NATS : System DiagramINFOID:0000000006226180
INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS : System DescriptionINFOID:0000000006226181
SYSTEM DESCRIPTION
 The INFINITI VEHICLE IMMOBILIZER SYSTEM-NAT S [IVIS (NATS)] prevents the engine from being
started by Intelligent Key whose ID is not registered to the vehicle (BCM). It has higher protection against
auto theft involving the duplication of mechanical keys.
 The ignition key integrated in the Intelligent Key cannot start the engine. When the Intelligent Key battery is
discharged, the IVIS (NATS) ID verification is performed between the transponder integrated with Intelligent
Key and BCM via NATS antenna amp. when the Intelligent Key backside is contacted to push-button ignition
switch. If the verification results are OK, the engine start operation can be performed by the push-button igni-
tion switch operation.
 Locate the security indicator lamp and apply the anti-t heft system equipment sticker that warns that the IVIS
(NATS) is on board the model.
 Security indicator lamp always blinks when the pow er supply position is any position other than ON.
 Up to 4 Intelligent Keys can be registered (including the standard ignition key) upon request from the owner.
 Specified registration is required when replacing ECM, BCM or Intelligent Key. For the registration proce-
dures, refer to CONSULT-III O peration Manual NATS-IVIS/NVIS.
 Possible symptom of IVIS (NATS) malfunction is “Engine cannot start”. The engine can not be started
because of other than IVIS (NATS) malfunction, so start the trouble diagnosis according to SEC-48, "
Work
Flow".
 If ECM other than genuine part is installed, the engi ne cannot be started. For ECM replacement procedure,
refer to EC-143, "
Work Procedure".
JMKIA5734GB
